Curves

First of all

- You may ask yourselves What did those papers

have to do with computer graphics? - Valid question
- Answer I thought they were cool, unique

applications of computer graphics - This week were looking at scan conversion of

curves

Interpolation

- Bresenhams line drawing algorithm is nothing

more than a form of interpolation - Given two points, find the location of points in

between them - The function (in this case its a line) must pass

through the given points, by definition

Interpolation Usage

- We used Bresenham line drawing (interpolation) to

scan convert a symbolic representation of a line

to a rasterized line - Other applications exist
- Computing calendar years are leap years (believe

it or not) - Line Drawing, Leap Years, and Euclid, Harris and

Reingold, ACM Computing Surveys, Vol. 36, No. 1,

March 2004, pp. 66-80 - Path planning for key frame animation

Key Frame Animation

- Key frames are infrequent scenes that capture the

essential flow of an animation - Think of them as the endpoints of a line
- In between frames (tweens) may be generated by

interpolating between two key frames - Think of these as the points drawn by the

Bresenham algorithm

Approximation

- Another possibility for generating tweens is to

specify tie-points that guide the generation of

the intermediate path points but the path does

not pass through the tie-points - This technique is called approximation or curve

fitting

Curves

- Well look at two techniques for generating

curves (to be used as either paths or drawn

objects) - Interpolation
- Approximation
- Well also see that interpolation is very

restrictive when considering parametric curves - Approximation is a much better approach

Parametric Curves

- Recall the parametric line equations
- The parameter t is used to map out a set of (x,

y) pairs that represent the line

Parametric Curves

- In the case of a curve the parametric function is

of the form - Q(u) (x(u), y(u), z(u)) in 3 dimensions
- The derivative of Q(u) is of the form
- Q(u) (x(u), y(u), z(u))
- Significance of the derivative?
- It is the tangent vector at a given point (u) on

the curve

Derivative

Parametric Curves

- In the case of object drawing, u is a spatial

parameter (like t was for the line) - In the case of key frame animation, u is a

temporal parameter - In both cases Q(0) is the start of the curve and

Q(1) is the end, as was the case for the

parametric line

Parametric Curves

- Curvature
- Curvature k 1/ ?
- The higher the curvature, the more the curve

bends at the given point

Parametric Curves

- From calculus, a function f is continuous at a

value x0 if - In laymans terms this means that we can draw the

curve without ever lifting our pen from the

drawing surface - f(x) is continuous over an interval (a,b) if it

is continuous for every point in the interval - We call this C0 continuity

Parametric Curves

Continuous over (a,b) C0

Continuous over (a,b) C0

Parametric Curves

- From calculus, a functions derivative f is

continuous at a value x0 if - In laymans terms this means that there are no

sharp changes in direction - f(x) is continuous over an interval (a,b) if it

is continuous for every point in the interval - We call this C1 (tangential) continuity

Parametric Curves

Continuous derivative over (a,b) C1

Discontinuous derivative over (a,b) not C1

Parametric Curves

- When we need to join two curves at a single point

we can guarantee C1 continuity across the joint - For the case when we cant make one continuous

curve - Just make sure that the tangents of the two

curves at the join are of equal length and

direction - If the tangents at the joint are of identical

direction but differing lengths (change in

curvature) then we have G1 continuity

Lagrange Polynomials

- To generate a function that passes through every

specified point, the type of function depends on

the number of specified points - Two points ? linear function
- Three points ? quadratic function
- Four points ? cubic function
- Generating such functions makes use of Lagrange

polynomials

Lagrange Polynomials

- The general form is (n is the number of points)
- Lets look at an example

Lagrange Polynomials

- For two points P0 and P1
- For the starting point (t00) and ending point

(t11)

Lagrange Polynomials

- For three points P0 , P1 , and P2
- And it only gets worse for larger numbers of

points - Suffice it to say, this isnt the most optimum

way to draw curves - Too many operations per point
- Too complex if the artist decides to change the

curve - But you could do it

A Better Way

- The problem with Lagrange polynomials lies in the

fact that we try to make the curve pass through

all of the specified points - A better way is to specify points that control

how the curve passes from one point to the next - We do so by specifying a cubic function

controlled by four points - The four points are called boundary conditions

Hermite Boundary Conditions

- Two points
- Two tangent vectors
- Two of the points are interpreted as vectors off

of the other two points

Cubic Functions

- Generalized form
- Derivative
- Our goal is to solve these equations in closed

form so that we can generate a series of points

on the curve

Cubic Functions

- There are four unknown values in the equation
- a, b, c, and D (remember, a, b, c, and D are

vectors in x, y, z so there is actually a set of

3 equations) - We need to use these equations to generate values

of x, y, and z along the curve - We can generate a closed form solution (solve the

equations for x, y, and z) since we have four

known boundary conditions - u 0 ? Q(0) P0 and Q(0) P0
- u 1 ? Q(1) P1 and Q(1) P1

Solution of Equations

- Go to the white board

Implementation

- So, all you have to do to generate a curve is to

implement this vector (x, y, z) equation - by stepping 0 u 1
- P0, P1, P0 and P1 are vectors in x, y, z so

there are really 12 coefficients to be computed

and youll be implementing 3 equations for Q(u)

Implementation

- Note that youll have to estimate the step size

for u or(any ideas?) - use your Bresenham code to draw short straight

lines between the points you generate on the

curve (to fill gaps) - There is no trick (that Im aware of) comparable

to the Bresenham approach

Bezier Curves

- Similar derivation to Hermite
- Different boundary conditions
- Bezier uses 2 endpoints and 2 control points

(rather than 2 endpoints and 2 slopes)

Bezier Curves

Implementation

- So, all you have to do to generate a curve is to

implement this vector (x, y, z) equation - by stepping 0 u 1
- P0, P1, P2 and P3 are vectors in x, y, z so there

are really 12 coefficients to be computed and

youll be implementing 3 equations for Q(u)

Bezier example

Hermite vs. Bezier

- Hermite is easy to control continuity at the

endpoints when joining multiple curves to create

a path - But difficult to control the internal shape of

the curve - Bezier is easy to control the internal shape of

the curve - But a little more (not much) difficult to control

continuity at the endpoints when joining multiple

curves to create a path - Bottom line is, when creating a path you have to

be very selective about endpoints and adjacent

control points (Bezier) or tangent slopes

(Hermite)

Result

- Go to the demo program
- My code generates a Hermite curve that is of C1

continuity - As I generate new segments along the curve I join

them by keeping the adjoining tangent vectors

equal

Homework

- Implement Bezier and Hermite curve drawing
- Parameters should be control points and brush

width - Create a video sequence to show in class
- Demonstrate Bezier and Hermite curves of various

control points and brush widths - Be creative
- Due date Next week Turn in
- Video to be shown in class
- All program listings
- Grading will be on completeness (following

instructions) and timeliness (late projects will

be docked 10 per week)
