Definite Clause Grammars

1
Definite Clause Grammars

• t.k.prasad_at_wright.edu
• http//www.knoesis.org/tkprasad/

2
Review Difference Lists

• Represent list L as a difference of two lists L1
  and L2
• E.g., consider L a,b,c and various L1-L2
  combinations given below.

L1 L2
a,b,cT T
a,b,c,dT dT
3
Review Append using Difference Lists

• append(X-Y, Y-Z, X-Z).
• Ordinary append complexity O(length of first
  list)
• Difference list append complexity O(1)

X-Z
X
X-Y
Y
Y
Y-Z
Z
Z
Z
4
DCGs

• Mechanize attribute grammar formalism (a
  generalization of CFG)
• Executable specification
• Use difference lists for efficiency
• Translation from DCGs to Prolog clauses is
  automatic

5
Sample Applications of DCGs

• Coding recursive descent backtracking parser
• Encoding and checking context-sensitive
  constraints
• Simple NLP
• In general, enabling syntax directed translation
• E.g., VHDL Parser-Pretty Printer

6
DCG Example Syntax

• sentence --gt noun_phrase, verb_phrase.
• noun_phrase --gt determiner, noun.
• verb_phrase --gt verb, noun_phrase.
• determiner --gt a.
• determiner --gt the.
• determiner --gt many.
• noun --gt president.
• noun --gt cat.
• noun --gt cats.
• verb --gt has.
• verb --gt have.

7
DCG to Ordinary Prolog Syntax

• sentence(S,R) -
• noun_phrase(S,T), verb_phrase(T,R).
• noun_phrase(S,T) - determiner(S,N), noun(N,T).
• verb_phrase(T,R) - verb(T,N), noun_phrase(N,R).
• determiner(aR,R).
• determiner(theR,R).
• determiner(manyR,R).
• noun(presidentR,R).
• noun(catR,R).
• noun(catsR,R).
• verb(hasR,R).
• verb(haveR,R).

8
Queries

• ?- sentence(the, president, has, a, cat, ).
• ?- sentence(the, cats, have, a, president, ).
• ?- sentence(a, cats, has, the, cat, president,
  president).
• ?- sentence(a, cats, has, the, cat, President,
  President).
• Each non-terminal takes two lists as arguments.
• In difference list representation, they together
  stand for a single list.

9
DCG Example Number Agreement

• sentence --gt noun_phrase(N),verb_phrase(N).
• noun_phrase(N) --gt determiner(N), noun(N).
• verb_phrase(N) --gt verb(N), noun_phrase(_).
• determiner(sgular) --gt a.
• determiner(_) --gt the.
• determiner(plural) --gt many.
• noun(sgular) --gt president.
• noun(sgular) --gt cat.
• noun(plural) --gt cats.
• verb(sgular) --gt has.
• verb(plural) --gt have.

10
Extension AST plus Number agreement

• sentence(s(NP,VP)) --gt noun_phrase(N,
  NP),verb_phrase(N, VP).
• noun_phrase(N, np(D,NT)) --gt determiner(N, D),
  noun(N, NT).
• verb_phrase(N, vp(V,NP)) --gt verb(N, V),
  noun_phrase(_, NP).
• determiner(sgular, dt(a)) --gt a.
• determiner(_, dt(the)) --gt the.
• determiner(plural, dt(many)) --gt many.
• noun(sgular, n(president)) --gt president.
• noun(sgular, n(cat)) --gt cat.
• noun(plural, n(cats)) --gt cats.
• verb(sgular, v(has)) --gt has.
• verb(plural, v(have)) --gt have.

11
Queries

• ?- sentence(T,the, president, has, a, cat, ).
• T s(np(dt(the), n(president)), vp(v(has),
  np(dt(a), n(cat))))
• ?- sentence(T,the, cats, have, a, presidentX,
  X).
• ?- sentence(T,a, cats, has, the, cat, preside,
  preside).
• Each non-terminal takes two lists as arguments
  for input sentences, and additional arguments for
  the static semantics (e.g., number, AST, etc).
• Number disagreement causes the last query to
  fail.

12
Prefix Expression DCG

• expr --gt if, expr, then, expr,
• else, expr.
• expr --gt , expr, expr.
• expr --gt , expr, expr.
• expr --gt m.
• expr --gt n.
• expr --gt a.
• expr --gt b.

13
Queries

• ?-expr(, m, n, ).
• ?-expr(m, , n, ).
• ?-expr(, m, , a, n, n, n).
• ?-expr(if, a, then, m, else, n, ).
• ?-expr(if, a, then, a, else, , m, n, ).

14
Prefix Expression DCG Type Checking Version

• tExpr(T) --gt if, tExpr(bool), then, tExpr(T),

• else, tExpr(T).
• tExpr(T) --gt , tExpr(T), tExpr(T).
• tExpr(T) --gt , tExpr(T), tExpr(T).
• tExpr(int) --gt m.
• tExpr(int) --gt n.
• tExpr(bool) --gt a.
• tExpr(bool) --gt b.
• Assume that and are overloaded for int and
  bool.

15
Queries

• ?-tExpr(T,, m, n, ).
• ?-tExpr(T,m, , n, ).
• ?-tExpr(T,, m, , a, n, n, n).
• ?-tExpr(T,if, a, then, m, else, n, ).
• T int
• ?-tExpr(T,if, a, then, b, else, , m, n, ).

16
Prefix Expression DCG Type Checking and
Evaluation Version

• evalExpr(V) --gt etExpr(V,_).
• etExpr(V,T) --gt if, etExpr(B,bool), then,
  etExpr(V1,T), else, etExpr(V2,T),
• Btrue -gt V V1 V V2.
• etExpr(V,bool) --gt ,
• etExpr(V1,bool), etExpr(V2,bool),
• or(V1,V2,V).
• etExpr(V,int) --gt ,
• etExpr(V1,int), etExpr(V2,int),
• V is V1 V2.

17
(contd)

• etExpr(V,bool) --gt ,
• etExpr(V1,bool), etExpr(V2,bool),
• and(V1,V2,V).
• etExpr(V,bool) --gt ,
• etExpr(V1,int), etExpr(V2,int),
• V is V1 V2.
• etExpr(V,int) --gt m, value(m,V).
• etExpr(V,int) --gt n, value(n,V).
• etExpr(V,bool) --gt a, value(a,V).
• etExpr(V,bool) --gt b, value(b,V).

18
(contd)

• value(m,10). value(n,5).
• value(a,true). value(b,false).
• and(true,true,true). and(true,false,false).
• and(false,true,false). and(false,false,false).
• or(true,true,true). or(true,false,true).
• or(false,true,true). or(false,false,false).

19
Prefix Expression DCG AST Version

• treeExpr(V) --gt trExpr(V,_).
• trExpr(cond(B,V1,V2),T) --gt
• if, trExpr(B,bool), then,
  trExpr(V1,T), else, trExpr(V2,T).
• trExpr(or(V1,V2),bool) --gt ,
• trExpr(V1,bool), trExpr(V2,bool).
• trExpr(plus(V1,V2),int) --gt ,
• trExpr(V1,int), trExpr(V2,int).

20
(contd)

• trExpr(and(V1,V2),bool) --gt ,
• trExpr(V1,bool), trExpr(V2,bool).
• trExpr(mul(V1,V2),int) --gt ,
• trExpr(V1,int), trExpr(V2,int).
• trExpr(m,int) --gt m.
• trExpr(n,int) --gt n.
• trExpr(a,bool) --gt a.
• trExpr(b,bool) --gt b.

21
Other Compiler Operations

• From parse tree and type information, one can
• compute (stack) storage requirements for
  variables and for expression evaluation
• generate assembly code (with coercion
  instructions if necessary)
• transform/simplify expression
• Ref http//www.cs.wright.edu/tkprasad/papers/At
  tribute-Grammars.pdf

22
Variation on Expression Grammars

• Inefficient
• Backtracking Parser Exists

• Unsuitable Grammar

• E -gt T E T
• T -gt F T F
• F -gt (E)
• x
• y

• E -gt E E
• E E
• x
• y

23
Relationship to Attribute Grammars
24
Attribute Grammars

• Formalism for specifying semantics based on
  context-free grammars (BNF)
• Static semantics (context-sensitive aspects)
• Type checking and type inference
• Compatibility between procedure definition and
  call
• Dynamic semantics
• Associate attributes with terminals and
  non-terminals
• Associate attribute computation rules with
  productions

25

• Attributes A(X)
• Synthesized S(X)
• Inherited I(X)
• Attribute computation rules (Semantic functions)
• X0 -gt X1 X2 Xn
• S(X0) f( I(X0), A(X1), A(X2), , A(Xn) )
• I(Xj) Gj( I(X0), A(X1), A(X2), , A(Xj-1))
• for all j in 1..n
• P( A(X0), A(X1), A(X2), , A(Xn) )

26
Information Flow
inherited
computed
available
synthesized
...
...
27

• Synthesized Attributes
• Pass information up the parse tree
• Inherited Attributes
• Pass information down the parse tree
  or from left siblings to the right siblings
• Attribute values assumed to be available from the
  context.
• Attribute values computed using the semantic
  rules provided.
• The constraints on the attribute evaluation
  rules permit top-down left-to-right (one-pass)
  traversal of the parse tree to compute the
  meaning.

28
An Extended Example

• Distinct identifiers in a straight-line
  program.
• BNF
• ltexpgt ltvargt ltexpgt ltexpgt
• ltstmgt ltvargt ltexpgt ltstmgt ltstmgt
• Attributes
• ltvargt ? id
• ltexpgt ? ids
• ltstmgt ? ids ? num
• Semantics specified in terms of sets (of
  identifiers).

29

• ltexpgt ltvargt
• ltexpgt.ids ltvargt.id
• ltexpgt ltexp1gt ltexp2gt
• ltexpgt.ids ltexpgt.ids U ltexpgt.ids
• ltstmgt ltvargt ltexpgt
• ltstmgt.ids ltvargt.id U ltexpgt.ids
• ltstmgt.num ltstmgt.ids
• ltstmgt ltstm1gt ltstm2gt
• ltstmgt.ids ltstm1gt.ids U ltstm2gt.ids
• ltstmgt.num ltstmgt.ids

30
Alternative Semantics using lists

• Attributes
• ? envi list of vars in preceding context
• ? envo list of vars for following context
• ? dnum number of new variables
• ltexpgt ltvargt
• ltexpgt.envo
• if member(ltvargt.id,ltexpgt.envi)
• then ltexpgt.envi
• else cons(ltvargt.id,ltexpgt.envi)

31
Attribute Computation Rules

• ltexpgt ltexp1gt ltexp2gt
• ? envi ? envi ? envi
• ? envo ? envo ? envo
• ? dnum ? dnum ? dnum
• ltexp1gt.envi ltexpgt.envi
• ltexp2gt.envi ltexp1gt.envo
• ltexpgt.envo ltexp2gt.envo
• ltexpgt.dnum length(ltexpgt.envo)
