ARCH-2 UML 101 - From Design to Implementation
using UML
Frank Beusenberg
Senior Technical Consultant
2
Theory vs. Practice
The difference between theory and practice is
that, in theory, there is no difference between
theory and practice.
3
Shu-Ha-Ri
Shu - Learning Ha - Understanding Ri - Be
creative
4
Agenda

• Introduction
• UML 2.0 Diagrams
• Use Case View
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

5
Introduction
What is UML? Facts

• UML Unified Modeling Language
• First UML spec in 1997
• Current version 2.0
• Object Management Group (OMG)
• Graphical language
• Object Oriented in nature
• Has syntax rules
• Can be extended using stereotypes
• NOT a methodology!

6
Introduction
What is UML?
7
Introduction
Why model?

• Manage complexity
• Mitigate risk
• Facilitate communication
• Modeling provides ability to visualize entire
  systems, assess options and designs
• Software has grown from do-it-yourself into
  highly complex systems
• Software is integral part of business process, so
  has to be well planned
• Software has become capital equipment that cannot
  just be removed/changed

8
Introduction
Why use UML?

• Specify, visualize, and document models of
  software systems
• Current and new systems
• Structure and design
• Behavior and interaction
• De facto standard (Tool Support!)
• Unambiguous and consistent notation
• Documentation

9
Agenda

• Introduction
• UML 2.0 Diagrams
• Use Case View
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

10
UML 2.0 Diagrams
UML 2.0 Types of Diagrams Behavior Diagrams
11
UML 2.0 Behavioral Diagrams
UML Use Case Diagram

• Describes the functional requirements of the
  system

12
UML 2.0 Behavioral Diagrams
UML Activity Diagram

• Describe procedural logic, business processes and
  workflow

13
UML 2.0 Behavioral Diagrams
UML Sequence Diagram

• Describes the message flow between objects in
  chronological order

14
UML 2.0 Diagrams
UML 2.0 Types of Diagrams Structure Diagrams
15
UML 2.0 Structural Diagrams
UML Class Diagram

• Captures logical structure of system

16
UML 2.0 Structural Diagrams
UML Component Diagram

• Illustrates the pieces of software that will make
  up a system.

17
UML 2.0 Structural Diagrams
UML Deployment Diagram

• Shows how and where the system will be deployed.

18
UML Modeling
Logical View
Implementation View
Use Case View
Dynamic View
Deployment View
19
Model-Driven Architecture (MDA)
20
Agenda

• Introduction
• UML 2.0 Diagrams
• Use Case View
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

21
AutoPark - Use Case View
Describing system functionality

• Gathering requirements
• Functional non-functional requirements
• Document functional requirements
• UML Use Case Diagram
• Use Case Description Documents
• Identify actor(s) and association to use case
• Create different levels of use cases (re-use!)

22
AutoPark - Use Case View
Use Case Packages
23
AutoPark - Use Case View
Use Case Diagram
24
AutoPark - Use Case View
Describing use case scenario(s)

• Scenario Use Case Activity Flow
• Basic Scenario
• Alternate Scenario(s)
• UML Activity Diagram
• Describe what happens, now how!

25
AutoPark - Use Case View
Activity Diagram
26
AutoPark - Use Case View
Creating Test Scenarios

• Identify paths in activity diagram
• Create minimal test-scenarios (using each path
  once)
• Create all possible test-scenarios (combining all
  paths to create unique scenarios)

27
Agenda

• Introduction
• UML 2.0 Diagrams
• Use Case View
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

28
AutoPark - Logical View
Designing The System Structure

• Identify entities/things used in use case
• Identify attributes
• Identify operations
• Identify entity relations
• Identify multiplicity
• Create class diagram

29
AutoPark - Logical View
Class Diagram
30
AutoPark - Logical View
Patterns

• "A pattern is a proven solution to a problem in a
  context."

31
Agenda

• Introduction
• UML 2.0 Diagrams
• Requirements
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

32
AutoPark - Dynamic View
Describing Behavior

• Identify objects involved
• Identify interactions (messages)
• Use public operations
• Describe how things work

33
AutoPark - Dynamic View
Describing Behavior
34
Agenda

• Introduction
• UML 2.0 Diagrams
• Requirements
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

35
AutoPark - Implementation View
36
Agenda

• Introduction
• UML 2.0 Diagrams
• Requirements
• Logical View
• Dynamic View
• Implementation View
• Demonstration
• QA

37
Demonstration
38
In Summary

• Model Design
• Manage complexity
• Minimize risk
• Facilitate communication
• Use UML
• De facto standard
• Unambiguous
• Documentation

39
For More Information, go to
Relevant Exchange Sessions

• ARCH-6 UML Modeling with Enterprise Architect

40
For More Information, go to
Relevant Web Resources

• Object Management Group
• http//www.omg.org
• Hillside.net Patterns Library
• http//hillside.net/patterns

41
For More Information, go to
Relevant Literature

• Addison-Wesley Object Technology Series
• UML Distilled Third Edition
• Martin Fowler ISBN 0-321-19368-7
• Use Case Driven Object Modeling with UML
• Doug Rosenberg ISBN 0-201-43289-7
• Developing Software with UML
• Bernd Oestereich ISBN 0-201-75603-X
