Crystal Geometry

1
Classification of lattice The Seven Crystal
System And The Fourteen Bravais Lattices
2
7 crystal Systems
System Unit Cell Shape 1. Cubic abc,
???90?
3
7 crystal Systems
System Unit Cell Shape 2. Tetragonal ab?c,
???90?
4
7 crystal Systems
System Unit Cell Shape 3 Orthorhombic a?b?c,
???90?
5
7 crystal Systems
System Unit Cell Shape 4. Hexagonal ab?c,
?? 90?, ?120? 5. Rhombohedral abc,
????90? 6. Monoclinic a?b?c, ??90??? 7.
Triclinic a?b?c, ?????
6
14 Bravais lattices divided into seven crystal
systems

• Crystal system Bravais lattices
• Cubic P I F

Simple cubicPrimitive cubicCubic P
Body-centred cubicCubic I
Face-centred cubicCubic F
7
14 Bravais lattices divided into seven crystal
systems

• Crystal system Bravais lattices
• Cubic P I F
• Tetragonal P I
• Orthorhombic P I F C
• Hexagonal P
• Trigonal P
• Monoclinic P C
• Triclinic P

8
Orthorhombic CEnd-centred orthorhombicBase-centr
ed orthorhombic
9
14 Bravais lattices divided into seven crystal
systems

• Crystal system Bravais lattices
• Cubic P I F
• Tetragonal P I
• Orthorhombic P I F C
• Hexagonal P
• Trigonal P
• Monoclinic P C
• Triclinic P

10
End-centred cubic not in the Bravais list ?
End-centred cubic Simple Tetragonal
11
14 Bravais lattices divided into seven crystal
systems

• Crystal system Bravais lattices
• Cubic P I F C
• Tetragonal P I
• Orthorhombic P I F C
• Hexagonal P
• Trigonal P
• Monoclinic P C
• Triclinic P

12
Face-centred cubic in the Bravais list ?
Problem 3.1
Cubic F Tetragonal I
13
14 Bravais lattices divided into seven crystal
systems

• Crystal system Bravais lattices
• Cubic P I F C
• Tetragonal P I
• Orthorhombic P I F C
• Hexagonal P
• Trigonal P
• Monoclinic P C
• Triclinic P

14
(No Transcript)
15
What is the basis for classification of lattices
into 7 crystal systems and 14 Bravais lattices?
16
Lattices are classified on the basis of their
symmetry
17
What is symmetry?
18
Symmetry
If an object is brought into self-coincidence
after some operation it said to possess symmetry
with respect to that operation.
19
Rotational symmetry
A rectangle comes into self-coincidence by 180
degrees rotation
20
Rotation Axis
If an object come into self-coincidence through
smallest non-zero rotation angle of ? then it is
said to have an n-fold rotation axis where
?180?
2-fold rotation axis
n2
?90?
n4
4-fold rotation axis
21
Reflection (or mirror symmetry)
22
Translational symmetry
Lattices also have translational symmetry
23
Symmetry of lattices
Lattices have
Translational symmetry
Rotational symmetry
Reflection symmetry
24
Symmetry classification of lattices

• Based on rotational and reflection symmetry
  alone ? 7 types of lattices
• ? 7 crystal systems

Based on complete symmetry, i.e., rotational,
reflection and translational symmetry ? 14
types of lattices ? 14 Bravais lattices
25
7 crystal Systems

• System Required symmetry
• Cubic Three 4-fold axis
• Tetragonal one 4-fold axis
• Orthorhombic three 2-fold axis
• Hexagonal one 6-fold axis
• Rhombohedral one 3-fold axis
• Monoclinic one 2-fold axis
• Triclinic none

26
Tetragonal symmetry
Cubic symmetry
Cubic C Tetragonal P
Cubic F ? Tetragonal I
27
The three Bravais lattices in the cubic crystal
system have the same rotational symmetry but
different translational symmetry.
Simple cubicPrimitive cubicCubic P
Body-centred cubicCubic I
Face-centred cubicCubic F
28
Symmetry classification of lattices

• Based on rotational and reflection symmetry
  alone ? 7 types of lattices
• ? 7 crystal systems

Based on complete symmetry, i.e., rotational,
reflection and translational symmetry ? 14
types of lattices ? 14 Bravais lattices
29
Notation P Primitive (lattice points only at
the corners of the unit cell) I Body-centred
(lattice points at the corners one lattice
point at the centre of the unit cell) F
Face-centred (lattice points at the corners
lattice points at centres of all faces of the
unit cell) C End-centred or base-centred
(lattice points at the corners two lattice
points at the centres of a pair of opposite
faces)
