Title: Subject%20Characteristics


1
(No Transcript)
2
Monitoring of Respiration BYAHMAD
YOUNESPROFESSOR OF THORACIC MEDICINE Mansoura
Faculty Of Medicine
3
The three major components of respiratory
monitoring during sleep include
  • 1-Measurement of airflow,
  • 2-Measurement of respiratory effort,
  • 3-Measurement of arterial oxygen saturation
    (SaO2).
  • Ancillary monitoring may include detection of
    snoring and recording surrogates of the arterial
    partial pressure of carbon dioxide (PaCO2)
    including end-tidal partial pressure of carbon
    dioxide (PETCO2) and transcutaneous partial
    pressure of carbon dioxide (TcPCO2).
  • The AASM scoring manual recommends specific
    sensor types and techniques to be used for
    recording respiration during sleep,

4
(No Transcript)
5
TECHNIQUES TO MEASURE AIRFLOW OR TIDAL VOLUME
  • The pneumotachograph (PNT) is the most accurate
    method to measure airflow during sleep studies ,
  • This device quantifies airflow by measurement of
    the pressure drop across a linear (constant)
    resistance (usually a wire screen). The
    relationship between the pressure change, flow
    rate, and resistance is given by the following
    equation Pressure change Flow X Resistance
  • The PNT is worn in a mask covering the nose and
    mouth.
  • Although the PNT is commonly used to measure
    airflow during sleep research, this device is
    rarely used during clinical sleep studies.

6
The setup will consist of a flow head
(pneumotachometer) and a transducer which will
integrate volume from flow.
7
Thermal devices were the first to be used to
monitor airflow during clinical sleep studies.
  • These devices actually detect changes in
    temperature induced by airflow (cooler inspired
    air, warmer exhaled air).
  • The changes in device temperature result in
    changes in voltage output (thermocouples) or
    resistance (thermistors).
  • Thermal sensors are generally adequate to detect
    an absence of airflow (apnea), but their signal
    does not vary in proportion to airflow.
    Therefore, thermal sensors are not an ideal means
    of detecting a reduction in airflow (hypopnea).

8
Thermal signals and PNT flow are equal at 1
L/sec. However, as airflow decreases, the thermal
signals overestimate flow.
  • This illustrates that thermal sensors are not
    ideal sensors to detect hypopneas (reductions in
    flow).
  • The thermal sensor signal decreases when the
    nostrils are large or the thermal sensor is
    further from the nares.
  • Thermal devices composed of polyvinylidine
    fluoride (PVDF) film may offer a better estimate
    of flow.
  • Nasal-oral thermal sensors usually have a portion
    of the device placed within or just outside the
    nostrils with another portion over the mouth
    (detection of oral flow).
  • A major advantage of thermal sensors is that they
    can detect both nasal and oral airflow without
    the need for a cumbersome mask covering the face.

9
(No Transcript)
10
Measurement of nasal pressure (NP) provides an
estimate of nasal airflow that is more accurate
than one obtained with most thermal sensors.
  • NP is measured using a nasal cannula connected to
    an accurate pressure transducer .
  • Because the cannula tips are inside the nares and
    the other side of the pressure transducer is open
    to the atmosphere, the pressure being measured is
    actually the pressure drop across the resistance
    of the nasal inlet associated with nasal airflow.
  • The relationship of NP and flow is given by
    Equations
  • NP K1(Flow)2 K1 constant
  • Flow K2 NP. K2
    constant
  • Changes in cannula position, periods of partial
    oral flow, and obstruction of the cannula by
    nasal secretions make the linearized NP signal a
    less accurate measure of flow over the entire
    night.

11
The nasal prongs signal decreases more than that
of the pneumotachograph during a reduction in
airflow. The linearized nasal prongs signal is
very similar to that of the pneumotachograph
12
The AHI values from both the NP and the
linearized NP signals showed excellent agreement
with the AHI values determined from the PNT
  • The AHI values detected by the NP signal tended
    to be slightly higher than the linearized NP
    signal, but the differences were usually small.
  • The inter-measurement agreements (kappa) between
    NP and PNT and linearized NP and PNT signals were
    both excellent and essentially identical.
  • During normal unobstructed flow, the inspiratory
    shape (contour) of the NP signal is round ,
    whereas during airflow limitation , the shape of
    the PNT and NP signals is flattened .
  • Airflow limitation is characteristically present
    during obstructive reductions in airflow
    (hypopnea) or snoring.
  • In contrast, when reductions in airflow are
    simply due to a fall in inspiratory effort, the
    NP signal amplitude is reduced but the shape is
    round.
  • The most important limitation of the NP technique
    is that approximately 10 of patients are mouth
    breathers and the NP signal may be misleading.

13
At A, the flow is rounded, whereas at C, the
flattened airflow contour is associated with an
increase in pressure drop across the upper airway
and airflow limitation. AC,
14
The AASM scoring manual recommends nasal-oral
thermal sensors for detection of apnea and NP
sensors (with or without square root
transformation of the signal) for detection of
hypopnea
  • Simultaneous use of both NP and nasal-oral
    thermal sensors is recommended and has the
    additional advantage of having a backup sensor if
    the other airflow detection device fails .
  • The AASM scoring manual notes that if the
    recommended sensor signal is not reliable, the
    alternative sensor can be used.
  • In adults, the alternative airflow sensor for
    apnea detection is the NP signal. The alternative
    sensors for hypopnea detections are oronasal
    thermal flow and respiratory inductance
    plethysmography (RIP).

15
The nasal pressure signal shows an absence of
airflow, whereas the nasal-oral thermal sensor
shows continued airflow. This pattern of airflow
is due to oral breathing.
16
RIP is another method that can be used to detect
apnea and hypopnea
  • The signals from rib cage (RC) and abdominal
    bands (AB) sensors can be summed in an
    uncalibrated manner (RIPsum RC AB) or as a
    calibrated signal (RIPsum a RC b AB) as
    an estimate of tidal volume (not airflow).
  • Here, RC and AB are signals from bands around the
    rib cage and abdomen and a and b are
    calibration factors determined during a
    calibration procedure.
  • If one takes the time derivative of the RIPsum
    signal, the result is an estimate of airflow
    (RIPflow).
  • The RIPsum during apnea has minimal deflections
    (approximately zero tidal volume) and during
    hypopnea reduced deflections (reduced tidal
    volume).

17
In the case of an obstructive apnea , the RC and
AB deflections must nearly exactly cancel each
other (paradox).In the case of hypopnea, there
is a reduction in the RIPsum signal (low tidal
volume) as well as both the RC and the AB
signals.
  • In the case of obstructive hypopnea, there may
    also be paradox with chest and abdomen moving in
    opposite directions .
  • If a RIPsum signal is not available, one can
    detect hypopnea by a reduction in the RC and AB
    RIP signals.
  • The AHI values obtained from the RIPsum and time
    derivative of the RIPsum signals showed good
    agreement with AHI values from the PNT signal.

18
Obstructive apnea Respiratory inductance
plethysmography signals from the rib cage (RC)
and abdominal bands (AB) are summed (RIPsum). The
RIPsum is an estimate of tidal volume.
19
Obstructive hypopnea Respiratory inductance
plethysmography signals from the rib cage (RC)
and abdominal bands (AB) are summed (RIPsum). The
RIPsum is an estimate of tidal volume.
20
(No Transcript)
21
MEASURING RESPIRATORY EFFORT
  • Determination of respiratory effort is essential
    to classify apneas as obstructive (continued
    respiratory effort), central (absent effort), or
    mixed (central followed by obstructive portions).
  • The most sensitive and accurate method of
    detecting respiratory effort is by measurement of
    esophageal pressure.
  • Changes in esophageal pressure are estimates of
    changes in pleural pressure that occur during
    respiration (negative intrathoracic pressure
    during inspiration).
  • Esophageal pressure monitoring can detect rather
    feeble respiratory efforts even when RC and AB
    movements are minimal. In addition, the size of
    the pressure deflections provides an estimate of
    the magnitude of respiratory effort.
  • Detection of respiratory effortrelated arousals
    (RERAs) is most accurately performed with
    esophageal pressure manometry.

22
MEASURING RESPIRATORY EFFORT
  • Measurement of esophageal pressure can be
    performed using air-filled balloons, fluid-filled
    catheters, or catheters with pressure transducers
    on their tips.
  • The technique does require special equipment and
    expertise and is routinely performed in only a
    few sleep centers.
  • Some research sleep studies measure supraglottic
    pressure instead of esophageal pressure using a
    transducer tip placed just below the tongue base.
    This allows measurement of the pressure drop
    across the upper airway . Because this site is
    below the area of upper airway closure or
    narrowing in obstructive respiratory events,
    supraglottic pressure can also be used to detect
    respiratory effort.

23
Esophageal pressure deflections increase during
an obstructive apnea that might at first glance
appear to be central apnea (absent inspiratory
effort).The chest and abdomen effort belt signals
showed minimal deflections during obstructive
apnea.
24

25
The most common method for detecting respiratory
effort in clinical sleep studies utilized
piezoelectric (PE) sensors connected to bands
around the RC and AB.
  • Changes in the tension on the PE transducer as
    the RC and AB expand and contract produce a
    voltage that can be measured .The signal from
    these devices depends on the degree of tension on
    the transducer.
  • The PE belts are adequate for detection of
    respiratory effort in most patients but do not
    really quantify the changes in RC or AB volume.
  • Although relatively inexpensive compared with RIP
    effort belts, the PE effort belts may provide
    misleading information (false absence of
    respiratory effort), especially if not properly
    positioned and tensioned.

26
RIP belts provide a more accurate method of
detecting changes in RC and AB motion during
respiration than PE belts.
  • The inductance of coils in bands around the RC
    and AB changes during respiration as the RC and
    AB expand and contract.
  • The band inductance varies proportionately to the
    cross-sectional area the band encircles.
  • An oscillator is applied to each circuit and
    changes in inductance are converted into a
    voltage output.
  • The RIP bands consist of wires attached to a
    cloth band in a zig-zag pattern. This produces a
    larger change in inductance for a given change in
    band circumference.
  • Recall that if the RIP signals are calibrated,
    the RIPsum signal aX RC bX AB is an estimate
    of tidal volume. Here ,the constants a and b are
    determined during a calibration procedure.

27
The accuracy of the RIPsum signal can deteriorate
if body position changes or the positions of the
bands change during sleep.
  • Studied patients with sleep apnea using both
    calibrated RIP belts and esophageal pressure
    monitoring showed that only 9 of patients were
    obstructive apneas sometimes misclassified as
    central apneas by the RIP belts. In these
    instances, esophageal pressure deflections were
    present when there was no detectable change in
    the RIP belt signals.
  • Thus, RIP effort belts are not 100 sensitive for
    detecting respiratory effort. However, if the
    bands are properly positioned and tensioned
    (sized) , they will detect respiratory effort (if
    present) in most patients.
  • The vast majority of sleep centers do not perform
    RIP belt calibration. It should be noted that the
    deflections of uncalibrated RIP bands do not
    always accurately reflect the magnitude of
    inspiratory effort or always show paradox during
    obstructive apnea and hypopnea.

28
Surface diaphragm EMG recording utilizes two
electrodes about 2 cm apart horizontally in the
seventh and eighth intercostal spaces in the
right anterior axillary line.
  • The right side of the body is used to reduce ECG
    artifact.
  • Intercostal EMG recording often uses the right
    parasternal area (second and third intercostal
    spaces in the midaxillary line).
  • Inspiratory EMG activity is noted in the
    intercostal muscles and the diaphragm during
    nonrapid eye movement (NREM) sleep.
  • During rapid eye movement (REM) sleep, the
    intercostal activity is inhibited but
    diaphragmatic activity persists, although often
    diminished in amplitude during bursts of eye
    movements.
  • The AASM scoring manual recommends use of
    esophageal manometry or calibrated or
    uncalibrated RIP belts for detection of
    respiratory effort during sleep studies in adults
    and children . The measurement of respiratory
    muscle EMG is listed as an alternative method of
    detecting respiratory effort in adults.

29
An obstructive apnea with respiratory effort
monitored by both chest and abdominal respiratory
inductance plethysmography (RIP) bands and right
intercostal electromyogram (EMG). The right
intercostal EMG signal shows bursts coincident
with inspiratory effort (and movement of chest
and abdomen).A blow up of one EMG burst is shown
at the bottom of the figure in a raw form and
with the electrocardiogram (ECG) artifact
minimized.
30
OXYGEN SATURATION
  • Pulse oximetry. In this method SaO2 is determined
    by the passage of two wavelengths of light (650
    nm and 805 nm) through a pulsating vascular bed
    from one sensor to another. The light is
    partially absorbed by the oxygen-carrying
    molecule, hemoglobin, depending on the percent of
    the hemoglobin saturated with oxygen. A processor
    calculates absorption at the two wavelengths and
    computes the proportion of hemoglobin that is
    oxygenated, giving it a numerical value.
  • A thin anatomic pulse site (such as the finger
    tip, ear lobe, nose, or toe) is required, as is
    proper alignment of the sensors.
  • With movement in sleep, the device can become
    dislodged.
  • The readings can also be affected by anemia,
    hemoglobinopathies, a high carboxyhemoglobin
    level, elevated methemoglobin level, anatomic
    abnormalities/previous injury to the site tested,
    sluggish arterial flow (due to hypovolemia or
    vasoconstriction),and the use of nail polish.

31
(No Transcript)
32
Apneas are followed by arterial oxygen
desaturations. Longer apneas are associated with
more severe desaturation. SpO2 pulse oximetry.
33
OXYGEN SATURATION
  • In sleep monitoring, an arterial oxygen
    desaturation is usually defined as a decrease in
    the SpO2 of 3 or 4 or more from baseline.
  • The nadir in SaO2 commonly follows apnea
    (hypopnea) termination by approximately 6 to 8
    seconds (longer in severe desaturations) . This
    delay is secondary to circulation time and
    instrumental delay (the oximeter averages over
    several cycles before producing a reading).

34
(No Transcript)
35
OXYGEN SATURATION
  • The assessment of the severity of desaturation
    include the number of desaturations, the average
    minimum SpO2 during desaturations, the time below
    80, 85, 90,as well as the mean SaO2 and the
    minimum saturation during NREM and REM sleep.
  • The time with an SpO2 88 is also commonly
    determined.
  • Oximeters may vary considerably in the number of
    desaturations they detect and their ability to
    discard movement artifact.
  • Using long averaging times may dramatically
    decrease the detection of desaturations.
  • The ability of oximeters to detect desaturations
    is especially important in light of the
    definitions of hypopnea that depend on an
    associated desaturation.
  • The AASM scoring manual recommends a maximum
    averaging time of 3 seconds at a heart rate of 80
    bpm. In patients with a slow heart rate, a
    slightly longer averaging time (at least a 3-beat
    average) may be needed.

36
MEASUREMENT OF PaCO2 DURING SLEEP
  • Documentation of hypoventilation during sleep
    requires measurement (or estimate) of the PaCO2.
  • The AASM scoring manual defines sleep-related
    hypoventilation in adults as an increase in the
    PaCO2 during sleep 10 mm Hg compared with an
    awake supine value.
  • Continuous ABG monitoring during polysomnography
    to determine the PaCO2 is not practical. An ABG
    sample sometimes is performed at the start or the
    end of the study. The sample can be used to
    validate a surrogate measure of PaCO2 such as
    PETCO2 or TcPCO2.
  • If an ABG sample is taken just at awakening, it
    may be used to infer hypoventilation.

37
PETCO2
  • Capnography consists of the continuous
    measurement of the fraction of CO2 in exhaled
    gas.
  • This is usually performed using an infrared
    sensor and, less commonly, a mass
    spectrophotometer.
  • The PCO2 is determined by multiplication of the
    fraction of CO2 by (Patm47 mm Hg). Here, the
    Patm is the atmospheric pressure (760 mm Hg at
    sea level )and 47 mm Hg is the partial pressure
    of H2O in exhaled gas at body temperature.
  • During initial exhalation, the dead space (PCO2
    0) reaches the sensor (phase 1), then a mixture
    of dead space and alveolar gas (phase 2),and
    finally, alveolar gas (phase 3). The alveolar
    plateau occurs because the PCO2 in the air from
    the different alveoli differs slightly.
  • The differences are larger (slope of alveolar
    plateau steeper) in patients with lung disease.
  • The PETCO2 is an estimate of the mean alveolar
    PCO2 (and, therefore, an estimate of the PaCO2).
  • Of note, there is a gradient between the PaCO2
    and the PETCO2 (PaCO2PETCO2) with the PaCO2
    being typically 2 to 5 mm Hg higher than the
    PETCO2 in normal individuals.
  • In lung disease, the gradient can be much larger.
  • In general, the PETCO2 is a valid estimate of
    PaCO2 only if an alveolar plateau is present.

38
Nonstructural risk factors
  • Some nonstructural risk factors include obesity,
    age, male sex, postmenopausal state, and habitual
    snoring with daytime somnolence.
  • Familial factors Relatives of patients with SDB
    have a 2- to 4-fold increased risk of OSA
    compared with control subjects.
  • Environmental exposures include smoke,
    environmental irritants or allergens, and alcohol
    and hypnotic-sedative medications.
  • Both hypothyroidism and acromegaly are associated
    with macroglossia and increased soft tissue mass
    in the pharyngeal region. They are associated
    with an increased risk of OSA. Hypothyroidism is
    also associated with myopathy that may contribute
    to UA dysfunction

39
PETCO2
  • In the mainstream method, the sensor is located
    directly in the path of exhaled gas.
  • In the side stream method, gas is continually
    suctioned through a tube to a more remote sensor
    (in the instrument at bedside).
  • In the side stream approach, nasal cannulas are
    used to suction exhaled gas from the nares . When
    no CO2 is exhaled (during inspiration or apnea),
    the nasal cannula suctions room air (PCO2 0).
  • In the side stream method, there is a delay in
    exhaled gas reaching the sensor so the CO2
    tracing is delayed compared with the exhaled
    airflow .
  • The exhaled CO2 tracing is sometimes used to
    indicate apnea (absence of exhaled PCO2).
    However, this is not recommended for two reasons.
    First, gas sampled by the nasal cannula may not
    detect mouth breathing, and second, small
    expiratory puffs rich in CO2 may still produce
    deflections in the exhaled CO2 trace.
  • Capnography is used much more frequently during
    pediatric than in adult sleep studies.

40
Imaging Studies
  • Modalities available for identifying the site of
    obstruction include lateral cephalometry,
    endoscopy, fluoroscopy, CT scanning, MRI.
  • At present, UA imaging is used primarily as a
    research tool. Routine radiographic imaging of
    the UA in the initial evaluation of SDB patients
    is of uncertain benefit and should not be
    performed unless a specific indication is
    present.

41
The exhaled CO2 tracing shows continued
deflections during inspiratory apnea due to
small exhaled puffs of air rich in CO2
42
TcPCO2 MONITORING
  • Measurement of TcPCO2 depends on the fact that
    heating of capillaries in the skin causes
    increased capillary blood flow and makes the skin
    permeable to the diffusion of CO2.
  • The CO2 in the capillaries diffuses through the
    skin and is measured by an electrode at the skin
    surface.
  • The measured value is corrected for the fact that
    heat increases the skin CO2 production as the
    measured value exceeds the PaCO2 measured at 37C.
  • Typically, TcCO2 electrodes are calibrated with a
    reference gas.
  • A thermostat controls the heating of the
    membrane-skin interface.
  • It is usually recommended that the probe of most
    TcPCO2 monitoring devices be moved every 3 to 4
    hours to avoid skin irritation/damage.
  • The response time of newer TcPCO2 units has
    improved, but in general, the measured PCO2 may
    not increase rapidly enough to correlate with
    short respiratory events. However,TcPCO2 can be a
    good instrument for documenting trends in the
    PCO2 during the night.

43
Trends in the SpO2 and TcPCO2 during the night.
Note the simultaneous increase in transcutaneous
PCO2 and the decrease in SpO2 during episodes of
REM sleep.
44
ACCURACY OF PETCO2 AND TcPCO2
  • The measurement of PETCO2 and TcPCO2 was not
    found to be accurate for determining changes in
    PaCO2 during sleep .
  • PETCO2 was especially inaccurate during
    simultaneous administration of supplemental
    oxygen or during positive airway pressure
    treatment as exhaled gas was sampled from a mask
    rather than using a nasal cannula.
  • The AASM scoring manual in the respiratory
    scoring rules for adults states that there was
    insufficient evidence to recommend a specific
    method for detecting hypoventilation during
    sleep. However, it was stated that PETCO2 or
    TcPCO2 may be acceptable if validated and
    calibrated. In the pediatric rules, it states
    that acceptable methods for assessing alveolar
    hypoventilation are either transcutaneous or
    end-tidal PCO2 monitoring.

45
ACCURACY OF PETCO2 AND TcPCO2
  • Concerning PETCO2 monitoring, the clinician
    should review the exhaled CO2 tracings to
    determine whether an alveolar plateau is present.
  • If an alveolar plateau is not present, the PETCO2
    value may not be an accurate estimate of PaCO2.
  • Other problems for exhaled PCO2 monitoring
    include oral breathing and occlusion of the nasal
    cannula with secretions.
  • If tidal volumes are very small, a true alveolar
    sample may never reach the sensor. So PETCO2
    value will likely be much lower than the PaCO2.
  • Concerning TcPCO2 measurement, the actual
    tracings should also be carefully reviewed. If an
    abrupt change (offset) in the TcPCO2 tracing is
    noted, this suggests a measurement artifact is
    present.
  • Most TcPCO2 devices require calibration at the
    start of monitoring.
  • Poor application of the sensor or dislodgment of
    the sensor during sleep can cause a measurement
    artifact.
  • There is some advantage to the simultaneous use
    of both PETCO2 and TcPCO2 if tolerated. If the
    values show reasonable agreement during periods
    of stable breathing, this increases confidence in
    their validity. Of course, the goal standard to
    validate the accuracy of their measurements is a
    simultaneous ABG measurement.

46
SNORING SENSORS
  • Snoring is a sound produced by vibration of upper
    airway structures.
  • When snoring is present, upper airway narrowing
    of some degree can be inferred.
  • Snore sensors are usually microphones or PE
    transducers that are usually applied to the neck
    near the trachea.
  • Microphones can also be attached to the upper
    chest area or the face.
  • Snoring can also be seen in the NP signal as a
    rapid oscillation in the pressure tracing if an
    appropriate high frequency filter setting (100
    Hz) is used and the transducer is sufficiently
    sensitive.
  • The AASM scoring manual does not provide guidance
    on use of snoring sensors and the signal is not
    part of the scoring criteria for respiratory
    events in adults.
  • Snoring is mentioned in scoring of RERAs in
    children.

47
Snoring noted both in the snore sensor (applied
to the neck near the trachea) and as a vibration
(oscillation) in the nasal pressure signal. Note
that the nasal pressure signal also has a
flattened shape. SpO2 pulse oximetry
48
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
