Title: Cirrus Aircraft


1
Cirrus Aircraft
NTAS _at_ ERAU Presentation
2
History
  • Cirrus founded in 1984
  • Developed VK-30 kit plane in 1988
  • Began development of ST50 in 1992
  • Production SR20 deliveries begin July 1999
  • Cirrus expands product line with SR22
    certification in November 2000
  • Crescent/FIIB financing complete August 2001
  • July 2002 production reaches 2/day
  • July 2004 production rate increased to 12/week
  • February 2006 production rate increased to
    14/week
  • Cirrus Vision the-jet introduced June 2007
  • SRS introduced July 2007
  • Cirrus Perspective avionics suite introduced May
    2008

3
Cirrus Development History
Kit Aircraft
Multiple Certified Aircraft
1988 1990 1992 1994 1996 1998 2000
2001 2002 2003 2004 2005 2006
2007 2008
SR22 Cert.
SR22 Dev.
Mode S
XM Weather
SR22 Production
SR22-Turbo
XM In-flight Entertainment
SR20 Production
SR20 FAA Certification
SR20 Development
Cirrus Perspective
GTS Intro.
SR20 G.W.I
SR22-G3
TUAV Program
VK30 Development
TAWS
VK30 Production
Vision SF50
ST50 Development
PFD Intro.
SR22-G2 Dev.
Airbag Seatbelts
SR22-G2 Cert.
SR22-G2 Prod.
4
Ownership
  • Cirrus Industries, Inc. is a privately held
    corporation
  • Over 200 shareholders
  • Private Equity Investment
  • Institutional Investment
  • Individual Investment
  • Controlling interest shareholder is Arcapita
  • Arcapita is the U.S. private equity arm of First
    Islamic Investment Bank E.C. of Bahrain.

5
Cirrus Facilities
Minnesota
Duluth Production Facility
  • Duluth Production Facility
  • Built in 1993
  • Expansions in 1997 2006
  • Total sq/ft 195,201
  • Office 35,886 sq ft
  • Production 15,315 sq ft

195, 201 sq/ft
Total both plants 435,372 sq ft
Duluth Customer Center
  • Duluth Customer Center
  • Built in 2002
  • Total sq/ft 70,671
  • Office 20,754 sq ft
  • Production 49,917 sq ft

70,671 sq/ft
North Dakota
Grand Forks Facility
169,500 sq/ft
  • Grand Forks Facility
  • Built in 1997
  • Expansion in 2006
  • Total sq/ft 169,486
  • Office 10,050 sq ft
  • Production 159, 436 sq ft

6
Our Cirrus Team
925 Total Employees 733 Duluth 195 Grand
Forks 33 Regional/International Many
International Representatives

Cirrus Gender Population 84 Male 16
Female Industry Standard 92 Male 8
Female Cirrus Average Age 37.4 years
7
Company Philosophy
If we can deliver the highest quality aircraft
available in class, at reasonable cost,
incorporating best available safety technology,
we will change the entire GA industry.
  • Design Criteria
  • Safe
  • Comfortable
  • Easy to operate
  • Fast and appealing

8
Cirrus Product Line Strong Market Performers
SR20
SR22
SR22 Turbo
X Edition
SR20 S SR20 GS
SR20 GTS Gross Weight 3050 lbs. Cruise
Speed 155 KTAS Horsepower 200
HP Powerplant TCM IO-360-ES
SR22 S SR22 GS
SR22 GTS Gross Weight 3400 lbs. Cruise
Speed 185 KTAS Horsepower 310
HP Powerplant TCM IO-550-N
Turbo GS Turbo GTS Gross
Weight 3400 lbs. Cruise Speed 219
KTAS Horsepower 310 HP Powerplant
TCM IO-550-N Tornado Alley Turbo System
Available on GS and GTS Models Premium
Interior and Exterior Package
Style Prestige
Identity
Unparalleled
Performance Higher, Farther,
And Faster
The High Performance Class
Leader With Its Easy Handling And
Advanced Technology
Versatile, Rugged, And Technologically
Advanced Yet Simple To Fly And Affordable To
Maintain
  • S, GS, GTS all available with Cirrus
    Perspective
  • S 10/1 x AHRS/S-TEC 55SR
  • GS 12/1 x AHRS/S-TEC 55X Ice Protection
    aircraft upgrades
  • GTS 12/2 x AHRS/Garmin AP Known Ice
    Protection aircraft upgrades

9
Cirrus Perspective
  • Dual AHRS
  • Obstacles Depiction and Pathways
  • Destination Block
  • Traffic Window
  • Blue LVL Button
  • Yaw Damper
  • Redundant/Fault Tolerant
  • Electrical system
  • 12 MFD/PFD Screens (35 more the 10)
  • Synthetic Vision Technology
  • GCU 478 Keyboard/Controller
  • Target fuel flow
  • GFC700/GMC705 Digital Autopilot
  • Go Around Button
  • Engine/Oxygen/Anti-Ice Integration

10
Growing the Cirrus Family - Future Models
11
SRS
  • DESIGN
  • Composite Construction
  • Electronic Flaps
  • Low Wing Design
  • Single Piece Canopy
  • Castering Nose Wheel
  • PERFORMANCE
  • Engine Rotax 912S (100 bhp)
  • Fuel Capacity 18.6 US Gal
  • Cruise Speed 120 KCAS
  • Useful Load 500 lb.
  • SAFETY
  • CAPS
  • 4-Point Safety Harness
  • Advanced Avionics
  • Low stall Speed

THE ECONOMY IS IN ITS OPERATION, NOT IN ITS
FEATURES
12
Vision First Flight July 2008
13
Ownership Programs Making It Easier
One Stop Shop Easier
14
The Only Certified Aircraft with a Parachute
Cirrus Airframe Parachute System (CAPS) Safety
System for Use in Life-threatening Situations 15
Deployments 33 Lives Saved
15
Cirrus Market Share
2008 Thru Q3 Cirrus 425 AC 33.3 Cessna
465 AC 36.5
Q1 - 2008
CESSNA 32.5
CIRRUS 26.3
Q2 - 2008
CESSNA 32.5
CIRRUS 33.2
Q3 - 2008
CESSNA 37.6
CIRRUS 37.6
16
Market Expansion Activities
  • Fleet Activity
  • Western Michigan University
  • Lund University
  • DAE Flight Academy
  • Delta Connection
  • SATS Air Taxi
  • - Now flying 25 Cirrus aircraft on daily basis

17
Production Complexity Made to Look Easy
  • Mixed Build Operation
  • 3 models SR20,SR22, Turbo - Different wing-
    Different engine
  • Up to 30 different configurations and option
    packages for SR20 and SR22
  • Over 153 composite parts bonded together per AC
  • Over 3330 assembly parts per AC
  • 54 assembly stations moving over 10,000
    parts/components and assemblies each day
  • Vertically integrated on core competencies

18
Focus World Class Manufacturing (Lean Thinking)
  • Building the6S foundation

Tool and partsorganization
Visualcontrols
Optimize layout
  • Showcase areas throughout facility
  • Standardized approach

19
Integrated Design Manufacturing
  • In house tool design and fabrication
  • Strategic tooling partner-GTS out of Detroit

20
Advanced Tooling System
21
Lean Production
22
GFK Composite Process
23
Streamlined Assembly Process
Production Capability
24
Cirrus Delivery Growth
2/day
3/day
4/day
We will continue to drive market demand
25
Worldwide Service and Support
  • 183 Service Centers World Wide
  • 145 Domestic
  • 38 International

26
Questions ?
