Title: Configuration Management


1
Configuration Management
  • By Guy Davis,
  • Stephane Saleh and Kejin Huang

2
Abstract
  • The concept (Kejin)
  • Basic principles (Guy)
  • SCM Automation and Tools (Stephane)
  • SCM in the Future (Stephane)
  • Tools comparison (Kejin)

3
Introduction
  • Configuration Management(CM) is a
  • documentation system for tracking the
  • work.

4
History
  • 1980, Bersoff, E. H., Henderson, V.D., and
    Siegel, S. G. Software Configuration Management.
    Prentice-Hall.
  • 1984, The British Standard BS 6488
  • 1987, IEEE Guide to Software Configuration
    Management 1987. IEEE/ANSI Standard 1042-1987.
  • 1987, U. S. Department of Defense. DoD 2167a
    Standard 1987. DoD.

5
Why SCM is needed
  • The project body
  • The project may be big. When a change is made in
    a shared component, the user may not be notified.
    (The change may be a bug fix or an improvement.)
  • The time
  • The development progress steps may last long.
    When the versions become a tree, the bugs could
    appear or disappear in different nodes.
  • The people
  • A lot of people may be involved. A simultaneous
    update may destroy the others work.

6
The goal (why)
  • To have change activity converge
  • Controlling ad-hoc change creates a stable
    software development environment
  • Control of change is a major part of baseline
    management
  • SCM co-ordinates access to change of the software
    work products which is particularly important
    when there is more than one individual work on a
    software work product

7
Concept
  • Configuration management involves the collection
    and maintenance of data concerning the hardware
    and software of computer systems that are being
    used. SIMON DENNIS - Ref 1
  • CM embodies a set of techniques used to help
    define, communicate and control the evolution of
    a product or system through its concept,
    development, implementation and maintenance
    phases. SWEETMAN - Ref 2
  • CM, a key concept in the Information Age, is a
    set of systematic controls to keep information up
    to date and accurate. MORRIS - Ref 3

8
Concept (contd)
  • A discipline applying technical and
    administrative direction and surveillance to.
    (IEEE)
  • A collection of hardware, software, and/or
    firmware, which satisfies an end-use function and
    is designated for configuration management." (ISO)

9
What is not
  • Just version management
  • Just change management
  • Just a build-and-release tool
  • An administration tool

10
The Scope
11
Principles of SCM
  • Configuration Identification
  • Baselines
  • Change Control
  • Configuration Status Accounting
  • Configuration Audits and Reviews
  • SCM metrics

12
Configuration Identification
  • SCM Planning document
  • Objectives, responsibilities, and methods
  • Identify configuration items
  • Independent components of the system
  • Logical configuration hierarchy
  • Object-based view
  • Directory-based view

13
Baselines
  • Complete status of a CI at a given time
  • Know quality and functionality
  • Unchangeable and able to recreate

Mozilla SCM Roadmap
14
Change Control
  • Control change between baselines
  • Various levels of control
  • Open policy (no control, just tracking)
  • Informal code review by module owner
  • Change Control Board (CCB)
  • Tailor level to organization and project

15
Configuration Status Accounting
  • Monitor status of CIs and change requests
  • Complete listing of all changes since last
    baseline (including who, what, when)
  • Ideally changes should be traceable to rationale
  • Allows tracking of progress to next baseline
  • Allows for previous releases/versions to be
    extracted for testing

16
Configuration Audits and Reviews
  • Validation of completeness and consistency
  • SCM audits occur during project transitions
  • Requirements, design, implementation, test,
  • Ensures that SCM plan is being followed
  • Useful to review SCM metrics gathered
  • Feedback allows process improvement

17
Implementation Issues
  • Requires champions, sponsors, agents
  • Requires planning (SCMP)
  • Requires training and documentation
  • Requires maintenance
  • Can be measured and improved

18
SCM Automation
  • Why Automation?
  • Difficult to manage developments
  • by large teams operating at different
  • remote sites
  • Projects are becoming bigger and more complex

19
SCM Automation (contd)
(A. Brown, S. Dart, P. Feiler, K. Wallnau, 1991)
20
SCM Automation (contd)
  • Components Concepts
  • Component concepts help identify and access
    components of a software product.
  • Requirements covered version control,
    configuration, repository, etc.
  • Example of tools or systems Revision Control
    System (RCS), Sherpa Design Management System
    (DMS)

21
SCM Automation (contd)
  • Structure and Construction Concepts
  • Concepts that deal with capturing changes to a
    component and its structure.
  • Requirements covered building, optimizing ,
    recording information to allow regeneration of
    components, etc.
  • Example of tools or systems Aide-De-Camp (ADC),
    Jasmine system model, Rational

22
SCM Automation (contd)
  • Team Concepts
  • Concepts that help with the co-ordination and
    synchronization of software engineering teams
    working on a project.
  • Requirements covered work areas for
  • isolating work, synchronizing, concurrent
    work
  • Example of tools or systems Shape, Software
    Management System (SMS), Network Software
    Environment (NSE)

23
SCM Automation (contd)
  • Process Concepts
  • Concepts that are related to process
    functionalities.
  • Requirements covered lifecycle support, task
    management, communication and automatically
    recording information.
  • Example of tools or systems PowerFrame, ISTAR,
    LIFESPAN, Change and Configuration Control (CCC)

24
Tool Class 1
  • Code or Developer oriented CM tools only
  • supply the code management, version
  • control, including check-in, check-out,
  • merge, etc.

25
Tool Class 2
  • Process oriented CM tools also supply management
    for software development activities. It may
    cover
  • Version Control
  • Change Control
  • Product Management
  • Problem Tracking
  • Activity Tracking
  • Build Management
  • Document Management
  • Requirements Tracking.

26
SCM Challenges
  • Technological Issues
  • Process-Oriented Issues
  • Managerial Issues
  • Political Issues
  • Standardization Issues

27
SCM Challenges (contd)
  • Technological Issues
  • Switching CM Capabilities
  • Interoperability between CM
  • Global Perspective on CM
  • Repositories
  • Distributed CM
  • Perfective Maintenance Support

28
SCM Challenges (contd)
  • Process-oriented Issues
  • Political Issues
  • Standardization Issues

29
Q / A
30
Tool Index (contd)
  • FtpVC http//www.nisnevich.com/ftpvc/ftpvc.htm
    .
  • PERFORCE http//www.perforce.com/
  • PVCS http//www.merant.com/
  • QEF http//www.qef.com/
  • QVCS http//www.qumasoft.com/.
  • RAZOR http//www.razor.visible.com/
  • SABLIME http//www.bell-labs.com/project/sabli
    me
  • Software Manager (MKS) http//www.verticalsky.com/
    solutions/
  • Source Code Manager http//www.unipress.com/fre
    e_evals/
  • StarTeam http//www.starbase.com/.
  • TeamConnection (IBM) http//www.software.ibm.co
    m/ad/teamcon/
  • TLIB http//www.burtonsys.com/.
  • CVS
    http//www.cvshome.org/

31
Comparison
32
Comparison (contd)
33
Comparison (contd)
34
Comparison (contd)
35
Comparison (contd)
36
Comparison (contd)

37
References
  • A. Brown, S. Dart, P. Feiler, K. Wallnau. The
    State of Automated Configuration Management,
    Software Engineering Institute. Carnegie Mellon
    University. 1991.
  • http//www.sei.cmu.edu/legacy/scm/abstracts/absat
    r_cm_state.html
  • Berlack, R.H. Evaluation Selection of Automated
    Configuration Management Tools. 1995.
    http//www.stsc.hill.af.mil/crosstalk/1995/nov/eva
    luati.asp
  • Dart, Susan. Concepts in Configuration
    Management. Software Engineering Institute.
    Carnegie Mellon University. 1991.
    http//www.sei.cmu.edu/legacy/scm/abstracts/abscm_
    concepts.html
  • Eich, Brendan. Mozilla Tree Management Roadmap.
    Mozilla Organization. 2002. http//www.mozilla.org
    /roadmap.html
  • Humphrey, Watts S. Managing the Software Process.
    Addison-Wesley Publishing Company. Reading,
    Massachusetts. 1990
  • Kelly, Marion. Configuration Management The
    Changing Image McGraw-Hill U.K., 1996.
  • Menks, D. Software Configuration Management.
    University Of Calgary. 2001.
  • http//www.ucalgary.ca/dbmenks/seng/seng621
    /scm.html
