Customization Using Variable Instruction Sets

1
Customization Using Variable Instruction Sets

• Krishna V Palem
• CTO
• Proceler Inc.

2
Designing Instruction Sets

• Choice of instructions is determined by several
  trade-offs
• Implementation in a fixed silicon area
• Ability of the compiler to exploit its presence
• Trade-off between impact on cycle time vs.
  frequency
• Implementation cost is amortized across many
  applications
• Infeasible to tailor support for a small number
  of low volume applications
• Reconfigurable logic enables a new degree of
  freedom

3
Dynamically Variable Instruction Set
Architecture (DVAITA)

• Software engineer
• C programming
• Algorithm Design

Off-line Construction
Fundamentally alters the hardware/software
interface
Compiler
Fixed ISA
DVAITA ISA
Application specific Soft Processor
Soft Micro-architecture Components
Microprocessor core
Reconfigurable Logic
4
DVAITA

• DVAITA is a soft ISA
• Pre-synthesized, pre-placed instruction
  implementations
• DVAITA compiler
• Analysis, program transformation, and scheduling
  algorithms
• Compilation to a domain specific ISA
• Create a customized micro-architecture at compile
  time
• DVAITA Hardware Support Package
• Analogy with Board Support Packages (BSP)
• Run-time for host-FPGA communication
• Abstraction for linking the supporting
  hardware/software interfaces

5
DVAITA Enabled Customization

• Customization at the domain level
• Soft ISAs for DSP, Telecommunications, Industrial
  automation and control, etc.
• Customization at the program level
• Tailored micro-architecture produced at compile
  time
• Customization at the operation level
• Tailored arithmetic and logic operations, for
  example, power vs. speed

6
Compiling Code Segments to Hardware
L1 for () L2 for () ..
.. L3 for () L4 for ()
L5 for () ..
..

• Datapath
• Control
• Memory
• I/O Interfaces

DVAITA ISA

• Datapath
• Control
• Memory
• I/O Interfaces

DVAITA ISA
7
Compile-time generation of Application-specific
soft processors
ISAs can be selected on a domain specific basis
8
Application-Specific Soft Processors
Software Engineer

• C Programming
• Algorithm Design

Application-specific soft processors
Communication
Reconfigurable Computing System (RCS)
Compiler
Soft Micro- architecture Components
Networking
Microprocessor core
Security
Reconfigurable Logic
9
Commercial Hardware Platforms

• High-end System-on-a-Chip solutions
• Xilinx Virtex 2 with embedded PPC 405
• Altera Excalibur with embedded ARM
• Low-end System-on-a-Chip solutions
• Triscend Configurable System on a Chip (CSoC)
  with embedded ARM
• Atmel Field Programmable System Level Integrated
  Circuits (FPSLIC) with embedded 8-bit custom RISC
  processor
• Board-level products
• Mix embedded processors and commercial FPGA
  solutions

10
More Generally Architecture Assembly
Applications

• An ISA view
• Synthesis and other hardware design off-line
• Much closer to compiler optimizations implies
  faster compile time

Build off-line (synthesis, place and route)
Program
Prebuilt Implementations
Compiler selects assembles and optimizes
program
Data path
Storage
Interconnect
Dynamically variable ISA Architecture
implementation
Also applicable to yield fixed implementations in
silicon
11
Placing in Perspective
12
The Space for these Technologies
ASIC
PICO
CMP
NP
Performance
COTS PROCESSOR
Speed to market
