An Introduction to Random Number Generators and Monte Carlo Methods

1
An Introduction to Random Number Generators and
Monte Carlo Methods

• Josh Gilkerson
• Wei Li
• David Owen

2
Random Number Generators
3
Uses for Random Numbers

• Monte Carlo Simulations
• Generation of Cryptographic Keys
• Evolutionary Algorithms
• Many Combinatorial Optimization Algorithms

4
Two Types of Random Numbers

• Pseudorandom numbers are numbers that appear
  random, but are obtained in a deterministic,
  repeatable, and predictable manner.
• True random numbers are generated in
  non-deterministic ways. They are not
  predictable. They are not repeatable.

5
True Random Generators

• Use one of several sources of randomness
• decay times of radioactive material
• electrical noise from a resistor or semiconductor
• radio channel or audible noise
• keyboard timings
• some are better than others
• usually slower than PRNGs

6
RNG And Random Machines

• It is not viable to generate a true random number
  using computers since they are deterministic.
  However, we can generate a good enough random
  numbers that have properties close to true random
  numbers.
• The first machine used to produce a table of
  100,000 random digits was done by M. G. Kendall
  and B. Babington-Smith in 1939.
• RAND Corporation in 1955 released a table of a
  million random digits.
• ERNIE is a random number generator machine used
  to pick the winning numbers in the British
  Premium Bonds lottery.

7
Desirable Properties of PRNGs

• Uniform
• Lengthy period
• Serially uncorrelated
• Fast

8
Problems With PRNG

• It is very difficult to pin point the problem
  with random number generators when they arise.
  Usually, the programmers would need to replace
  the whole random number generator with a better
  ones.
• With small test cases, problems rarely arises.
  However, when it gets to large scale random
  number generations (possibly in millions or even
  billions of numbers) the problem could be
  apparent. This makes debugging difficult.
• In large-scale computing problems, one might need
  to use a parallel algorithm. The effect is that,
  sometimes it is not possible to duplicate the
  simulation exactly.

9
Linear Congruential Generator(LCG)

• Most common
• Maximum period of 2n for n-bit numbers
• Xn1( aXn c ) mod m
• a,c,m are constants
• X0 is the seed

10
Advantages of LCG

• Most common
• Very easily implemented
• Fast and small (remember only last number)
• Easily parallelized
• N processes 1 ... N.
• numbers for process n are XniN
• no more expensive than serial version.

11
Disadvantages of LCGs

• Other generators have longer maximum periods.
• Bad choices of M result in very bad sequences
  (primes work best, powers of 2 are fast, but not
  nearly as good).
• Initial seed affects period.
• Low order bits are not random.

12
Lagged Fibonacci Generators

• Similar to Fibonacci Sequence
• Increasingly popular
• Xn (Xn-l Xn-k) mod m (lgtkgt0)
• l seeds are needed
• m usually a power of 2
• Maximum period of (2l-1)x2M-1 when m2M

13
Add-with-carry Subtract-with-borrow

• Similar to LFG
• AWC Xn(Xn-lXn-kcarry) mod m
• SWB Xn(Xn-l-Xn-k-carry) mod m

14
Multiply-with-carry Generators

• Similar to LCG
• Xn(aXn-1carry) mod m

15
Inverse Congruential Generators

• Xn(a Xn-1 b) mod m
• m should be prime
• y is the multiplicative inverse of y in the
  field over 0,1,...,m-1.

16
PRNG Review

• This is just a short review. There are many
  other PRNGs.
• Linear Congruential Generator
• Lagged Fibonacci Generator
• Add-with-carry Generator
• Subtract-with-carry Generator
• Multiply-with-carry Generator
• Inverse Congruential Generator

17
Testing Randomness

• Test for uniform distribution (of singletons,
  pairs, triples, etc) of the sequence and all
  subsequences.
• DIEHARD - http//stat.fsu.edu/pub/diehard/
• NIST - http//csrs.nist.gov/rng

18
Monte Carlo Methods
19
Introduction of Monte Carlo

• Monte Carlo methods have been used for centuries.
• However during World War II, this method was used
  to simulate the probabilistic issues with neutron
  diffusion (first real use).
• Named after the capital of Monaco (one of the
  worlds center for gambling), due to the
  similarity to games of chance.

20
What is Monte Carlo

• Non Monte Carlo methods typically involve ODE/PDE
  equations that describe the system.
• Monte Carlo methods are stochastic techniques.
• It is based on the use of random numbers and
  probability statistics to simulate problems.
• Something can be called a Monte Carlo method if
  it uses random numbers to examine the problem it
  is solving.
• First, we would need to determine the probability
  density function (PDF). Then perform random
  sampling from the PDF. We keep record of each
  simulation performed and tally them.

21
Probability Density Function

• A probability density function (or probability
  distribution function) is a function f defined on
  an interval (a, b) and having the following
  properties

22
Why use Monte Carlo

• It allows us to examine complex system. And is
  usually easy to formulate (independent of the
  problem).
• For example, solving equations which describe two
  atoms interactions. This would be doable without
  using Monte Carlo method. But solving the
  interactions for thousands of atoms using the
  same equations is impossible.
• However, the solutions are imprecise and it can
  be very slow if higher precision is desired.

23
Components of Monte Carlo simulation

• Probability distribution functions (pdf's) - the
  physical (or mathematical) system must be
  described by a set of pdf's.
• Random number generator - a source of random
  numbers uniformly distributed on the unit
  interval must be available.
• Sampling rule - a prescription for sampling from
  the specified pdf's, assuming the availability of
  random numbers on the unit interval, must be
  given.
• Scoring (or tallying) - the outcomes must be
  accumulated into overall tallies or scores for
  the quantities of interest.

24
Components of Monte Carlo simulation (cont.)

• Error estimation - an estimate of the statistical
  error (variance) as a function of the number of
  trials and other quantities must be determined.
• Variance reduction techniques - methods for
  reducing the variance in the estimated solution
  to reduce the computational time for Monte Carlo
  simulation
• Parallelization and vectorization - algorithms to
  allow Monte Carlo methods to be implemented
  efficiently on advanced computer architectures.

25
Monte Carlo Example Computing Pi
26
Monte Carlo Example (cont.)

• So, we can compute PI by generating two numbers
  for x and y component of a simulated throw. Then
  we can figure out by using Pythagorean theorem if
  this throw is inside or outside the circle. We
  count this hits, and after doing this thousands
  of times (or more), we can get an estimate value
  of PI.
• Accuracy of the estimate depends on the number of
  throws. An example code would be (assuming we
  set the radius 1)
• double x rand() // get random in 0, 1 for
  x
• double y rand() // get random in 0, 1 for
  y
• double dist sqrt(xx yy)
• if (distFromOrigin(x,y) lt 1)
• hits

27
What MC Needs

• MC methods might needs different RNG.
• For example, when simulating outgoing direction
  for a launched particle and interactions of the
  particle with the medium, the following would be
  the desirable properties
• The attribute of each particle should be
  independent from each other.
• The attribute of all the particles should span
  across the entire attribute space. I.e., as we
  approach infinite numbers of particles, the
  particles launched into a space should cover the
  space completely.
• Next slide will states the properties of the RNG
  needed.

28
What MC Needs (cont.)

• Any subsequence of random numbers should not be
  correlated with any other subsequence of random
  numbers. For example, when simulating the
  launched particles, we should not generate
  geometrical patterns.
• Random number repetition should occur only after
  a very large generation of random numbers.
• The random numbers generated should be uniform.
  This point and the first one are loosely related.
  To achieve more uniformity, some correlations
  between random numbers must be established.
• The RNG should be efficient. It should be
  vectorizable with low overhead. The processors in
  parallel systems, should not be required to talk
  between each other.

29
Appropriate PRNGs

• The following are packages of available RNGs
  (http//www.agner.org/random/).
• Uniform RNG in C assembly language
• Mersenne twister.
• Mother-of-all.
• RANROT.
• In C, we can use drand48() to generate a double
  type of random number which is produced using
  48-bit integers.

30
An Application of the Monte Carlo Method

• The Effect of Space Discretization on the
  Canonical Monte Carlo Simulation

31
Agenda

• Introduction to the Monte Carlo (MC) molecular
  simulation
• Canonical Ensemble
• Importance Sampling
• Simulation Process
• Simulation of the equation of state of the
  Lennard-Jones Fluid Continuum Model
• Discretized Model
• Comparison of the simulation results

32
Introduction

• Why molecular simulation?
• Help explaining experimental observations
• simulate critical or extreme conditions
• Guide real experiments
• Purpose of this study
• Long-term goal - simulation of self-assembly of
  surfactant solutions fine lattice
• The continuum model is not viable under the
  current computing power
• The discretized model is at least 10 times faster
  compared with the continuum model
• The effect of space discretization on the
  simulation results

33
Canonical Ensemble

• fixed number of molecules N, fixed volume V
  (volume), fixed temperature T
• The canonical ensemble partition function from
  statistical mechanics
• Evaluation of observable properties A
• Random sampling - brute force Monte Carlo
• When estimate ltf(x)gt , most of the computing is
  wasted

34
Importance Sampling
Change the integration variable
Standard deviation
Impossible to find the weight function w in
multidimensional integrals
35
The Metropolis Method
Evaluation of observable properties A
Probability of finding the system in a
configuration around r
Randomly generate sampling points according to
the probability distribution N(r)
36
The Detailed Balance
Generate sampling points according to the
probability distribution detailed balance
If a is a symmetric matrix
If a is a symmetric matrix
37
Simulation Process

• Initialize the system
• Put the system in a random state
• Make a trial move
• Randomly make a trial move
• Calculate the energy change
• Reevaluate the interactions of the moved
  particles with its neighbors and calculate the
  energy change
• Accept the trial move with the Metropolis scheme
• Keep trying the moves until system approach
  equilibrium
• Either monitor the total energy change, or
  monitor the structure formed in the simulation
  box
• Sampling
• Sample a certain property over a certain number
  of configurations

38
Continuum Model

• Fixed N, V, T
• Lennard-Jones potential
• Intermolecular force
• Virial of the system
• Pressure of the system

39
Simulation Process
Monte Carlo loop Subroutine
Main program
Start
Start
Read simulation parameters
Trial move
yes
Satisfy Metropolis rule?
Accept the trial move
yes
no
New simulation?
no
Update energy and virial
Initialize positions of all particles
Read old configuration
Sample the pressure
Monte Carlo loop
no
End of simulation?
yes
Stop
Stop
40
Parameters Modeling
Potential minimum between 2 particles Average
distance between 2 particles Maximum displacement
of a particle Number of particles Temperature Dens
ity of the system
41
Simulation Results Continuum Model
42
Discretized Model

• Space is discretized. Particles can only move on
  a 3D mesh (fine lattice).
• Distance between particles is a set of fixed
  values.
• Evaluation of complex functions against distance
  can be precalculated.
• Depends on the form the functions, the simulation
  can be accelerated 10-100 times

move
move
43
Simulation Results Discretized Model
44
Conclusion

• The equation of state of L-J fluid from the
  canonical MC simulation agrees with what reported
  on literature
• The Discretized Model can produce results
  comparable to the Continuum Model
• The Discretized Model can make simulations where
  the normal Continuum Model cannot access

45
RNG Resources

• True Random Numbers
• http//www.random.org/
• http//www.fourmilab.ch/hotbits/
• http//www.robertnz.net/hwrng.htm
• http//world.std.com/reinhold/truenoise.html
• Pseudo-random Number Generators
• http//random.mat.sbg.ac.at/
• http//www.math.utah.edu/alfeld/Random/Random.htm
  l
• http//www.mathcom.com/corpdir/techinfo.mdir/scifa
  q/q210.html
• http//csep1.phy.ornl.gov/rn/rn.html
• Others
• ftp//ftp.isi.edu/in-notes/rfc1750.txt

46
Monte Carlo Method Resources

• http//csep1.phy.ornl.gov/mc/mc.html
• http//www.chem.unl.edu/zeng/joy/mclab/mcintro.htm
  l
• http//csep1.phy.ornl.gov/rn/rn.html
• http//mathworld.wolfram.com/QuasirandomSequence.h
  tml
• http//www.agner.org/random/
• http//web.cz3.nus.edu.sg/yzchen/teach/comphys/se
  c03.html
