Title: Bayesian Networks


1
Bayesian Networks
  • Representation and Inference
  • Dapeng Zhang

2
Bayesian Networks
  • What are Bayesian Networks (BN)
  • Definition and Concept
  • Independence in a BN structure
  • d-separation
  • Inference within BN
  • Exact inference and approximate inference

3
Joint Probability Distribution(JPD)
  • P(A, B)
  • JPD, Probability of both A and B.
  • P(A,B)ltP(AB)
  • P(AB)
  • Conditional probability. The probability of A,
    given that B already happen.

B
A
4
Joint Distributions
  • 3 variables A, B, C need a table of 8 values.
  • 100 variables, need ... Too big to be acceptable.

5
BN example from AI course
  • Directed, acyclic graphs
  • Node for variable.
  • Directed edges for dependency
  • Conditional probability distribution in the
    table.
  • P(B,E,A,J, M) P(B)P(E)P(AB,E) P(JA)P(MA)

6
BN vs Full Joint Distributions
  • Given Alarm, John call is independent from Marry
    call. (redundancy of the data)
  • Considering other variables E, B, then table
    become larger. (efficiency)

7
A more complex example
  • A 37 nodes BN need a JPD table with
    137,438,953,472 values.

8
The reasons for using BN
  • Whatever you want can be get from it.
  • Diagnostic task. (from effect to cause)
  • P(JohnCallsBurglaryT)
  • Prediction task. (from cause to effect)
  • P(BurglaryJohnCallsT)
  • Other probabilistic queries (queries on joint
    distributions).
  • P(Alarm)
  • Reveal the structure of JPD
  • Dependencies are given by arrow.
    Independencies are specified, too (later)
  • More compact than JPD
  • Get rid of redundancy.
  • All kinds of query can be calculated (later)

9
BN formal definition(1/2)
  • NonDescendants(Xi)
  • Denote the variables in the graph that are not
    descendants of Xi. NonDescendants(A)B, E
  • I(M BA)
  • Denote given A, variables M and B are
    independent. P(B)P(BE)
  • Pa(Xi)
  • Denote the parents of Xi. Pa (A) B, E.

10
BN formal definition(2/2)
  • A Bayesian network structure G is a directed
    acyclic graph whose nodes represent random
    variables X1...Xn. Then G encodes the following
    set of conditional independence assumptions
  • For each variable Xi, we have that
  • I(Xi NonDescendants(Xi)
    Pa(Xi))
  • i.e., Xi is independent of its
    nondescendants given its parents.
  • From Daphne Koller
    Representing Complex Distributions
  • Example I(M JA).

Back?
11
Dependencies Independencies
  • Dependencies
  • Intuitive.
  • Two connected nodes influence each other.
    Symmetric.
  • Independencies
  • Example I(JMA), I(BE)
  • Others? I(BEA)?
  • -- d-seperation.

12
d-separation(1/5)
  • Enumerate all possibilities for 3 connected
    nodes.
  • Case 1/3
  • Indirect causal effect, no evidence.
  • Clearly earthquake will effect Marry call.
  • Same situation for indirect evidence effect,
    because independence is symmetric. -- if I(EMA)
    then I(MEA).

B
A
M
13
d-separation(2/5)
  • Case 2/3

Influence can flow from John call to Mary
call if we dont know whether or not there is
alarm. But I(JMA)
A
J
M
14
d-separation(3/5)
  • Case 3/3

Influence cant flow from Earthquake to
burglary if we dont know whether or not there is
alarm. So I(EB) Special structure which
cause independence. V-Structure

E
B
A
15
d-separation(4/5)
  • In a BN structure, if influence can flow from one
    node to another, then the two nodes depend each
    other.
  • Two nodes are Independence if all possible paths
    among them are proved to be not active.

16
d-separation(5/5)
  • From E, B, A, M, J to M, J, A, E, B

M
J
E
B
A
A
M
J
B
E
Back?
17
Query
  • Interesting information from joint probabilities.
  • What is the probability of both Mary call and
    John call if a Burglary happens? P(M, JB)
  • What is the most probable explanation of
    Marry call?
  • Query can be answered by inferencing the BN.
  • P(M,JB)P(B, M, J)/P(B)

  • Variable elimination algorithm

18
Vairable-Elimination Algorithm(1/3)
  • Idea Sum up one variable at a time, generating a
    new distribution with respect to other variables
    connecting with the eliminated variable.
  • When eliminate E, generate a distribution of
    A and B

19
Vairable-Elimination Algorithm(2/3)
f1(A1,B1) P(E0)P(A1E0,B1)
P(E1)P(A1E1,B1)
20
Vairable-Elimination Algorithm(3/3)
  • Go on eliminating A using the distribution
    created by last step.
  • Any query P(XY) where X X1..Xn Y Y1..Ym
    ZZ1..ZkOther nodes except X and Y, can be
    calculated by the below way, where P(X, Y, Z) is
    given by BN structure and ? can be eliminate step
    by step.

21
Complexity for exact inference
  • Exact inference problem is NP-hard, the cost of
    computing is decided by the size of intermediate
    factors.
  • Junction Tree algorithm in practice
  • Overall complexity is same with VE.
  • Allow multi-directional inference.
  • Comsume more space...

22
Approximate Inference in BN (1/4)
  • Sampling
  • Construct samples according to probabilities
    given in a BN.
  • Alarm example (Choose the right sampling
    sequence)
  • 1) SamplingP(B)lt0.001, 0.999gt suppose it is
    false, B0. Same for E0.
  • P(AB0, E0)lt0.001, 0.999gt suppose it is
    false...
  • 2) Frequency counting
  • In the samples right, P(JA0)P(J,A0)/P(A0)
    lt1/9, 8/9gt

23
Approximate Inference in BN (2/4)
  • Direct Sampling
  • We have seen it.
  • Rejection Sampling
  • Create samples like direct sampling, only
    count samples which is consistent with given
    evidences.
  • Likelihood weighting, ...
  • Sample variables and calculate evidence
    weight. Only create the samples which support the
    evidences.
  • Monte Carlo Markov Chain (MCMC)

24
Approximate Inference in BN (3/4)
  • Markov-Blanket
  • A variable is independent from others, given
    its parents, children and childrens parents.
    d-separation.
  • MCMC
  • Create a random sample. Every step, choose one
    variable and sample it by P(XMB(X)) based on
    previous sample.

MB(A)B, E, J, M MB(E)A, B
25
Approximate Inference in BN (4/4)
  • To calculate P(JB1,M1)
  • Choose (B1,E0,A1,M1,J1) as a start
  • Evidences are B1, M1, variables are A, E, J.
  • Choose next variable as A
  • Sample A by P(AMB(A))P(AB1, E0, M1, J1)
    suppose to be false.
  • (B1, E0, A0, M1, J1)
  • Choose next random variable as E ...

26
Complexity for Approximate Inference
  • Approximate inference problem is NP-hard.
  • It will never reach the exact probability
    distribution. But only close to the value.
  • Much better than exact inference when BN is big
    enough. In MCMC, only consider P(XMB(X)) but not
    the whole network.

27
A 448 nodes example
28
Reference Acknowledgements
  • Daphne Kollers BN Book.
  • Ruessell Norvig Artificial Intelligence A
    Modern Approach.
  • The slides of Foundation of AI in last semester.
  • Milos Hauskrecht Bayesian Belief Networks
    Inference
  • Kristian Kersting, guiding me through this
    seminar.
