6Digit Selcall Interoperability Status Update

1
6-Digit Selcall Interoperability Status Update

• November 2004

2
Agenda

• References summary
• Intellectual Property Exchange Deed
• Implementation process phases
• 6 digit protocols
• Codan selcall protocols features
• Codan supported call types

3
References Summary

• 1. Codan Open Letter to UN 19 April 04 Six
  Digit Selective Calling System
• Codan had previously opened the protocol for
  6-digit Selcall, Group Call, Channel Test
  (Beacon) Call Phone (Tel) call in August 2003
• Codan offered to exchange further details of
  protocols with concerned manufacturers
• Codan concerned to ensure fault free
  interoperability
• 2. UN WGET Statement of 6-digit Selcall 27
  April 04
• Urged concerned manufacturers to implement a
  shared 6-digit Selcall standard
• Compatibility to be proven certified
• Codan radio (NGT and 9360 V.3.03) compatible
• 6 months to bring to market
• Concrete evidence at Autumn 04 Meeting

4
References Summary (Cont.)

• Codan - Barrett IP Exchange Deed
• An appropriate process was agreed to ensure
  implementation and testing to achieve fault free
  interoperability between manufacturers for the
  benefit of customers
• Codan Bid for UN Tender 046/2004 25 Aug 04
• Support for Codan, Barrett and UN specified
  protocol
• Status Letter to UN dated 17 Nov 04
• Will have interoperability by Dec 04
• Letter provided

5
Intellectual Property Exchange Deed

• Codan Barrett have worked through and signed an
  Intellectual Property Exchange Deed
• The Deed is aimed at bi-lateral exchange of full
  6-digit Selcall protocol details between
  manufacturers
• Allows products from either manufacturer to be
  fully backwards compatible with currently fielded
  equipment from the other company
• Ensures fault-free interoperability through
  testing prior to making it available to the UN

6
Intellectual Property Exchange Deed Phases

• Exchange Phase
• (Completed)
• Bi-lateral Selcall Protocol Information exchanged
  between companies
• Implementation Test Phase (Currently underway)
• Each company implements the other companys
  protocol
• Each company makes their products available for
  interoperability testing with the other company
  product
• Release Phase (Expected Jan 2005)
• Each company to release products that are tested
  to be interoperable with each other

7
6-digit Protocols Supported

• 8 Codan Call types (for NGT and 9360)
• Available since Aug. 03
• Selcall (also as Group Call)
• Phone (Tel) Call
• Channel Test (Beacon) Call
• Available through Exchange Deed
• (Deed signed with Barrett)
• Emergency (also as Group Call)
• With and without GPS data
• Message (page) call (also as Group Call)
• Up to 64 characters of upper and lower case text
• GPS Beacon/Request Call (poll for position data)
• GPS Position Call (send position data)
• Status Call
• Retrieve diagnostic data
• Retrieve configuration data
• Remote Disable (Stun) (NGT only)
• Send remote programming data (NGT only)

8
6-digit Protocols Supported

• UN Protocol in Codan NGT
• Released as part of the UN Consortium bidding
  document
• Barrett Protocol in Codan NGT
• Complete Barrett protocol now exchanged with
  Codan allowing Codan transceivers to be backward
  interoperable with fielded Barrett equipment.
• Any and all of these protocols will be
  available for interoperable use

9
Codan Selcall Protocol Features

• Full backwards compatibility for all call types
  to previous (i.e 9360) and current (i.e. NGT)
  Codan transceivers series.
• No software upgrades of Codan transceivers
  already in the field will be required for
  interoperability.
• Transparent operation in networks with mixed
  4-digit and 6-digit addressing.
• Ensured privacy with data encryption available
  for all messaging functions (GPS, Message (Page)
  Status Call).
• Privacy Password Length (6 digits for 9360, 15
  digits for NGT)
• Encryption protocol exchanged via Deed
• Text messages with up to 64 characters, lower
  case characters and receipt acknowledgement.

10
Codan Supported 6-digit Call Types
