THRUST FAULTS: ASSOCIATED STRUCTURES AND IMPLICATIONS IN HYDROCARBONS TRAPS

1
THRUST FAULTS ASSOCIATED STRUCTURES AND
IMPLICATIONS IN HYDROCARBONS TRAPS
STRUCTURE AND HYDROCARBON PROSPECTIVITY OF BASINS
James Moore Alex Nyombi Christian
Hidalgo Adekunle Odutola
2
Aims Objectives

• A brief introduction to Thrust Faults
• Define Tectonics Settings involving Thrust Faults
  formation
• Review structures associated with Thrust Faults
• Highlight two examples of Hydrocarbon Traps
  associated with Thrust Faults
• Summarise

3
Why Study Thrust Faults ?

• The are very damaging. Host of the largest and
  potentially most destructive earthquakes
• Associated with mountain building and
  collisional tectonics
• Influence positions of ore deposits and
  hydrocarbons

4
What Are Thrust Faults ?

• They are reverse faults with low dip that form in
  layered sequences where horizontal stress is
  greater than vertical stress.
• They are formed by compressive stresses
• Thrust faults are dip-slip faults
• They have dip less than 45

5
What Are Thrust Faults ?
6
Major Types of Thrust Faults

1. Thin-Skinned Thrusts

• Thin skinned thrusts developed within sedimentary
  basins
• Basement may act as a basal detachment
• Basement is not involved
• Typical of leading edges of compressive orogens

7
Major Types of Thrust Faults
2. Thick-Skinned Thrusts

• Thick skinned thrusts cut upward through the
  basement and propagate through the sediment
• Thick skinned thrusts usually steepen upwards and
  are covered by drape folds

8
Rules For Thrust Development

• Thrust always cut up-section in the direction of
  transport
• Thrust always place older over younger rocks
• Higher thrust develop first
• Thrusting proceeds from higher to lower and from
  hinterland towards foreland

9
Dynamics of Thrust Motion

• Conditions for thrust movement include
  overcoming
• Frictional resistance to sliding on the basal
  fault surface
• Gravitational forces resulting from the mass of
  the sheet

• Hypothesis supporting thrust movement include
• Gravity sliding hypothesis
• Fluid pressure hypothesis

10
Mechanisms of Thrusting

• They are formed by compressive tectonic stresses
  and occur at convergent plate boundaries.
• ?1 is horizontal and ?3 is vertical.
• The two sets of thrust faults intersect along the
  horizontal ?2 axis with dip less that 45.
• Horizontal contraction parallel to ?1 and
  vertical extension parallel to ?3

11
Components of a Thrust System

• Foreland is the area in front of the thrust belt
• Hinterland is the area behind the thrust belt
• Imbricate fan Individual thrust sheets overlap
  like roofing tiles
• Duplex system of imbricate thrusts that branch
  off from a single fault below and merge with a
  thrust fault above. The rock body bounded by
  faults above and below is called a horse
• Ramps Flats Faults consist of flats parallel
  to bedding (surface of weakness) and ramps where
  the fault cuts across the bedding

12
Components Of Thrust Faults
13
Tectonic Setting of Thrust Fault

• Thrust faults accommodate shortening of the
  earth's crust
• Most big mountain ranges are fold-and-thrust
  belts
• Consists of a set of folds and thrust faults that
  extend for 10s to 100s of kilometres along strike
• Usually shortening takes place near the plate
  boundary in convergent margins (Himalayas, Alps,
  Appalachians, Urals)

14
Formation of Duplex Structure
15
Formation of Thrust Duplex
16
Structures Associated with Thrust Faults

• Foreland thrust and fold belts
• Belts of deformed sedimentary rock in which the
  layers are folded and duplicated by thrust faults
  are common at the edges of orogens
• Folds and thrust faults are the dominant
  structures
• Results in the formation of foreland basin and
  piggy- back basin
• Classic examples occur in the Main Ranges,
  Valley and Ridge province of the Appalachians,
  and the Jura Mountains in the Alps

17
Foreland Thrust And Fold Belt
18
Folds Associated with Thrust Faults

• Fault bend folds
• Detachment folds
• Fault propagation fold

19
Thrust Faults as Hydrocarbon Traps Hypothetical
Example

• Thrust Faults
• This example shows sediment deposited by a
  glacier 10,000 years ago.

• When the glacier moved back over the sediments,
  faulting occurred. A glacial readvance.

20
Thrust Faults as Hydrocarbon Traps Hypothetical
Example

• Hypothetical situation set up below.

• Sandstone source rock, Shale seal rock.

• Rock sequence is thrusted creates a possible
  hydrocarbon trap.

21
Thrust Faults as Hydrocarbon Traps Nepal
Location of Nepal
22
Thrust Faults as Hydrocarbon Traps Nepal

• Traps can be seen in the Siwalk Fold Belt.
• A blind thrust is also seen. This can also act
  as a trapping mechanism.

23
Thrust Faults as Hydrocarbon Traps Moose
Mountain, Canada
McConnell Thrust
Moose Mountain
24
Thrust Faults as Hydrocarbon Traps Moose
Mountain, Canada

• Moose Mountain
• thrust sheet is defined
• as the uppermost thrust
• sheet which strata are
• exposed at the surface.
• This thrust essentially
• placed a single repetition of the entire Cambrian
  through Cretaceous sequence in the hanging wall,
  over the footwall.
• Strata in the footwall of the Moose Mountain
  thrust range from Paleozoic to the Lower
  Cretaceous.

25
Summary

• They are found in compressional settings like
  orogenic belts, salt domes and diapiric
  structures in general
• Repeat stratigraphy, puts older rocks on top of
  younger rocks and contracts layering
• They closely associated with folds and thrust
  belts
• 2 major types of Thrust faults Thin-Skinned
  Thrusts and Thick-Skinned Thrusts.

26
Summary

• Components of a Thrust System Foreland,
  Hinterland, Imbricate fans, Duplexes, Ramps
  Flats
• When rock sequence is trusted creates a possible
  hydrocarbon trap
• Two examples of thrust faults forming a
  structural trap for hydrocarbons Nepal, Moose
  Mountains

27
Questions ?
28
References

• Park, R.G. Foundations of Structural Geology,
  Chapman Hall. pp 95 96, 1997.
• Twiss, R. J. and E. M. Moores, Structural
  Geology, W. H. Freeman Co., New York, 256p,
  1992.
• http//vle.leeds.ac.uk/site/nbodington/earthscienc
  e/fifth/msc_struc/
• http//ic.ucsc.edu/casey/eart150/Lectures/4Thrust
  Flts/4thrustfaults.htm
• http//courses.eas.ualberta.ca/eas421/lecturepages
  /thrust.html
• http//earth.leeds.ac.uk/faults/thrust/tipline/fbf
  old.htm
• http//www.colorado.edu/geolsci/courses/GEOL3120/3
  120lect_13.pdf
• (Taken from http//www.cseg.ca/conferences/2000/20
  00abstracts/505.PDF)
