Atomic Structure

1
Atomic Structure

• The Idea of the Atom

2
Early Models

• Greek philosophers 450 B.C. what is the
  smallest particle?
• Democritus - Particles are atomos
• An atom is the smallest particle of an element
  that retains the chemical identity of that
  element.

3
Aristotle Wins

• Greek society - slave based
• Beneath them to work with hands no experiments
• Settled disagreements by arguments
• Aristotle more famous than Democritus ?Aristotle
  wins
• Didnt believe or look into atoms until

4
Late 1700s

• Chemists believed elements
• couldnt be broken down by ordinary means
• Combine to form compounds
• Advancements in balances ? better experiments

5
Laws Discovered

• Law of Conservation of mass mass is neither
  created nor destroyed during chemical or physical
  changes
• Then discovered no matter where or how a compound
  is made it is made of fixed proportions of
  elements ? Law of Definite Proportions
• Ex Sodium Chloride, table salt, always has
  39.34 Na and 60.66 Cl by mass

6
Laws Discovered

• Elements combine to form more than one compound
  Ex carbon monoxide, CO, and carbon dioxide CO2

7
John Dalton

• 1808 DALTONS ATOMIC THEORY
• All matter is composed of small particles called
  atoms.
• All atoms of a given element are identical, but
  they differ from those of any other element.

8
Daltons Atomic Theory

• Atoms cannot be subdivided, created, or
  destroyed
• Atoms of different elements combine in whole-
  ratios to form compounds
• In a chemical reaction, atoms are combined,
  separated, or rearranged.

9
1800s The atom IS divisible

• Atom has two regions
• Nucleus center of atom
• Protons () charged
• Neutrons no charge
• Electron cloud region around nucleus containing
  electrons, (-) charged
• Subatomic particles p, no, and e-

10
J.J. Thomsons ExperimentCathode - Ray Tube

-
Moving electrical current (Cathode Ray) through
glass tube with inert gas (Noble Gas)
11
J.J. Thomsons Experiment

-

• By adding magnets, found the moving (-) particles

12
Thomsons Model

• Same properties no matter what element used
• All atoms had ELECTRONS!!
• Thomsons Model ?Plum pudding bunch of positive
  stuff, with the electrons able to be removed.

13
Ernest Rutherford - 1911

• Atoms have e- (-) charge
• Atoms are neutral ? need () to balance
• Must be other particles to account for mass of
  atom
• Rutherford used alpha particles to test.
• Alpha particle () charge, (2 p and 2 no)
• Experiment beam of high speed alpha particles
  into thin gold foil

14
Florescent Screen
Lead block
Uranium
Gold Foil
15
His prediction.
16
What he expected
17
What he happened
18
Results

• Most particles passed through
• 1 in 8000 bounced back
• Some particles completely reversed path!!!

19
Plum-pudding is WRONG!

• Atom is mostly empty
• Small dense, positive pieceat center,
  nucleus
• Alpha particlesare deflected by nucleus if
  they get close.

20
(No Transcript)
21
Electron Cloud Model

• Current model of atom
• Nucleus surrounded by negative cloud electron
  cloud

22
Size of Atom

• Atom size of football stadium
• Nucleus smaller than a dime in center
• Electron each one smaller than Roosevelts eye
  on the dime
• Atom is mostly empty space!

23
Composition of Atom

• Proton has () charge equal in magnitude to (-)
  charge of electron
• Atoms neutral ? p e-
• p and no about same mass
• e- 1836 times smaller than p
• Nucleus has majority of mass
• Nuclear Forces short-range forces that hold
  nucleus together
• p-p, p-no, no-no

24
Counting Atoms

• Atomic Number (Z) number of p of each atom of
  the element
• Identifies Elements!!

25
Atomic Number

• What is the atomic number for
• Hg
• What is the element with
• 20 p
• Neutral atoms ? p e-
• In neutral atoms, atomic number e-

26
Isotopes

• Def atoms of same element with different of no
  (different masses)
• 3 H isotopes
• Protium 1 p 99.9885
• Deuterium 1 p 1 no 0.0115
• Tritium 1 p 2 no

27
Mass Number

• Use mass number to determine isotopes
• Mass of p and n0
• Atom with 17 p and 20 no has mass of
• Chlorine-37 Hyphen Notation

28
Writing Isotopes

• Nuclear symbol

37
Mass number
Cl
Elemental symbol
17
Atomic number
29
Finding of Neutrons

• of neutrons mass - atomic
• How many p, no and e- are in
• Selenium 79
• 27Al
• Oxygen - 18

13
30
Isotopes

• Write the complete chemical/nuclear symbol for
  the isotope with 21 protons, 24 neutrons, and 21
  electrons.

31
Relative Mass of Atom

• Mass of Oxygen-16 2.656 x 10-23 g
• Use relative atomic masses
• Pick standard ? other masses are expressed in
  relation to standard
• Standard Carbon 12 atom

32
Carbon - 12

• Has mass of 12 atomic mass units (amu)
• 1 amu is exactly 1/12 the mass of a carbon-12
  atom
• Carbon-12 how many p and no?
• 1 p ? 1 amu (1.007276 amu)
• 1 no ? 1 amu (1.008665 amu)
• 1 e- ? 0 amu (0.005486 amu)

33
Carbon - 12

• What element is 4 x mass of Carbon 12?
• What element is 1/3 mass of Carbon 12?

34
Average Atomic Masses

• Most elements are mixture of isotopes
• Mass of element is average mass of isotopes
• We need the of each isotope
• Average Atomic Mass weighted average of the
  atomic masses of the naturally occurring isotopes
  of an element.

35
Weighted Average

• Box with 100 marbles of 2 sizes
• 25 have mass of 2.00g
• 75 have mass of 3.00g
• What is the average mass of a marble?
• 2.75g (sig figs!!)

36
Average Atomic Mass

• Or (atomic weight) found on periodic table (ROUND
  TO 2 DECIMAL PLACES!!)
• Average Atomic Mass
• ( Iso. 1)(Mass Iso.1) (Iso.2)(Mass
  Iso.2)
• 100

37
Average Atomic Mass

• Find the atomic mass of Li if
• 7.5 is Lithium 6 6.015 amu
• 92.5 is Lithium 7 7.016 amu

38
Example
39
The Mole
40
Groups

• 1 dozen
• 12
• 1 gross
• 144
• 1 ream of paper
• 500
• In chemistry 1 mole 6.022 x 1023

41
The Mole

• SI unit for amount of substance (mol)
• Def the number of particles in exactly 12 g of
  carbon 12.
• 12 g of carbon 12 has 6.022 x 1023 atoms
• Avogadros , after Amadeo Avogadro
• The number is HUGE!!

42
Molar Mass

• Def mass of 1 mole of a pure substance
• 1 mole Carbon 12 12 g
• 1 atom Carbon 12 12 amu
• Mass of 1 mole of He atoms?
• 4.00g/mol
• Same as atomic mass from periodic table,
  different units

43
Molar Mass

• Contains one mole of atoms
• So 4.00g He, 6.94 g Li and 200.59 g Hg all have
  6.022 x 1023 atoms!!!
• Molar mass (g/mol) is used as a conversion
  factor!!

44
Gram/Mole Conversions

• Mass, in g, of 3.6 mol of C?
• 43g
• How many moles are in 23.5 g S?
• 0.733 mol
• p. 85 problems

45
Conversions with Avogadros

• Diatomic Molecules elements that exist as 2-atom
  molecules in natural state
• 7 diatomic molecules
• H2, O2, N2, F2, Cl2, Br2, I2
• Remember!!! HONClBrIF

46
Conversions with Avogadros

• How many moles of oxygen are in 2.00x1022
  molecules of oxygen?
• How many atoms of sodium are in 3.80 mol of
  sodium?

47
Conversions with Avogadros

• How many molecules of hydrogen are in 0.020 g of
  hydrogen?
• Mass of 5.0x109 atoms of neon?
• p.86 problems
