Listeria monocytogenes Prevalence, Persistence, and Control

1
Listeria monocytogenes Prevalence, Persistence,
and Control
Haley F. Oliver, Ph.D. Associate Professor Purdue
University
2
Oliver Lab Listeria and Retail

• Objective
• Improve public health through evidence-based
  interventions to control Listeria monocytogenes.
• Strategies
• Collaborate with retailers sanitation providers
• Locate environmental niches
• Determine transient vs. persistent contamination
• Test alternative sanitation procedures
• Identify best practices
• Develop long-term practical controls

3
Longitudinal study of deli environments
4
Conclusions From Longitudinal Study

• LM can be prevalent in retail delis (10-40)
• LM can persist in retail delis (observed 1.5
  years)
• LM does not persist in all stores (only11/30
  observed)
• Non-food contact surfaces have higher LM
  prevalence than food contact surfaces (NFCS 15
  vs. FCS 4)

5
Phase 3 -- Intervention

• SSOP Transfer Points
• Deli case handle
• Cold room door handle
• Slicer adjustment knobs and handles
• Scale top keypad
• Floors
• General floor cleaning
• Floor wall juncture
• Drains surface. Each retailers will retain
  current protocols for drain management
• Single and 3 basin sinks
• General floor cleaning
• Floor wall juncture
• Deli Case Food Contact Surfaces
• Deli case trays
• Opened product (i.e. in-use product) display
  shelving
• Slide and display doors

• Deli Case Down to the Coils
• Entire deli case (not in sections see FMI
  protocol)
• Slicers, Handles, and Knobs
• Entire slicer
• FCS including blade, guards, and slicer case
  under the blade
• Additional Actions/SOPs
• Squeegee
• High Pressure Hoses (i.e. spray nozzle/spray gun
  style)
• Training
• Verification/ATP Testing
• Survey

6
Previous Longitudinal Study
Pre-Intervention Post-Intervention
Food Contact 63/1595 (4.0) 63/1595 (4.0)
Transfer Point 18/540 (3.3) 18/540 (3.3)
Non-Food Contact 334/2368 (14.1) 369/2360 (15.6)
Overall 425/4512 (9.4) 450/4495 (10.0)

• 17/30 stores show low LM prevalence (lt5)
• 5/30 stores show moderate LM prevalence (5-10)
• 8/30 stores show high LM prevalence (10)
• 11/30 stores show evidence for persistence

7

  April May June July August September October November December
Food Contact Sites
Slicer - - - - - - - - -
Deli case NT NT NT - - - - - -
Deli case near raw meat NT NT NT - - - - - -
Deli case trays NT NT NT - - - - - -
3-basin sink interior NT NT NT CU-57,267 - - - - -
1-basin sink interior NT NT NT CU-258,69 - - - CU-294,321 -
Cold room rack - - - - - - - - -
Cutting board NT NT NT NT - - NT NT -
Rewrap table NT NT NT - - - - - -
Counter NT NT NT - - - - - -
Non-food contact sites
3-basin sink exterior NT NT NT - - - - - -
Floor/wall junction (3-basin) CU-258,69 CU-258,69 CU-258,69 CU-258,69 CU-258,69 CU-8,96 LM CU-258,69 CU-258,69
1-basin sink exterior NT NT NT CU-258,69 - - LM - CU-258,69
Floor/wall junction (1-basin) NT NT NT CU-258,69 - - LM CU-258,69 CU-258,69
Deli drain NT NT NT CU-258,69 CU-258,333 - CU-258,69 CU-258,69 CU-258,69
Floor adjacent to drain - CU-258,69 CU-258,69 CU-258,69 CU-258,69 - - CU-258,69 CU-258,69
Deli floor NT NT NT CU-258,69 - - - CU-258,69 -
Cold room floor NT NT NT CU-258,69 CU-295,329 - CU-258,69 CU-258,69 CU-258,69
Cold room wall CU-258,69 - - - - - - - -
Cold room drain NT NT NT CU-258,69 CU-258,69 - CU-258,69 CU-258,69 CU-258,69
Standing water NT NT NT NT - - NT NT -
Squeegee NT NT NT CU-258,69 CU-258,69 - CU-258,69 CU-258,69 CU-258,69
Cart Wheel - - CU-258,69 CU-258,69 - - - - -
Hose NT NT NT - CU-258,69 - - - -
Trash can - - CU-258,69 - CU-258,69 - - - -
Transfer Points
Slicer knob - - - - - - - - -
Case handle - - - - - - - - -
Scale NT NT NT - - - - - -
8
(No Transcript)
9
Aggressive Deep Cleans

• Goal To adapt and execute manufacturing-based
  mitigation strategies in retail delis
• Method
• 12-16 hour overnight shutdown
• 10-20 person crew
• Remove products
• Disassemble equipment
• Clean and sanitize all surfaces

10
Overnight Deep Clean Protocol
11
(No Transcript)
12
Interventions by Store
13
(No Transcript)
14
Longitudinal Efficacy

• Reduced average monthly LM prevalence a mean 9.7
  percentage points (CI95 2.50, 16.90 p0.017)
  per store.

15

• Employee-executed deep cleans with training were
  more effective for long-term control than third
  party execution of the same protocol.

16

• Whole-genome sequencing shines a new light in
  this area that helps us find unsuspected gaps in
  the food safety system this is a wake-up call to
  the ice cream industry in general and to the
  regulators.
• Robert Tauxe, CDC
• DOI 10.1126/science.aac4551

17
(No Transcript)
18
L. monocytogenes WHOLE GENOME SEQUENCING PROJECT

• In the first year of the project, integrating WGS
  with other Listeria surveillance activities
• Improved detection of listeriosis clusters.
• Increased the number of outbreaks solved.
• Reduced the average cluster size.
• One persons listeriosis infection was linked to
  prepackaged lettuce. Prior to WGS it would have
  been almost impossible to make a link between the
  contaminated food and one person who was not part
  of an outbreak.
• December 2014 identified caramel apples as
  source of large listeriosis outbreak. WGS
  identified the illnesses one week faster than
  would have occurred with PFGE alone.

19
L. monocytogenes WHOLE GENOME SEQUENCING PROJECT
20
Whole Genome Sequencing improves Identification
of persistent LM in retail

1. apply single-nucleotide polymorphism (SNP)-based
   phylogenetics to subtype
2. to differentiate persistent from repeatedly
   reintroduced strains
3. identify genetic determinants of L.
   monocytogenes persistence

21
NGS technologies

• Illumina MiSeq and HiSeq platforms
• Solid state amplification
• Single- and paired-end reading (resolve ambiguous
  alignment)
• Use of Solexa chemistry for fluorescent labeling
• Read lengths of 300bp (MiSeq) and 125bp (HiSeq)
• Read quantity up to 25million (MiSeq) and
  2billion (HiSeq)

22
WGS

• Unique to a single retail deli, supporting
  persistence within the deli
• Unique to a single state, supporting clonal
  spread within a state
• In 13 events, nearly indistinguishable isolates
  (0 to 1 SNP) were found across multiple delis

23
PFGE WGS
24

• Now that were turning whole-genome sequencing
  on, were identifying outbreak after
  outbreakwere also finding smaller outbreaks
  that we werent able to find before.
• Brendan Jackson, CDC
• DOI 10.1126/science.aac4551

25
Current Work

• USDA-NIFA-AFRI 2015-05673
• Prevalence, Persistence and Control Strategies
  of Listeria ssp. and Salmonella in Retail Grocery
  Produce Storage and Sales Environments

26
(No Transcript)
