Hoard: A Scalable Memory Allocator for Multithreaded Applications

1
Hoard A Scalable Memory Allocator for
Multithreaded Applications
Emery Berger, Kathryn McKinley, Robert Blumofe,
Paul Wilson
Department of Computer Sciences
Department of Computer Science
2
Motivation

• Parallel multithreaded programs becoming
  prevalent
• web servers, search engines, database managers,
  etc.
• run on SMPs for high performance
• often embarrassingly parallel
• Memory allocation is a bottleneck
• prevents scaling with number of processors

3
Assessment Criteria for Multiprocessor Allocators

• Speed
• competitive with uniprocessor allocators on one
  processor
• Scalability
• performance linear with the number of processors
• Fragmentation ( max allocated / max in use)
• competitive with uniprocessor allocators
• worst-case and average-case

4
Uniprocessor Allocators on Multiprocessors

• Fragmentation Excellent
• Very low for most programs Wilson Johnstone
• Speed Scalability Poor
• Heap contention
• a single lock protects the heap
• Can exacerbate false sharing
• different processors can share cache lines

5
Allocator-InducedFalse Sharing
A cache line

• Allocators cause false sharing!
• Cache lines can end up spread across a number of
  processors
• Practically all allocators do this

processor 1
processor 2
x2 malloc(s)
x1 malloc(s)
thrash
thrash
6
Existing Multiprocessor Allocators

• Speed
• One concurrent heap (e.g., concurrent B-tree)
  too expensive
• too many locks/atomic updates
• O(log n) cost per memory operation
• ? Fast allocators use multiple heaps
• Scalability
• Allocator-induced false sharing and other
  bottlenecks
• Fragmentation P-fold increase or even unbounded

7
Multiprocessor Allocator IPure Private Heaps

• Pure private heapsone heap per processor.
• malloc gets memoryfrom the processor's heap or
  the system
• free puts memory on the processor's heap
• Avoids heap contention
• Examples STL, ad hoc (e.g., Cilk 4.1)

processor 1
processor 2
x1 malloc(s)
x2 malloc(s)
free(x1)
free(x2)
x3 malloc(s)
x4 malloc(s)
allocated by heap 1
free, on heap 2
8
How to Break Pure Private Heaps Fragmentation

• Pure private heaps
• memory consumption can grow without bound!
• Producer-consumer
• processor 1 allocates
• processor 2 frees

processor 1
processor 2
x1 malloc(s)
free(x1)
x2 malloc(s)
free(x2)
x3 malloc(s)
free(x3)
9
Multiprocessor Allocator IIPrivate Heaps with
Ownership

• Private heaps with ownershipfree puts memory
  back on the originating processor's heap.
• Avoids unbounded memory consumption
• Examples ptmalloc Gloger, LKmalloc Larson
  Krishnan

processor 1
processor 2
x1 malloc(s)
free(x1)
x2 malloc(s)
free(x2)
10
How to Break Private Heaps with
OwnershipFragmentation

• Private heaps with ownershipmemory consumption
  can blowup by a factor of P.
• Round-robin producer-consumer
• processor i allocates
• processor i1 frees
• This really happens (NDS).

processor 1
processor 2
processor 3
x1 malloc(s)
free(x1)
x2 malloc(s)
free(x2)
x3malloc(s)
free(x3)
11
So What Do We Do Now?
12
The Hoard Multiprocessor Memory Allocator

• Manages memory in page-sized superblocks of
  same-sized objects
• - Avoids false sharing by not carving up cache
  lines
• - Avoids heap contention - local heaps allocate
  free small blocks from their set of superblocks
• Adds a global heap that is a repository of
  superblocks
• When the fraction of free memory exceeds the
  empty fraction, moves superblocks to the global
  heap
• - Avoids blowup in memory consumption

13
Hoard Example
processor 1
global heap

• Hoardone heap per processor a global heap
• malloc gets memory from a superblock on its heap.
• free returns memory to its superblock. If the
  heap is too empty, it moves a superblock to the
  global heap.

x1 malloc(s)
some mallocs
some frees
free(x7)
Empty fraction 1/3
14
Summary of Analytical Results

• Worst-case memory consumption
• O(n log M/m P) instead of O(P n log M/m)
• n memory required
• M biggest object size
• m smallest object size
• P number of processors
• Best possible O(n log M/m) Robson
• Provably low synchronization in most cases

15
Experiments

• Run on a dedicated 14-processor Sun Enterprise
• 300 MHz UltraSparc, 1 GB of RAM
• Solaris 2.7
• All programs compiled with g version 2.95.1
• Allocators
• Hoard version 2.0.2
• Solaris (system allocator)
• Ptmalloc (GNU libc private heaps with
  ownership)
• mtmalloc (Suns MT-hot allocator)

16
Performance threadtest
speedup(x,P) runtime(Solaris allocator, one
processor) / runtime(x on P processors)
17
Performance Larson
Server-style benchmark with sharing
18
Performance false sharing
Each thread reads writes heap data
19
Fragmentation Results

• On most standard uniprocessor benchmarks,Hoards
  fragmentation was low
• p2c (Pascal-to-C) 1.20 espresso 1.47
• LRUsim 1.05 Ghostscript 1.15
• Within 20 of Leas allocator
• On the multiprocessor benchmarksand other codes
• Fragmentation was between 1.02 and 1.24 for all
  but one anomalous benchmark (shbench 3.17).

20
Hoard Conclusions

• Speed Excellent
• As fast as a uniprocessor allocator on one
  processor
• amortized O(1) cost
• 1 lock for malloc, 2 for free
• Scalability Excellent
• Scales linearly with the number of processors
• Avoids false sharing
• Fragmentation Very good
• Worst-case is provably close to ideal
• Actual observed fragmentation is low

21
Hoard Heap Details

• Segregated size class allocator
• Size classes are logarithmically-spaced
• Superblocks hold objects of one size class
• empty superblocks are recycled
• Approximately radix-sorted
• Allocate from mostly-full superblocks
• Fast removal of mostly-empty superblocks

8
40
16
24
32
48
sizeclass bins
radix-sorted superblock lists (emptiest to
fullest)
superblocks
