SYNCHROPHASOR TEAM
The Strategy for Modernizing Electric Grid
Dr. Naim Logic
August 27-31, 2008
2
Outline of presentation

• Synchronized Phasor Measurements
• Global positioning system (GPS)
• Global Warming
• Growing energy prices
• New energy sources needed
• Renewable energy
• Smart Grid
• R D programs
• New Generation of Engineers Needed

3
Synchronized phasor measurements
GPS Time Receiver
Time, sync
60 Hz component
DFT
Frequency Rate-of- Change of Frequency Algorithm
Symmetrical Component Transformation
DFT
Voltage, Current
Frequency, dFreq/dt
Positive Sequence Phasors
Real Time Data Output
DFT
Power System
Time synchronized sampling of three phase
waveform. 12 samples/cycle (720/sec). Discrete
Fourier Transform uses 12 samples for each
phasor conversion.
Disturbance and transcient detectors, data table
storage
Trigger flags
4
Phasor measurement system
Enables operators to start effective
countermeasures in time
5
GPS

• 24 satellites are orbiting the earth about 12,000
  miles above us (full constellation achieved in
  1994)
• Time accuracy /-0.2 s over a wide area
• Opens up new possibilities for a secure and
  reliable operation of electric power system

6
Global warming
7
Growing energy prices
8
New energy sources needed
Available renewable energy
9
Renewable energy resources and costs

• The technical potential is a more practical
  estimate of how much could be put to human use by
  considering conversion efficiencies of the
  available technology and available land area
• The estimate of solar energy assumes that 1 of
  worlds unused land surface is used for solar
  power

10
Smart grid

• Todays AC power grid was created in 1896, based
  on Nikola Tesla design from 1888.
• Development of modern microprocessors and
  satellite technology opened new ways to
  significantly improve power grid control.
• Evolutionary integration of intelligent,
  distributed, and highly-adaptive control systems
  Smart Grid.
  Examples
• Demand side management reducing power
  consumption on client side.
• Demand response interacting of generators and
  loads

11
Smart grid
12
Smart grid

• The earliest example of Smart grid is the one
  installed by Enel, Italy covering 27.2M
  residents, completed in 2005.
• In the US, Austin Energy is building and managing
  about 200.000 devices real-time (smart meters,
  smart thermostats, and sensors)
• In the spring of 2008., Xcel Energy announced its
  plans to build the first fully integrated Smart
  grid city in the US Boulder, CO

13
Smart grid
R D Programs

• IntelliGrid
• EPRI vision of the future electric delivery
  system
• Modern Grid initiative
• DOE NETL effort to modernize electrical grid
• Grid 2030
• Vision statement for the US electrical system
• Gridwise
• DOE program focused on information technology
• Gridwise Architecture Council
• DOE program to promote interoperability
• Gridworks
• DOE program focused on reliability improvement

14
New generation of engineers needed

• According to IEA, more than 16 trillion will be
  spent worldwide by 2030. in pursuit of the Smart
  grid vision
• How to meet power energy engineering education
  workforce needs?
• By straightening education and research in
  university power programs.
• Huge role of universities

15
Applications
Network parameter data calculation / verification
During steady-state operation transmission lines
may be characterized by ABCD parameters and
sending-end (s) and receiving-end (r ) quantities
For any two phasor measurement sets
complex-valued A, B, C, D can be determined. Line
impedance and admittances for nominal model
are
16
Applications
Frequency change tracking (islanding)
17
Applications
Voltage stability
ABB solution
18
Role of synchronized measurements in Power system
visibility

• By capturing the geographic variation of the
  phase angle over the region, one can identify the
  prevailing direction of power flow through the
  system

• In this Figure larger angles are shaded in yellow
  and orange, and smaller angles are shaded in blue

19
Role of synchronized measurements in Power system
visibility
Combination displays
20
World wide applications
Etrans Switzerland
21
World wide applications
NiP Norway Interconnection Project
VIP Voltage Instability Predictor
22
World wide applications
European reconnection
23
World wide applications
PMU in adaptive protection
24
Thank you for your time and interest
