The Spaghetti Bowl (D-STAR Political Football)

1
The Spaghetti Bowl (D-STAR Political Football)

• Rick Bandla (VE3CVG)

2
Gateway Designs

• Icom USTrust The Original
• KI4KLF/VA3UW NATrust ( aka FreeStar)
• G4ULF NI Star
• ircDDB Gateway Trustless
• Others?

3
Repeater Controller Designs

• Icom RP2C controller, software by Icom
• Satoshi Yasuda (7M3TJZ) board the first
  non-Icom, firmware by Satoshi, app by Mark
  McGregor KB9KHM
• Mark Phillips (G7LTT/NI2O) board, does not supply
  firmware, app by KB9KHM
• Dutch board and firmware by Fred van Kempen
  PA4YBR, app by KB9KHM
• Scott (KI4KLF)/Ramesh (VA3UW) linux and
  dextra-based software-controller (and GMSK
  interface) simple PTT circuit

4
Central Databases 1

• Needed primarily to enable Call Sign Routing to a
  specific station
• US Trust is the first
• 1 database for the world
• Sometimes slow to update
• No cleanup so becomes corrupted
• Poorly documented, closed, closely-guarded
  secrets
• Fragile
• Also has dplus server database to keep track of
• Multi Trust was the second
• distributed data amongst several strategic
  servers
• Much faster than US Trust
• European servers removed when ircDDB came along
• North American Trust remains as a scaled down
  version
• dextra based
• Now uses ircDDB

5
Central Databases 2

• ircDDB
• central redundant database
• data is rcvd by gateway using IRCclient in Java
  using RFC2812
• data is sent by gateway using dsm
• no interference w USTrust database or dplus
  database
• open source
• fast
• Dutch
• dpns or d-Plus name server by Fred van Kempen
  PA4YBR
• Alternative to the dplus database (which only
  shows Icom systems)
• permits hot spots, dvdongles, dvaps to see
  registered hot spots as well as Icom and non-Icom
  gateways
• Does not interfere with other databases

6
Repeater Radio Designs

• Icom RP2000 (144MHz)
• Icom RP4000 (440MHz)
• Icom RP2V (1.3GHz Voice)
• Icom RP2D (1.3GHz Data)
• Friendcom Digital Radios
• Modified FM Radios

7
Network Designs

• Icom US Trust System
• Single trust (central database)
• Can use ircDDB
• By JRL and Icom HQ
• Refined by several US amateurs
• NA Trust System
• Also known as FreeStar aka multi-trust
• Multi-trust means multiple redundant DBs
• uses ircDDB
• Trustless System
• Uses ircDDB gateway
• Others
• private

8
The Problem

• We would like it all to work together nicely
• We would like any mess to be transparent to the
  user
• We want it to be easy to use . well, easier
  than it is now
• We want it to be reliable

9
Our Mission Today

• To meet each other
• To talk about the various combinations and their
  respective problems
• To help us all use the networks effectively
• To enjoy our hobby

10
The End
