407C Refrigerant

1
The Hashemite University of JordanFaculty of
EngineeringDepartment of Mechanical Engineering

• 407C Refrigerant

Mohammad Hammoudi 631295
Mohammad Al-Shrah 631294
2
INTRODUCTION

• On refrigerated ships (reefers), besides R22, the
  main refrigerants used are R410A, R407C and
  R404A. In 1993, five refrigerated ships using
  ammonia were built.
• Since then, ammonia has no longer been used,
  except on fishing boats.
• Indirect systems using brines such as calcium
  chloride, and plate exchangers, are the most
  commonly used.

3
INFORMATION

• the R-407C is a blend refrigerant of HFC32,
  HFC-125 and HFC-134a.
• It is a long life substitute of R22, harmless to
  Ozone
• It is used in various of air conditioner, and
  non-centrifugal refrigeration system.
• Retrofit of existing R-22 systems. However, 407C
  should not be used as a direct, "drop-in"
  replacement.
• Also, you should not use 407C in equipment that
  uses a flooded evaporator because of the
  zeotropic behaviour within the system.

4
TOXICOLOGICAL INFORMATION

• IMMEDIATE (ACUTE) EFFECTS
• HFC-32 LC50 4 hr. (rat) - 520,000 ppm / Cardiac
  Sensitization threshold (dog) 350,000 ppm
• HFC-125 LC50 4 hr. (rat) - gt 800,000 ppm /
  Cardiac Sensitization threshold (dog) 75,000 ppm
• HFC-134a LC50 4 hr. (rat) - gt 500,000 ppm /
  Cardiac Sensitization threshold (dog) gt 80,000
  ppm

5
PRODUCT INFORMATION
R-407C ASHRAE
R-22 Replaces
Similar to R-22 in capacity and energy efficiency. Benefits
Consult the specific regulations in your country or region Phaseout Schedule
POE Lubricant Recommendation
A1 ASHRAE Safety Classification
See specific container size information in your country or region. Cylinder Sizes
6
POTENTIAL HEALTH HAZARDS

• SKIN Irritation would result from a defeating
  action on tissue.
• EYES Liquid contact can cause severe irritation
  and frostbite.
• INHALATION R-407C is low in acute toxicity in
  animals.
• INGESTION Ingestion is unlikely because of the
  low boiling point of the material
• DELAYED EFFECTS None known.

7
Application

• Positive displacement equipment
• new or existing residential and commercial
  air-conditioners
• new or existing residential and commercial heat
  pumps
• conditioning applications. They include
• New residential and other unitary air
  conditioning, non-flooded evaporator chillers.
  With few modifications, 407C can be used in the
  same equipment designed for use with R-22

8
Suva 407C Refrigerant

• We will see now some a company cat logic which
  manufacture this type of refrigerants nowadays
  and have some real information about its
  properties, charts, curves and tables.
• We will take the Suva 407C Refrigerant

9
P.h DIAGRAM
10
(No Transcript)
11
(No Transcript)
