Software Engineering 2 Spring 2003 Project Management

1
Software Engineering 2Spring 2003 Project
Management

• Eliezer Kaplansky
• and
• Guy Viener

2
software development process is a business process
Our view
The client view
3
Unified Process for EDUcation (UPEDU)
http//www.upedu.org/upedu/
Rational Software Corporation
École Polytechnique de Montréal
4
Phases and Iterations
5
The final goal Artifacts

• A document, such as Software Requirements
  Specification
• A model, such as the Use-Case Model or the
  Design Model
• A model element that is, an element within a
  model, such as a class, or a subsystem .

6
Use cases is the BASIC tool for SE
7
Test phase

• Example test case serves to check the correct
  functioning of the Withdraw-money use-case
• Input
• The bank customer identifies himself correctly
• The account 12-121-1211 has 1.500.000 Lire
• The bank customer wishes to withdraw 1.000.000
  Lire from the account 12-121-1211
• There is enough money available in the ATM
• Result
• The balance of the customer account 12-121-1211
  decreases to 500.000 Lire
• The bank customer receives 1.000.000 Lire from
  the ATM
• Conditions
• No other use-cases are allowed to access the
  account 12-121-1211 during this transaction

8
Configuration Change Management

• Identifying configuration items.
• Restricting changes to those items.

• Auditing changes made to those items.
• Defining and managing configurations of those
  items.

9
Configuration Change Management Workflow
10
Roles and Activities

• A role is an abstract definition of a set of
  activities performed and artifacts owned..
• Roles are typically realized by an individual,
  or a set of individuals, working together as a
  team.
• A project team member typically fulfills many
  different roles.

11
List of Roles

• Analyst
• Designer
• Implementer
• Integrator
• Tester
• Change Control Manager
• Configuration Manager
• Reviewer
• Stakeholder
• Project Manager

Role responsibilities allocated to people.
Worker
12
Role  Analyst

• The system analyst role leads and coordinates
  requirements elicitation and use-case modeling by
  outlining the system's functionality and
  delimiting the system for example, establishing
  what actors and use cases exist, and how they
  interact.

• A person that is good facilitator and has
  above-average communication skills. Knowledge of
  the business and technology domains.

13
Role  Designer

• The designer role defines the responsibilities,
  operations, attributes, and relationships of one
  or several classes, and determines how they will
  be adjusted.

• The designer must have a knowledge of
• use-case modeling techniques
• system requirements
• software design techniques, including
  object-oriented analysis and design techniques,
  and the Unified Modeling Language
• technologies with which the system will be
  implemented

14
Role  Implementer

• The implementer role is responsible for
  developing and testing components.

• The appropriate skills and knowledge for the
  implementer include
• Knowledge of the system or the application
  domain.
• Familiarity with testing and test automation
  tools.
• Programming skills

15
Role  Tester

• The Tester role is responsible for the core
  activities of the test effort.

• Knowledge of testing approaches and techniques
• Diagnostic and problem-solving skills.
• Knowledge of the system or application being
  tested (desirable)
• Knowledge of networking and system architecture
  (desirable)

16
Test Artifact Set
17
Role  Change Control Manager

• The change control manager role oversees the
  change control process.

• The change control manager should
• Understand configuration management principles.

• He/she should be skilled in estimating cost and
  schedule impacts of change requests.
• He/she should be able to communicate effectively.

18
Artifact  Change Request

• Size
• How much existing work will have to change?
• How much new work will need to be added?
• Alternatives - Are there any?
• Complexity - Is the proposed change easy to make?

• What are the possible ramifications of making
  this change?
• Severity - Is there any loss of work or data
  involved?
• What is the impact of not implementing this
  request?
• Is this an enhancement request?
• Is it a minor annoyance?
• Schedule - When is the change required?
• Is that feasible?
• Impact - What are the consequences of making the
  change?
• What are the consequences of not making the
  change?
• Cost - What is the cost of saving from making
  this change?

19
Role  Configuration Manager

• The configuration manager provides the overall
  Configuration Management (CM) infrastructure and
  environment .

• The configuration manager is also responsible
  for
• Writing the CM Plan.
• Reporting progress statistics based on change
  requests.
• To ensure that the CM environment facilitates
  product review, and change and defect tracking
  activities.

20
Role  Reviewer

• The Reviewer plans and conducts the formal
  reviews in different disciplines.

• A person acting as reviewer has some
• Essential knowledge of the business or
  technology domain.
• Another skill reviewers possess  is detailed
  knowledge of the applied facilitation and
  modeling techniques.

21
Configuration Change Management Artifact Set
22
Role  Project Manager

• The project manager
• Allocates resources.
• Shapes priorities.
• Coordinates interactions with customers and
  users.
• Generally keeps the project team focused on the
  right goal.
• Establishes a set of practices that ensure the
  integrity and quality of project artifacts.

23
Project Management Artifact Set
24
Role  Stakeholder

• Examples of stakeholders
• Customer or customer representative
• User or user representative
• Investor
• Shareholder
• Production manager
• Buyer
• Designer
• Tester
• Documentation writer
