ATLAS software workshop at BNL 2328 May 2004

1
ATLAS software workshop at BNL 23-28 May 2004

• Summary of notes taken during talks and some
  slides taken from interesting talks Ricardo, 29
  May 2004

2
Outline
Overall notes and plans
Core software, distribution kit, etc
Simulation and detector description
Reconstruction and event selection
Analysis tools and Event Data Model
Combined Test Beam
3
Overall notes and plans
4
Many different sessions and working group
meetingswill try to summarize and will focus on
some subjects more than others.Also, most of
this talk is a transcription of my notes, not all
of it makes sense of is very explicit.

• Software plenary sessions I II
• Event selection, reconstruction and analysis
  tools
• Software infrastructure
• Simulation and detector description
• Data challenge
• Framework working group
• Grid and distributed analysis
• Event Data Model (EDM) working group
• SUSY working group
• Reconstruction working group
• Physics coordination
• Physics Event Selection Algorithms (PESA) working
  group

• Grid working group
• Physics validation
• Detector description working group
• Distributed analysis working group
• Database and calibration/alignment
• Combined performance
• International computing board
• Analysis tools working group
• Database working group
• Software distribution and deployment working
  group
• Calibration/alignment working group
• Software plenary session III

5

• Major production activities soon DC2, Combined
  Test Beam
• Also HLT testbed and physics studies leading up
  to Physics Workshop 2005
• Next software week 20-24 September after DC2 and
  at end of beam test
• Documentation is only in the minds of a few
  people some plans to document parts of software
  during the next year
• Several buzzwords in this meeting
• Geant4
• Pileup
• Digitization
• event mixing
• EDM ESD/AOD (what information should be in AOD?
  100kB max)
• Use of Python job options (no more athena.exe in
  gt 8.2.0, use jobOptions_XXX.py)
• Grid
• Calibration etc.

6
ATLAS Computing Timeline
7

• Planning (T.LeCompte)
• For the first time delay in schedule is
  consistent with zero
• Several project reviews expected soon
• Inner Detector and Core software seem to need
  lots of work and people

8
Core software, distribution, validation, etc
9
Core software
Release plans 8.2.0 22 May 8.3.0 9
June 9.0.0 30 June DC2 production

• Core software (C.Leggett)
• Gaudi
• Current version is v14r5ATLAS-specific patches
  (ATLAS version 0.14.6.1)
• Changes for v14
• Uses SEAL, POOL, PI (?)
• AIDA histogram Svc replaced with ROOT
• GaudiPython
• Events merging can now control exactly which
  events from 2 files are merged
• Pileup see Davide's talk Tuesday
• Interval of Validity (IoV) Svc improved
• v8.2.0 new version of CLHEP causes wrong version
  of HepMC to load when using athena.exe (not
  athena.py) -gt segfault
• Athena and Gaudi heading towards rel. 9, Gaudi
  v15 (try to stay in step with LHCb) extend
  installArea to gaudi

10
Distribution kit

• Development platform vs. deployment platform
• Kit philosophy
• Address multiple clients running binaries/doing
  development
• Possibility of downloading partial releases,
  binaries only (Gregory working on this one),
  source code
• Multiple platforms (not yet)
• Until recently only RedHat7.3 gcc 3.2 supported
  in future, CERN Enterprise Linux (CEL) 3 gcc
  3.2.3 / icc8 (64-bit compiler) / Windows / MacOSX
• Complication in development platforms from
  external software need to cleanup packages and
  think about dependencies
• Runtime environment has some problems not easy
  to setup for partial distributions
• Pacman/Kit tutorial to be organized soon

11
Validation (D.Costanzo)

• 3 activities
• - reconstruction of DC events with old zebra
  events
• - validation of generators for DC2
• - reconstruction of G4 events for DC2
• Plan for next year generate more events and
  prepare for physics workshop 2005
• v8.2.0 should be next usable release
  (moore/muid?), exercise reconstruction
• Various details
• Some degeneration of reconstruction was found wrt
  7.0.2
• Atlfast needed to validate generated event
• Several problems found e.g. xKalman in 8.0.3
• A lot of activity in electron reconstruction
• Jet/ETmiss jetRec under restructuring, H1-style
  weights need to be recalculated for Geant4
• DC2 going into production mode

12
Grid infrastructure (Luc Goosens, et al.)

• production system architecture (2)
• executors
• one for each facility flavour
• LCG (lexor), NG (dulcinea), GRID3 (Capone), PBS,
  LSF, BQS, Condor?,
• translates facility neutral job definition into
  facility specific language
• XRSL, JDL, wrapper scripts,
• implements facility neutral interface
• usual methods submit, getStatus, kill,
• data management system
• allows global cataloguing of files
• we have opted to interface to existing replica
  catalog flavours
• allows global file movement
• an atlas job can get/put a file anywhere
• presents a uniform interface on top of all the
  facility native data management tools
• implementation -gt Don Quijote
• see separate talk

13
Data Management (database) Don
Quixote Supervisor Windmill Executors NG
(dulcinea), LCG (lexor), GRID3 (Capone), batch
prodDB
dms
Don Quixote
super
super
super
super
super
Windmill
jabber
jabber
jabber
jabber
jabber
LCG exe
LCG exe
NG exe
G3 exe
LSF exe
Executors
RLS
RLS
RLS
Grids
LCG
NG
Grid3
LSF
14
DC2 running (S.Albrand)

• DC2 will have a much more sophisticated
  production system than DC1 and uses POOL instead
  of ZEBRA
• Only one database for all data types data type
  is stored in database
• Users add properties to their datasets
  (collection of logical files) from a predefined
  list of possible properties
• Allows database searches for datasets
• Dataset names proposed to user (mods. possible)
• User interface to submit tasks
• Datasets not owned by one physics group alone
  anymore notion of principal physics group
• Possibility to extract parent and children
  datasets parent may be generator level dataset
  and children may be reconstructed dataset

15
Simulation and Detector Description
16
Detector description (J.Boudreau)

• The detector description in GeoModel will be
  used in both simulation and reconstruction
• LAr is last detector missing in GeoModel
• TileCal has finished GeoModel description but
  will not be available for DC2
• Volumes know their sub-volumes calculate dead
  material etc in transparent way
• Relational database (Oracle) will contain
  versions of whole detector no hardwired detector
  description numbers in reconstruction code
• Changing things such as alignment will be dealt
  with through different versions of detector
  description in database
• Great live demo of GeoModel!

17
Simulation (A.Rimoldi)

• Simulation (A.Rimoldi)
• Generators in advanced stage in both Atlfast and
  Atlsim added Cascade and Jimmy some
  differences between G3 and G4 Herwig events
• G4atlas being debugged use versions gt 6.0 new
  Geant4 release 6.1 (25/3/2004)
• Digitization most infrastructure software now in
  place, but work to do for each subdetector
• Pileup under development and test different
  subdetectors can be affected by different bunch
  crossings
• Combined test beam general infrastructure is
  ready

18
G4ATLAS status (A.Dell'Acqua)

• Concentrating on DC2 production
• G4 v6.1 gave some problems, went back to v6.0
• 6.0 has some physics problems (which don't seem
  to be serious from his tone), but aiming for
  rubustness at the cost of some accuracy
• MC truth fully deployed with rel.8.0.2, full
  support in v8.0.3
• Need guinea pigs to test MC truth and for
  simulation and reconstruction
• G4 truth uses same HepMC format as generated
  event
• Migration to python job options

19
Digitization and Pileup (D.Costanzo)

• Sub-detector breakdown ID getting there,
  calorimetry very mature since DC1, muons not so
• Pileup each detector reads pileup from different
  bunch crossings
• Number of files in POOL should be kept low many
  files leads to mem.leaks!
• Disk usage explodes with use of pileup. most of
  this is MC truth for backgr.event
• Which doesn't have to be written, will be
  eliminated
• Memory leak problems

20
Detector Simulation Conclusions

• G4atlas (A.Rimoldi)
• Work on digitization and pileup
• Full deployment of MCtruth
• Migration to Python job options
• Major changes in AtlasG4Sim to converge with
  atlas
• human resources problem (Armin)
• Digitization and Pileup (D.Costanzo)
• Detector folders ? each detector reads hits from
  different bunch crossings
• Emphasis moved to detector description in
  GeoModel
• Inner Detector Noise was implemented with no
  hits from pixel/SCT
• LAr calorimeter Improvements wrt G3 use of
  GeoModel
• Still bugs and calibration issues in G3/G4
• Muon spectrometer migration to GeoModel done in
  the last few days
• Effort put in validation of hit positions
• Detailed simulation of MDT digitization and
  response
• Realistic pileup procedure still needs work
• Setup for combined test beam in place (or almost)

21
Analysis Tools
22
Analysis tools (K.Assamagan)

• RTF recommendations looked at modularity,
  granularity design of reconstruction software
• AnalysisTools span gap between reconstruction
  and ntuple analysis
• Tools Artemis analysis framework prototype
  Seems to diverge from EDM, may not be supported
  for long
• PID - prototype to handle part.identif.
• Workshop in april at UCL http//www.usatlas.bnl.g
  ov/PAT/ucl_workshop_sumary.pdf
• - PyRoot, PyLCGDict
• - Physicists Interfaces (PI) project
• extends AIDA provides services for batch
  analysis in C, fitting and minimization,
  storage in HBOOK/ROOT/xml,
• plotting in ROOT/Hippodraw/OpenScientist, etc.

data
algorithms
Data flow
23
Python scripting language (W.Lavrijsen)

• GaudiPython provides binding to Athena core
  objects basis for job options after release
  8.2.0
• PyROOT bridge between Python and ROOT
  distributed with ROOT 4 http//root.cern.ch/root/
  HowtoPyROOT.html
• PyBus software bus (modules can be plugged in
  to bus) implemented in Python http//cern.ch/wlav
  /pybus
• ASK (Athena Startup Kit) DC2-inspired tutorial
  online full chain of algorithms (generators gt
  ... gt simulation gt ... gt analysis)
  http//cern.ch/wlav/athena/athask/tutorials.html

24
Analysis with PyROOT (S.Snyder)

• Why? Because ROOT C not reliable enough, python
  much better and as good if
• No speed problems found
• PyROOT now part of ROOT release
• Can use pyroot to interface own code (or any code
  that cint would do)
• PyLCGDict, does the same thing with different
  data dictionary (data definition). When to use?
• If you have external code that already has
  ROOT/LCG dictionary that helps to decide
• PyRoot has less dependencies

25
Reconstruction, Trigger and Event Data Model
26
Reconstruction (D.Rousseau)

• RTF recommendation Detectors (e.g.TileCal and
  LAr) should share code to facilitate downstream
  algorithms
• Combined beam test analyse CBT data with offline
  code, as little dedicated code as possible big
  effort e.g. to integrate conditions database for
  various detectors
• DC2 reconstruction (release 9.x.x )
• Run on Geant4 data with new detector description
  validate G4
• Persistence
• ESD (event summary data), EDM output issues with
  200k cal cells target size 100kB/ev
• Ongoing discussions on AOD (analysis object data)
  definition aim for 10kB/ev

27
Reconstruction (D.Rousseau)

• Work model
• Reconstruction ? Combined ntuple ? ROOT/PAW
  analysis
• Changes to
• reconstr ? ESD/AOD ? analysis in Athena ? small
  ntuple ? ROOT
• CBNT remains as debugging tool but will not be
  produced in large scale for DC2
• Status
• Python job options (no more jobOptions_xxx.txt)
• People needed for transverse tasks
  documentation, offline/CBNT reconstruction
  integration, AOD/ESD definition

28
Calorimeter reconstruction (P.Loch)

• CALO EDM has navigable classes CaloCell,
  CaloTower and CaloCluster using consistent
  4-momentum representations (INavigable4Momentum),
  v8.1.0) can now be used directly by JetRec
• Container class CaloCellContainer holds both LAr
  and TileCal CaloCells and persistifies them in
  StoreGate (8.2.0, key AllCalo) used by
  LArCellRec, LArClusterRec, TileRecAlgs explicitly
• Clusters produced by CaloClusterMaker (Sven
  Menke, v8.1.0, topological and sliding window
  clusters) have full 3D neighbours option,
  crossing boundaries between calorimeters (8.2.0)
• Cluster splitter with 3D clusters spanning
  different calorimeters under test (aim for 8.3.0)
  finds individual showers (peaks) in large
  connected cluster

29
(No Transcript)
30
Calorimeter reconstruction (P.Loch)

• New structure for algorithm class
  CaloTowerAlgorithm calls different builders for
  towers according to calorimeter makes older
  FCAL minicells obsolete
• CALO algorithm structure slightly behind EDM new
  CaloCellMaker (David Rousseau) to be tested
  makes cells also calls cell-type corrections (gt10
  corrections for LAr) aim for 8.3.0, needed in
  9.0.0
• No hardwired numbers in code anymore, detector
  description/job options (Database? Job options?)
• Implement relations between cells and clusters
  for 9.0.0 (using STL maps?) Proposal to have
  classes such as particleWithTrack to implement
  relations was rejected
• Asked for volunteers for design, implementation
  and testing of both the calorimeter EDM and the
  reconstruction algorithms

31
Tracking (E.Moyse)

• Many recent developments
• new tracking class converters from old formats
• very good Doxygen documentation available from
  the ID software homepage
• A lot of reorganization and new packages recently
• track extrapolation for ID - Dmitri Emeliyakov
• DC2 will be based on iPatRec and xKalman
• there will be manual for EDM and utility packages
  for v9.0.0

32
Track Overview

• New interface for Track, shown above.
• TrackStateOnSurface - provides a way of iterating
  through hits and scatterers on the track. It
  contains pointers to
• RIO_OnTrack
• TrackParameter
• FitQualityOnSurface
• ScatteringangleOnSurface
• Summary
• old summary object still in Track in 8.2.0.
  Could not be removed without changing interface
  (see later slide)

33
TrackParticle Overview

• Why do we need TrackParticle?
• Need lightweight object for analysis, providing
  momentum
• Need to transform parameters from detector to
  physics frame
• Provides navigation

34
Muon Reconstruction (S.Goldfarb)

• Packages Moore and Muonboy (became MuonBox)
• Moore moved to GeoModel, reconstructs G4 data,
  DC2 development
• MuonBoy G4 reco expected shortly, not using
  GeoModel, development for testbeam
• Common features unit migration now validated
• Efficiency in eta is now perfect (features
  reported in SUSY full.sim. paper are gone)
• Combined reconstruction Staco (now ported to
  Athena, will accept all types of tracks
• being prepared for new EDM)
• MuID low pT muon development using tilecal, etc
• Track task force

35
Discussions on EDM/ESD/AOD

• Data flow is
• Reconstruction ? ESD (100kB) ? AOD (10kB) ? User
  code ? ntuples
• Meeting at UCL in April document with
  conclusions at
• http//www.usatlas.bnl.gov/PAT/ucl_workshop_sumary
  .pdf
• Discussion
• Proposal for a class of IdentifiedParticle
  which could be lepton, tagged jet etc - Proposal
  was rejected, it seemed to need either a very
  complicated or a redundant implementation to be
  sufficiently general
• Discussion on e.g. e/gamma ID
• egammaBuilder - high-pT electron ID
• softeGammaBuilder better for low pT/non-isol.
  electrons but much overlap
• Both collections must be kept, but balance must
  be found in similar matters due to AOD size
  restrictions (aim for 10kB/ev.)
• CaloCells (200,000! Cannot all be kept!) can
  keep cells above noise plus sum of all cells
  (critical for ETmiss)
• Similar issues for tracking, muons, etc
• Conclusions
• Keep more than one collection of , e.g.
  electrons, introduce event view to help choose
  between candidates
• CaloCellContainer a technical solution in sight
  but worries about cell removal, needs study

36
Reference frames (Richard Hawkins)

• Need for more than one frame ?
• Global frame is defined in ATL-GE-QA-2041
• Easier to do reconstruction if we have several
  subdetector-specific frames?
• Boosted frames? For example, such that sum of
  pT_beam0, to correct for beam tilt (10-4rad, but
  p_beam7TeV)
• QA
• Markus Elsing - one global frame must be used for
  reconstruction. Also global frame should be
  determined by inner detector frame, if possible.
  Problem otherwise when using lookup tables for
  subdetector position
• Various - beam tilt should be corrected for if
  possible/necessary and size of effect estimated
  may be done in Monte Carlo
• Conclusions
• Strive to use only one global frame
• Beam tilt should be taken care of in the
  simulation, same as the vertex smearing

37
PESA (Simon)

• Several technical matters, software automatic
  testing move from development to production
  phase (stable, user-friendly code etc)
• Discussion on forced acceptance a fraction of
  the events must be kept regardless of trigger
  acceptance -gt studies of noise, background,
  trigger efficiency etc
• Discussion on how this should be implemented
  fine-grained (according to LVL1 flags), global
  (global of bunch crossings), etc
• Rather technical reports on status of e/gamma,
  LAr and muon slices

38
Example e/gamma slice
TrigIdScan
7.0.2 had efficiency problem in both TrigIdScan
and SiTrack, now solved
Mean effic. 94
Mean effic. 91
7.0.2
7.0.2
SiTrack
h
h
Mean effic. 95
Mean effic. 96
8.0.0
8.0.0
h
h
-3 2 1 0 1 2 3
-3 2 1 0 1 2 3
Single electrons pile-up 1034
Single electrons pile-up 2x1033
39
egamma Workshop
Several topics have come up which need more
discussion

• Combined testbeam
• How to integrate what we will learn there?
• Reconstruction
• what is done in clustering, what in egamma
  electron/photon id?
• Calibration/Corrections
• what is specific to e and gamma and how to?
• G4/G3
• Geometry use
• Physics Studies
• Zee etc
• Validation of Releases

Difficult to find time to discuss all of this in
the usual weeks Date Mon-Tue, June 28-29
(tbc) Place LPNHE Paris (Fred Derue)
40
Several combined performance studies

• Discrepancy found between G3 and G4 see
  K.Benslama, Electron Study
• Apparently already explained from difference G3
  and G4 (E-field effect not simulated in G3)
  see G.Unal, LAr calibration
• Below 50 GeV electrons vs. eta

E 20 GeV
?
41
JetRec (P.Loch)

• First look at new jets
• Kt for towers seems to be slower than used to be
  found some long standing bugs
• Most jets in forward direction are extremely low
  in transverse energy ? apply cuts on jet finder
  input (towers, so far)
• Number of jets in calorimeter and MC truth is
  very comparable if no cut on Et of input cells
  Et gt 100/200/500 MeV (very low Et cuts!!!)
• As soon as cuts are applied, basically all
  distributions (multiplicity, jet shapes, radius,
  etc become different from truth (see next slide)
• Verify hadronic calibration
• Invited contributions of new jet algorithms if
  needed
• Physics groups should use jet finders and give
  feedback
• Preparing extensive documentation for 8.3.0

42

• Number of Kt jets in calorimeter and MC truth

ok!
43
Up date on vertexing II

• Vertexing tools work quite stable by now
• - Billoir FastFit method heavily in use
• - SlowFit method first use case by B-physics
  people in Artemis (J. Catmore)
• InDetPriVxFinder package is the standard primary
  vertex finder in Athena reconstruction
• Several clients for VxBilloirTools already
  (B-physics group, several people from Bonn
  University, b-tagging, )

Andreas Wildauer
44
Results of InDetPriVxFinder
H?uu and H?bb with vertex constraint, Geant4 H
?bb (0., 0., 0.)(0.015, 0.015, 56) mm, 4800
events in total
12 µm 13 µm
32 µm 36 µm
Andreas Wildauer
45
Results on QCD di-jets events from D. Cavalli
OLD H1 Calibration - Athens results
NEW H1 Calibration from MissingET improves
proportionality curve
46
Combined Test Beam
47
Combined Test Beam (A.Farilla)

• Immediate plans
• Finalize and validate first version of simulation
  package
• Finalize first version of reconstruction with ESD
  and CBNT output
• Start plugging Combined Reconstruction algorithms
  into RecExTB
• Finalize code access to Conditions Database
• Develop basic analysis framework for
  reconstructed data
• Work in progress for a combined event display in
  Atlantis

Looking for new people from the CTB community to
add algorithms from combined reconstruction into
RecExTB
48
Thats it
49
Acronyms

• PESA Physics event selection algorithms
• ESRAT Event Selection, Reconstruction and
  Analysis Tools
• EDM Event Data Model
• ID Inner Detector
• CBT (CTB) Combined Beam Test
• STL Standard Template Library
• SEAL Shared Environment for Applications at LHC
  (http//cern.ch/seal/)
• AIDA Abstract Interface for Data Analysis
• LCG LHC Computing Grid (http//lcg.web.cern.ch)
• PI Physicist Interface (extends AIDA, part of
  LCG)
• POOL Pool Of persistent Objects for Lhc (part
  of LCG)
