Introduction to Polylines and MultilinesChapter
15
  • Sacramento City College
  • EDT 310

2
Polylines
3
Polylines
  • The term polyline is composed of the words "poly"
    and "line."
  • Poly means many.

4
Polylines
  • A polyline is
  • A single object that can be
  • Made up of one or more varied-width line segments.

5
The PLINE Command
6
Polylines
  • Polylines are drawn with the PLINE command.
  • The TRACE command, is similar to the PLINE
    command.
  • Both commands can be used to draw thick lines.
  • PLINE has numerous advantages over TRACE

7
Polylines
  • Polylines advantages over normal lines
  • 1. Polylines can be drawn as thick or tapered
    lines.
  • 2. Polylines are more flexible than lines drawn
    with the TRACE command.
  • 3. Polylines can be any linetype.

8
Polylines
  • 4. Polylines can be edited.
  • 5. Closed polygons can be drawn.
  • 6. The area or perimeter of a polyline object can
    be determined easily.
  • 7. Arcs and straight lines of varying thickness
    can be joined as single objects.

9
Polylines
  • The PLINE command is similar to the LINE command.
  • But
  • All segments of a polyline are treated as a
    single object.
  • Lines drawn with the LINE command, are individual
    segments.

10
Polylines
  • To draw a polyline,
  • Pick the Polyline button from the Draw toolbar
  • OR
  • Pick Polyline from the Draw pull-down menu
  • OR
  • Type PL or PLINE at the Command prompt

11
Polylines
  • Command PL or PLINE
  • Specify start point (select a point)
  • Current line-width is 0.0000
  • Specify next point or Arc/Close/Halfwidth/Length/
    Undo/Width (select the next point)
  • Press Enter to end the PLINE command and return
    to the Command prompt.

12
Polylines
  • A line width of 0.0000 produces a line of minimum
    width.

13
Setting the Polyline Width
  • To adjust the Width of a PLINE
  • Use the Width option after you enter the PLINE
    command to change the line width, and
  • have selected the first point of the PLINE.

14
Polyline Options
15
Polyline Options
  • Polyline Options
  • Width
  • Halfwidth
  • Length
  • Undo

16
Setting the Polyline Width
  • Width option
  • Specify the starting and ending widths of the
    line.
  • The starting width value that you specify becomes
    the default setting for the ending width.
  • To keep the line the same width, press Enter at
    the second prompt.

17
Setting the Polyline Width
  • If a tapered line is desired, enter different
    values for the starting and ending widths.

Starting Width 0.0000
Ending Width 1.0000
18
Halfwidth Option
  • Halfwidth option
  • Allows you to specify the width of the polyline
    from the center to one side.

19
Length Option
  • Length option
  • Not intuitive
  • Allows you to draw another polyline having the
    same angle as the previous polyline.
  • To use After drawing a polyline
  • Reissue the PLINE command
  • Pick a starting point.
  • Enter the Length option
  • Give the desired length.
  • The 2nd PLINE will be parallel to the first PLINE.

20
Undoing Previously Drawn Polylines
  • Undo option
  • Use while inside the PLINE command
  • Erases the last polyline segment drawn.
  • Enter U at the prompt line and then press Enter
  • Each time you use the Undo option, another
    polyline segment is erased.

21
Undoing Previously Drawn Polylines
  • The cursor remains attached to the end of the
    polyline segment that was drawn before the undone
    segment.
  • You can now continue to draw additional polyline
    segments
  • OR
  • Type U and press Enter again to undo another
    segment.

22
Undoing Previously Drawn Polylines
  • Undo Option
  • You can use the Undo option to remove all of the
    polyline segments up to the first point of the
    polyline.
  • The segments are removed in reverse order (from
    the order in which they were drawn).

23
The U Command
24
The U Command
  • The U command works in much the same way.
  • The U Command is not the Undo option of the PLINE
    command.
  • The U command can be used to undo any previous
    commands.

25
The U Command
  • To execute the U command
  • Pick the Undo button from the Standard toolbar
  • OR
  • Pick Undo from the Edit pull-down menu
  • OR
  • Pressing the CtrlZ key combination
  • OR
  • Enter U at the Command prompt.

26
The U Command
  • The U command can also be activated by
  • Right-clicking in the drawing area.
  • Selecting Undo from the shortcut menu.
  • AutoCAD gives you a message indicating which
    command was undone
  • Command U
  • PLINE
  • Command

27
The U Command
  • You can only undo one command at a time.
  • Repeated UNDOs can be executed.
  • The UNDO command,
  • Has more options than the U command
  • Is more versatile than the U command.

28
The REDO Command
29
The REDO Command
  • The REDO command
  • is used to bring back objects that were erased
    with the UNDO and U commands.

30
The REDO Command
  • Enter REDO at the Command prompt
  • OR
  • Pick Redo from the Edit pull-down menu
  • OR
  • Press the CtrlY key combination
  • OR
  • Pick the Redo button from the Standard toolbar to
    activate the command.

31
The UNDO Mark
  • The REDO command works only immediately after
    undoing something.
  • REDO does not bring back polyline segments that
    were removed using the Undo option of the PLINE
    command.

32
The TRACE Command
33
The TRACE Command
  • To draw thick lines, the TRACE command can be
    used instead of the PLINE command.

34
The TRACE Command
  • To use the TRACE command
  • Enter TRACE at the Command prompt.
  • Specify the trace width.
  • Select points as you would with the LINE command.
  • The trace width is stored in the TRACEWID system
    variable.

35
The TRACE Command
  • Command TRACE
  • Specify trace width ltcurrentgt (enter width)
  • Specify start point (select start point)
  • Specify next point (select second point)
  • Specify next point (select additional points or
    press Enter to complete)
  • Command
  • Trace segment ends are mitered to fit the next
    segment.

36
The TRACE Command
  • The problems with TRACE are
  • The previous trace segment is not drawn on screen
    until the next endpoint is specified.
  • There is no close option with the TRACE command.

37
Filling Polylines and TracesThe FILL Command
38
The FILL Command
  • Traces and polylines can be
  • Filled in, or
  • Shown as an outline.
  • These functions are controlled by the FILL
    command.
  • The FILL command has two modes, ON and OFF.

39
The FILL Command
  • Command FILL
  • Enter mode ON/OFF ltcurrentgt
  • When the FILL is on, traces and polylines appear
    filled after they are drawn.
  • When FILL is off, traces and polylines appear as
    outlines, and the corners are mitered.

40
The FILL Command
  • After turning FILL off, REGEN to have the fill
    removed.

41
The FILL Command
  • FILL on
  • May slow down your computer.
  • If you have many wide polylines or traces in a
    drawing, keep FILL mode turned off.
  • This saves time when redrawing, regenerating, or
    plotting a check copy of the drawing.

42
The UNDO Command
43
The UNDO Command
  • The UNDO command is different from the U command.
  • The UNDO command offers several options that
    allow you to undo a single command or a number of
    commands at once.

44
The UNDO Command
  • The command sequence is as follows
  • Command UNDO
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back

45
The UNDO Command
  • The default option allows you to designate the
    number of previous command sequences you wish to
    remove.
  • If you enter 1, the previous command sequence is
    removed.
  • If you enter 2, the previous two command
    sequences are removed.
  • AutoCAD tells you which commands were undone with
    a message after you press Enter.

46
The UNDO Command
  • Command UNDO
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back 2
  • PLINE LINE
  • Command

47
The UNDO Command
  • There are several other types of undo operations
    that can be performed with the UNDO command.

48
The UNDO Command - Auto Option
  • The Auto option can be turned on or off.
  • When Auto option is on, any commands that are
    part of a group and used to perform a single
    operation are removed together.
  • When a command contains other commands, all of
    the commands in that group are removed as one
    single command.
  • The Auto option is on by default.

49
The UNDO Command - Auto Option
  • If Auto is turned off, each command in a group of
    commands is treated individually.

50
The UNDO Command - Control Option
  • The Control option allows you to specify how many
    of the UNDO command options you want active.
  • You can even disable the UNDO command altogether.

51
The UNDO Command - Control Option
  • To use the Control option
  • Enter C after issuing the UNDO command
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back C
  • Enter an UNDO control option All/None/One
    ltAllgt (enter a control option and press Enter)

52
The UNDO Command - All Option
  • The All suboption keeps the full range of UNDO
    command options active.
  • All is the default setting.

53
The UNDO Command - None Option
  • The None suboption disables the U and UNDO
    commands.
  • When disabled, and the U command is entered, the
    following prompt appears
  • Command U
  • U command disabled. Use UNDO command to turn it
    on
  • This prompt indicates how to reactivate the U and
    UNDO commands.

54
The UNDO Command - Auto Option
  • If you type UNDO at the Command prompt, the
    following appears
  • Command UNDO
  • Enter an UNDO control option All/None/One
    ltAllgt
  • To activate the UNDO options, press Enter for
    All.

55
The UNDO Command - One Option
  • Enter 0 for the One suboption.
  • This setting limits UNDO to one operation only.
  • Command UNDO
  • Control/ltlgt -i
  • LINE
  • Everything has been undone Command

56
The Auto Option
  • Type C at the Control/ltlgt prompt to redisplay
    the Control suboptions.

57
The Begin and End Options
  • The BEgin and End options of the UNDO command are
    used together to perform several undo operations
    at once.
  • They allow you to group a series of commands and
    treat the entire group as a single command.
  • Once the group is defined, the U command is then
    used to remove the commands that follow the BEgin
    option but precede the End option.

58
The Begin and End Options
  • These options are useful if you can anticipate
    the possible removal of several commands that are
    entered consecutively.

59
The Begin and End Options
  • For example, to undo the next three commands
  • Command UNDO
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back BE
  • Command L or LINE
  • Command PL or PLINEJ
  • Command L or LINE-I
  • Command UNDO
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back EJ
  • Command U

60
The Begin and End Options
  • The U command undoes the three commands that were
    executed in the previous sequence.
  • The BEgin option must precede the command
    sequence
  • The End option must immediately follow the last
    command to be undone.

61
The UNDO Mark
  • The UNDO Mark option allows you to insert a
    "marker" in the undo file.
  • The UNDO Back option then enables you to delete
    commands "back" to the marker.

62
The UNDO Mark
  • If you do not want certain work to be undone by
    the Back option, enter the Mark option after
    completing the work
  • Command UNDO
  • Enter the number of operations to undo or
    Auto/Control/BEgin/End/Mark/Back Mj
  • Command

63
The UNDO Mark
  • If you decide to remove any work, reissue the
    UNDO command and enter the Back option.
  • This will undo everything back to the marker
  • Command UNDO
  • Enter the number of operations to undo or
    (Auto/Control/BEgin/End/Mark/Back B

64
The UNDO Mark
  • If no marks have been entered, this undoes
    everything in the entire drawing!
  • AutoCAD questions your choice with the following
    message
  • This will undo everything. OK? ltYgt

65
The UNDO Mark
  • If you want everything that you have drawn and
    edited to be undone, press Enter.
  • If not, enter N or NO and press Enter, or press
    the Esc key.

66
The UNDO Mark
  • CAUTION Be very careful when using the UNDO Back
    option.
  • Entering this option undoes everything in the
    entire drawing.
  • You can bring back what you have undone if you
  • type REDO at the Command prompt and
  • press Enter immediately after using the UNDO
    Back option.

67
The UNDO Mark
  • If you use any other command, even REDRAW, after
    using UNDO Back, the drawing is lost forever !

68
The UNDO Mark
  • The REDO command can be used to restore commands
    removed with UNDO.

69
The UNDO Mark
  • The UNDO Mark option can be used to assist in the
    design process.
  • If you are working on a project and have
    completed a portion of the design, mark that spot
    with the Mark option and then begin work on the
    next design phase.
  • If anything goes wrong with this part of the
    design, use the UNDO Back option to remove
    everything back to the mark.

70
Multilines
71
Drawing Multilines
  • A multiline consists of between 1 and 16 parallel
    lines that act as one line.
  • The lines in the set of multilines are called
    elements.

72
Drawing Multilines
  • Multilines are commonly used for drawing
  • Roads
  • Walls of buildings for architectural plans.

73
Drawing Multilines
  • The MLINE command is accessed by
  • Picking the Multiline button from the Draw
    toolbar
  • OR
  • Picking Multiline in the Draw pull-down menu
  • OR
  • Typing ML or MLINE at the Command prompt.

74
Drawing Multilines
  • Three commands relate to multilines
  • MLINE. (ML)
  • MLSTYLE.
  • MLEDIT.

75
Drawing Multilines
  • The MLSTYLE command
  • Allows you to create multilines.

76
Drawing Multilines
  • The default multi-line style has
  • Two elements (lines).
  • Continuous line type.
  • Is called STANDARD.

77
Multiline Justification
  • Justification determines how the resulting lines
    are offset.

78
Multiline Justification
  • Justification
  • Can be specified only once during a single MLINE
    command sequence and
  • Is based on a counterclockwise rotation direction.

79
Multiline Justification
  • The justification options are
  • Top
  • Zero
  • Bottom
  • TOP is the default
  • The current value remains in effect until changed.

80
Top Justification
81
Zero Justification
82
Bottom Justification
83
Multiline Justification
  • To change the justification
  • Enter J at the first prompt
  • Enter the first letter of the desired
    justification
  • Top
  • Zero
  • Bottom

84
Multiline Justification
  • The justification setting is stored in the
    AutoCAD CMLJUST system variable.

85
Adjusting the Multiline Scale
  • The Scale option controls the multiplier for the
    offset values specified in the MLSTYLE command.
  • The multiplier is stored in the CMLSCALE system
    variable.

86
Adjusting the Multiline Scale
  • When the scale is 1, the distance between
    multiline elements is equal to 1 times the offset
    distance.
  • If the offset distance is 0.5, the distance
    between multiline elements is 0.5 when the
    multiline scale is 1.
  • If the multiline scale is 2, the distance between
    multiline elements is 1 (0.5 x 2).

87
Adjusting the Multiline Scale
  • For zero justification,
  • The multiline elements are offset 0.5 units on
    either side of the definition points picked.
  • Example If the multiline scale is 2
  • Top and Bottom justification 2 units offset
  • Zero justification 1 unit and -1 unit offset.

88
Setting Your Own Multiline Style
  • ML Command Style option
  • Allows you to specify the current multiline
    style.
  • The style must be saved before it can be accessed.

89
Setting Your Own Multiline Style
  • Using saved Multiline styles
  • Type ML
  • Type ST - to access the style option,
  • Type the known multiline style name.
  • A ? lists all of the names of the multiline
    styles.
  • Typing a name of a multiline style that does not
    exist, the Load multiline style from file dialog
    box is displayed

90
(No Transcript)
91
Setting Your Own Multiline Style
  • Multilines are stored in the acad.mln file
    library.

92
(No Transcript)
93
(No Transcript)
94
Setting Your Own Multiline Style
  • You can load the multiline style from another
    file (not acad.lin).
  • Custom multilines can be purchased for AutoCAD.

95
Defining Multilines
96
Multiline Styles
  • Use the MLSTYLE command to define multilines.

97
Multiline Styles
  • The MLSTYLE command can be accessed by
  • Picking the Multiline Style entry in the Format
    pull-down menu
  • OR
  • Typing MLSTYLE at the Command prompt.

98
Multiline Styles
  • The Multiline options are
  • Current
  • Name
  • Description
  • Load... Button
  • Save... button.
  • Add button.
  • Rename button.

99
(No Transcript)
100
Multiline Styles
  • Current Text box.
  • The Current text box makes the specified
    multiline style current.
  • Specifying a different style changes the setting
    of the CMLSTYLE system variable.
  • Until you create a multiline style, the only
    style available is STANDARD.

101
Multiline Styles
  • NameText box.
  • This text box is used to enter the name for a new
    style.
  • Description Text box.
  • An optional description of your multiline style
    may be entered in this text box.

102
(No Transcript)
103
Multiline Styles
  • Load... button.
  • This button allows you to load a multiline style
    from an external multiline definition file.
  • Save... button.
  • The Save... button is used to save a style to a
    file.

104
(No Transcript)
105
Multiline Styles
  • Add button.
  • Pick the Add button after entering a multiline
    style name in the Name text box.
  • This adds the multiline style name to the list of
    defined styles.
  • Rename button.
  • Pick this button to rename a multiline style.

106
(No Transcript)
107
Creating A Multiline
108
Element Properties Dialog Box
  • Create a new multiline style by
  • 1. MLStyle
  • 2. Type name of new multiline
  • NewExample
  • 3. Click ADD

109
Multiline Element Properties
110
(No Transcript)
111
Element Properties Dialog Box
  • Elements Properties Dialog Box contains
  • Elements area.
  • Add button.
  • Delete button.
  • Offset text box.
  • Color... button.
  • Linetype... button.

112
Element Properties Dialog Box
  • Elements area.
  • Displays the current
  • Offset.
  • Color
  • Linetype settings
  • for each multiline element.
  • Picking one of the elements highlights the items
    for modification.

113
(No Transcript)
114
Element Properties Dialog Box
  • Add button.
  • Add a new element to the multiline definition.
  • Delete button.
  • Deletes a highlighted item in the Elements area.

115
(No Transcript)
116
(No Transcript)
117
Element Properties Dialog Box
  • Offset text box.
  • Enter either a positive or negative offset value
    for a highlighted element.

118
(No Transcript)
119
Element Properties Dialog Box
  • Color... button.
  • Accesses the Select Color dialog box.
  • Pick the color you wish to assign to the
    highlighted element.
  • After picking OK, the new color is displayed in
    the image tile next to the Color... button.

120
(No Transcript)
121
(No Transcript)
122
Element Properties Dialog Box
  • Linetype... button.
  • Pick the desired linetype from the Loaded
    Linetypes list.
  • Linetypes must be loaded before they can be used.

123
(No Transcript)
124
(No Transcript)
125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
(No Transcript)
130
Multiline Properties Options
131
Multiline Properties Dialog Box
  • The Multiline Properties dialog box offers
    additional options for customizing multiline
    styles.
  • Access by
  • Picking the Multiline Properties... button in the
    Multiline Styles dialog box.
  • See Figure 15-12.

132
(No Transcript)
133
(No Transcript)
134
Multiline Properties Dialog Box
  • You can add the following to multi-line elements
  • Caps.
  • Segment joints.
  • Background color.

135
Multiline Properties Dialog Box
  • Joints
  • Are lines that
  • connect the vertices of adjacent multiline
    elements.
  • Joints are also called miters.
  • Display joints check box.
  • This check box turns the display of joints on and
    off.

136
(No Transcript)
137
(No Transcript)
138
Multiline Properties Dialog Box
  • Caps
  • Are lines that
  • Connect the vertices of the beginning or ending
    points of the multiline elements.
  • Caps area.
  • Controls the placement of caps on multilines.

139
(No Transcript)
140
(No Transcript)
141
(No Transcript)
142
(No Transcript)
143
Multiline Properties Dialog Box
  • Caps can be set at the
  • Start points
  • Endpoints
  • Both.

144
Multiline Properties Dialog Box
  • Arcs can also be specified.
  • Arcs can be set to connect the
  • Ends of the outermost elements only
  • Pairs of interior elements
  • Both the outer and interior elements.
  • The arcs are drawn tangent to the elements they
    connect.
  • Specifying outermost arcs to be drawn requires at
    least two multiline elements.

145
(No Transcript)
146
(No Transcript)
147
(No Transcript)
148
(No Transcript)
149
(No Transcript)
150
(No Transcript)
151
(No Transcript)
152
Multiline Properties Dialog Box
  • Angle Text Box
  • Allows you to change the angle of the caps
    relative to the direction of the multiline
    elements.

153
(No Transcript)
154
(No Transcript)
155
Multiline Properties Dialog Box
  • Fill area.
  • If the check box labeled On is activated, the
    multiline is filled with a solid fill pattern in
    the color specified.
  • Pick this check box to activate the Color...
    button.
  • You can leave the color set to BYLAYER or change
    it by picking the Color... button.

156
(No Transcript)
157
(No Transcript)
158
(No Transcript)
159
(No Transcript)
160
Multiline Styles
161
Multiline Styles
  • MLSTYLE command
  • Displays the Multiline Styles dialog box.
  • Use this box to define, edit, and save multiline
    styles.
  • Styles can be saved to an external file so they
    can be used in other drawings.

162
(No Transcript)
163
Editing Multilines
164
Editing Multilines
  • The MLEDIT command permits limited editing
    operations for multiline objects.

165
Editing Multilines
  • Access this command by
  • Picking Multiline... from the Modify pull-down
    menu
  • OR
  • Entering MLEDIT at the Command prompt
  • OR
  • Picking the Edit Multiline button in the Modify
    toolbar.

166
Editing Multilines
  • The Multiline Edit Tools dialog box is displayed.

167
Editing Multilines
  • The image buttons give you an example of what to
    expect when using each editing option.

168
(No Transcript)
169
Editing Intersections
  • Pick a button to create the type of intersection
    shown.
  • The name of the MLEDIT option is displayed in the
    lower left comer of the dialog box when you pick
    an image button.

170
Editing Intersections
  • Closed Cross.
  • The first multiline selected is called the
    background. It remains unchanged.
  • The second multiline selected is called the
    foreground. It remains unchanged.

171
Editing Intersections
  • Note that the trimming is apparent, not actual. (
    ! )
  • This means that the line visibility of the
    background multiline is changed, but it is still
    one multiline.

172
(No Transcript)
173
Editing Intersections
  • U to undo the intersection you have just made.

174
Editing Intersections
  • Cross editing options
  • Closed Cross.
  • Open Cross.
  • Merged Cross.

175
(No Transcript)
176
Editing Tees
  • Other Tee editing options
  • Closed Tee
  • Open Tee.
  • Merged Tee.

177
(No Transcript)
178
Editing Intersections
  • Other options
  • Corner Joint.
  • Add Vertex.
  • Delete Vertex.
  • Cut Single.
  • Cut All.
  • Weld All.

179
(No Transcript)
180
Editing Intersections
  • Corner Joint.
  • Allows you to create a corner joint between two
    multilines.
  • The first multiline is trimmed or extended to its
    intersection with the second multiline.

181
(No Transcript)
182
Editing Intersections
  • Add Vertex.
  • Adds a vertex to an existing multiline at the
    location you pick.

183
Editing Intersections
  • Add Vertex
  • The command sequence differs slightly from the
    sequences used with the other MLEDIT options.
  • After you select the Add Vertex option and pick
    OK, you are prompted with the following
  • Select mline (pick a location on the
    multilinefor the new vertex)
  • Select mline or Undo j
  • Command

184
Editing Intersections
  • Delete Vertex.
  • The Delete Vertex option allows you to remove a
    vertex from an existing multiline.
  • The vertex closest to the location you pick is
    deleted.

185
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
