Solar Cooking

1
Solar Cooking

• Matthew Stonecash

2
Overview

• Need Establishment
• Goal Objective
• Ideas
• Methodology
• Results Conclusion

3
Need

• In developing nations, electricity and gas for
  cooking are often unavailable.
• Water often needs to be boiled in order to kill
  pathogens.

4
Solar Oven in Nicaragua
5
Goal and Objective

• The goal of my study was to determine a method
  for modeling an oven with solar concentration.
• The objective was to get the oven hot enough to
  boil water.

6
Different Methods of Cooking

• Glass-covered Boxes, sometimes with Flat-Plate
  Reflectors to Increase Heat Gain.
• Parabolic Concentrators like those used for
  PV-these can reach very high temperatures.
  Drawbacks- must be aimed at the sun and
  temperature can reach dangerous levels.

7
Methodology Step One

• Find View factor what portion of the radiation
  from the reflector does the oven see?

8
Geometry
9
Step Two Energy Balance

• Find the Temperature inside the oven using an
  energy balance.

10
Results

• These Results Compare an Oven With a Reflector to
  an Oven With No Reflector in San Juan, Puerto
  Rico (18 degrees latitude)

11
At Noon in San Juan
12
At 900 am in San Juan
13
Improved Oven at 900
14
For 5 kg of Water at Noon
15
Conclusion

• Solar reflectors have a significant impact on the
  effectiveness of solar ovens, as does the hour of
  day at which one is attempting to use them.
• For improved performance, increasing the area of
  the reflector and adding insulation are
  recommended.
