Other Plant Tissue Topics

1
Other Plant Tissue Topics
2
Somaclonal Variation

• Somaclonal variation is a general phenomenon of
  all plant regeneration systems that involve a
  callus phase
• There are two general types
• Heritable, genetic changes (alter the DNA)
• Stable, but non-heritable changes (alter gene
  expression, epigenetic)
• With or without mutagen

3
Somaclonal/Mutation Breeding

• Advantages
• Screen very high populations (cell based)
• Can apply selection to single cells
• Disadvantages
• Many mutations are non-heritable
• Requires dominant mutation (or double recessive
  mutation) most mutations are recessive
• Can avoid this constraint by not applying
  selection pressure in culture, but you lose the
  advantage of high through-put screening have to
  grow out all regenerated plants, produce seed,
  and evaluate the M2

4
Somaclonal Breeding Procedures

• Use plant cultures as starting material
• Idea is to target single cells in multi-cellular
  culture
• Usually suspension culture, but callus culture
  can work
• Optional apply physical or chemical mutagen
• Apply selection pressure to culture?
• Target very high kill rate, you want very few
  cells to survive, so long as selection is
  effective
• Regenerate whole plants from surviving cells

5
Requirements for Somaclonal Breeding

• Effective screening procedure
• Most mutations are deleterious
• With fruit fly, the ratio is 8001 deleterious
  to beneficial
• Most mutations are recessive
• Must screen M2 or later generations
• Consider using heterozygous plants?
• Haploid plants seem a reasonable alternative if
  possible
• Very large populations are required to identify
  desired mutation
• Can you afford to identify marginal traits with
  replicates statistics? Estimate 10,000 plants
  for single gene mutant
• Clear Objective
• Cant expect to just plant things out and see
  what happens relates to having an effective
  screen
• This may be why so many early experiments failed

6
Introduction into suspension
Sieve out lumps 1 2
Initial high density

Subculture and sieving
Plate out
7
Synchronization

• Cold treatment 4oC
• Starvation deprivation of an essential growth
  compound, e.g. N ?accumulation in G1
• Use of DNA synthesis inhibitors thymidine,
  5-fluorodeoxyuridine, hydroxyurea
• Colchicine method arresting the cells in
  metaphase stage, measured in terms of mitotic
  index ( cells in the mitotic phase)

8
Selection

• Select at the level of the intact plant
• Select in culture
• single cell is selection unit
• possible to plate up to 1,000,000 cells on a
  Petri-dish.
• progressive selection over a number of phases

9
Selection Strategies

• Positive
• Negative
• Visual
• Analytical Screening

10
Positive selection

• Add into medium a toxic compound e.g. hydroxy
  proline, kanamycin
• Only those cells able to grow in the presence of
  the selective agent give colonies
• Plate out and pick off growing colonies.
• Possible to select one colony from millions of
  plated cells in a days work.
• Need a strong selection pressure - get escapes

11
Negative selection

• Add in an agent that kills dividing cells e.g.
  chlorate / BUdR.
• Plate out leave for a suitable time, wash out
  agent then put on growth medium.
• All cells growing on selective agent will die
  leaving only non-growing cells to now grow.
• Useful for selecting auxotrophs.

12
Visual selection

• Only useful for colored or fluorescent compounds
  e.g. shikonin, berberine, some alkaloids
• Plate out at about 50,000 cells per plate
• Pick off colored / fluorescent-expressing
  compounds (cell compounds?)
• Possible to screen about 1,000,000 cells in a
  days work.

13
Analytical Screening

• Cut each piece of callus in half
• One half subcultured
• Other half extracted and amount of compound
  determined analytically (HPLC/ GCMS/ ELISA)

14
Targets for Somaclonal Variation

• Herbicide resistance and tolerance
• Specific amino acid accumulators
• Screen for specific amino acid production
• e.g.Lysine in cereals
• Abiotic stress tolerance
• Add or subject cultures to selection agente.g.
  salt, temperature stress
• Disease resistance
• Add toxin or culture filtrate to growth media

15
(No Transcript)
16
T-DNA Tagging

• T-DNA is inherited as a single dominant gene
  locus
• Insertion of the T-DNA can result in a mutation
• Large T-DNA tag populations have been generated
  a primary goal is to disrupt the function
  (mutate) every gene, it is estimated that300,000
  random insertions will saturate the genome with
  mutations
• Tag insertion of the T-DNA tags the region
  in the genome because the T-DNA sequence is known
  and it can be located in the genome

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Embryo Culture
21
Embryo Culture Uses

• Rescue F1 hybrids from wide crosses
• Overcome seed dormancy, usually with addition of
  hormone (GA) to medium
• To overcome immaturity in seeds
• To speed generations in a breeding program
• To rescue a cross or self (valuable genotype)

22
(No Transcript)
23
Haploid Plant Production

• Embryo rescue of interspecific crosses
• Bulbosum method
• Anther culture/Microspore culture
• Culturing of anthers or pollen grains
  (microspores)
• Derive a mature plant from a single microspore
• Ovule culture
• Culturing of unfertilized ovules (macrospores)

24
Androgenesis

• History
• 1964, 1966 Datura innoxia (Guha and Maheshwari)
• 1967 Nicotiana tabacum (Nitsch)
• Critical factor - change in developmental
  pattern from mature pollen to embryogenesis

25
Factors influencing androgenesis

• Genotype of donor plants
• Anther wall factors
• Culture medium and culture density
• Stage of microspore or pollen development
• Effect of temperature and/or light
• Physiological status of donor plant

26
(No Transcript)
27
(No Transcript)
28
Tetrad
Pollen mother cell
Pollen forming
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Bulbosum Method
Hordeum bulbosum Wild relative 2n 2X 14
Hordeum vulgare Barley 2n 2X 14
X
?
Embryo Rescue
Haploid Barley 2n X 7 H. Bulbosum chromosomes
eliminated

• This was once more efficient than microspore
  culture in creating haploid barley
• Now, with an improved culture media (sucrose
  replaced by maltose), microspore culture is much
  more efficient (2000 plants per 100 anthers)

33
Ovule Culture

• Haploids can be induced from ovules
• The number of ovules is less and thus is used
  less than anther culture
• May be by organogenesis or embryogenesis
• Used in plant families that do not respond to
  androgenesis
• Liliaceae
• Compositae

34
Haploids

• Typically weak, sterile plant
• Usually want to double the chromosomes, creating
  a dihaploid plant with normal growth fertility
• Chromosomes can be doubled by
• Colchicine treatment
• Spontaneous doubling

35
Protoplasts

• Created by degrading the cell wall using enzymes
• Very fragile

36

• Protoplasts can be induced to fuse with one
  another
• Electrofusion A high frequency AC field is
  applied between 2 electrodes immersed in the
  suspension of protoplasts- this induces charges
  on the protoplasts and causes them to arrange
  themselves in lines between the electrodes. They
  are then subject to a high voltage discharge
  which causes their membranes to fuse where they
  are in contact.
• Polyethylene glycol (PEG) causes agglutination
  of many types of small particles, including
  protoplasts which fuse when centrifuged in its
  presence
• Addition of calcium ions at high pH values

37
Uses for Protoplast Fusion

• Combine two complete genomes
• Another way to create allopolyploids
• Partial genome transfer
• Exchange single or few traits between species
• May or may not require ionizing radiation
• Genetic engineering
• Micro-injection, electroporation, Agrobacterium
• Transfer of organelles
• Unique to protoplast fusion
• The transfer of mitochondria and/or chloroplasts
  between species

38
chloroplast
mitochondria
Fusion
nucleus
heterokaryon
cybrid
hybrid
cybrid
hybrid
39
Identifying Desired Fusions

• Complementation selection
• Can be done if each parent has a different
  selectable marker (e.g. antibiotic or herbicide
  resistance), then the fusion product should have
  both markers
• Fluorescence-activated cell sorters
• First label cells with different fluorescent
  markers fusion product should have both markers
• Mechanical isolation
• Tedious, but often works when you start with
  different cell types
• Mass culture
• Basically, no selection just regenerate
  everything and then screen for desired traits

40
Germplasm Preservation

• Extension of micropropagation techniques
• Two methods
• 1. Slow growth techniques
• ?Temp., ?Light, media supplements (osmotic
  inhibitors, growth retardants), tissue
  dehydration, etc
• Medium-term storage (1 to 4 years)
• 2. Cryopreservation
• Ultra low temperatures. Stops cell division
  metabolic processes
• Very long-term (indefinite?)

41
Why not seeds?

• Some crops do not produce viable seeds
• Some seeds remain viable for a limited duration
  only and are recalcitrant to storage
• Seeds of certain species deteriorate rapidly due
  to seed borne pathogens
• Some seeds are very heterozygous not suitable for
  maintaining true to type genotypes
• Effective approach to circumvent the above
  problems may be application of cryopreservation
  technology

42
Cryogenic explants

• Undifferentiated plant cells
• Embryonic suspension
• Callus
• Pollen
• Seeds
• Somatic embryos
• Shoot apices

43
Cryopreservation

• Requirements
• PreculturingUsually a rapid growth rate to
  create cells with small vacuoles and low water
  content
• CryoprotectionGlycerol, DMSO, PEG, etc, to
  protect against ice damage and alter the form of
  ice crystals
• FreezingThe most critical phase one of two
  methods
• Slow freezing allows for cytoplasmic dehydration
• Quick freezing results in fast intercellular
  freezing with little dehydration

44
Cryopreservation Requirements

• Storage
• Usually in liquid nitrogen (-196oC) to avoid
  changes in ice crystals that occur above -100oC
• Thawing
• Usually rapid thawing to avoid damage from ice
  crystal growth
• Recovery
• Thawed cells must be washed of cryo-protectants
  and nursed back to normal growth
• Avoid callus production to maintain genetic
  stability

45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Synthetic Seeds
55
(No Transcript)
56
(No Transcript)
