Introduction to Bioinformatics Microarrays 3: Data Clustering

1
Introduction to Bioinformatics Microarrays 3
Data Clustering

• Course 341
• Department of Computing
• Imperial College, London
• Moustafa Ghanem
• Yike Guo

2
Data ClusteringLecture Overview

• Introduction What is Data Clustering
• Key Terms Concepts
• Dimensionality
• Centroids Distance
• Distance Similarity measures
• Data Structures Used
• Hierarchical non-hierarchical
• Hierarchical Clustering
• Algorithm
• Single/complete/average linkage
• Dendrograms
• K-means Clustering
• Algorithm
• Other Related Concepts
• Self Organising Maps (SOM)
• Dimensionality Reduction PCA MDS

3
IntroductionAnalysis of Gene Expression Matrices

• In a gene expression matrix, rows represent genes
  and columns represent measurements from different
  experimental conditions measured on individual
  arrays.
• The values at each position in the matrix
  characterise the expression level (absolute or
  relative) of a particular gene under a particular
  experimental condition.

4
IntroductionIdentifying Similar Patterns

• The goal of microarray data analysis is to find
  relationships and patterns in the data to achieve
  insights in underlying biology.
• Clustering algorithms can be applied to the
  resulting data to find groups of similar genes or
  groups of similar samples.
• e.g. Groups of genes with similar expression
  profiles (Co-expressed Genes) --- similar rows in
  the gene expression matrix
• or Groups of samples (disease cell
  lines/tissues/toxicants) with similar effects
  on gene expression --- similar columns in the
  gene expression matrix

5
IntroductionWhat is Data Clustering

• Clustering of data is a method by which large
  sets of data is grouped into clusters (groups) of
  smaller sets of similar data.
• Example There are a total of 10 balls which are
  of three different colours. We are interested in
  clustering the balls into three different groups.
• An intuitive solution is that balls of same
  colour are clustered (grouped together) by colour

• Identifying similarity by colour was easy,
  however we want to extend this to numerical
  values to be able to deal with gene expression
  matrices, and also to cases when there are more
  features (not just colour).


6
IntroductionClustering Algorithms

• A clustering algorithm attempts to find natural
  groups of components (or data) based on some
  notion similarity over the features describing
  them.
• Also, the clustering algorithm finds the centroid
  of a group of data sets.
• To determine cluster membership, many algorithms
  evaluate the distance between a point and the
  cluster centroids.
• The output from a clustering algorithm is
  basically a statistical description of the
  cluster centroids with the number of components
  in each cluster.

7
Key Terms and ConceptsDimensionality of gene
expression matrix

• Clustering algorithms work by calculating
  distances (or alternatively similarity in
  higher-dimensional spaces), i.e. when the
  elements are described by many features (e.g.
  colour, size, smoothness, etc for the balls
  example)
• A gene expression matrix of N Genes x M Samples
  can be viewed as
• N genes, each represented in an M-dimensional
  space.
• M samples, each represented in N-dimensional
  space
• We will show graphical examples mainly in 2-D
  spaces
• i.e. when N 2 or M2

8
Key Terms and ConceptsCentroid and Distance

• In the first example (2 genes 25 samples) the
  expression values of 2 Genes are plotted for 25
  samples and Centroid shown)
• In the second (2 genes 2 samples) example the
  distance between the expression values of the 2
  genes is shown

9
Key Terms and ConceptsCentriod and Distance
Cluster centroid The centroid of a cluster is a
point whose parameter values are the mean of the
parameter values of all the points in the
clusters. Distance Generally, the distance
between two points is taken as a common metric to
assess the similarity among the components of a
population. The commonly used distance measure is
the Euclidean metric which defines the distance
between two points p ( p1, p2, ....) and q (
q1, q2, ....) is given by
10
Key Terms and ConceptsProperties of Distance
Metrics

• There are many possible distance metrics.
• Some theoretical (and intuitive) properties of
  distance metrics
• Distance between two profiles must be greater
  than or equal to zero, distances cannot be
  negative.
• The distance between a profile and itself must be
  zero
• Conversely if the difference between two profiles
  is zero, then the profiles must be identical.
• The distance between profile A and profile B must
  be the same as the distance between profile B and
  profile A.
• The distance between profile A and profile C must
  be less than or equal to the sum of the distance
  between profiles A and B and profiles Ba and C.

11
Key Terms and ConceptsDistance/Similarity
Measures

• Euclidean (L2) distance
• Manhattan (L1) distance
• Lm (x1-x2my1-y2m)1/m
• L8 max(x1-x2,y1-y2)
• Inner product x1x2y1y2
• Correlation coefficient
• Spearman rank correlation coefficient
• For simplicity we will concentrate on Euclidean
  and Manhattan distances in this course

12
Key Terms and ConceptsDistance Measures
Minkowski Metric
13
Key TermsCommonly Used Minkowski Metrics
14
Key Terms and Concepts Examples of Minkowski
Metrics
15
Key Terms and ConceptsDistance/Similarity
Matrices

• Gene Expression Matrix
• N Genes x M Samples
• Clustering is based on distances, this leads to a
  new useful data structure
• Similarity/Dissimilarity matrix
• Represents the distance between either N Genes
  (NxN) or M Samples (MxM)
• Only need half the matrix, since it is symmetrical

16
Key TermsHierarchical vs. Non-hierarchical

• Hierarchical clustering is the most commonly used
  methods for identifying groups of closely related
  genes or tissues. Hierarchical clustering is a
  method that successively links genes or samples
  with similar profiles to form a tree structure
  much like phylognentic tree.
• K-means clustering is a method for
  non-hierarchical (flat) clustering that requires
  the analyst to supply the number of clusters in
  advance and then allocates genes and samples to
  clusters appropriately.

17
Hierarchical ClusteringAlgorithm

• Given a set of N items to be clustered, and an
  NxN distance (or similarity) matrix, the basic
  process hierarchical clustering is this
• Start by assigning each item to its own cluster,
  so that if you have N items, you now have N
  clusters, each containing just one item.
• Find the closest (most similar) pair of clusters
  and merge them into a single cluster, so that now
  you have one less cluster.
• Compute distances (similarities) between the new
  cluster and each of the old clusters.
• Repeat steps 2 and 3 until all items are
  clustered into a single cluster of size N.

18
Hierarchical Cluster Analysis

• Scan matrix for minimum

19
Hierarchical Cluster Analysis

• Scan matrix for minimum

• Join genes to 1 node

20
Hierarchical Cluster Analysis

• Update matrix

21
Hierarchical Cluster Analysis

• Scan matrix for minimum

• Join genes to 1 node

22
Hierarchical ClusteringDistance Between Two
Clusters

• Single-Link Method / Nearest Neighbor
• Complete-Link / Furthest Neighbor
• Their Centroids.
• Average of all cross-cluster pairs.

Whereas it is straightforward to calculate
distance between two points, we do have various
options when calculating distance between
clusters.
23
Key TermsLinkage Methods for hierarchical
clustering

• Single-link clustering (also called the
  connectedness or minimum method) we consider
  the distance between one cluster and another
  cluster to be equal to the shortest distance from
  any member of one cluster to any member of the
  other cluster. If the data consist of
  similarities, we consider the similarity between
  one cluster and another cluster to be equal to
  the greatest similarity from any member of one
  cluster to any member of the other cluster.
• Complete-link clustering (also called the
  diameter or maximum method) we consider the
  distance between one cluster and another cluster
  to be equal to the longest distance from any
  member of one cluster to any member of the other
  cluster.
• Average-link clustering we consider the distance
  between one cluster and another cluster to be
  equal to the average distance from any member of
  one cluster to any member of the other cluster.

24
Single-Link Method
Euclidean Distance
a
a,b
b
a,b,c
a,b,c,d
c
c
d
d
d
(1)
(3)
(2)
Distance Matrix
25
Complete-Link Method
Euclidean Distance
a
a,b
a,b
b
a,b,c,d
c,d
c
c
d
d
(1)
(3)
(2)
Distance Matrix
26
Key Terms and ConceptsDendrograms and Linkage
The resulting tree structure is usally referred
to as a dendrogram. In a dendrogram the length of
each tree branch represents the distance between
clusters it joins. Different dendrograms may
arise when different Linkage methods are used
27
Two Way Hierarchical Clustering
Note we can do two way clustering by performing
clustering on both the rows and the columns It is
common to visualise the data as shown using a
heatmap. Dont confuse the heatmap with the
colours of a microarray image. They are different
! Why?
28
K-Means Clustering

• Basic Ideas using cluster centroids (means) to
  represent cluster
• Assigning data elements to the closet cluster
  (centroid).
• Goal Minimise square error (intra-class
  dissimilarity)

29
K-means ClusteringAlgorithm

• 1) Select an initial partition of k clusters
• 2) Assign each object to the cluster with the
  closest centroid
• 3) Compute the new centeroid of the clusters
• 4) Repeat step 2 and 3 until no object changes
  cluster

30
The K-Means Clustering MethodExample
31
k-means Clustering Procedure (1)
Step 1a Specify the number of cluster k e.g, k 4
Each point is called gene
32
k-means Clustering Procedure (2)
Step 1b Assign k random centroids
33
k-means Clustering Procedure (3)
Step 1c Calculate the centroid (mean) of each
cluster
(6,7)
(3,4)
(3,2)
(1,2)
34
k-means Clustering Procedure (4)
Step 2 Each gene is reassigned to the nearest
cluster
35
k-means Clustering Procedure (5)
Step 3 Calculate the centroid (mean) of each
cluster
36
k-means Clustering Procedure (5)
Step 4 Iterate until the means are converged
37
ComparisonK-means vs. Hierarchical Clustering

• Computation Time
• Hierarchical clustering O( m n2 log(n) )
• K-means clustering O( k t m n )
• t number of iterations
• Memory Requirements
• Hierarchical clustering O( mn n2 )
• K-means clustering O( mn kn )
• t number of iterations
• Other
• Hierarchical Clustering Need to select Linkage
  Method, and then a sensible split threshold
• K-means Need to select K
• In both cases Need to select distance/similarity
  measure

38
Other Related ConceptsSelf Organising Maps

• Self Organising Maps (SOM) algorithm is similar
  to k-means in that the user specifies a
  predefined number of clusters as a seed.
• However, as opposed to k-means, the clusters
  related to another via a spatial topology ---
  Usually the clusters are arranged in a square or
  hexagonal grid.
• Initially, elements are allocated to the clusters
  at random. The algorithm iteratively recalculates
  the cluster centroids based on the elements
  assigned to each cluster as well as those
  assigned to its neighbours, and then re-allocates
  the data elements to the clusters.
• Since the clusters are spatially related,
  neighbouring clusters can generally be merged at
  the end of a run based on a threshold value.

39
Other Related ConceptsDimensionality Reduction
If you take genes to be dimensions, you may end
up with up to 30,000 dimensions describing each
sample !

• Clustering of data is a form of data reduction
  since it allows us to describe large data sets
  (large number of points) into smaller sets.
• A related concept is that of dimensionality
  reduction.
• Each point in a data set is a point in a large
  multi-dimensional space (Dimension can either by
  genes or samples)
• Dimensionality reduction methods aim to map the
  same data points to a lower dimensional space
  (e.g. 2-D or 3-D) that preserves their
  inter-relationships.
• Dimensionality reduction methods are very useful
  for data visualisation, and also as a
  pre-processing step before applying data analysis
  algorithms such as clustering or classification
  that cannot cope with a very large number of
  dimensions.
• The maths behind these methods is beyond this
  course, and the following slides introduce only
  the basic idea.

40
Dimensionality ReductionMulti-dimensional
Scaling (MDS)

• MDS algorithms work by finding co-ordinates in
  2-D or 3-D space that preserve the distance
  ranking between the points in the high
  dimensional space.
• The staring point of MDS algorithm is the
  distance or similarity matrix between the data
  points and work through an optimisation
  algorithm.
• MDS preserve the notion of nearness, and
  therefore clusters in the high dimensional space
  still look like cluster on an MDS plot.

41
Dimensionality ReductionPrincipal Component
Analysis (PCA)
42
Dimensionality ReductionPrincipal Component
Analysis (PCA)

• PCA aims to identify the direction(s) of greatest
  variation of the data.
• Conceptually this is as if you rotate the data to
  find the 1st dimension of greatest variation,
  then the 2nd,
• Once the 1st dimension is found, a recursive
  procedure is applied on the remaining dimensions.
• The resulting PCA dimensions ordered first
  dimension captures most of the variation, second
  dimension captures most of the remaining
  variation, etc.
• PCA algorithms work using linear algebra (by
  calculating Eigen vectors)
• After calculating all the PCA components, you
  keep only the top-k components. In general the
  first few can usually capture about 90 of the
  variation of the data

43
Summary

• Clustering algorithms used to find similarity
  relationships between genes, diseases, tissue or
  samples
• Different similarity metrics can be used mainly
  Euclidean and Manhattan)
• Hierarchical clustering
• Similarity matrix
• Algorithm
• Linkage methods
• K-means clustering algorithm
• SOM, MDS, and PCA (only for reference)
