ZonePRO Modulating Thermostats

1
ZonePRO Modulating Thermostats

• New Product Introduction
• Technical Training
• July 10, 2006

2
Models and Features

• Models with 1 output
• TB6980A1007 (Floating)
• TB7980A1006 (Analog 0-10V or 2-10V)
• Models with 3 outputs
• TB6980B1006 (1st output is floating)
• TB7980B1005 (1st output is analog 0-10V or 2-10V)
• 2nd output can be configured for
• Analog 0-10V
• Analog 2-10V
• 24V
• 3rd output is 24V only
• Features for all models
• Automatic changeover (duct sensor required)
• Manual changeover (remote switch or relay
  required)
• Night setback
• Min and Max temperature setpoint stops

3
Applications and Accessories

• Hydronic and pressure dependent VAV with or
  without reheat
• Non-programmable
• Up to three outputs depending on model
• Can be used for
• Floating or Analog damper/valve actuator control
• Damper/valve actuator with duct reheat and aux
  heat (B models)
• Hydronic systems (room control, perimeter heating
  and cooling)
• Compatible accessories
• R841 family of electromechanical relays
• 50014156-002 remote room sensor
• 50014157-001 duct temperature sensor
• 32004800-001 bare thermistor

4
Terminal Connections
5
Typical Applications
Relay
24 VAC not COM
TB6980B
Damper control with electric reheat and
auxiliary hot-water heating
6
Typical Applications
Relay
TB7980B
Relay
Damper control with electric reheat and auxiliary
baseboard heating
7
Typical Applications
50014157-001
Relay
TB7980B
Damper control with automatic changeover,
electric reheat and central cooling
8
Typical Applications
50014157-001
Relay
TB6980B
Temperature control of fresh air supply
9
Typical Applications
TB7980B
TB7980B
TB7980B
Changeover and NSB inputs sharing the same 24-Vac
transformer
10
Configuration TB7980B1005
Default configuration
11
Configuration TB6980B1006
Default configuration
12
Configuration menu TB6980B
Output 1 Activation
output 1 default mode
13
Configuration menu TB6980B
Output 1 Modes
14
Configuration menu TB6980B
Output 2 Activation
output 1 default mode
Output 1 jumps at 100 if there is an instant
5F difference
15
Configuration menu TB6980B
Output 2 Modes
16
Configuration menu TB6980B
Output 3 Activation
Output 1 jumps at 100 if there is an instant
5F difference
output 1 default mode
Output 2 jumps at 100 if there is an instant
11F difference
17
Configuration menu TB6980B
Output 3 Modes
18
Configuration menu TB6980B
Output 3 Activation Contact Mode
output 1 default mode
19
Configuration and Operation

• Configuration
• Dip switches
• Temperature display, F or C (SW1)
• Access mode (SW2)
• Output 2 type (SW6)
• This sets output 2 type (analog or triac)
• Operation
• Backlight (on for 12 seconds)
• Temperature setting by 1 increments (2F in
  changeover)
• Output display (Hold Override for 4 seconds)

20
Operation (continued)

• Operation
• Changeover
• Manual changeover (contact)
• Automatic changeover (9F differential between
  duct and room)
• Night setback
• Override (2 hours)
• Error codes
• E1 (internal sensor defective)
• E2 (internal sensor shorted)
• E3 (external temperature sensor defective or not
  connected)
• E4 (external temperature sensor shorted)

21
System Components
22
Literature and Point of Purchase Materials
All ZonePRO sales, technical and PowerPoint
materials can be downloaded at customer.honeywell.
com/buildings
