Circle Theorems (Including Proofs)

1
(No Transcript)
2
Parts
A Reminder about parts of the Circle
Major Segment
diameter
chord
Minor Segment
Major Sector
Minor Sector
3
Termgy
Introductory Terminology
Arc AB subtends angle x at the centre.
Arc AB subtends angle y at the circumference.
Chord AB also subtends angle x at the centre.
Chord AB also subtends angle y at the
circumference.
4
Th1
5
The angle subtended at the centre of a circle (by
an arc or chord) is twice the angle subtended at
the circumference by the same arc or chord.
(angle at centre)
Watch for this one later.
6
42o (Angle at the centre).
70o(Angle at the centre)
7
(180 2 x 42) 96o (Isos triangle/angle sum
triangle).
48o (Angle at the centre)
124o (Angle at the centre)
(180 124)/2 280 (Isos triangle/angle sum
triangle).
8
Th2
This is just a special case of Theorem 1 and is
referred to as a theorem for convenience.
90o angle in a semi-circle
90o angle in a semi-circle
20o angle sum triangle
90o angle in a semi-circle
60o angle sum triangle
9
Th3
10
Angle x 30o
Angle x angle y 38o
Angle y 40o
11
Th4
12
(No Transcript)
13
If OT is a radius and AB is a tangent, find the
unknown angles, giving reasons for your answers.
180 (90 36) 54o Tan/rad and angle sum of
triangle.
90o angle in a semi-circle
60o angle sum triangle
14
Th5
45o (Alt Seg)
60o (Alt Seg)
75o angle sum triangle
15
Th6
The opposite angles of a cyclic quadrilateral are
supplementary. (They sum to 180o)
Angles p q 180o
Angles x w 180o
Angles y z 180o
Angles r s 180o
16
180 85 95o (cyclic quad)
180 135 45o (straight line)
180 70 110o (cyclic quad)
180 110 70o (cyclic quad)
180 45 135o (cyclic quad)
17
Th7
From any point outside a circle only two tangents
can be drawn and they are equal in length.
18
PQ and PT are tangents to a circle with centre O.
Find the unknown angles giving reasons.
yo
Q
xo
O
90o (tan/rad)
98o
90o (tan/rad)
49o (angle at centre)
360o 278 82o (quadrilateral)
wo
zo
T
P
19
PQ and PT are tangents to a circle with centre O.
Find the unknown angles giving reasons.
zo
Q
O
yo
90o (tan/rad)
xo
180 140 40o (angles sum tri)
50o (isos triangle)
50o (alt seg)
80o
wo
50o
T
P
20
Th8
OS 5 cm (pythag triple 3,4,5)
21
Angle SOT 22o (symmetry/congruenncy)
Angle x 180 112 68o (angle sum triangle)
22
Mixed Q 1
65o (Alt seg)
130o (angle at centre)
25o (tan rad)
25o (isos triangle)
23
Mixed Q 2
22o (cyclic quad)
68o (tan rad)
44o (isos triangle)
68o (alt seg)
24
Worksheet 3
The angle subtended by an arc or chord at the
centre of a circle is twice the angle subtended
at the circumference by the same arc or chord.
A
O
B
C
Theorem 1 and 2
25
Worksheet 4
Angles subtended by an arc or chord in the same
segment are equal.
A
Theorem 3
26
Worksheet 5
The angle between a tangent and a radius drawn to
the point of contact is a right angle.
O
B
T
A
Theorem 4
27
Worksheet 6
The angle between a tangent and a chord through
the point of contact is equal to the angle
subtended by the chord in the alternate segment.
D
B
O
C
T
A
Theorem 5
28
The opposite angles of a cyclic quadrilateral are
supplementary (Sum to 180o).
B
A
C
D
Theorem 6
29
Worksheet 8
The two tangents drawn from a point outside a
circle are of equal length.
Theorem 7
P
Theorem 8
A line, drawn perpendicular to a chord and
passing through the centre of a circle, bisects
the chord.
C
