Title: BLACKBODY RADIATION: PLANCK


1
(No Transcript)
2
BLACKBODY RADIATION PLANCKS LAW
3
COLOR and SPECTRAL CLASS
  • The light emitted by stars consists of a mixture
    of all colors, but our eyes (and brain) perceive
    such light as being white or tinged with pastel
    color.
  • In fact, different stars have varying amounts of
    each color in their light this causes stars to
    have different colors.
  • Most people, however, have never noticed that
    stars come in a variety of colors.
  • When light from the Sun (or any other star) is
    passed through a prism, it is separated into its
    component colors -- a continuous spectrum.

4
When a beam of white light is passed through a
prism, it is broken up into a rainbow-like
spectrum.
5
COLOR and SPECTRAL CLASS
  • If the spectra of different stars are analyzed,
    it is found that the intensity of the various
    colors differs from star to star.
  • Relatively cool stars have their peak intensity
    in the red or orange part of the spectrum.
  • The hottest stars emit blue light most strongly.
  • In other words, the color (or wavelength, ?) of
    the maximum intensity depends upon the
    temperature of the star.
  • The star is not necessarily the color of the
    max-imum intensity in fact, there are no green
    stars.

6
  • Max
  • Karl
  • Ernst
  • Ludwig
  • Planck
  • 1858 - 1947

7
  • In the late 1890s, Wien and Rayleigh had
    unsuccessfully attempted to formulate an
    equation expressing the intensity of
    electromagnetic radiation as a function of
    wavelength and the temperature of the source.
  • In 1900, Planck derived the equation empirically.
  • By December of 1900, Planck had derived the
    equation from fundamental principles.

Max Planck 1858 - 1947
8
Plancks Law Intensity of Radiation vs. Wavelength
  • The intensity (I) of electromagnetic radiation at
    a given wavelength (?) is a complicated function
    of the wavelength and the temperature (T).

9
Plancks Law Intensity of Radiation vs. Wavelength
10
Plancks Law Radiation Intensity vs. Wavelength
at 3000oK (Note Peak in Infrared)
11
Plancks Law Radiation Intensity vs. Wavelength
at 6000oK (Note Peak in Visible)
12
Plancks Law Radiation Intensity vs. Wavelength
at 10000oK (Note Peak in Ultraviolet)
13
Plancks Law Actual Radiation Intensity vs.
Wavelength at 3000, 6000, and 10000oK
14
Plancks Law Intensity of Radiation vs.
Wavelength Normalized Intensity vs. Wavelength
15
Plancks Law Normalized Intensity vs.
Wavelength at 3000, 6000, and 10000 oK
16
Plancks Law Normalized Radiation Intensity vs.
Wavelength at Various Temperatures
17
Plancks Law Normalized Radiation Intensity vs.
Wavelength at Various Temperatures
18
Stefan-Boltzmann Law
ET ? T4 where ET total energy radiated per
unit area over all wavelengths, and ? 5.67051
? 10-12 J / cm2 s ?K4
ET
19
  • Wilhelm
  • Carl
  • Werner
  • Otto
  • Fritz
  • Franz
  • Wien
  • 1864 - 1928

20
  • In 1896, Wilhelm Wien unsuccessfully attempted to
    derive what is now known as Plancks Law.
  • However, he did notice a relationship between the
    temperature of a glowing object and the
    wavelength of its maximum intensity of emission.
  • The result of his investigation is now known as
    Wiens Displacement Law.

Wilhelm Wien 1864 - 1928
21
  • Wiens
  • Displacement
  • Law
  • The peak of the emission spectrum of a glowing
    object is a function of its temperature. The
    hotter the object, the shorter the peak
    wavelength.

22
Wiens Displacement Law
  • Gives lmax as f(T), which allows us to calculate
    the temperature of a star if we know the
    wavelength of its maximum emission, which is easy
    to measure from its spectrum.
  • From Plancks Law, take dI/dl, set 0.
  • Then, lmax?T 2.8979 ? 106 nm??K.
  • Example lmax for the Sun 502 nm.
  • Therefore, T 5770?K 5500?C.

23
The three types of Spectra Continuous, Emission
Line, and Absorption Line
24
  • Sodium Absorption Lines
  • The sodium vapor subtracts out the yellow lines
    from the continuous spectrum emitted by the
    source.

25
  • As an excited hydrogen atom returns to its ground
    state, it emits the extra energy in the form of a
    photon with a certain wavelength.

26
  • Each energy transition within an atom gives rise
    to a photon of a particular wavelength.

27
  • Solar Spectrum
  • (Original Drawings by Fraunhofer)

28
  • Absorption lines in a stars spectrum reveal the
    presence of elements and compounds.

29
Continuous Spectrum
Absorption Spectrum of the Sun
Bright-line Spectrum of Sodium
Bright-line Spectrum of Hydrogen
Bright-line Spectrum of Calcium
Bright-line Spectrum of Mercury
Bright-line Spectrum of Neon
30
  • The Inverse Square Law When light from a
    point source travels twice as far, it covers four
    times the area, and is therefore only one fourth
    as bright.

31
T H E E N D
32
(No Transcript)
