From Theoretical Foundations to a Hierarchical Circuit for Selective Attention

1
Neural Models of Visual Attention John K.
Tsotsos Center for Vision Research York
University, Toronto, Canada Marc
Pomplun Department of Computer
Science University of Massachusetts at Boston
2
Theories/Models
Müller (1873) Exner (1894) Wundt (1902)
Pillsbury (1908) Broadbent 1958 (Early
Selection) Deutsch, Deutsch Norman 1963/68
(Late Selection) Treisman 1964 Milner 1974
Grossberg 1976 (Adaptive Resonance Theory)
Treisman Gelade 1980 (Feature Integration
Theory) von der Malsburg 1981 (Correlation
Theory) Crick 1984 Koch and Ullman
1985 Anderson and Van Essen 1987 (Shifter
Circuits) Sandon 1989 Wolfe et al. 1989
(Guided Search 1.0, 2.0. 3.0) Phaf, Van der
Heijden, Hudson 1990 (SLAM) Tsotsos et al. 1990
(Selective Tuning) Mozer 1991 (MORSEL) Ahmad
1991 (VISIT) Olshausen, Anderson Van Essen
1993 Niebur, Koch et al. 1993 Desimone
Duncan 1995 (Biased Competition) Postma 1995
(SCAN) Schneider 1995 (VAM) LaBerge 1995
Itti Koch 1998 Cave et al. 1999
(FeatureGate)
The number of models that address the
neurobiology of visual attention is small ( in
the list). The number that have real
computational tests on actual images is even
smaller ( in the list). However, many
relevant ideas have appeared in psychological
models. A selected historical perspective on the
ideas important to the modelling task appears in
the following slides.
3
Issues

• Models of visual attention need to include
  solutions to or exhibit observed
  neurobiological/psychophysical performance for
• computational complexity of visual processes
• information routing through the processing
  hierarchy
• attentional control
• time course of attentive modulation
• single cell attentive modulation
• attentive modulation in (apparently) all visual
  areas
• suppressive surround effects
• serial/parallel visual search performance
• binding of features to objects

4
Format of Overview Not all models are included,
only those that have historical importance or
that claim neuro-psycho relevance Due to space
and time limits, each model is described only
with 1. key references 2. key ideas 3.
neurobiological relationship (where possible) (
v has supporting evidence X does not have
supporting evidence ? open question) Note
that this can only be regarded as a partial
review!
5
Koch and Ullman 1985Koch, C., Ullman, S. (1985).
Shifts in selective visual attention Towards the
underlying neural circuitry, Human
Neurobiology 4, 219-227.
Key ideas - saliency map (Treismans map) ? -
winner-take-all competition v (Findlay 1996, Lee
et al. 1999) - WTA selects items to route to
central representation X - inhibition of return
for shifts ? - time to move attention
proportional to logarithmic in distance between
stimuli X (Krose Julesz 1989) - no single
cell modulations X
6
Anderson and Van Essen 1987 Shifter
CircuitsAnderson, C., Van Essen, D. (1987).
Shifter Circuits a computational strategy for
dynamic aspects of visual processing, Proc.
Natl. Academy Sci. USA 84 6297-6301.
Key ideas - information routing is accomplished
by simple shifting circuits starting in the
LGN and input layers of primate visual area V1
X - realignment is based on the preservation of
spatial relationships - stages linked by
diverging excitatory inputs. - direction of
shift by inhibitory neurons that selectively
suppress sets of ascending inputs. -
stages are grouped into small and large scale
shifts. - control comes from pulvinar ?
7
(No Transcript)
8
Tsotsos 1990 Selective Tuning
ModelTsotsos, J.K., Analyzing Vision at the
Complexity Level, Behavioral and Brain Sciences
13-3, p423 - 445, 1990.Tsotsos, J.K. (1993).
An Inhibitory Beam for Attentional Selection, in
Spatial Vision in Humans and Robots, ed. by
L. Harris and M. Jenkin, p313 - 331, Cambridge
University Press. Tsotsos, J.K., Culhane, S.,
Wai, W., Lai, Y., Davis, N., Nuflo, F. (1995).
Modeling visual attention via selective
tuning, Artificial Intelligence 78(1-2),p 507 -
547.Tsotsos, J.K. (1995). Towards a
Computational Model of Visual Attention, in Early
Vision and Beyond, ed. by T. Papathomas, C,
Chubb, A. Gorea, E. Kowler, MIT Press/Bradford
Books, p207 - 218.Tsotsos, J.K., Culhane,
S., Cutzu, F., From Theoretical Foundations to a
Hierarchical Circuit for Selective Attention,
Visual Attention and Cortical Circuits, ed. by J.
Braun, C. Koch J. Davis, MIT Press (in
press).
9
Key ideas - attention modulates neurons to
earliest levels wherever there is a
many-to-one mapping v - signal interference
controlled by surround inhibition throughout
processing network - task knowledge biases
computations throughout processing network -
inhibition of connections not units v
Hernandez-Peon, Scherrer, Jouvet (1956) -
attentional control is local, distributed and
internal - competition is based on WTA
(different form than previous models) - pyramid
representation with reciprocal convergence and
divergence v Salin Bullier(1995)
10
The basic idea (BBS 1990)
not the same as von derMalsburg - only
connections leading to interference are
inhibited other unattended ones left alone
11
v Kastner, De Weerd, Desimone, Ungerleider,
1998
v Caputo Guerra 1998 Bahcall Kowler
1999 Vanduffel, Tootell, Orban 2000 Smith et al.
2000
12
Hierarchical Winner-Take-All
top-down, coarse-to-fine WTA hierarchy for
incremental selection and localization
unselected connections are inhibited

Simulation
13
Selection Circuits
unit and connection
l
a
y
e
r


1
l
in the interpretive network
unit and connection
in the gating network
l
a
y
e
r

l
l
a
y
e
r

-
1
l

I
14
Search for Blue Regions
15
Predictions
from 1990 paper attention in all visual areas,
down to earliest competition can be biased by
task inhibition of unselected connections
within beam inhibitory surround impairs
perception around attended item distractor
effects depend on distractor-target separation

16
Olshausen, Anderson Van Essen 1993Olshausen,
B., et al. (1993). A neurobiological model of
visual attention and invariant pattern
recognition based on dynamic routing of
information, J. of Neuroscience, 13(1)4700-4719.
Key ideas - implementation of shifter circuits -
forms position and scale invariant
representations at the output layer X - control
neurons, originating in the pulvinar,
dynamically modify synaptic weights of
intracortical connections to achieve routing ? -
the topography of the selected portion of the
visual field is preserved - uses Koch Ullman
mechanism (luminance saliency only) for selection
- associative recognition at output layer
17
only attended item reaches output layer
Olshausen seeks to achieve translation-rotation
invariant recognition
18
Itti 1998Itti, L., Koch, C., Niebur, E. (1998).
A model for saliency-based visual attention for
rapid scene analysis, IEEE Trans. Pattern
Analysis and Machine Intelligence 20, 1254-1259.
Key ideas - a newer implementation of Koch and
Ullmans scheme - fast and parallel pre-attentive
extraction of visual features across 50 spatial
maps (for orientation, intensity and color, at
six spatial scales) - features are computed using
linear filtering and center-surround structures
- these features form a saliency map ? -
Winner-Take-All neural network to select the most
conspicuous image location -
inhibition-of-return mechanism to generate
attentional shifts - saliency map
topographically encodes for the local conspicuity
in the visual scene, and controls where the
focus of attention is currently deployed
19
(No Transcript)
20
(No Transcript)
21
Conclusions

• Several ideas have endured
• Winner-Take-All for selection (competition)
• Hierarchies
• Inhibition of return to force serial search
• Some kind of gating process
• Inhibitory surrounds
• However, modeling seems to be still in its early
  days
• Progress will depend on whether modelers and
  experimenters can work together
