Reflection%20and%20Refraction

1

• Reflection and Refraction

2
Reflection

• Most objects we see reflect light rather than
  emit their own light.

3
Principle of Least Time

• Fermat's principle - light travels in straight
  lines and will take the path of least time to
  strike mirror and reflect from point A to B

Wrong Path
True Path
MIRROR
4
Law of Reflection

• The angle of incidence equals the angle of
  reflection.
• This is true for both flat mirrors and curved
  mirrors.

5

MIRROR
6
(No Transcript)
7
Types of Reflection

• Specular Reflection - images seen on smooth
  surfaces (e.g. plane mirrors)
• Diffuse Reflection - diffuse light coming from a
  rough surface (cannot see a reflection of
  yourself)

8
(No Transcript)
9
Locating the Image for Plane Mirrors

1. Draw the image the same distance behind the
   mirror as the object is in front.
2. Draw a connector line from each object to each
   image.
3. If the connector line passes through the mirror,
   the image will be seen.

10
These lines are pointed to the only images that
will be seen from each of the original locations
(A-E) NOTE No images will be seen from E
11

12
Concave Mirrors


13
Light from Infinite Distance
Focuses at the focal point

14
Two Rules for Locating the Image for Concave
Mirrors

• Any incident ray traveling parallel to the
  principal axis on the way to the mirror will pass
  through the focal point upon reflection

15
(No Transcript)
16
Two Rules for Concave Mirrors

• Any incident ray traveling parallel to the
  principal axis on the way to the mirror will pass
  through the focal point upon reflection

• Any incident ray passing through the focal point
  on the way to the mirror will travel parallel to
  the principal axis upon reflection

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Virtual Image
21
Real vs. Virtual Image

• When a real image is formed, it still appears to
  an observer as though light is diverging from the
  real image location
• only in the case of a real image, light is
  actually passing through the image location
• Light does not actually pass through the virtual
  image location
• it only appears to an observer as though the
  light was emanating from the virtual image
  location

22
(No Transcript)
23
Will an image ever focus at a single point with a
convex mirror?
Therefore, the images you see are virtual!
24
Refraction

• Refraction is the bending of light when it passes
  from one transparent medium to another
• This bending is caused by differences in the
  speed of light in the media

25
(No Transcript)
26
Light Beam
AIR
WATER
AIR
27
(No Transcript)
28
Light Beam
AIR
WATER
AIR
29
Refraction Examples

• Light slows down when it goes from air into water
  and bends toward the normal.
• An Analogy A car slows down when it goes from
  pavement onto gravel and turns toward the normal.

• An Illusion Fish in the water appear closer and
  nearer the surface.

30
http//cougar.slvhs.slv.k12.ca.us/pboomer/physics
lectures/secondsemester/light/refraction/refractio
n.html
31
Refraction
Observer
AIR
WATER
False Fish
True Fish
32
Atmospheric Refraction

• Our atmosphere can bend light and create
  distorted images called mirages.

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
Lenses

• Work due to change of direction of light due to
  refraction
• Diverging Lens
• A lens that is thinner in the middle than at the
  edges, causing parallel light rays to diverge.
• Converging Lens
• A lens that is thicker in the middle and refracts
  parallel light rays passing through to a focus.

37
Diverging or Concave Lens
38
Converging or Convex Lens
C
F
39
Converging or Convex Lens
C
F
40
Converging or Convex Lens
C
F
41
Converging or Convex Lens
C
F
42
Converging or Convex Lens
C
F
43
Converging or Convex Lens
C
F
44
Converging or Convex Lens
C
F
45
Converging or Convex Lens
C
F
46
Converging or Convex Lens
C
F
47
Converging or Convex Lens
C
F
48
(No Transcript)
49
Total Internal Reflection...

• is the total reflection of light traveling in a
  medium when it strikes a surface of a less dense
  medium
• sin ? n2/n1

50
http//cougar.slvhs.slv.k12.ca.us/pboomer/physics
lectures/secondsemester/light/refraction/refractio
n.html
51
Refraction
Critical Angle
AIR
WATER
49
Total Internal Reflection
Light Source
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
What Is Fiber Optics ?

• Transmitting communications signals over hair
  thin strands of glass or plastic
• Not a "new" technology
• Concept a century old
• Used commercially for last 25 years

Fiber Optics Association
56
Fiber Has More Capacity

• This single fiber can carry more communications
  than the giant copper cable!

Fiber Optics Association
57
Fiber Optic Communications

• Applications include
• Telephones
• Internet
• LANs - local area networks
• CATV - for video, voice and Internet connections
• Utilities - management of power grid
• Security - closed-circuit TV and intrusion
  sensors
• Military - everywhere!

Fiber Optics Association
58
Why Use Fiber Optics?

• Economics
• Speed
• Distance
• Weight/size
• Freedom from interference
• Electrical isolation
• Security

Fiber Optics Association
59
Fiber Optic Applications

• Fiber is already used in
• gt 90 of all long distance telephony
• gt 50 of all local telephony
• Most CATV networks
• Most LAN (computer network) backbones
• Many video surveillance links

Fiber Optics Association
60
Fiber Optic Applications

• Fiber is the least expensive, most reliable
  method for high speed and/or long distance
  communications
• While we already transmit signals at Gigabits per
  second speeds, we have only started to utilize
  the potential bandwidth of fiber

Fiber Optics Association
61
Fiber Technology
Fiber Optics Association
62
Fiber Technology
Fiber Optics Association
63
Fiber Optic Data Links
Fiber Optics Association
64
Light Used In Fiber Optics

• Fiber optic systems transmit using infrared
  light, invisible to the human eye, because it
  goes further in the optical fiber at those
  wavelengths.

Fiber Optics Association
65
Wavelength-Division Multiplexing
Fiber Optics Association
66
Fiber Optic Cable

• Protects the fibers wherever they are installed
• May have 1 to over 1000 fibers

Fiber Optics Association
67
Fiber Optic Connectors

• Terminates the fibers
• Connects to other fibers or transmission
  equipment

68
Medical Fiberscopes

• Electromagnetic radiation has played a role in
  medicine for decades
• Particularly interesting is the ability to gain
  information without invasive procedures
• Using fiber optics in medicine has opened up new
  uses for lasers

69
Fiberscope Construction

• Fiberscopes were the first use of optical fibers
  in medicine
• Invented in 1957
• The objective lens forms a real image on the end
  of the bundle of fiber optics
• This image is carried to the other end of the
  bundle where an eyepiece is used to magnify the

70
Endoscopes

• An endoscope is a fiberscope with additional
  channels besides those for illuminating and
  viewing fibers
• The uses of these extra channels may include
• Introducing or withdrawing fluids
• Vacuum suction
• Scalpels for cutter or lasers for surgical
  applications

71
(No Transcript)
72
Air Diamond Interface

• sin ? n2/n1
• Air nair 1 and Diamond n2 2.42
• sin ? 1.00/2.42 0.413
• sin ? 0.413
• ? sin-1 0.413
• ? 24o

73
http//cougar.slvhs.slv.k12.ca.us/pboomer/physics
lectures/secondsemester/light/refraction/refractio
n.html
74
Dispersion...

• is the separation of white light into pure
  colors (ROY G. BIV).
• The index of refraction is higher for higher
  frequencies, so violet is bent the most
• Dispersion Examples
• Prisms
• Diffraction Gratings
• CDs
• Raindrops

75
(No Transcript)
76
(No Transcript)
77
Rainbows

• Raindrops refract, reflect and disperse sunlight.
• Rainbows will always appear opposite of the Sun
  in the sky.
• You cannot run from or run to a rainbow!

78
(No Transcript)
79
(No Transcript)
