• Application Specific Integrated Circuits

2
What is an ASIC?

• An application-specific integrated circuit (ASIC)
  is an integrated circuit (IC) customized for a
  particular use

3
The design cycle for an ASIC follows a number of
main stages

• design entry

• functional simulation

• Synthesis

• Design verification

• Layout

4
(No Transcript)
5
Design Description

• At initial stage of design process designer
• provides a Behavioral description of the
• functionality intended.
• Behavioral model does not care about the
• structure of the design, and does not include
• timing information.

6
Design Description cont.

• RTL description (Register Transfer Level)
• In this model the entire design is split into
  registers with flow of information between these
  registers at each clock cycle.
• All the registers are updated at the same time in
  a clock cycle.
• RTL captures the data flow but fails to give a
  good description of control flow.

7
Design Description cont.

• Structural Description
• Structural description consists of a network of
  instances of logic gates and registers described
  by a technology library.
• Technology library is a description of simple
  AND, OR, NOT and complicated multiple
  functionality cells.
• The description of a cell includes its geometry,
  delay and power characteristics.

8
functional simulation

• There are mainly three classes of logic
• simulators
• compiled code logic simulators.
• event-driven logic simulators.

9
functional simulation cont.

• Compiled code logic simulator
• Compiled code logic simulation algorithm
• evaluates every logic element in the design at
• each time step.
• In a compiled code simulator a combinational
  circuit is topologically ordered and equation is
  generated for each gate output in terms of its
  inputs using Boolean operators AND, OR and NOT.
• since circuit activity is very low at each
  element, run time of such algorithm is huge for
  big circuits.

10
functional simulation cont.

• Interpretive Event Driven logic simulator
• Event-driven logic simulator works on the
  principle that output of a logic element changes
  only when one of its inputs change.
• Statistical data shows that event activities in
  large circuits are very low and with increase in
  size of the circuit percentage activity on a
  logic element decreases.
• one major class of event driven logic simulation
  algorithms is Asynchronous Simulation Algorithms.

11
functional simulation cont.

• This algorithm has two different conservative
• and optimistic approaches

1. In conservative schemes only safe evaluation time
   is allowed, evaluations which guarantee correct
   result. A logic element is evaluated only after
   it receives all its input tokens. As a logic
   element is evaluated its output is decided on the
   basis of its inputs and time stamp of output is
   decided by time stamp of last arriving token and
   delay of the logic element.

12
functional simulation cont.

• One disadvantage of Conservative scheme
• is that it can lead to deadlock. If an input of a
• logic element is driven by one of its output or
• output of a forward logic element then it
• leads to deadlock.

There exist both deadlock detection and deadlock
prevention schemes to take care of this situation.
13
functional simulation cont.

1. In optimistic scheme evaluation of a logic
   element takes place as soon as an input token
   arrives at its input. If the output produced
   turns out to be incorrect then roll back takes
   place to return to previous know correct state
   and messages are sent to forward elements to
   cancel effect of incorrect message sent earlier.
   This algorithm does not lead to deadlocks but has
   an added cost of state saving and more complex
   control mechanism because of rollback. Optimistic
   scheme is most efficient as long as rollbacks are
   few.

14
ASIC Synthesis

• RTL Synthesis involves three major steps
• Transition from RTL description into gates and
  flip-flops. (in order to reduce number of gates
  in the design)
• Optimization of logic.
• Placement and routing of optimized netlist.

15
ASIC Synthesis cont.
Area Optimization

• With shrinking system size ASIC should be able to
  accommodate maximum functionality in minimum
  area.
• Area can be optimized by having lesser number of
  cells and by replacing multiple cells with single
  cell that includes both functionality.

16
ASIC Synthesis cont.
Timing Optimization

• Designer specifies maximum delay between primary
  input and primary output.

Power Optimization

• Development of hand-held devices has led to
  reduction of battery size and hence low power
  consuming systems.
• Low power consumption has become a big
  requirement for lot of designers.

17
ASIC Synthesis cont.

• Transition from RTL to FSM to Gates
• First step in synthesis process is to convert a
  given RTL into a finite state machine (FSM), in
  order to reduce number of states.
• Some of the common transformations applied to FSM
  are constant propagation, gate merging, dead code
  elimination, arithmetic merging.
• Next step is to generate hardware.

RTL to FSM(or graph)
FSM(graph) to Gates.
18
ASIC Synthesis cont.

• Gate Level Logic Optimization
• Timing and area constraints are provided by the
  designer.
• Slack is defined as difference between the
  expected arrival time and actual arrival time of
  signal at a particular output port.
• Slack is calculated for input to output paths.
• The aim of timing optimization is to reduce the
  slack.

19
ASIC Synthesis cont.
Optimizations to reduce area include following

• Constant propagation Boolean minimization may
  lead to dissolution of certain section of code
  into constants. Such constants should be
  propagated at this stage in order to reduce gate
  count and area.

1. Eliminate redundant logic For example a ab
   should be replaced by a.0

• 3) converting all Boolean logic to 2 level
  sum-of-products
• produces very fast designs but increases
  area.
• For example (a b) ( c d) ac bc ad
  bd

20
ASIC Synthesis cont.
Some optimizations to improve timing are as
follows

1. Restructuring If arrival times of signals at
   various input gates are known, they can be
   re-arranged to obtain better timing delay.

• 2) Buffer insertion to improve timing along
  critical
• path. Replacing cell with a cell of higher
  drive
• strength can improve delay along critical
  path.

21
ASIC Synthesis cont.

1. Pin assignment can be changed to match the late
   arriving input pin with pin having faster
   propagation delay to output.

22
ASIC Synthesis cont.

• Area Reclamation
• Certain timing optimizations might lead to area
• escalation. Area Reclamation algorithms try to
  reclaim
• area which does not affect timing on critical
  paths.
• Downsizing the gates which contain extra pins.
• Buffers which were inserted to reach fan-out
  constraint and are unnecessary are removed.

23
Verification

• Biggest challenge in IC design is verification
  because the cost of single error is huge.
• One type of verification methods include
  Simulation, and Emulation and hardwareacceleratio
  n.
• Emulator is a hardware device that can be used to
  emulate a piece of hardware functionality. It is
  commonly used as a debugging tool to test a
  system under development for functional
  correctness.

24
- cont.Verification

• Emulation is a faster solution to verification
• problem. In Emulation a portion of emultable
• design is synthesized and optimized.
• Emulators are able to provide execution
• speed close to real time. This allows
• verification engineers to reduce Verification
• time.

25
Gate-level simulation and Extraction

• Placement and routing involves placement of
  modules on chip area and routing interconnect
  between various modules.

26
Gate-level simulation and Extraction cont.

• Various aspects of signal integrity include
• Technology scale down
• Aluminium has been used until recently to
• manufacture interconnects but increasing
• contribution of interconnects in signal
• propagation has forced IC manufacturers to
• replace it with material like copper with lower
• resistance.

27
Gate-level simulation and Extraction cont.

1. CrossTalk When two wire segments are closer to
   each other more than a minimum threshold, they
   will interfere in each other's functioning.
   Signal on one wire may weaken due to
   electromagnetic effects of signal carried by
   other wire. With diminishing technology size
   Crosstalk is major contributor to high speed IC
   defects.

28
