Congenital Disorder

1
Congenital Disorder
2
Although present at birth masses may not become
clinically apparent until childhood or even
adulthood
3
Congenital neck mass

• Branchial system
• Thyroid gland
• Dermoid
• Teratoid
• vascular

4
Important criteria

• Age of presentation
• Location of the mass
• Associated symptom

5
Thyroglossal duct cyst

• The most common congenital neck mass
• MF
• Majority before age 12

6

• Thyroid gland descent begin in the third week
  complete by the eight week
• As it descent it is intimately associated with
  the hyoid bone which is in the process of fusing
  in the midline

7
It is the failure of thyroglossal duct to
involute that causes thyroglossal duct cysts
8

• The majority of the cysts present at or below the
  level of the hyoid bone in the midline of the
  neck

9
Thyroid arrest ( ectopic thyroid )

• Lingual thyroid
• As far as superior mediastinum

10
Thyroglossal duct cyst ( physical examination )

• Smooth , nontender
• Rise with swallowing
• Cyst infection
• acute ? in size
• skin erythema
• tenderness
• spontaneous
  drainage

11

• connection with the pharynx
• polymicrobial infection
• oral pathogen

12

• Determination of the location of normal thyroid
  tissue is essential prior to the excision of any
  suspected cyst or ectopic thyroid .
• US is the preferred mode of imaging
• In uncooperate child or dense cyst thyroid scan
  should be considered

13
Treatment

• preop. Antibiotic for infected cyst
• Sistrunk excision
• Rarely papillary adenoarcinoma

14
Reccurence

• 10 in Sistrunk
• Failure of hyoid removal
• Failure of remove section of tongue
• Rupture of the cyst
• Resurgery

15
Teratoma dermoid are true developmental
neoplasm

• Arises from pluripotent cells at anatomic sites
  where they are not normally found

16
Dermoid cyst

• Consist ectoderm mesoderm
• Lined by epidermis and contain hair follicle
  sebsceous glands
• Smooth nontender mass in submental region
• Surgical removal

17
teratoma

• Three germ layers
• Disorganized teratoid cyst ? true teratoma (
  epignathi )
• Cervical region
• Firm mobile
• Cystic and solid composition
• Surgical removal

18
Branchial arch anomaly

• Present at birth , clinically apparent at
  childhood
• Develop during third to 7th embryonic week
• Six pairs arches,four paired groove
  externally,four paired pouch internally

19
First arch

• Meckels cartilage
• Maxilla, malleus , incus , mandible
• Sphenomandibular ligament
• Mylohyoid , ant. Belly of digastric, tensor
  tympani , TVP , masseter , temporalis , medial
  lateral pterygoids
• Trigeminal nerve
• Maxillary artery

20
Second arch

• Reichert's cartilage
• Upper body of hyoid bone lesser cornu ,
  stylohyoid ligament , styloid process , stapes
• Muscle of facial expression , platysma ,
  stylohyoid, post. Belly of digastric , stapedius
  muscle
• Facial nerve
• Stapedial artery

21
Third arch

• Greater cornu lesser portion of hyoid bone
• Stylopharyngeous , super and middle constrictor
  of the pharynx
• Glossopharyngeal nerve
• Part of the internal carotid artery

22
Fourth arch

• Thyroid cartilage
• Cricothyroid muscle
• vagus nerve
• arch of the aorta

23
Sixth arch

• Cricoid and arytenoid cartilage
• Corniform corniculate cartilage
• RLN
• Inferior constrictor muscle
• Ductus arteriosus

24
Pharyngeal pouch

• First pouch form ET middle ear cleft
• Second pouch palatine tonsil
• Third pouch inf parathyroid gland thymic duct
• Fourth pouch sup parathyroid gland
• Sixth pouch ultimobranchial body

25
Pharyngeal groove

• First groove external auditory meatus
• The remaining grooves are obliterated by the
  caudal overgrowth of the second branchial arch

26
A cyst is a collection of fluid in an epithelium
lined sac
27

• Groove cyst line with squamous epithelium
• Pouch cyst line with respiratory epithelium
• Sinus tract from epithelial surface to the
  deeper tissue
• Fistula a tract between skin to the pharynx or
  larynx internally

28
Branchial cleft anomaly

• At birth or shortly there after
• Small opening along the anterior border of SCM
• Mocoid discharge with URI
• A complete fistula is uncommon with most ending
  before the pharynx is reached
• Cyst is more common than fistula or sinuses

29
Cont.

• Majority arises from second branchial cleft
• Usual course is recurrent infection
• Early surgical excision
• Recurrent cases preopertive fistulogram

30
First branchial cleft anomaly

• Uncommon
• First category
• absent external auditory canal
• Second category
• Type I Duplication of membranous EAC
• Type II Duplication of membranous bony
  EAC
• At angle of mandible
• Fistulous tract at bony membranous junction

31
Drainage may occur from EAC by palpation of angle
or preauricular mass
32
Preauricular sinus

• Malformation of six hillocks that form the
  auricle .
• Excision

33
Second branchial cleft anomalies

• Most common anomaly
• Opening lower half of the neck
• Anterior border of SCM
• Internal opening If present is in the tonsillar
  fossa
• Surgical removal

34

• First branchial sinuses open anterior to the SCM
  , above the hyoid bone
• Second branchial sinuses open anterior to the SCM
  below the thyroid .

35
The tract runs between the internal external
carotid arteries and passes lateral to the IX
XII and continues inferior to the posterior belly
of the digastric , opening into the tonsillar
fossa
36

• If the fistula opens into the tonsillar fossa ,
  the tonsil should be removed to obtain complete
  exposure .

37
Third branchial cleft cyst

• Very rare Courses posterior and lateral to the
  ICA and CN XII , terminate its course at the
  level of the piriform sinus

38
Lymphangiomas

• Abnormal lymphatic development along the jugular
  lymphatic sac
• 50 present by 1year
• 90 preent by age 2
• Occurs in the sixth week of emberyonic
  development .
• Thin-walled endothelial-lined cysts infiltrating
  into the surrounding tissue

39
Lymphangioma simplex

• Thin-walled lymphatic channel

40
Cavernous lymphangioma

• Large lymphatic channel

41
Cystic hygroma

• Large lymphatic dilatation

42
The lesion present most often in the posterior
cervical triangle of the neck and are soft ,
nontender poorly defined mass that
transilluminate
43

• Surgical excision is the treatment of choice .
• The timing is dependent on the surgeon philosophy
  .
• Early excision for possibility of infection ,
  rapid growth , and potential airway compromise .
• Waiting until 3-4 years of age because of
  involution and technical ease of operation

44
Hemangiomas

• The most common tumor of infancy
• Majority was recognized by the age of 6 months of
  age .
• Defective embryonic development of the peripheral
  vessel .
• Arrested development at the endothelial stage
  gives rise to these subcutaneous vascular mass

45
Type of hemangiomas

• Capillary
• Cavernous
• Juvenile

46

• Soft
• Compressible
• Nonpulsatile bluish mass
• Involvement
• parotid
• Neck
• Tongue
• Skin

47

• Rapid growth in neonatal period
• Involution at 5 years 50
• Involution at 7years 70

48
Lesions that not involve critical structure are
usually observed
49
Imaging

• CT scanning outline the lesion
• Angiography
• diagnosis
• embolization

50

• Symptomatic lesion
• corticosteroid
• interferon-a2a

51
Surgical excision

• Critical area
• Spontaneous bleeding
• Recurrent infection
• consumption coagulopathy

52
Fibromatosis colli

• Congenital tumor of SCM
• Often detected 2-3 weeks after birth
• Firm nontender
• Involved with the underlying muscle
• Torticollis
• Difficult vaginal delivery and traction on the
  HN

53

• Usually resolved by 18 months
• US is diagnostic
• Physical therapy prevent long term difficulty
• Permanent lesion surgery
