Wafer Bonding using Dielectric Glues for 3D IC Technology

1
Wafer Bonding using Dielectric Glues for 3D IC
Technology
Yongchai Kwon, Jian-Qiang Lu, Russell P. Kraft,
John F. McDonald, Ronald J. Gutmann and Timothy
S. Cale
Rensselaer Polytechnic Institute
2
Desired Properties of Bonding Glue

• Wafer bonding of fully processed 200 mm wafers
  requires
• intimate contact over the entire wafer
• compatibility with both conventional BEOL
  processes and subsequent thinning and inter-chip
  interconnection
• Approach use of a dielectric "glue" layer with
  the following desired properties

• Good adhesion and cohesion
• - Substrate to glue (adhesive)
• - Glue to glue (cohesive)
• No outgassing during bonding process
• Stability over range of BEOL processing
  conditions
• - high glass transition temperature
• - rigid structure after bonding
• CTE of glue well-matched to that of substrate
• Low stress relaxation and creep
• Low moisture uptake

3
Glue Materials and Process

• Low-k materials under evaluation
• - Spin-on amorphous polymers
• Coating and baking with FlexiFabTM
  system
• ? FlareTM (Poly arylene ether)
• ? Accuspin T18 (MSQ Methylsilsesquioxan
  e)
• ? FOX (HSQ Hydrogensilsesquioxane)
• ? CycloteneTM ( DVS-BCB
  Divinylsiloxane-Benzocyclobutene)
• - Vapor-deposited polymer
• Deposition with SCS PDS 1050 system
• ? Parylene-N
• All bonding (curing) processes were carried out
  with a
• EVG 501 bonder system

4
EVG 501 Bonder and Cross-Sectional View
Pneumatic cylinder
Uniforce Compliant Membrane
Top and bottom heater
Key programmable parameters - Temperature,
Pressure and Time - Temperature ramp-up and
cool-down speeds - Vacuum 10-4 mbar or inert
gas
5
Main Parameters of Bonding Process Using Spin-On
Polymers
Two wafers with glue layers are placed
glue-to-glue, separated by three flags

• Pre-cleaning
• Spin-on recipes
• Baking process to release solvent
• ? Baking temperature
• ? Baking time
• ? Flow of N2 gas
• Bonding(curing) process
• ? Temperature ramp up speed
• ? Final cure temperature
• ? Final cure time
• ? Applied pressure
• ? Pressure vs. time protocol
• ? Cool down speed

Uniforce Compliant Membrane
(a)
Down Force
Top Wafer
Bottom Wafer
Bottom Chuck
Flag
Down Pressure
(b)
Top Wafer
Bottom Wafer
Bottom Chuck
6
Bonding Process with Dielectric Glues
Pressure
Polymer resin
Substrate
Flags
Glue interdiffusion
Fully crosslinked glue
After alignment

• Before bonding, two wafers are separated by flags
  on the wafer edge
• During bonding process, glue polymers on each
  wafer interdiffuse when held near the glass
  transition temperature
• Pressure enhances the polymer interdiffusion and
  crosslinking

7
FTIR Result of Flare
C-H
C-H

• Solvent (Cyclohexanone) peak (C-H and CO bond)
  disappeared after bake
• No peak difference between after baking and
  after curing of a flare deposited on a prime Si
  Wafer

CO
CO
? No outgassing after final bake
Wavenumbers (cm-1)
8
Wafer Bonding Result Using Flare
Large clean void-free bonded area
Small voids may be caused by particles and/or
defects.

• Bonded wafer pair (200mm)
• Si wafer P(100) prime wafer
• Glass wafer Corning 7740

Sufficient for fabrication of via chain test
structure
9
Bonding Results Using Other Glues
(Corning glass to prime Si wafer)
Possible void source with MSSQ Outgassing
Void
Possible void source with Parylene-N
Small amount of interdiffused polymers

Parylene-N
10
Possible Void Sources with Flare
Polymer structural defect
Particle

• Bonded wafer pair (200mm)
• Si wafer P(100) prime wafer
• Glass wafer Corning 7740

100 ?m
11
Cross-Section of Bonded Wafers Using Flare
Glass
Glass
Flare
Flare
Si
Si
SEM micrograph Good adhesion without void
Section of bonded wafer pair
12
Bonded Wafer Interface
Void
Non-bonding area
Glass
Glass
Flare
Si
Si
Flare
Cross-section view of Si to glass bonding
Top view of Si to glass bonding
SEM micrographs
Glass
Glass
Glass
Flare
Flare
Si
Si
Flare
Bonding area
13
Initial Bonding Integrity Results with Flare

• Objective
• Bond integrity inspection by monitoring
• the change of the number and size of voids
• Methods
• - Thermal Cycling Test
• ? Heating/cooling test of bonded wafer
• (50 oC/min. ramp up, 60 oC/min. cool
  down)
• ? Good bond integrity after thermal
• cycling test
• - Wafer Thinning
• ? Grinding of 200 mm Si wafer in bonded
• wafer pair to 60 ?m thickness
• ? Good bond integrity after silicon wafer
• thinning to 60 ?m

Before cycling
After cycling
After grinding
Before grinding
14
Summary and Conclusions

• Dielectric glues for wafer bonding provide high
  bond strength, high bonding yield and
  compatibility with BEOL processes
• Flare has superior bonding properties compared
  to other glues studied to date
• Key parameters of wafer bonding process include
  pre-cleaning, applied pressure and holding time,
  and ramp-up/cool-down speed
• Bonding defects need to be reduced, but current
  process capability is adequate for
  first-generation via-chain test structure

15
Future Work

• Reduction of defect density of bonded wafer with
  Flare
• Bonding of damascene patterned wafers for
  via-chain test structure
• Wafer bonding using other dielectric glues (e.g.
  BCB)
• Quantitative evaluation of bonding strength
• Evaluation of bonding integrity including thermal
  and thermomechanical stability
