Muscle Structure and Function

1
Muscle Structure and Function

• Chapter 3

2
Learning Objectives

• To describe muscles macro and micro structures
• To explain the sliding-filament action of
  muscular contraction
• To differentiate among types of muscle fibres
• To describe group action of muscles

3
Types of Muscle

• The human body is comprised of 324 muscles
• Muscle makes up 30-35 (in women) and 42-47 (in
  men) of body mass.
• Three types of
  muscle

4
A. Skeletal (Striated) Muscle

• Connects the various parts of the skeleton
  through one or more connective tissue tendons
• During muscle contraction, skeletal muscle
  shortens and moves various parts of the skeleton
• Through graded activation of the muscles, the
  speed and smoothness of the movement can be
  gradated
• Activated through signals carried to the muscles
  via nerves (voluntary control)
• Repeated activation of a skeletal muscle can lead
  to fatigue
• Biomechanics assessment of movement and the
  sequential pattern of muscle activation that move
  body segments

5
B. Smooth Muscle

• Located in the blood vessels, the respiratory
  tract, the iris of the eye, the gastro-intestinal
  tract
• The contractions are slow and uniform
• Functions to alter the activity of various body
  parts to meet the needs of the body at that time
• Is fatigue resistant
• Activation is involuntary

6
C. Cardiac Muscle

• Has characteristics of both skeletal and smooth
  muscle
• Functions to provide the contractile activity of
  the heart
• Contractile activity can be gradated (like
  skeletal muscle)
• Is very fatigue resistant
• Activation of cardiac muscle is involuntary (like
  smooth muscle)

7
Components of skeletal muscle
d) myofibril c) muscle fibre b)
muscle fibre bundle a) Muscle belly
8
Muscle Fibres

• Cylinder-shaped cells that make up skeletal
  muscle
• Each fibre is made up of a number of myofilaments
• Diameter of fibre (0.05-0.10 mm)
• Length of fibre (appr. 15 cm)
• Surrounded by a connective tissue sheath called
  Sarcolemma
• Many fibres are enclosed by connective tissue
  sheath Perimycium to form bundle of fibres
• Each fibre contains contractile machinery and
  cell organelles
• Activated through impulses via motor end plate
• Group of fibres activated via same nerve motor
  unit
• Each fibre has capillaries that supply nutrients
  and eliminate waste

9
Muscle Teamwork

• Agonist (prime mover)
• - the muscle or group of muscles producing a
  desired effect
• Antagonist
• - the muscle or group of muscles opposing the
  action
• Synergist
• - the muscles surrounding the joint being
  moved
• Fixators
• - the muscle or group of muscles that steady
  joints closer to the body axis so that the
  desired action can occur

10
Bending or straightening of elbow requires the
coordinated interplay of the biceps and triceps
muscles
11
Contractile MachinerySarcomeres

• Contractile units
• Organized in series ( attached end to end)
• Two types of protein myofilaments
• - Actin thin filament
• - Myosin thick filament
• Each myosin is surrounded by six actin filaments
• Projecting from each myosin are tiny contractile
  myosin bridges

12
High microscope magnification of sarcomeres
within a myofibril
13
Contractile MachineryCrossbridge formation and
movement

• Cross bridge movement
• - similar to the stroking of the oars and
  movement of rowing shell
• - movement of myosin filaments in relation to
  actin filaments
• - shortening of the sarcomere
• - shortening of each sarcomere is additive

• Cross bridge formation

  - a signal comes from the motor nerve
  activating the fibre
  - the heads of the myosin filaments
  temporarily attach themselves to the actin
  filaments

Longitudinal section of myofibril
b) Contraction
14
Contractile MachineryOptimal Crossbridge
formation
Longitudinal section of myofibril

• Sarcomeres should be optimal distance apart
• For muscle contraction optimal distance is
  (0.0019-0.0022 mm)
• At this distance an optimal number of cross
  bridges is formed
• If the sarcomeres are stretched farther apart
  than optimal distance
• - fewer cross bridges can form ? less force
  produced
• If the sarcomeres are too close together
• - cross bridges interfere with one another
  as they form ? less force produced

c) Powerful stretching
d) Powerful contraction
15
Contractile MachineryOptimal muscle length and
optimal joint angle

• The distance between sarcomeres is dependent on
  the stretch of the muscle and the position of the
  joint
• Maximal muscle force occurs at optimal muscle
  length (lo)
• Maximal muscle force occurs at optimal joint
  angle
• Optimal joint angle occurs at optimal muscle
  length

16
Muscle tension during elbow flexion at constant
speed
17
Contractile MachineryTendons, origin, insertion

• In order for muscles to contract, they must be
  attached to the bones to create movement
• Tendons strong fibrous tissues at the ends of
  each muscle that attach muscle to bone
• Origin the end of the muscle attached to
  the bone that does not move
• Insertion the point of attachment of the
  muscle on the bone that moves

18
Muscle Fibre Types
19
A. Slow Twitch Fibres

• Suited for repeated contractions during
  activities requiring a force output of lt 20-25
  of max force output
• Examples lower power activities, endurance
  events

20
B) Fast Twitch Fibres

• Significantly greater force and speed generating
  capability than slow twitch fibres
• Well suited for activities involving high power
• Examples sprinting, jumping, throwing

21
The Muscle Biopsy

• Used to determine muscle fibre type
• 1. Injection of local anesthetic into the muscle
  being sampled
• 2. Incision of approximately 5-7mm is made in the
  skin and fascia of the muscle
• 3. The piece of tissue (250-300mg) removed via
  the biopsy needle is imbedded in OCT compound
• 4. The sample is frozen in isopentane cooled to
  180C

22
Muscle Biopsy
23
The Histochemistry

• The biopsy samples are first sectioned (8-10 µm
  thickness)
• Sections are processed for myosin ATPase

• Fast twitch fibres rich in myosin
  ATPase (alkaline labile)
• Slow twitch fibres low in myosin
  ATPase (acid labile)
• Sections are processed for other metabolic
  characteristics

24
Nerve-Muscle Interaction

• Skeletal muscle activation is initiated through
  neural activation
• NS can be divided into central (CNS) and
  peripheral (PNS)
• The NS can be divided in terms of function motor
  and sensory activity
• Sensory collects info from the various sensors
  located throughout the body and transmits the
  info to the brain
• Motor conducts signals to activate muscle
  contraction

25
Activation of motor unit and its innervation
systems

• Spinal cord 2. Cytosome 3. Spinal
  nerve
• 4. Motor nerve 5. Sensory nerve 6. Muscle
  with muscle fibres

26
Motor Unit

• Motor nerves extend from the spinal cord to the
  muscle fibres
• Each fibre is activated through impulses
  delivered via motor end plate
• Motor unit a group of fibres activated via the
  same nerve
• All muscle fibres of one particular motor unit
  are always of the same fibre type
• Muscles needed to perform precise movements
  generally consist of a large number of motor
  units and few muscle fibres
• Less precise movements are carried out by muscles
  composed of fewer motor units with many fibres
  per unit

27
All-or-none Principle

• Whether or not a motor unit activates upon the
  arrival of an impulse depends upon the so called
  all-or-none principle
• An impulse of a certain magnitude (or strength)
  is required to cause the innervated fibres to
  contract
• Every motor unit has a specific threshold that
  must be reached for such activation to occur

28
Intra-muscle Coordination

• The capacity to apply motor units simultaneously
  is known as intra-muscle coordination
• Many highly trained power athletes, such as
  weightlifters, wrestlers, and shot putters, are
  able to activate up to 85 of their available
  muscle fibres simultaneously (untrained 60)
• Force deficit the difference between assisted
  and voluntarily generated maximal force (trained
  10, untrained 20-35)

29
Intra-muscle Coordination cont.

• Trained athletes have not only a larger muscle
  mass than untrained individuals, but can also
  exploit a larger number of muscle fibres
• Athletes are more restricted in further
  developing strength by improving intra-muscular
  coordination
• Trained individuals can further increase strength
  only by increasing muscle diameter

30
Inter-muscle Coordination

• The interplay between muscles that generate
  movement through contraction (agonists) and
  muscles responsible for opposing movement
  (antagonists) is called inter-muscle coordination
• The greater the participation of muscles and
  muscle groups, the higher the importance of
  inter-muscle coordination
• To benefit from strength training the individual
  muscle groups can be trained in relative
  isolation
• Difficulties may occur if the athlete fails to
  develop all the relevant muscles in a balanced
  manner

31
Inter-muscle Coordination cont.

• High-level inter-muscle coordination greatly
  improves strength performance and also enhances
  the flow, rhythm, and precision of movement
• Trained athlete is able to translate strength
  potential to enhance inter-muscle coordination

32
Muscles Adaptation to Strength Training

• Individuals performance improvements occur
  through a process of biological adaptation, which
  is reflected in the bodys increased strength
• Adaptation process proceeds at different time
  rates for different functional systems and
  physiological processes
• Adaptation depends on intensity levels used in
  training and on athletes unique biological
  make-up
• Enzymes adapt within hours, cardiovascular
  adaptation within 10 to 14 days
