Title: Regression


1
Regression
2
Outline of Todays Discussion
  1. Coefficient of Determination
  2. Regression Analysis Introduction
  3. Regression Analysis SPSS
  4. Regression Analysis Excel
  5. Independent Predictors

3
Part 1
Coefficient of Determination
4
Coefficient of Determination
In correlational research Researchers often use
the r-squared statistic, also called the
coefficient of determination, to describe the
proportion of Y variability explained by X.
5
Coefficient of Determination
What range of values is possible for
the coefficient of determination (the r-squared
statistic)?
6
Coefficient of Determination
Example What is the evidence that IQ is
heritable?
7
Coefficient of Determination
R-value for the IQ of identical twins reared
apart 0.6. What is the value of r-squared in
this case?
8
Coefficient of Determination
So what proportion of the IQ is unexplained
(unaccounted for) by genetics?
9
Coefficient of Determination
Different sciences are characterized by the
r-squared values that are deemed
impressive. (Chemists might r-squared to be gt
0.99).
10
Coefficient of Determination
As we have already seen r-squared is the same as
eta-squared.
11
Part 2
Regression Analysis Introduction
12
Regression Analysis Introduction
  • Correlation is the process of finding a
    relationship between variables.
  • Regression is the process of finding the
    best-fitting trend (line) that describes the
    relationship between variables.
  • So, correlation and regression are very similar!

13
Regression Analysis Introduction
  • The r statistic can be tested for statistical
    significance!
  • Potential Pop Quiz Question What two factors
    determine the critical value (i.e., the number to
    beat) when we engage in hypothesis testing?

14
Regression Analysis Introduction
DF for Correlation Regression
Here n stands for the number of pairs of
scores. Why would this be n-2, rather than the
usual n-1?
15
Regression Analysis Introduction
  • In general, the formula for the degrees of
    freedom is the number of observations minus the
    number of parameters estimated.
  • For correlation, we have one estimate for the
    mean of X, and another estimate for the mean of
    Y.
  • For regression, we have one estimate for the
    slope, and another estimate for y intercept.

16
Regression Analysis Introduction
Slope can also be though of as rise over run.
17
Regression Analysis Introduction
The rise on the ordinate Y2 - Y1. The run
on the abscissa X2 - X1.
18
Regression Analysis Introduction
Rise over run in pictures.
19
Regression Analysis Introduction
Here, the regression is linear
20
Regression Analysis Introduction
Here, the regression is non-linear! What would
the equation look like for this trend?
21
Regression Analysis Introduction
  • Lets now return to linear regression, and learn
    how to manually compute the slope and
    y-intercept.
  • To compute the slope, we need two quantities that
    we have already learned. These are SPxy (sums of
    products) and SSx (sums of squares for X)

22
Regression Analysis Introduction
23
Regression Analysis Introduction
Once we have the slope, its easy to get the
y-intercept!
24
Part 3
Regression Analysis SPSS
25
Regression Analysis SPSS
  • Later well go to SPSS and get some practice with
    regression.
  • The steps in SPSS will be Analyze ---gt Regression
    --gt Linear.
  • We will place the criterion (i.e., the Y-axis
    variable) in the Dependent box, and the
    predictor (i.e., the X-axis variable) in the
    Independent(s) box.
  • Click the Statistics box, and check
    estimates, model fit, and descriptives.

26
Regression Analysis SPSS
The Coefficients Section In SPSS Output
The Coefficients Section in the SPSS
output contains all the info needed for the
regression equation, the r statistic, and the
evaluation of Ho (retain or reject).
27
Regression Analysis SPSS
The Coefficients Section In SPSS Output
The constant is the b in, Y mX b. Here, b
-9923.665
28
Regression Analysis SPSS
The Coefficients Section In SPSS Output
The slope is the m in, Y mX b. Here, m
1807.836
29
Regression Analysis SPSS
The Coefficients Section In SPSS Output
So, our regression equation is, Y mX b. or Y
1807.836X - 9923.665.
30
Regression Analysis SPSS
The Coefficients Section In SPSS Output
The r statistic is the standardized coefficient,
Beta. r .705
31
Regression Analysis SPSS
The Coefficients Section In SPSS Output
Lastly, we look at the sig value for the
predictor, (which is EDU in this case) to
determine whether predictor (x-axis variable) is
significantly correlated with the criterion
(y-axis variable). Evaluate Ho do we retain or
reject?
32
Part 4
Regression Analysis Excel
33
Regression Analysis Excel
  • Correlation and regression are very similar.
  • If we have a significant correlation, the
    best-fitting regression line is said to have a
    slope significantly different from zero.
  • Sometimes it is stated that the slope departs
    significantly from zero.

34
Regression Analysis Excel
  • Note A slope can be very modestly different from
    zero, and still be statistically significant if
    all data points fall very close to the line.
  • In correlation and regression, statistical
    significance is determined by the strength of the
    correlation between two variables (the r-value),
    and NOT by the slope of the regression line.
  • The significance of the r-value, as always,
    depends on the alpha level, and the df (which is
    n-2). Take a peak at the r-value table.

35
Regression Analysis Excel
36
Regression Analysis Excel
  • Remember The regression line (equation) can help
    us predict one score, given another score, but
    only if there is a significant r-value.
  • The terminology w/b the regression line
    explains (or accounts for) 42 of the
    variability in the scores (if r-squared .42).
  • To explain or account for does NOT mean to
    cause. Correlation does not imply
    causation!

37
Regression Analysis Continued
  • A synonym for regression is prediction! Recall
    that prediction is one of the four goals of the
    scientific method. What were the others?
  • A significant correlation implies a significant
    capacity for prediction, i.e., a prediction that
    is reliably better than chance!

38
Regression Analysis Continued
  • The equation for a straight line, again, is
  • y mx B
  • or
  • Criterion ( slope Predictor)
    Intercept
  • How many parameters in a linear equation?
  • How about a quadratic equation?

39
Part 5
Independent Predictors
40
Independent Predictors
  • So far, weve attempted to use regression for
    prediction.
  • Specifically, weve tried to predict one variable
    Y (called the criterion), using one other
    variable (called the predictor).
  • Multiple Regression - the process by which one
    variable Y (called the criterion) is predicted on
    the basis of more than one variable (say, X1, X2,
    X3).

41
Independent Predictors
Heres the simple case of one predictor
variable. The overlap (in gray) indicates the
predictive strength.
42
Independent Predictors
If the overlap in the Venn diagram were to
grow, the r-value would grow, too!
43
Independent Prediction
Variable X1
Criterion (Y)
Heres the same thing again but well call the
the predictor variable X1.
44
Independent Prediction
Variable X2
Variable X1
Criterion (Y)
By adding another predictor variable X2, we could
sharpen our predictions. Why?
45
Independent Prediction
Variable X2
Variable X1
Criterion (Y)
Unfortunately, X1 and X2 provide some
redundant information about Y, so the predictive
increase is small.
46
Independent Prediction
Variable X2
Variable X1
Criterion (Y)
Unfortunately, X1 and X2 provide some
redundant information about Y, so the predictive
increase is small.
47
Independent Prediction
Variable X3
Variable X2
Variable X1
Criterion (Y)
By contrast, variable X3 has no overlap with
either X1 or X2, so it would add the most new
information.
48
Independent Prediction
Variable X3
Variable X2
Variable X1
Criterion (Y)
In short, since all three predictors provide some
unique information, predictions w/b best when
using all three.
49
Independent Prediction
Variable X3
Variable X2
Variable X1
Criterion (Y)
If you wanted to be more parsimonious and use
only two of the three, which two would you pick,
and why?
50
Independent Predictors
  • That was a conceptual introduction to Multiple
    Regression (predicting Y scores from more than
    one variable).
  • We will not learn about the computations for
    multiple regression in this course (but you will
    if you take the PSYCH 370 course).
  • For our purposes, simply know that predictions
    improve to the extent that the various predictors
    are independent of each other.

51
