1
Privacy Preserving Data Mining Lecture
2 Cryptographic Solutions
Benny Pinkas HP Labs, Israel
2
Secure two-party computation - definition
y
x
Input
F(x,y) and nothing else
Output
y
As if
x
F(x,y)
F(x,y)
3
Secure Function Evaluation

• A major topic of cryptographic research
• How to let n parties, P1,..,Pn compute a function
  F(x1,..,xn)
• Where input xi is known to party Pi
• Parties learn the final input and nothing else
• Caveat cryptographic definitions of secure
  computation are both too strong and too weak
• Too strong do not allow leakage of harmless
  information the price of this extra security is
  in efficiency.
• Too weak do not address leakage or misuse caused
  by the function itself (e.g., information implied
  by the outputs, or misbehavior in choosing an
  input).

4
Leak no other information

• A protocol is secure if it emulates the ideal
  solution
• Alice learns F(x,y), and therefore can compute
  everything that is implied by x, her prior
  knowledge of y, and F(x,y).
• Alice must not be able to compute anything else
• Simulation
• A protocol is considered secure if
• For every adversary in the real world
• There exists a simulator in the ideal world,
  which outputs an indistinguishable transcript
  , given access to the information that the
  adversary is allowed to learn in the ideal model.

5
Secure Function Evaluation

• Major Result Yao Any function that can be
  evaluated using polynomial resources can be
  securely evaluated using polynomial
  resources(under some cryptographic assumption)

6
SFE Building Block 1-out-of 2 Oblivious Transfer
Y0, Y1
j?0,1
Bob
Alice

• 1-out-of-2 OT can be based on most public key
  systems
• There are implementations with two communication
  rounds

7
General Two party Computation

• Two party protocol
• Input
• Sender Function F (some representation)
• The senders input Y is already embedded in F
• Receiver X ??0,1?n
• Output
• Receiver F(x) and nothing else about F
• Sender nothing about x

8
Representations of F

• Boolean circuits Yao,GMW,
• Algebraic circuits BGW,
• Low deg polynomials BFKR
• Matrices product over a large field FKN,IK
• Randomizing polynomials IK
• Communication Complexity Protocol NN

9
Secure two-party computation of general functions
Yao

• First, represent the function F as a Boolean
  circuit C
• Its always possible
• Sometimes its easy (additions, comparisons)
• Sometimes the result is inefficient (e.g. for
  indirect addressing, e.g. Ax )
• Then, garble the circuit
• Finally, evaluate the garbled circuit

10
Garbling the circuit

• Bob constructs the circuit, and then garbles it.

W values will serve as cryptographic keys Wk0 ?
0 on wire k Wk1 ? 1 on wire k (Alice will learn
one string per wire, but not which bit it
corresponds to.)
11
Gate tables

• For every gate, every combination of input values
  is used as a key for encrypting the corresponding
  output
• Assume GAND. Bob constructs a table
• Encryption of wk0 using keys wi0,wJ0
  (AND(0,0)0)
• Encryption of wk0 using keys wi0,wJ1
  (AND(0,1)0)
• Encryption of wk0 using keys wi1,wJ0
  (AND(1,0)0)
• Encryption of wk1 using keys wi1,wJ1
  (AND(1,1)1)
• Result given wix,wJy, can compute wkG(x,y)

12
Secure computation

• Bob sends the table of gate G to Alice
• Given, e.g., wi0,wJ1, Alice computes wk0 by
  decrypting the corresponding entry in the table,
  but she does not know the actual values of the
  wires.

Encryption of wk0 using keys wi0,wJ0 Encryption
of wk0 using keys wi0,wJ1 Encryption of wk1 using
keys wi1,wJ1 Encryption of wk0 using keys wi1,wJ0
Permuted order
13
Secure computation

• Bob sends to Alice
• Tables encoding each circuit gate.
• Garbled values (ws) of his input values.
• Translation from garbled values of output wires
  to actual 0/1 values.
• If Alice gets garbled values (ws) of her input
  values, she can compute the output of the
  circuit, and nothing else.

14
Alices input

• For every wire i of Alices input
• The parties run an OT protocol
• Alices input is her input bit (s).
• Bobs input is wi0,wi1
• Alice learns wis
• The OTs for all input wires can be run in
  parallel.
• Afterwards Alice can compute the circuit by
  herself.

15
Secure computation the big picture

• Represent the function as a circuit C
• Bob sends to Alice 4C encryptions (e.g. 64C
  Bytes), 4 encryptions for every gate.
• Alice performs an OT for every input bit. (Can
  do, e.g. 100-1000 OTs per sec.)
• One round of communication.
• Efficient for medium size circuits!

16
Example

• The Millionaires problem comparing two N bit
  numbers
• Whats the overhead?

17
Applications

• Two parties. Two large data sets.
• Max?
• Mean?
• Median?
• Intersection?
• Decision Tree learning? ID3?

18
Fairplay a secure two-party computation
systemMalkhi, Nissan, P., Sella

• A a full fledged secure two-party computation
  system, implementing Yaos garbled circuit
  protocol.
• Goals
• Investigate whether two-party SFE is practical
• Actual measurements of overall computation
• Breakdown of computation into parts
• Computation versus communication?
• Test-bed for various optimizations

19
Fairplay

• The Compilation paradigm
• Programs written in SFDL, a high-level
  programming language
• Allows clear, formal, easily understandable
  definition and requirements by humans
• SHDL Low-level language describing Boolean
  circuits
• SFDL ? SHDL compiler and optimizer
• SHDL ? Java programs implementing Yaos protocol

20
Fairplay SFDL example

• program Millionaires
• type int Intlt20gt // 20-bit integer
• type AliceInput int
• type BobInput int
• type AliceOutput Boolean
• type BobOutput Boolean
• type Output struct AliceOutput alice,
  BobOutput bob
• type Input struct AliceInput alice,
  BobInput bob
• function Output output(Input input)
• output.alice input.alice gt input.bob
• output.bob input.bob gt input.alice

21
SFDL properties

• Conventional syntax (C/Pascal-like)
• Type system Boolean, integer, enumerated
• Program structure
• Declarations global constants, types
• Sequence of functions (no nesting C, no
  recursion)
• Function name is its return value Pascal
• Conditional execution and loops
• if-then, if-then-else statements, For-loop (loop
  boundaries should be known at compile time)
• Assignments and expressions
• constants, variables, array entries, structure
  items, function calls, operators (, -, logical,
  comparison), parenthesis

22
SHDL example

• 0 input //outputinput.bob0
• 1 input //outputinput.bob1
• 2 input //outputinput.bob2
• 3 input //outputinput.bob3
• 4 input //outputinput.alice0
• 5 input //outputinput.alice1
• 6 input //outputinput.alice2
• 7 input //outputinput.alice3
• 8 gate arity 2 table 1 0 0 0 inputs 4 5
• 9 gate arity 2 table 0 1 1 0 inputs 4 5

23
kth-ranked element (e.g. median)

• Inputs
• Alice SA Bob SB
• Large sets of unique items (?D).
• Output
• x ? SA ? SB s.t. x has k-1 elements smaller than
  it.
• The rank k
• Could depend on the size of input datasets.
• Median k (SA SB) / 2
• Motivation
• Basic statistical analysis of distributed data.
• E.g. histogram of salaries in CS departments
• The Problem Generic constructions using circuits
  Yao yield an overhead which is at least
  linear in k.

24
An (insecure) two-party median protocol
RA
LA
SA
mA
mA lt mB
SB
RB
LB
mB
LA lies below the median, RB lies above the
median. New median is same as original median.
Recursion ? Need log n rounds (assume each set
contains n2i items)
25
A Secure two-party median protocol
A deletes elements mA. B deletes elements gt
mB.
YES
A finds its median mA B finds its median mB
mA lt mB
A deletes elements gt mA. B deletes elements
mB.
NO
Secure comparison (e.g. a small circuit)
26
An example
B
A
mAgtmB
mAltmB
mAltmB
mAgtmB
Median found!!
mAltmB
27
Proof of security
median
B
A
mAgtmB
mAgtmB
mAltmB
mAltmB
mAltmB
mAltmB
mAgtmB
mAgtmB
mAltmB
mAltmB
28
Arbitrary input size, arbitrary k
SA
k
SB
Now, compute the median of two sets of size k.
Size should be a power of 2.
median of new inputs kth element of original
inputs
29
Hiding size of inputs

• Can search for kth element without revealing size
  of input sets.
• However, kn/2 (median) reveals input size.
• Solution Let S2i be a bound on input size.

Median of new datasets is same as median of
original datasets.
SA
SB
30
Privacy preserving data mining
P2
P1
Confidential database D1
Confidential database D2
Wish to mine D1 ? D2 without revealing more info

• Examples
• Medical databases protected by law
• Competing businesses
• Government agencies (privacy, need to know)

31
The classification problem
Goal based on available data design an algorithm
to classify new data
32
Classification using Decision Trees
33
Privacy Preserving ID3

• Scenario The inputs are private information of
  P1 and P2
• Main technical problem Comparing entropies while
  preserving privacy. (entropy ?x logx)
• Efficiency
• most computation done independently by parties.
• The overhead of cryptographic operations depends
  only on the size of the decision tree (not on the
  input size).
• Basic task compute x log x.
• x x1x2 e.g., total number of customers
  with (age gt 30) and (fraud yes)

34
Privacy Preserving ID3

• Computing x log x
• x x1 x2, known to P1 and P2 respectively
  (independently computed from databases).
• Might as well compute x lnx, or lnx.
• First run a protocol to compute random shares, y1
  y2 ln x
• ln x is Real. Crypto works over finite fields.
  Must do numerical analysis.

35
Cryptographic Tools

• Secure Function Evaluation (SFE) Yao
• Oblivious Polynomial Evaluation NP

A polynomial Q()
x
Input
Q(x) and nothing else
nothing
Output
Implementation Two passes, O(degree) (or O(
logF) ) exponentiations.
36
Computing random shares of lnx ln(x1x2)

• Use Taylor approximation for lnx
• x x1 x2 2 n (1?) -½ lt ? lt ½
• lnx ln(2 n (1?)) ln 2 n ln(1?)
• ? ln 2 n ?
  i1..k (-1) i-1 ? i / i
• ln 2 n T(?)

• T(?) is a polynomial of degree k. Error is
  exponentially small in k.
• We only know how to work over finite fields
• Compute clnx, where c compensates for fractions.
• Work in F, where F sufficiently large.

37
ln(x1x2) Protocol

• Step 1 of the protocol Find n, ?
• Apply Yaos protocol to the following small
  circuit
• Input x1 and x2
• Output (random shares)
• random a1 and a2 s.t. a1 a2 x-2 n ? 2 n
• random b1 and b2 s.t. b1 b2 ln 2 n
• Operation The protocol finds 2 n closest to
  x1x2, computes ?2 n x1x2- 2 n.
• x x1 x2 2 n ?2 n
• lnx ln(2 n (1?)) ln 2 n ln(1?)

38
ln(x1x2) Protocol (Cont.)

• Step 2 of the protocol
• Compute random shares of T(?) (Taylor approx.)

• P1 chooses a random w1? F and defines a
  polynomial Q(x), s.t. w1 Q(a2) T(?)
  (recall a1 a2 ?2 n)
• Namely, Q(x) T( (a1x)/2 n ) w1 .

• Run an oblivious poly evaluation in which P2
  computes
• w2 Q(a2) T(?) w1 .

• Now the parties have random w1 and w2 s.t.
• w1 w2 T(?) ? ln(1?)
• (b1 w1) (b2 w2) ? ln 2 n ln(1?) ln x

39
Computing x lnx

• Tool Multiply(c1,c2)
• Input c1, c2
• Output d1, d2 s.t. d1 d2 c1 c2
• How? OPE of Q(z) c1z -d1
• Actual task x lnx
• Input x1 x2 x, c1 c2 ln x
• Output x lnx (x1 x2 )(c1 c2)
• Run Multiply(x1 ,c2), Multiply (c1 ,x2)

40
The rest of the work..

• The parties compute shares of lnx
• Then they compute shares of xlnx
• Each party computes a share of the entropy by
  summing shares of x lnx (H(X) ? x lnx )
• A small circuit finds the attribute giving the
  minimal conditional entropy
• The attribute is assigned to the node
• The databases are divided according to the value
  of this attribute

41
Efficiency

• lnx protocol
• secure computation of a small circuit
• one oblivious polynomial evaluation

• ID3 for a database with
• 1,000,000 transactions
• 15 attributes
• 10 values per attribute
• 4 class values
• Communication per node takes seconds (T1)
• Computation per node takes minutes (P3)

42
Contributions

• Cryptographic protocols where the bulk of the
  operations is done independently.
• Data mining
• Rigorous model for secure data-mining.
• Efficient, secure protocol for specific problems
  (median, ID3).
• Cryptography
• Sub-linear complexity - secure computation for
  large data sets.
• Efficient protocols for complex known algorithms.
• Secure computation of logarithms (real function -
  numerical analysis).
• Drawbacks
• Privacy preserving solutions are less efficient
• Its hard to find efficient private solutions for
  all interesting functions
• Security against malicious parties

43
References

• Lecture notes and overview papers
• B. Pinkas, Cryptographic Techniques for
  Privacy-Preserving Data Mining, SIGKDD
  Explorations, January 2003. http//www.pinkas.net/
  PAPERS/sigkdd.pdf
• R. Cramer Introduction to Secure Computation,
  2000. http//homepages.cwi.nl/cramer/papers/CRAME
  R_revised.ps
• Ivan Damgård, Theory and practice of multiparty
  computation, 8th EWSCS, http//www.cs.ioc.ee/yik/s
  chools/win2003/damgard.php
• Research papers
• G. Aggarwal, N. Mishra and B. Pinkas, Secure
  Computation of the K'th-ranked Element, Eurocrypt
  '2004. http//www.pinkas.net/PAPERS/ANP04.pdf
• Y. Lindell and B. Pinkas, Privacy Preserving Data
  Mining, Journal of Cryptology, Vol. 15 No. 3,
  2002. http//www.pinkas.net/PAPERS/id3-final.pdf
