Version Control Abstract Data Types

1
Version ControlAbstract Data Types

• CS2023 Intersession 2007

2
Outcomes Version Control

• Applying RCS and SCCS, by Don Bolinger and Tan
  Bronson, on reserve in the library. Official RCS
  homepage www.cs.purdue.edu/homes/trinkle/RCS/
• Version Control with Subversion, Ben
  Collins-Sussman, Brian W. Fitzpatrick, C. Michael
  Pilato
• http//svnbook.red-bean.com/
• After the conclusion of this section you should
  be able to
• Use RCS for personal version control for personal
  projects, and for collaboration on small projects
• Understand the principles of version control, so
  that other VC systems (CVS, Subversion, ...) can
  be mastered quickly

3
Source File Modification Cycle
Create or Modify file
Test the modified file
no
Tests Succesful?
yes
Capture result
4
Managing Source Code Files and Revisions

• Very important to be able to trace the changes
  made throughout the life of software
• May want to revert to a previous version of a
  file, in the event of a problem, or simply to
  compare versions
• Could create a backup of each version
• Better way is to have changes to a file tracked
  for us
• this is what version control does

5
Modification Cycle with Archiving
Get existing revision
Modify
Test
Capture
Save modified file as new revision
Get existing revision
Modify
Test
Capture
Save modified file as new revision
6
Goals of Source Control

• Ability to record file revisions
• Ability to retrieve previous file revisions
• Control over new revision creation
• sometimes need to modify older version
• Ability to record why a new revision was made
• Control of file modification
• Prevent conflicting modifications
• Easy access to all file revisions
• all revisions kept in a single file

7
SCCS, RCS, CVS

• There are many revision control systems
• SCCS
• available on most commercial Unices, but not on
  Linux
• RCS
• available on Linux and many BSD-based Unices
• very popular for personal version control and
  small projects
• CVS
• Built on top of RCS
• Manages groups of files and projects distributed
  over a network better than RCS
• Widely used for Open Source projects, however,...

8
Subversion

• Since August 2001
• Open source, all platforms
• Addresses limitations of CVS
• Features include
• Directory versioning
• File renaming
• Plugs into Apache HTTP server
• ...

9
The Problem of File Sharing
10
Lock-Modify-Unlock Solution (eg. RCS)
11
Copy-Modify-Merge Solution (e.g., Subversion,
CVS)
12
(No Transcript)
13
Basics of Source Control

• So what do I archive?
• dynamic source files
• files that can't be reconstructed from other
  files
• What don't I archive
• derived files
• static (read-only files)

14
Basics of Source Control

• Nomenclature
• revision
• each archived version of a source file
• associated with a revision number
• check-in
• adding a new revision to an archive file
• check-out
• removing new revision from an archive file
• working file
• source file revision checked out

15
Basics of Source Control

• Source file revision numbers
• n.m. major (n) and minor (m) revision numbers
• 1.1, 1.2, ...
• Not necessarily the same as release numbers
• Source file revision storage
• only one revision of source file stored in
  literal form
• all others stored as differences (or diffs) from
  that single revision
• saves disk space!

16
Basics of Source Control

• Log
• archive file also contains reasons why each
  revision was checked-in
• Steps in source control
• create an archive file for each source file
• get a working file for reading
• source control system forces you to say
  explicitly when you intend to modify a file
  revision
• OK if you just want to compile or read
• get a working file for modification

17
Basics of Source Control

• Steps in source control (cont'd)
• get a working file for modification
• if no one else has that revision locked, it will
  be locked in your name
• if someone else has that revision locked, you
  won't be allowed to lock it
• while lock is set, no one else can modify that
  revision
• comparing a working file to its archive file
• adding a working file to an archive file

18
Basics of Source Control

• Steps in source control (cont'd)
• discarding a working file
• can't just delete working file
• need also to remove lock
• viewing history of an archive file

19
Basic Source Control Operations
Create an archive file
archive file exists
Get working file for reading
Get working file for modification
View working file history
Compare working file to archive file
keep changes ?
Discard working file
no
yes
Add working file to archive file
archive file updated
20
RCS

• ci check in RCS revisions
• co check out RCS revisions
• rcs change RCS file attributes
• rcsdiff compare RCS revisions
• rlog print log messages

21
RCS Basics

• Create an RCS directory in your development
  directory
• Place the file under source control
• ci filename
• Check out a file to make a change
• co -l filename
• Edit the file as normal (emacs filename)
• Compare working file to its RCS file
• rcsdiff filename
• Check the file back in, creating a new version
• ci filename

22
RCS initial check in ci

• ci source.c
• enter description, terminated with a '.' or end
  of file
• Your description here
• .
• initial revision 1.1
• done
• Working file checked in to archive and deleted

23
RCS check out for modification co

• co -l source.c
• RCS/source.c,v -- source.c
• revision 1.1
• done
• Latest revision checked out and stored in working
  file

24
Compare working file to RCS file

• rcsdiff source.c
• RCS file source.c,v
• retrieving version 1.1
• diff -r1.1 source.c
• .... (output from diff command)
• Can compare working file to any version
• rcsdiff -r1.3 prog.c
• Can compare any version to any other
• rcsdiff -r1.2 -r1.3 prog.c

25
Discard working file

• rcs -u source.c
• RCS file source.c,v
• 1.1 unlocked
• done
• Can then remove working file
• rm source.c

26
RCS check in ci

• ci source.c
• new revison 1.2 previous revision 1.1
• enter log message, terminated with a '.' or end
  of file
• Your messsage here
• .
• done

27
RCS check in with implicit check out ci -l and
ci -u

• ci -l source.c
• Checks in source.c, and checks it out again with
  a lock
• ci -u source.c
• Checks in source.c, checks it out again without a
  lock

28
View history of RCS file

• rlog source.c
• RCS file source.c,v
• working file source.c
• head 1.2
• ...
• description
• ...
• revision 1.2
• date ..
• your log message
• revision 1.1
• date ...
• initial revision (default log message)

29
Basic Source Control Operations
Create an archive file
ci
archive file exists
Get working file for reading
Get working file for modification
View working file history
co
rlog
co -l
Compare working file to archive file
keep changes ?
Discard working file
no
rcsdiff
rcs -u rm
yes
Add working file to archive file
ci
archive file updated
30
RCS Identifiers

• RCS can put special strings inside your files, to
  give version information
• These strings automatically get updated each time
  a new version is created
• Place string markers inside your source files
  (eg. in comments)
• Id
• Gives information on version no., date,
  author,...
• Log
• Displays entire file history with version
  description

31
Version Control within emacs

• Use ctrl-x v v to register, check in/out
• Upon check-in, working file not erased, but
  changed to read-only.
• must check out in order to modify
• When checking in changes, enter log message into
  window, and terminate with crtrl-c ctrl-c

32
Outcomes Abstract Data Types

• Books on reserve
• C for Java Programmers, Chapter 11 (11.5) and C
  Programming - a Modern Approach, Chapter 19
• After the conclusion of this section you should
  be able to
• Use opaque data types to create modules that
  implement abstract data types

33
Stack Module

• stack.h
• ifndef STACK_H
• define STACK_H
• void make_empty(void)
• int is_empty(void)
• void push(int i)
• int pop(void)
• endif

34
Stack as array

• include "stack.h"
• define STACK_SIZE 100
• static int contentsSTACK_SIZE
• static int top 0
• void make_empty(void)
• top 0
• int is_empty(void)
• return top 0

35

• static int is_full(void)
• return top STACK_SIZE
• void push(int i)
• if (is_full())
• fprintf(stderr, "push stack is full\n")
• exit(EXIT_FAILURE)
• contentstop i
• int pop(void)
• if(is_empty())
• fprintf(stderr, "pop stack is empty\n")
• exit(EXIT_FAILURE)
• return contents--top

36
Stack as Linked List

• include "stack.h"
• typedef struct node
• int data
• struct node next
• NodeT
• static NodeT top NULL

37

• void make_empty(void)
• NodeT next
• while(top ! NULL)
• next top-next
• free(top)
• top next
• int is_empty(void)
• return top NULL

38

• void push(int i)
• NodeT newNode
• newNode malloc(sizeof(NodeT))
• if (newNode NULL)
• fprintf(stderr, "push stack is full\n")
• exit(EXIT_FAILURE)
• newNode-data i
• newNode-next top
• top newNode

39

• int pop(void)
• NodeT oldTop
• int i
• if(is_empty())
• fprintf(stderr, "pop stack is empty\n")
• exit(EXIT_FAILURE)
• oldTop top
• i top-data
• top top-next
• free(oldTop)
• return i

40
Stack Data Type

• Can only have one instance of preceding stack
  modules
• Need to create a stack type
• include "stack.h"
• int main()
• StackT s1, s2
• new_stack(s1)
• new_stack(s2)
• push(s1, 1)
• if (!is_empty(s1))
• printf("d\n", pop(s1)) / prints "1" /
• ...

41
Stack Data Type

• stack.h
• typedef struct node
• int data
• struct node next
• NodeT
• typedef struct
• NodeT top
• StackT
• void new_stack(StackT s)
• void make_empty(StackT s)
• int is_empty(const StackT s)
• void push(StackT s, int i)
• int pop(StackT s)

42
Stack Type as Linked List

• include "stack.h"
• void new_stack(StackT s)
• s-top NULL
• void make_empty(StackT s)
• NodeT next
• while(s-top ! NULL)
• next s-top-next
• free(s-top)
• s-top next

43

• void push(StackT s, int i)
• NodeT newNode
• newNode malloc(sizeof(NodeT))
• if (newNode NULL)
• fprintf(stderr, "push stack is full\n")
• exit(EXIT_FAILURE)
• newNode-data i
• newNode-next s-top
• s-top newNode

44

• int is_empty(const StackT s)
• return s-top NULL
• int pop(StackT s)
• NodeT oldTop
• int i
• if(is_empty(s))
• fprintf(stderr, "pop stack is empty\n")
• exit(EXIT_FAILURE)
• oldTop s-top
• i s-top-data
• s-top s-top-next
• free(oldTop)
• return i

45
Stack Type

• The previous module allowed for multiple
  instances, but at the expense of information
  hiding!
• Nothing prevents a client from using a StackT
  variable as a structure
• StackT s1
• s1.top NULL
• ...

46
Opaque Data Type

• Incomplete structure definition
• can define the type of a structure that hasn't
  been defined yet
• typedef struct hidden Visible
• allows one to use the type Visible as a synonym
  for struct hidden .

47
Opaque Data Type

• A data type is opaque because the client cannot
  access its full representation
• all the client knows is that it is represented by
  another data type
• client doesn't know that that data type is
• Consider module Mod that exports a data type
  called Abstract to the client
• mod.h defines a type Abstract as a pointer to a
  structure type called Concrete
• typedef struct Concrete Abstract
• there is no definition of Concrete in this file

48
Client
Implementation
mod.h
mod.c
typedef struct Concrete Abstract
typedef struct Concrete Abstract
struct Concrete ...
49
Opaque Data Type

• The type Concrete is defined in an
  implementation file
• The client can use the type provided there are
  no attempts to dereference values of this type
• void f(Abstract p)
• is legal, but
• Abstract p
• p-x
• is illegal, because the type Abstract represents
  a pointer to the Concrete type, and the compiler
  has no information about this type

50
Stack ADT Module

• 1) the type DataType of the data stored in the
  stack is known to the implementation
• 2) any number of stacks can be created all
  stacks must have elements of the same type,
  DataType
• 3) the representation of the stack and stack
  elements are not visible to the client.
• The first version will operate on a stack of
  integers.

51
Stack ADT Header

• ifndef STACK_H
• define STACK_H
• typedef int DataType
• typedef struct StackCDT StackADT
• StackADT Stack_new(void)
• int Stack_empty(StackADT s)
• void Stack_push(StackADT s, DataType i)
• DataType Stack_pop(StackADT s)
• void Stack_free(StackADT s)
• endif

52
Application of Stack ADT

• include "stack.h"
• StackADT s1, s2
• s1 Stack_new()
• s2 Stack_new()
• Stack_push(s1, 1)
• if (!Stack_empty(s1))
• printf("d\n", Stack_pop(s1))
• ...

53
Stack ADT Implementation

• include "stack.h"
• typedef struct node
• DataType d
• struct node next
• NodeT
• typedef struct StackCDT
• int count
• NodeT top
• StackCDT

54
Stack ADT Implementation

• StackADT Stack_new(void)
• StackADT s
• if((s malloc(sizeof(StackCDT))) NULL)
• exit(EXIT_FAILURE)
• s-count 0
• s-top NULL
• return s
• int Stack_empty(StackADT s)
• return s-count 0

55
Stack ADT Implementation

• void Stack_push(StackADT s, DataType d)
• NodeT newNode
• if ((newNode malloc(sizeof(NodeT)))
  NULL)
• fprintf(stderr, "push stack is full\n")
• exit(EXIT_FAILURE)
• newNode-d d
• newNode-next s-top
• s-top newNode
• s-count

56
Stack ADT Implementation

• DataType Stack_pop(StackADT s)
• DataType d
• NodeT oldNode
• oldNode s-top
• s-top oldNode-next
• s-count--
• d oldNode-d
• free(oldNode)
• return d

57
Stack ADT Implementation

• void Stack_free(StackADT s)
• NodeT p, q
• for (p (s)-top p p q)
• q p-next
• free(p)
• free(s)
• s NULL

58
Shallow and Deep Copy

• To push a new element d onto the stack
• newNode-d d
• If newNode-d and d are pointers, this results in
  a shallow copy.
• If client deallocates variable pointed to by d
  then newNode-d becomes a dangling reference

59
Shallow and Deep Copy

• For a deep copy, use a callback function
  copyData_Stack()
• For example, for strings and doubles
• DataType copyData_Stack(const DataType v)
• return strdup(v)
• DataType copyData_Stack(const DataType v)
• return v

60
char strdup(const char s) / return a copy of
s / char kopy / copy of s /
if((kopy calloc(strlen(s) 1,
sizeof(char))) NULL) return NULL
strcpy(kopy, s) return kopy
61
Shallow and Deep Copy

• We need another callback function,
  freeData_Stack()
• For example, for string and doubles
• void freeData_Stack(DataType v)
• free(v)
• void freeData_Stack(DataType v)

62
Stack ADT Header with Deep Copy

• typedef char DataType
• typedef struct StackCDT StackADT
• DataType copyData_Stack(const Datatype v)
• void freeData_Stack(DataType v)
• StackADT Stack_new(void)
• int Stack_empty(StackADT s)
• void Stack_push(StackADT s, DataType i)
• DataType Stack_pop(StackADT s)
• void Stack_free(StackADT s)

63
Stack ADT Header with Deep Copy

• Implementation of callback functions must be
  provided by the client
• DataType copyData_Stack(const Datatype v)
• void freeData_Stack(DataType v)
• They are declared in the header file so that the
  implementation code can call them

64
Stack ADT Implementation with Deep Copy

• void Stack_push(StackADT s, DataType d)
• NodeT newNode
• if ((newNode malloc(sizeof(NodeT)))
  NULL)
• fprintf(stderr, "push stack is full\n")
• exit(EXIT_FAILURE)
• newNode-d copyData_Stack(d)
• newNode-next s-top
• s-top newNode
• s-count

65
Stack ADT Implementation with Deep Copy

• DataType Stack_pop(StackADT s)
• DataType d
• NodeT oldNode
• oldNode s-top
• s-top oldNode-next
• s-count--
• d copyData_Stack(oldNode-d)
• freeData_Stack(oldNode-d)
• free(oldNode)
• return d

66
Stack ADT Implementation with Deep Copy

• void Stack_free(StackADT s)
• NodeT p, q
• for (p (s)-top p p q)
• q p-next
• freeData_Stack(p-d)
• free(p)
• free(s)
• s NULL
