BioPortalDisease and Bioagent Information
Sharing, Surveillance, Analysis, and Visualization

• Research Team
• University of Arizona
• University of California, Davis
• Kansas State University
• Arizona Department of Public Health
• University of Utah
• New York State Department of Health/HRI
• California Department of Health Services/PHFE
• U.S. Geological Survey
• The SIMI Group
• Acknowledgements NSF, ITIC, DHS, DOD/AFMIC,
  IDIWC, AZDPS

2
Research Partners and Supports

• University of Arizona
• University of California, Davis
• Kansas State University
• University of Utah
• Arizona Department of Public Health
• New York State Department of Health/HRI
• California Department of Health Services/PHFE
• U.S. Geological Survey
• The SIMI Group

• NSF
• CIA/ITIC
• DHS
• DOD/AFMIC
• CDC
• AZDPS

3
UA Team Members

• Dr. Hsinchun Chen
• Dr. Daniel Zeng
• Lu Tseng
• Cathy Larson
• Kira Joslin
• Wei Chang
• James Ma
• Hsinmin Lu
• Ping Yan
• Aaron Sun

• Keith Alcock
• Sapna Brahmanandam
• Milind Chabbi
• Yuan Wang

4
Outline

• Project Background
• BioPortal V1.0 Achievements
• System Architecture
• System Functionalities
• BioPortal Collaboration Framework
• New Developments
• International Foot-and-mouth Disease Monitoring
• Syndromic Surveillance
• Livestock Health Surveillance

5
BioPortal Background
Acknowledgment NSF, ITIC, NYSDH, CDHS,
USGS (Drs. Kvach and Ascher)
6
Background (I)

• In September, 2002, representatives of 18
  different agencies, including DOD, DOE, DOJ, DHS,
  NIH/NLM, CDC, CIA, NSF, and NASA, were convened
  to discuss disease surveillance.
• An interagency working group called Disease
  Informatics Senior Coordinating Committee (DISCC)
  was established.
• DISCC established an Infectious Disease
  Informatics Working Committee (IDIWC) to survey
  the field and identify gaps.
• IDIWC developed requirements for a National
  Infectious Disease Informatics Infrastructure
  (NIDII).

7
Background (II)

• In June, 2003, IDIWC was charged with the task of
  developing one or more rapid prototype systems to
  demonstrate interoperability and innovation
  across species and jurisdictions.
• Botulism and West Nile virus were selected as
  diseases.
• States of New York and California were selected
  as partners.
• The University of Arizona was chosen as
  integrator and was provided with a supplement to
  an existing NSF grant.

8
BioPortal Project Goals

• Demonstrate and assess the technical feasibility
  and scalability of an infectious disease
  information sharing (across species and
  jurisdictions), alerting, and analysis framework.
• Develop and assess advanced data mining and
  visualization techniques for infectious disease
  data analysis and predictive modeling.
• Identify important technical and policy-related
  challenges in developing a national infectious
  disease information infrastructure.

9
BioPortal V1.0 Accomplishments

• Prototype system design and development
• Initial design and implementation of
  interoperable messaging backbones
• Live prototype systems
• Preliminary user evaluation
• Information sharing
• Data sharing agreements/memoranda of
  understanding (MOUs) developed
• Many disease datasets integrated into the portal
• Analysis and visualization
• Hotspot analysis research
• Spatial-Temporal Visualizer (STV)

10
Information Sharing Infrastructure Design
Portal Data Store (MS SQL 2000)
Data Ingest Control Module Cleansing /
Normalization
Info-Sharing Infrastructure
Adaptor
Adaptor
Adaptor
SSL/RSA
SSL/RSA
XML/HL7 Network
PHINMS Network
New
NYSDOH
CADHS
11
Data Access Infrastructure Design
12
BioPortal Collaboration Framework

• A Memorandum of Understanding (MOU) is used to
  document the relationship between parties that
  will be sharing data
• Who the entities are and how they will act
  independently and cooperatively
• What the mutual interests, benefits, and purposes
  of sharing data are
• How each party will maintain control over and
  share their resources, and what each party shall
  provide to the other (e.g., system accounts,
  portal access)
• Which types of data are to be shared (e.g., dead
  bird surveillance)

13
Summary of MOU

• Confidentiality
• Data is not to be shared outside of the project.
• Data is to be returned or destroyed after 5
  years.
• Ownership
• Original data is owned by providers.
• Data analysis is jointly owned.
• Scope
• Specific diseases are listed.
• Additional diseases can be added.
• Parties agree separately on which data elements
  can be shared (e.g., species, gender, etc.)
• Purpose
• Data may be used for system development, for
  example.

14
Datasets Integrated WNV, BOT
15
Communications/Messaging

• Scalable, flexible, light-weight, and extendible.
  Easy to include
• New diseases
• New jurisdictions
• New techniques!
• Messaging infrastructure installed and tested
• NYSDOH-UA PHIN MS
• CADHS-UA Regional message broker
• NWHC-UA PHIN MS
• XML generation/conversion
• NY_DeadBird, NY_Alerts, NY_BotHuman, NY_WNVHuman,
  NY_CaptiveAnimal, NY_Mosquito
• CA_BotHuman, CA_WNVHuman, CA_DeadBird,
  CA_Chicken, CA_Mosquito
• USGS_Epizoo

16
BioPortal Research Framework

• BioPortal Demo Develop the system for
  demonstration purposes using scrubbed data.
  Refine system functionality and performance based
  on user feedback.
• BioPortal Operation Develop the system for
  production mode with real data and real users.
• BioPortal Research Continue to develop
  advanced technologies and practical sharing
  policies. Expand to new diseases and
  jurisdictions.

17
BioPortal Prototype Systems
18
Spatio-Temporal Data Mining Hotspot Analysis

• A hotspot is a condition indicating some form of
  clustering in a spatial and temporal distribution
  (Rogerson Sun 2001 Theophilides et al. 2003
  Patil Tailie 2004).
• For WNV, localized clusters of dead birds
  typically identify high-risk disease areas
  (Gotham et al. 2001).
• Automatic detection of dead bird clusters using
  hotspot analysis can help predict disease
  outbreaks and aid in effective allocation of
  prevention/control resources.

19
Existing Hotspot Analysis Approach SaTScan

• The spatial scan statistical techniques
  implemented in SaTScan are widely used to detect
  and evaluate disease outbreaks (Kulldorff 2001).
• NYSDOH has used SaTScan to develop an early
  warning system for WNV (Gotham et al. 2001).
• An important factor considered by spatial scan
  statistical analysis is the baseline.
• The significance of the density of dead birds
  depends on the historical distribution of bird
  deaths, human population, and so on.

20
Other Hotspot Analysis Approaches CrimeStat and
RSVC

• Hotspot analysis techniques applied to crime
  analysis CrimeStat (Levine 2002).
• CrimeStats Risk-Adjusted Nearest Neighbor
  Hierarchical Clustering (RNNH) Uses a kernel
  density estimation obtained from baseline data to
  adjust the threshold that controls whether data
  points can be grouped together.
• Risk-Adjusted Support Vector Machine Clustering
  (RSVC) It combines the power and flexibility of
  support vector machine-based clustering and the
  risk adjustment idea of RNNH.

21
Case Study (NY WNV)

• On May 26, 2002, the first dead bird with WNV was
  found in NY
• Based on NYs test dataset

140 records
224 records
March 5
May 26
July 2
new cases
baseline
22
(No Transcript)
23
Dead Bird Hotspots Identified
24
Hotspot Analysis Findings

• RSVC delivers similar recall levels and higher
  precision than SaTScan.
• RNNH matches RSVC precision, but has very low
  recall.
• RSVC significantly outperforms other methods in
  the F-measure.
• Techniques could be complementary for different
  hotspot analysis tasks.

25
Spatial-Temporal Visualization

• Integrates four visualization techniques
• GIS View
• Periodic Pattern View
• Timeline View
• Central Time Slider
• Visualizes the events in multiple dimensions to
  identify hidden patterns
• Spatial
• Temporal
• Hotspot analysis
• Phylogenetic (planned)

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
BioPortal HotSpot Analysis RSVC, SaTScan, and
CrimeStat Integrated (first visual, real-time
hotspot analysis system for disease surveillance)

• West Nile virus in California

30
Hotspot Analysis-Enabled STV
31
BioPortal New Developments

• NSF Infectious Disease Informatics Grant (2004-9)
• International Foot-and-Mouth Disease BioPortal
  (2005-6) FMD Lab, UC Davis
• Human Syndromic Surveillance System Arizona
  State Department of Health (2005-6)
• Livestock Syndromic Surveillance System Kansas
  State University RSVP-A (2005-6)

32
New Research Directions

• Analytical Algorithms
• Prospective hotspot analysis auto baseline
  discovery
• Spatial-Temporal correlation analysis
• Dynamic Network Analysis
• Visualization
• International FMD news visualization
• Phylogenetic Spatial-Temporal visualization
• Syndromic Surveillance
• Syndromic surveillance system survey
• Emergency room chief complaint syndromic
  classification
• Livestock syndromic surveillance

33
Extended BioPortal Research Framework

• BioPortal Demo
• BioPortal Operation
• BioPortal Research
• FMD BioPortal A dedicated instance of
  BioPortal customized for International
  Foot-and-Mouth disease monitoring. Additional
  functionalities such as gene sequence analysis
  and FMD News are added
• BioPortal Syndromic Surveillance A specialized
  BioPortal instance that processes chief
  complainants using a hybrid method of ontology
  and knowledge rules
• BioPortal Livestock A BioPortal instance
  devoted in Livestock syndromic surveillance case
  management and data analysis

34
International FMD BioPortal
Acknowledgment DHS, DOD, UC Davis (Drs. Thurmond
and Lynch)
35
Introduction

• Foot-and-mouth disease (FMD) is the top disease
  on the Office International des Epizooties (OIE)
  List A, which can infect all cloven-hoofed
  animals.
• FMD is the most contagious infectious diseases of
  livestock animals
• Massive shedding of virus and contamination of
  the environment.
• Transmitted by direct or indirect contact
  (droplets), animate vectors (humans), inanimate
  vectors (vehicles
• Serologically diverse with seven distinct types
  (A, O, C, SAT1, SAT2, SAT3, Asia1), which makes
  diagnosis and vaccination problematic, and
  genetic diversity likely.
• Endemic in Africa, Asia, Middle East and South
  America
• Potential cost for U.S. outbreaks gt10 billion
• Broader economic impact trade and travel
  restrictions.

36
FMD Information Model
37
International FMD BioPortal Goals

• Real-time, web-based situational awareness of FMD
  outbreaks worldwide through the establishment of
  an international information sharing and analysis
  system
• FMDv characterization at the genomic level
  integrated with associated epidemiological
  information and modeling tools to forecast
  national, regional, and/or international spread
  and the prospect of import into the U.S. and the
  rest of North America
• Web-based crisis management of resourcesfacilitie
  s, personnel, diagnostics, and therapeutics

38
Research Plans

• Global FMD epidemiological data
• (Near) real-time data collection
• Web-based information sharing and analysis
• International FMD news
• Indexed collection of global FMD news
• Search and visualization of the FMD news via the
  web
• FMD genetic/sequence data
• Predictive model using phylogenetic, spatial, and
  temporal information to stop FMD at the boarder
• Visualization for FMD event in time, space, and
  genetic space

39
Preliminary Global FMD Dataset

• Provider UC Davis FMD Lab
• Information sources reference labs and OIE
• Coverage 28 countries globally
• Time span May, 1905 March, 2005
• Dataset size 30,000 records of which 6789
  records are complete
• Host species Cattle, Caprine, Ovine, Bovine,
  Swine, NK, Elephant, Buffalo, Sheep, Camelidae,
  Goat

40
Global FMD Coverage in BioPortal
41
FMD Migration Visualization using BioPortal
(cases in South Asia)
FMD Cases travel back and forth between countries
42
International FMD News

• Provider UC Davis FMD Lab
• Information sources Google, Yahoo, and open
  Internet sources
• Time span Oct 4, 2004 present (real-time
  messaging under development)
• Data size 460 events (6/21/05)
• Coverage 51 countries
• (Africa11, Asia16,
• Europe12, Americas12)

43
Searching FMD News

• http//fmd.ucdavis.edu/
• Searchable by
• Date range
• Country
• Keyword

44
Visualizing FMD News on BioPortal
45
FMD Genetic Information Analysis

• Genome clustering analysis
• Phylogenetic clustering
• Spatial clustering
• Temporal clustering
• Hotspot detection among gene sequences
• Create a tree structure based on semantic
  distance between gene sequences.
• Automatically detect the dense portion of the
  tree.
• Identify the connection between the semantic
  cluster and the geographic pattern of gene
  sequences.

46
FMD Genetic Visualization

• Goal Extend STV to incorporate 3rd dimension,
  phylogenetic distance
• Include a phylogenetic tree.
• Identify phylogenetic groups and color-code the
  isolate points on the map.
• Leverage available NCBI tools such as BLAST.
• Proof of concept SAT 2 3 analysis
• Data 54 partial DNA sequence records in South
  Africa received from UC Davis FMD Lab
  (Bastos,A.D. et al. 2000, 2003)
• Date range 1978-1998
• Countries covered South Africa, Zimbabwe,
  Zambia, Namibia, Botswana

47
Sample FMD Sequence Records
Color-coded View (MEGA3)
Textual View of Gene Sequence
48
Phylogenetic Trees
49
Interactive Phylogenetic Tree
Color coding shows similarity of sequences
User-adjustable grouping threshold to change
clusters
50
Phylogenetic Treeof Sample FMD Data
Identify 6 groups within 2 major families (MEGA3
based on sequence similarity)
Group6
Group1
Group2
Group5
Group4
Group3
51
Genetic, Spatial, and Temporal Visualization of
FMD Data
Phylogenetic tree color coded
Isolates locations color coded
Isolates appearances in time
52
FMD Time Sequence Analysis
First family cases appeared throughout the period
2nd family cases exist before 1993 and a comeback
lately
Second family cases existed before 1993 and
reappeared later after 1997
53
FMD Periodic Pattern Analysis
2nd family concentrated in Feb. while 1st family
spread evenly
54
Locations of Family 1 records
Selected only groups 1, 2, and 3 and found a
spatial cluster
55
Locations of Family 2 records
Sparse isolate locations
Selected only groups 4, 5, and 6
56
Syndromic Surveillance

• What is syndrome?
• Syndrome is a group of symptoms which shows
  possibility of a certain disease
• What is syndromic surveillance?
• The term syndromic surveillance applies to
  surveillance using health-related data that
  precede diagnosis and signal a sufficient
  probability of a case or an outbreak to warrant
  further public health response.
• Why use syndromic surveillance?
• Traditional disease surveillance systems mainly
  rely on physicians to report reportable
  diseases occurrences. This process is too
  lengthy and does not leave enough response time.

57
Syndromic Surveillance System Survey
58
Syndromic SurveillanceData Sources
59
Syndrome Classification

• To tag emergency room chief complaints with
  syndrome label
• EX coughing with high fever gt upper
  respiratory
• Challenges
• Free text no standard language. Ex chst pn,
  CP, c/p, chest pai, chert pain, chest/abd pain,
  chest discomfort all mean chest pain
• Very short usually no more than 3 words
• Multiple languages
• Existing approaches
• Rule-based classification (EARS)
• Bayesian Net classification (RODS)

60
Proposed Syndrome Classification
Symptom Groups
CC Cleansing
EMT-P
Chief Complaints
UMLS hierarchy
UMLS concepts
Rule processing engine (defined by public health
officers)
fever
Upper Respiratory Syndrome
cough
If Fever and (cold or cough) -gtthen upper
respiratory
UMLS Unified Medical Language System
61
Kansas RSVP-A System
62
Rapid Syndrome Validation Project Animal
(RSVP-A) System

• URL http//clh.vet.ksu.edu
• Main function allows vets to enter syndromic
  observations and retrieve statistics bar charts
• A complete system with administrative functions
  such as profile editing
• Provides 2 web-based interfaces
• Regular browser
• Mobile devices (WAP)
• Current users 17 vets in 29 counties
• Projected users 200 (Kansas), 10K (nationwide)

63
BioPortal Integration Livestock
64
Data Characteristics

• Time Period
• 7/16 2003 10/17 2005
• Cross 2 states/29 counties in Kansas and New
  Mexico

65
Imported Attributes

• RSVP-A monitors 6 syndromes
• Non-neonatal diarrhea,
• Neurologic / recumbant
• Unexpected deaths
• Weight loss/feed refusal
• Abortion/birth defect
• Erosive lesions

66
Records
67
STV Map View

• Geocoded at county level

68
Seasonal Effect

• Tuesdays and Fridays have high volumes

• Dec and Jan have higher volume

69
BioPortal Surveillance Future Work

• Complete systems comparison and user evaluation
• Multi-lingual chief complaints tagging and
  analysis
• Establish real-time data messaging
• Integrate potential new datasets
• Plant disease surveillance in Great Plains
• Hanta virus in South America

70
BioPortal Future Work

• Complete open source, generic BioPortal
  architecture and system
• Develop multi-lingual BioPortal
• Incorporate other diseases, e.g., avian
  influenza, SARS
• Solicit partners and expand test sites
• Continue infectious disease informatics research

71
For more informationBioPortal web site
http//www.bioportal.orgAI Lab web site
http//ai.arizona.eduhchen_at_eller.arizona.edu
