The N to Delta transition form factors from Lattice QCD

1
The N to Delta transition form factors from
Lattice QCD
Antonios Tsapalis University of Athens, IASA
EINN05, Milos, 21-9-2005
2
outline

• Nucleon Deformation
• N-D transition form factors
• LATTICE QCD
• Hadronic states and transitions between them
• Limitations
• Calculation of the N-D transition matrix element
• Results
• Quenched QCD
• Dynamical Quarks included
• Outlook

3
Nucleon Deformation
Spectroscopic quadrupole moment vanishes
Intrinsic quadrupole moment w.r.t. body-fixed
frame exists
prolate
oblate
modelling required !
4
?(qqq) I J 1232 MeV
Spherical ? M1
Deformed ? M1 , E2 , C2
Deformation signal
5
EMR CMR Experimental Status
uncertainties in modelling final state
interactions
Thanks to N. Sparveris (Athens, IASA)
6
Lattice QCD

• Rotate to Euclidean time t -gt -i t

• Discretize space-time

Fermions on sites
X (m1,2,3)
Gauge fields on links
t (m4)
7
Wilson formulation (1974)
3
a
2
4
1
Plaquette gauge action
1
2
Wilson-Dirac operator DW
8
Generate an ensemble of gauge fields U
distributed with the Boltzmann weight
Calculate any n-point function of QCD
9
Limitations

• finite lattice spacing a 0.1 fm (momentum
  cutoff p/a)

• finite lattice volume La 2-3 fm

• finite ensemble of gauge fields U

• det(DW) very expensive to include

set det(DW) 1 quenched approximation
ignore quark loops

• DW breaks chiral symmetry

heavy quarks mp gt 400 MeV
Overlap or Domain-Wall maintain chiral symmetry
but very CPU expensive
10
The Transition Matrix Element
H.F.Jones and M.C.Scadron, Ann. Phys. (N.Y.) 81,1
(1973)
static D frame
11
Hadrons and transitions in Lattice QCD
B(x)
d

• generate a baryon at t0
• annihilate the baryon at time t
• measure the 2-pt function
• extract the energy from the exponential
• decay of the state in Euclidean time

12

• generate a nucleon at t0
• inject a photon with momentum q at tt1
• annihilate a Delta at time tt2
• measure the 3-pt function
• extract the form factors from suitable ratios
• of 3-pt and 2-pt functions

13
Quenched Results
C. Alexandrou, Ph. de Forcrand, H. Neff, J.
Negele, W. Schroers and A. Tsapalis PRL,
94, 021601 (2005)
323 x 64 lattice ß 6.0 200
gauge fields Wilson quarks La 3.2 fm
14
EMR ()
CMR ()
15
V. Pascalutsa M. Vanderhaeghen, hep-ph/0508060
In Chiral Effective Field Theory
d-expansion scheme
is small
L 1 GeV
fit low energy constants
Non-analyticities in mp reconcile the heavy quark
lattice results with experiment
NLO results at Q2 0.1 GeV2
16
Full QCD
C. Alexandrou, R. Edwards, G. Koutsou, Th.
Leontiou, H. Neff, J. Negele, W. Schroers and
A. Tsapalis
Hybrid scheme
valence quarks
sea quarks
domain wall quarks

• 2 light 1 heavy flavour
• action with small
• discretization error

good chiral properties lighter pions very
CPU expensive
V mp (GeV)
203 x 32 0.60 203 x 32 0.50
283 x 32 0.36

a0.125 fm
17
GM1 dynamical vs quenched _at_ mp 0.50 GeV
18
GM1
19
(No Transcript)
20
conclusions

• The N to Delta transition form factors can be
  studied
• efficiently using Lattice QCD

• accurate determination of GM1 in quenched
  theory
• deviation from fitted experimental data (MAID)

• EMR CMR negative nucleon deformation

• calculation with dynamical quarks in progress

• smaller volumes ? increased noise

• higher statistics is required in order to reach
  the
• level of precision necessary for the
  detection of
• unquenching effects (pion cloud)
