Introduction to VXML

1
Introduction to VXML
2
What is VXML?

• Voice Extensible Markup Language
• Used in
• telephone-based speech applications
• voice browsing of the web

3
How does VXML work?

• Two main components
• tags -- control what the program does
• grammars -- control what speech is recognized
  what the user can say

4
Basic VXML tags

• ltvxmlgt -- defines a VXML application
• ltformgt -- basic component of a dialog
• ltpromptgt -- says something to the user
• ltfieldgt -- holds information supplied by user
• ltgrammargt -- defines what user can say
• ltfilledgt -- what to do once user says something

5
VXML Hierarchy

• ltvxmlgt contains one or more ltformgt
• ltformgt may contain one or more ltpromptgt and does
  contain one or more ltfieldgt
• ltfieldgt contains one or more ltpromptgt but one and
  only one ltgrammargt and an optional ltfilledgt

6
(No Transcript)
7
Example 1
8
Tonys Tips 1

• All files must end with the extension .vxml
• Use a simple editor such as Notepad or the editor
  provided by BeVocal. Do not use Word -- it tends
  to add extra hidden formatting
• All tags occur in pairs (e.g., ltformgt and
  lt/formgt)
• When using ltpromptgt avoid punctuation and
  capitalization

9
VXML Grammars

• Two types of grammars
• Programmer specified -- you decide what can be
  said
• Built-in or pre-defined
• Two tags related to grammars
• ltgrammargt -- what can be said
• ltfilledgt -- what to do once you recognize
  something

10
Built-in Grammars
OK
OK
11
(No Transcript)
12
Example 2a
13
Example 2b
14
Recognizing phrases

• Single words
• news sports weather exit
• phrases
• (i want the news)
• Combined
• ((i want the) news sports)
• ((i want the) news sports (home section))
• Saying something optional
• (?(i want the) news sports ?please)

15
Using slots

• Problem ltfieldgt holds entire phrase that is
  recognized
• would have to write a separate rule for each
  possible phrase (i.e., the vocabulary problem)
• Slots are a useful shortcut when recognizing
  phrases
• ((i want the) news sports (home section))
• ((i want the)
• news ltsection newsgt
• sports ltsection sportsgt
• (home section) ltsection home gt )

16
Example 2c
17
More on grammars

• Grammars do not have to be defined directly in
  vxml file
• can be defined in a separate file with .gsl
  extension (see example 3)

18
Tonys Tips 2

• avoid capitalizing words or using punctuation
  when defining a grammar
• Use built-in grammars whenever possible
• Use slots when trying to recognize phrases
• Use a separate grammar file if certain things
  will be recognized repeatedly (e.g. example 3)

19
So far...

• The metaphor is VXML as a form
• Dialog is overdetermined (i.e., the system is in
  control)

20
What about...
21
Design considerations
Main menu
people menu
Undergrad menu
Grad menu
22
Design considerations
Main menu
people menu
Undergrad menu
Grad menu
23
Design considerations
Main menu
people menu
Undergrad menu
Grad menu
24
Example 3
25
Example 4
Main menu
grammar
ex4_psych.vxml
psychology.gsl
ex4_undergr.vxml
ex4_grad.vxml
ex4_people.vxml
people menu
Undergrad menu
Grad menu
26
Tonys Tips 3

• When using external grammars the rule name must
  start with a capital letter and is case sensitive
  (e.g., Fish is different from FISH)
• Plan first, then write code
• Break the project into pieces
• Test each small piece individually then combine

27
(No Transcript)
28
Adding flexibility

• Handling speech recognition errors
• Handling long periods of silence
• Help
• Repeating
• Exiting/Hanging up gracefully

29
(No Transcript)
30
(No Transcript)
31
Adding flexibility

• Given/new information (e.g., emphasis)
• This implementation of VXML does not allow you to
  change emphasis despite having tags ltemphasisgt
  and ltprosodygt

32
(No Transcript)
33
You can get this correct
34
Additional options

• Change the timeout length
• Say as feature
• Ex. system can say a series of numbers in
  telephone style
• Use pre-recorded sounds (i.e., .wav files)
• Change the voice

35
Tonys Tips 4

• Start early
• Reuse code -- dont reinvent the wheel
• Put comments in your code
• If you get stuck ask someone for help
• See Tonys Tips 1-3

36
FUll flow chart Example 3/4
