Title: Using ASP'NET Rich Controls


1
Using ASP.NET Rich Controls
  • Introduction to ASP.NET
  • By Kathleen Kalata

2
Objectives
  • In this chapter, you will
  • Learn how ASP.NET Rich controls can enhance your
    Web applications
  • Identify the format and structure of an XML
    document
  • Create an XSLT stylesheet
  • Read and display an XML data file using the XML
    controls
  • Create a rotating banner advertisement on the Web
    page using the AdRotator control
  • Create an interactive calendar using the calendar
    control
  • Create ASP.NET pages that allow you to upload a
    file to the Web server

3
XML Technologies
  • Extensible Markup Language (XML), like HTML, is a
    markup language that provides access to
    structured content
  • But, unlike HTML, XML is not limited to a set of
    tags or to being displayed in a browser
  • XML allows you to define your own elements
  • XML documents can be shared across applications,
    file systems, and operating systems
  • The XML standards are maintained by the World
    Wide Web Consortium (www.w3c.org) and
    http//www.w3c.org/XML

4
XML Technologies
  • The XML document can be formatted using a style
    sheet known as XSLT stylesheets
  • XSL Transformations (XSLT) is a language for
    transforming XML documents
  • XSLT stylesheets use XSLT to interact with an XML
    document
  • XSLT stylesheets can format individual or groups
    of elements within the XML document
  • XSLT is a form of XSL that transforms the XML
    data using processing rules in the XSLT stylesheet

5
XML Technologies
6
XML Editing Tools
  • View the XML document using an XML parser
  • MSXML Parser is built into Internet Explorer
  • XML documents can be used by other types of
    applications such as Window Forms
  • Create the XML documents using
  • Simple text editor such as Notepad
  • Visual Studio .NET provides HTML/XML editor
  • Microsoft XML NotePad called xmlpad.exe
  • File extensions
  • Generally saved with the file extension .xml

7
XML Introduction
  • An XML document must be well-formed
  • A well-formed document follows XML standards and
    can therefore be read by any XML parser
  • There can be only one root element, within which
    all other elements are nested
  • You cannot mix nesting elements
  • ltbgtWelcome to ltigtTara Storelt/bgtlt/igt
  • ltbgtWelcome to ltigtTara Storelt/igtlt/bgt
  • Enclose the values of properties within double
    quotation marks
  • XML is case sensitive. The case for the opening
    and closing tags of an element must match

8
The Prologue
  • The first section, known as the prologue,
    contains global information such as the XML
    version, formatting information, and schema
    definitions
  • The question mark indicates that this tag, XML,
    is a processing instruction and therefore does
    not contain data. The Character-encoding property
    describes any coding algorithms
  • lt?xml version"1.0" encoding"utf-8" ?gt
  • Add a reference to a CSS stylesheet in an XML
    document to an external Cascading Style Sheet
    (CSS) or an XSL file to format the XML document
  • lt?xmlstylesheet type"text/css"
    href"taragifts.css"gt

9
The Body
  • The XML document complies with the XML DOM
    standards
  • The XML DOM states that XML documents must have a
    logical structure
  • The root container element (node) must nest all
    the elements and data
  • The root node can contain many other elements
  • All tags must be nested within the root node (or
    root tag)
  • The root node is a container element because all
    elements must be nested within the root element
    in an XML document

10
Sample Root Node
  • Productlist is the root node and contains other
    nodes
  • ltproductlistgt
  • ltproductgt
  • ltcodegt387-463-55-00lt/codegt
  • ltnamegtWaterford Crystal Shamrock
    Paperweightlt/namegt
  • ltpricegt99.00lt/pricegt
  • ltcategorygtWaterfordlt/categorygt
  • ltimagegt547.giflt/imagegt
  • ltratinggt4lt/ratinggt
  • lt/productgt
  • lt/productlistgt

11
Modifying an XML document
  • You can edit XML data manually in XML view, or in
    Data view which allows you to enter the data
    using a table structure
  • The XML view supports IntelliSense and color
    coding to help you create your XML code
  • Create a new ASP.NET Web application named
    Chapter4, create an images folder, import the
    project images, and import the products.xml file
    which contains eight products
  • Modify the products.xml file and use the XML
    Designer in Visual Studio .NET

12
Add a Product Node Using XML View
  • Add the product using the XML view
  • ltproductgt
  • ltcodegt387-463-55-00lt/codegt
  • ltnamegtWaterford Crystal Shamrock
    Paperwightlt/namegt
  • ltpricegt120.00lt/pricegt
  • ltcategorygtGiftslt/categorygt
  • ltimagegt547.giflt/imagegt
  • ltratinggt2lt/ratinggt
  • lt/productgt

13
Modify a Product Node Using Data View
14
Using Special Characters in an XML Document
  • Certain character entities are not supported
    within the tags because they are used to separate
    XML elements
  • Replace these characters with the equivalent
    element markup codes

15
XSLT Stylesheets
  • The XSTL stylesheet is an XML document that
    contains information about how to format a
    different XML document
  • The XSLT stylesheet can contain HTML, style
    rules, and XSTL commands
  • The first line identifies the version of XML and
    a root node is used to indicate that the document
    is an XSTL stylesheet
  • The name for the root node for the XSLT
    stylesheet is xslstylesheet
  • Add comments using the lt! - - and - - gt tags
  • The usual file extension for a cascading style
    sheet is .css and for the XSLT stylesheet is .xsl

16
XSLT Stylesheets
  • The xmlnsxsl attribute indicates the schema to
    be supported for the stylesheet
  • The schema or rules are the XSL Transform
    standards which are maintained by the W3C
  • These standards describe how XSLT stylesheets are
    used to format XML documents
  • Close the root element
  • ltxslstylesheet version"1.0"
  • xmlnsxsl"http//www.w3.org/1999/XSL/Transform"gt
  • lt!- - Put your formatting code here - - gt
  • lt/xslstylesheetgt

17
Formatting the Main Template
  • The main template is indicated by the match
    attribute with a forward slash and is used to
    format the XML document
  • You must match the root node of the existing XML
    document. This is used by the XSLT processor to
    read the document and to know where to start
    formatting the document
  • You do not have to use all of the elements that
    are contained within the XML document
  • You can nest basic HTML tags within the templates
  • The xslfor-each statement is a processing
    instruction that is applied to the node provided
    in the selected attribute
  • CSS Classes can be applied to format the XML
    elements

18
Formatting the Main Template
  • Displays the product name, a colon, and the
    category, followed by a line break tag
  • ltxsltemplate match"/"gt
  • lthtmlgtltheadgtlttitlegtTara Store Product
    Listlt/titlegt
  • ...lt/headgt
  • ltbodygt
  • ltH1gtProducts and their categories.lt/H1gt
  • ltxslfor-each select"//product"gt
  • ltxslapply-templates select"name" /gt
  • ltxslapply-templates select"category" /gt
  • ltbr /gt
  • lt/xslfor-eachgt
  • lt/bodygtlt/htmlgtlt/xsltemplategt

19
The Main Template
  • There is a template in the page outside of the
    main template that contains the formatting
    instruction for each element in the main template
  • ltxsltemplate match"/"gt
  • lthtmlgtltheadgtlttitlegtTara Store Product
    Listlt/titlegt
  • ...lt/headgtltbodygt...
  • ltxslfor-each select"//product"gt
  • ltxslapply-templates select"name" /gt
  • ltxslapply-templates select"category" /gt
  • ltxslapply-templates select"code" /gt
  • ltxslapply-templates select"price" /gt
  • ltxslapply-templates select"rating" /gt
  • lt/xslfor-eachgt
  • ... lt/bodygtlt/htmlgtlt/xsltemplategt

20
Formatting the Elements Using Element Templates
  • You can define individual templates for
    individual elements
  • The match attribute indicates the name of the
    element to apply the template
  • The xslvalue-of attribute indicates that the
    value of the element is retrieved and displayed
  • To display the contents of any node, use
    ltxslvalue-of select"." /gt
  • The period means that everything within the node
    is selected
  • ltxsltemplate match"product"gt
  • ltbgtltxslvalue-of select"." /gt lt/bgt
  • lt/xsltemplategt

21
Formatting the Elements Using Element Templates
  • If you want a template to apply to all the other
    elements, you can use an asterisk as the value
    for the match property
  • ltxsltemplate match""gt
  • ltdiv class"product"gt
  • ltxslvalue-of select"."/gt
  • lt/divgt
  • lt/xsltemplategt

22
Formatting the Elements Using Element Templates
  • The DIV tag uses the class defined in the
    embedded style sheet to determine how to format
    the output
  • ltxsltemplate match"name"gt
  • ltdiv class"product"gt
  • ltbgtProduct Name
  • ltxslvalue-of select"." /gt
  • lt/bgtltbr /gt
  • lt/divgt
  • lt/xsltemplategt

23
Create a Simple XSLT Stylesheet
  • Create listproducts.xsl to display the data in
    the products.xml file
  • In listproducts.xsl indicate the XSL stylesheet
    standard version
  • Add the prologue
  • Add the code to create the main template, and the
    for-each processing instruction
  • Add the element templates

24
Using the XML Control
  • Document property - indicates that the XML data
    is located in an object called XMLDocument
  • DocumentContent property indicates that the XML
    data is a string containing the entire text of
    the XML document
  • DocumentSource allows you to identify a physical
    or virtual path to the XML document
  • Transform property - where the style information
    is located
  • XSLTransform object contains the XSL or XSLT
    stylesheet
  • TransformSource attribute identifies the physical
    or virtual path to the XSL or XSLT stylesheet

25
Using the XML Control
  • Visual Studio .NET provides a graphical tool in
    the toolbox to insert the XML control
  • ltaspXml runat"server" id"Xml1"
  • TransformSource"listproducts.xsl"
  • DocumentSource"products.xml" /gt

26
Create the WebForm
  • Create a Web page named listproducts.aspx that
    displays an XML document named products.xml using
    an XSLT stylesheet
  • DocumentSource property to products.xml
  • TransformSource property to listview.xsl

27
listproducts.aspx
28
listproducts.aspx
29
Modifying XSLT Stylesheets
  • You can specify attributes for any of the HTML
    properties in the template using the
    xslattribute command
  • Create a hyperlink
  • ltxsltemplate match"image"gt
  • ltagt
  • ltxslattribute name"href"gt
  • ltxslvalue-of select"." /gt
  • lt/xslattributegt
  • Click here to go to the Web site.
  • lt/agt
  • lt/xsltemplategt

30
Inserting a Table with XSLT Stylesheets
  • The heading and closing table tag of the table is
    separated outside of the for-each loop so that
    the heading only appears once
  • ltxsltemplate match"/"gt
  • lttable border"0" cellspacing"10"gt
  • lttrgtltthgtImagelt/thgt...ltthgtPricelt/thgtlt/trgt
  • ltxslfor-each select"//product"gt
  • lttrgt
  • lttdgtltxslapply-templates select"image"/gtlt/tdgt
  • ...
  • lttdgtltxslapply-templates select"price"/gtlt/tdgt
  • lt/trgt
  • lt/xslfor-eachgt
  • lt/tablegt
  • lt/xsltemplategt
  • ...

31
Inserting an Image with an XSLT Stylesheet
  • ltxsltemplate match"image"gt
  • ltimggt
  • ltxslattribute name"src"gt
  • ltxslvalue-of select"." /gt
  • lt/xslattributegt
  • ltxslattribute name"align"gt
  • left
  • lt/xslattributegt
  • lt/imggt
  • lt/xsltemplategt

32
Write Out Text
  • The xsltext instruction is used to write out the
    value of the text such as special control
    characters
  • The disable-output-escaping attribute is used to
    generate characters without escaping such as the
    single lt character
  • Creates a hyperlink to a URL, and passes the name
    of the image in a querystring
  • You are creating an anchor tag that will create a
    basic hyperlink such as
  • lta href "ProcessingPage.aspx?ImageUrl15.jpg"gt
    Belleek Frames Clockslt/agt

33
Create Hyperlinks
  • ltxsltemplate match"/"gt
  • ltxslfor-each select"//Category"gt
  • ltxslapply-templates select"ImageUrl" /gt
  • ...
  • lt/xslfor-eachgtlt/xsltemplategt
  • ltxsltemplate match"ImageUrl"gt
  • ltagt
  • ltxslattribute name"href"gtimages/
  • ltxslfor-each select"."gt
  • lt/xslattributegtClick here to see the image.
  • lt/agt
  • lt/xsltemplategt ...

34
Processing XML Data with an XSLT Stylesheet
  • XSLT stylesheets can analyze the contents of the
    element and performs actions
  • Stylesheet
  • .over font-familyVerdana font-size11pt
  • colorgreen font-weightbold
  • .under font-familyVerdana font-size10pt
  • colorred font-weightbold
  • Main Template
  • ltxslfor-each select"//product"gt
  • ltxslapply-templates select"name"/gt
  • ltxslapply-templates select"rating"/gt
  • lt/xslfor-eachgt

35
Processing XML Data with an XSLT Stylesheet
  • Element Templates
  • ltxsltemplate match"name"gt
  • ltdiv class"product"gt
  • ltbgtltxslvalue-of select"." /gtlt/bgt
  • lt/divgt
  • lt/xsltemplategt

36
Additional XSL Commands
  • xslchoose - to analyze the value of the rating
  • xslwhen if the condition in the test attribute
    is met
  • The greater than sign is written as gt because
    the XML parser may interpret as XML
  • You can use the period (.) to represent the
    element data or the element name
  • xslotherwise - to apply when no choice listed is
    met
  • xslsort command to sort the data
  • xslif statement - similar to the xslif-else-end
    if
  • string-length - tests the length of the element

37
Additional XSL Commands
  • ltxsltemplate match"rating"gt
  • ltxslchoosegt
  • ltxslwhen test". gt 3"gt
  • ltspan class"over"gt
  • ltimg src"clover.gif" align"bottom"
  • hspace"5"/gt Excellent! lt/spangt
  • lt/xslwhengt
  • ltxslotherwisegt
  • This is within current projections.ltbr /gt
  • lt/xslotherwisegt
  • lt/xslchoosegt
  • ...lt/xsltemplategt

38
XML Schemas
  • To eliminate confusion when working with multiple
    XML documents, XML documents can identify a
    namespace associated with the document
  • This set of rules or namespace is called a schema
  • Schemas are used to define the structure,
    content, and semantics of XML documents
  • The schema can be written in a Document Type
    Definition (DTD) document or an XML Schema
    document
  • Parsers use the schema to determine the rules to
    validate the XML data. The XML parser will use
    that schema to validate the structure of the XML
    document

39
XML Schemas
  • Below is the DTD that is used with Web pages that
    comply with the strict HTML 4.0 standards. The
    DTD must be the first line in the Web page before
    the beginning lthtmlgt tag
  • lt!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01//EN"
  • "http//www.w3.org/TR/html4/strict.dtd"gt
  • When you create an ASP.NET page with Visual
    Studio .NET, the property used to identify the
    schema is called TargetSchema

40
Create a Schema for an XML Document
  • View the inventory.xml
  • Create a Schema named inventory.xsd using Visual
    Studio .NET based on inventory.xml. Visual Studio
    can create a schema for you based on an existing
    XML document within the XML Designer. The schema
    document file extension is .xsd
  • Modify the schema using the Schema view of the
    XML Designer. The DataSet view displays the
    schema using tables, while the XML view displays
    the schema using XML code
  • The xmlns attribute is added to the element to
    identify the XML schema document associated with
    the XML document as shown in the sample code
    below
  • ltelementname xmlns"http//tempuri.org/schemaname
    .xsd"gt

41
XML Schema in DataSet View
42
The AdRotator Control
  • The AdRotator control allows you to display a
    banner ad on a Web page
  • The AdRotator control class is contained within
    the System.Web.UI.WebControl.AdRotator namespace
  • The Advertisement File is an XML document that
    stores the ad information
  • The Web page is an ASP.NET page that contains a
    WebForm which displays the ads
  • The banner ad is a hyperlinked image

43
Advertisement File
  • External XML document which contains information
    that creates the HTML image tag, inserts the
    image, and creates the hyperlink using an anchor
    tag
  • The filename has the file extension .xml
  • The first line of the AdvertisementFile indicates
    the version of the XML document
  • lt?xml version"1.0" encoding"utf-8" ?gt
  • The rest of the file is contained within a root
    node named advertisements
  • The ad tag is an element that contains the
    individual properties for each ad used to create
    the image and hyperlink

44
Ad Properties and Methods
  • Each ad contains several properties that are used
    to create the image and hyperlink
  • ImageURL is used to create the SRC property in
    the image tag. Only images in the format of JPG,
    GIF, or PNG
  • NavigateURL is used to create the href property
    within the anchor (ltagt)
  • AlternateText is used to create the ALT property
    of the image tag

45
Ad Properties and Methods
  • Impressions property - used to indicate the
    frequency with which the banner ad is displayed.
    Refer to your log files to determine the exact
    number of times that the ad was displayed
  • Keyword property - used to indicate one or more
    words that categorize the banner ad
  • KeywordFilter method - screens the banner ads in
    the XML file where the keyword property matched

46
Advertisement File
  • Sample
  • ltAdvertisementsgt
  • ltAdgt
  • ltImageUrlgtbanner1.giflt/ImageUrlgt
  • ltNavigateUrlgthttp//www.course.com/
    lt/NavigateUrlgt
  • ltAlternateTextgtCourse Technologylt/AlternateTextgt
  • ltImpressionsgt60lt/Impressionsgt
  • ltKeywordgtBookslt/Keywordgt
  • lt/Adgt
  • ...
  • ltAdvertisementsgt

47
Creating the Advertisement File
  • Add a new banner ad to the AdvertisementFile in
    XML view, then,
  • ltAdgt
  • ltImageUrlgtimages/547.giflt/ImageUrlgt
  • ltNavigateUrlgtgetproduct.aspx?id547.gif
  • lt/NavigateUrlgt
  • ltAlternateTextgtWaterford Crystal Shamrock
  • Paperweightlt/AlternateTextgt
  • ltImpressionsgt10lt/Impressionsgt
  • ltKeywordgtWaterfordlt/Keywordgt
  • lt/Adgt

48
Creating the Advertisement File
  • Add a new record in DataView
  • ImageUrl images/803.gif
  • NavigateUrl getproduct.aspx?id803.jpg
  • AlternateText Traditional Music of Ireland
  • Impressions 10
  • Keyword Music

49
Inserting an Ad in Data View
50
Inserting the AdRotator Control
  • The control is identified with the prefix ASP,
    AdRotator, and a semicolon (ltaspAdRotatorgt)
  • Set the runat property to server
  • Configure the AdvertisementFile property to point
    to the location of the Advertisement File
  • Set the ID property
  • Set the height and width properties
  • Close the tag with /gt or lt/aspAdRotatorgt
  • ltaspAdRotator runat"server" id"AdRotator1"
  • AdvertisementFile"ads.xml"
  • KeywordFilter"Waterford" /gt

51
Additional Properties of the AdRotator Control
  • Style properties - can be set such as
    BorderColor, BorderWidth, BorderStyle, Visible,
    TabIndex, and absolute positioning
  • ToolTip property - stores a message as a string
    used by browsers that display the message in the
    ToolTip when the user mouses over the banner
  • Target property - the window to open the new
    link. Default is set to _top
  • KeywordFilter property - retrieves only the
    banner ads from the XML document where the
    Keyword matches exactly. Use quotation marks

52
displayBanner.aspx
  • Create a banner advertisement
  • Set the KeywordFilter property to Waterford
  • Set the AdvertisementFile property to ads.xml
  • Import the getproducts.aspx and add the code in
    the Page_Load handler that retrieves the value
    from the URL and displays the image
  • Dim imagename As String
  • imagename Page.Request.QueryString("ID")
  • Image1.ImageUrl "images/" imagename

53
displayBanner.aspx
54
The Calendar Control
  • The Calendar control is created by the Calendar
    class
  • The Calendar class is located in the
    System.Web.UI.WebControls.Calendar namespace
  • The calendar displays a single calendar month
  • By default, the current month is displayed
  • You can configure the appearance of the calendar
    by setting the properties of the calendar control
  • You can create programs that interact with the
    calendar using methods and event handlers

55
The Calendar Control
  • The name of the control includes the prefix ASP
    followed by calendar
  • The runat property must be assigned to server
  • Assign a value to the ID property
  • Close the tag with /gt or lt/aspCalendar
  • ltaspcalendar id"MyCal" runat"server" /gt
  • Style properties can modify the background color,
    text color, font face, size, and style,
    alignment, width and height, wrapping, and border
    style
  • You can also assign a CSS class to the property
    which can be used to configure the styles from an
    external style sheet

56
Calendar Style Properties
57
Calendar Style Properties
  • DayHeaderStyle sets the style for the days of the
    week
  • DayStyle sets the style for the individual dates
  • NextPrevStyle sets the style for the navigation
    controls in the heading
  • OtherMonthDayStyle sets the style for dates that
    are not in the current month
  • SelectedDateStyle sets the style for the dates
    that were selected
  • SelectorStyle sets the style for the month date
    selection column
  • TitleStyle sets the style for the title in the
    heading

58
Calendar Style Properties
  • TodayDateStyle sets the style for the current
    date
  • WeekendDayStyle sets the style for weekend dates
  • ShowDayHeader property shows or hides the days of
    the week heading row
  • ShowGridLines property shows or hides the
    gridlines which divide the days of the month.
    ShowTitle property shows or hides the title in
    the heading
  • ShowNextPrev property shows or hides the
    navigation controls. Navigation controls are used
    to navigate to the next or previous month

59
Calendar Properties and Methods
  • SelectionChanged event occurs when the user
    clicks a new date. This event changes the
    selected date to a new selected date
  • SelectedDate property is the new selected date.
    The calendar control visually indicates to the
    user which date is selected
  • ToShortDateString property of the SelectedDate
    displays the selected date using the short date
    format as mm/dd/yyyy
  • VisibleMonthChanged event occurs when the user
    clicks on the next or previous month hyperlinks

60
Retrieving Multiple Selected Dates
  • To refer to each date selected by its position
    within the SelectedDates object
  • MyCalendar.SelectedDates(i)
  • SelectedDates object can be used to retrieve
    the multiple values selected. Use a For-Next loop
    to iterate through each date that was selected
  • Count property - provides the number of dates
    that were selected
  • Index position - the position within the object

61
Create a Calendar
  • Insert a calendar control in a Web page and set
    the properties of the calendar control
  • Create an event handler which will detect when
    the user clicks on a new date, and display a
    message in the Web page indicating the value of
    the new date
  • You will use an if-then control structure to
    determine if the date selected is the current
    date
  • If the date selected is the current date, you
    will display a different message in the label
    control
  • The Page_Load code executes when the user clicks
    on a new date and changes the text property of a
    label control named Label1

62
Create a Calendar
  • The message displayed includes a string message.
    Use the ToShortDateString property for both date
    objects when comparing the dates
  • Private Sub Calendar1_SelectionChanged(...)
  • Label1.Text "You selected " _
  • ChrW(60) "br" ChrW(62) _
  • ChrW(60) "br" ChrW(62)
  • If Calendar1.SelectedDate.ToShortDateString()
    Date.Now.ToShortDateString() Then
  • Label1.Text _
  • "Today all Waterford products are 30 off."
  • Else
  • Label1.Text _
  • "Today all products are 10 off during this
    month."
  • End If
  • End Sub

63
calendar.aspx
64
The File Upload Control
  • The file upload control allows you to upload a
    file to a Web server
  • The file upload control is not listed as a rich
    control but can significantly enhance your
    application
  • Modifying the Form
  • The file upload control is an HTML server control
    known as the InputFile HTML Server Control
  • The file upload control class inherits from the
    System.Web.UI.HTMLInputControl namespace
  • Security Issues
  • You do not need to set permissions to allow
    anonymous users to create and write to the folder

65
Creating the File Upload Page The Form Tag
  • Enctype attribute is set to multipart/form-data
    and indicates that there is a file attached to
    the URL request
  • ltform enctype"multipart/form-data"
    runat"server"gt
  • ltinput id"uploadFilePath" type"file"
  • size"40" name"txtFileName" runat"server"gt
  • ltinput id"FileName" type"text" runat"server"gt
  • ltbr /gtltbr /gt
  • ltinput typebutton id"btnUpload"
  • value"Upload a File" runat"server"
  • OnServerClick"btnUpload_Click"gt
  • lt/formgt

66
Other Properties
  • Accept attribute - allows you to specify the MIME
    formats that can be uploaded
  • Accept image/jpg - upload only JPEG images
  • image/ - upload any image type
  • Enter multiple MIME formats delimited with a
    comma
  • MaxLength property - to limit the length of
    filename
  • Size attribute - to set the textbox width
  • ltINPUT id"uploadFilePath" type"file"
    MaxLength"50"
  • size"40" name"txtFileName" runat"server"
  • Accept "images/, text/css, text/htm"gt

67
Uploading the File
  • The file is uploaded using the HTTPPostedFile
    class
  • To save the file you must call the
    PostedFile.SaveAs command and pass the path to
    the file on the clients computer
  • The PostedFile allows you to upload the file,
    manipulate the file, and retrieve information
    about the file
  • Private Sub btnUpload_ServerClick(...)
  • strFilePath "c\upload\images\"
    txtFileName.Value
  • uploadFilePath.PostedFile.SaveAs(strFilePath)
  • End Sub

68
The Path Object
  • The Path object is derived from the System.IO
    namespace
  • MapPath method maps the path to a file. Written
    as Server.Mappath(filename)
  • GetExtension method retrieves the file extension
  • FileName property retrieves the complete filename
    on the clients computer

69
The Path Object
  • Retrieve the path and filename from the uploaded
    file and Path object
  • Dim UploadedFile as HttpPostedFile _
  • UploadedFile.PostedFile
  • Dim FilePath As String UploadedFile.FilePath
  • Dim FileName As String Path.GetFileName(FilePath)
  • Dim FileExtension As String Path.GetExtension(Fi
    leName)
  • Dim ContentType As String UploadedFile.ContentTy
    pe

70
Retrieving Information About the File
  • ContentLength property - obtains the size of the
    file
  • ContentType property - detects the MIME type
  • FileName property - retrieves the path, filename,
    and file extension
  • Dim UploadedFile as HttpPostedFile _
  • UploadedFile.PostedFile
  • If UploadedFile.ContentLength nothing then
  • "No file was selected. Pick a file to upload."
  • Else
  • "The file has been uploaded."
  • End if

71
uploadfile.aspx
  • Create a login form. After the user is
    authenticated, the file upload control is shown
  • Authenticated users are allowed to upload the
    file to the Web server
  • Here is the code to upload the file
  • Dim strFilePath As String
  • strFilePath
  • System.IO.Path.GetDirectoryName(Server.MapPath("u
    ploadfile.aspx"))
  • uploadFilePath.PostedFile.SaveAs((strFilePath
    "\" txtFileName.Value))

72
uploadfile.aspx
Write a Comment
User Comments (0)
About PowerShow.com
