Modeling Inline Structures using HECRAS Version 3.1

1
Modeling Inline Structures using HEC-RAS
Version 3.1
2
In Line Structures

• Can be used to model in-line gated spillways,
  overflow weirs, drop structures, and dams.
• Modeling method is very similar to bridges and
  culverts.
• Weir shapes are either ogee or broad crested.
• Gates are either radial (tainter) or vertical
  lift (sluice).
• Up to 10 groups of gates with up to 25 identical
  gates per group are allowed for each in line
  weir.
• Identical gates must have same type, size,
  elevation, and coefficient.
• Uncontrolled overflow area is also an option.

3
In Line Structures
4
Cross-Section Locations
Suggested cross-section locations are the same as
for bridges and culverts.
5
In Line Structure
Typical Cross-Section 2 with ineffective flow
areas defined.
6
In Line Structure
Typical Cross-Section 3 with ineffective flow
areas defined.
Uncontrolled Spillway
7
In Line Structure
Begin by selecting InLine Structure button from
Cross-Section Editor.
Select Lateral Structure button from
Cross-Section Editor for lateral weirs.
8
In Line Structure
Brings up window similar to culvert and bridge
windows.
9
In Line Structure
Must add structure as first step.
10
In Line Structure
Brings up window to input cross-section location
of the structure (weir)
11
In Line structure
Adds a plot of the upstream cross-section to the
window.
Note you can edit the upstream cross-section from
this button.
12
In Line Structure
Click on the Weir/Embankment button...
Which brings up the Weir Editor Window
13
In Line Structure
After filling in the data...
14
In Line Structure
the plot is updated to show the embankment.
15
In Line Structure
Click on the Gate button...
Which brings up the Gate Editor Window
16
In Line Structure
After filling in the data ...
Default values shown
C
Free Flow Condition
TE
BE
HE
C
Under free flow conditions the orifice cofficient
is not used. Orifice flow occurs with the
submerged condition.
17
In Line Structure
the plot is updated showing the gates.
18
Chapter 8 of the Hydraulic Reference Manual
describes the hydraulic computations through
gated spillways. Chapter 6 of the Users Manual
provides explanation for the various fields of
the Inline Gate Editor.
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Gate openings are input through the Steady Flow
Data editor
23
(No Transcript)
24
Each profile modeled separately
2 gate groups
All gates opened same height
25
The End
