Chapter 10: Heat Energy

1
Chapter 10 Heat Energy
2
Aim How is energy related to motion?
3
Movement of Molecules

• The speed of molecules in an object can be sensed
  as temperature-hot, cold, warm, cool
• Faster the speed, warmer the object
• Solids
• molecules vibrate back and forth
• Lined up right on top of each other
• Liquids
• Molecules spread out more
• Vibrate and collide into one another

4

• Gases
• molecules are spread out far apart
• Move in straight lines between collision
• Any object has energy due to its motion, whether
  its a molecule or car
• Energy is an ability to move other matter around

5
Aim What are the two main types of energy?
6
Kinetic Energy

• Energy of any moving object
• Measured in joules
• 3 forms
• Heat-sun
• Mechanical-machines
• Sound-vibrations

7
Potential Energy

• Energy stored in an object or material
• Ex moving an object up hill
• 3 forms
• Atomic-radioactive materials
• Chemical- batteries
• Gravitational-any 2 masses in the universe

8
Aim What is the difference between temperature
and heat?
9
Temperature

• The average speed of molecules in a material
  determines the molecules average kinetic energy
• The average kinetic energy determines the
  temperature
• How hot or cold a material is
• Thermometers measure temperature

10
Heat

• When energy flows between 2 objects because they
  have different temperatures
• Form of energy
• Measured in joules or calories
• Energy of a hot object flows as heat to the
  cooler object. This happens until both are the
  same temperature

11
Aim What is the difference between radiation,
conduction and convection?
12
Radiation

• The transfer of energy by electromagnetic waves
• Ex sun producing light
• Comes in the form of infrared, visible and
  ultraviolet rays
• Strength of each type of radiation depends on the
  temperature of the object
• Objects that absorb electromagnetic waves
  receives energy
• Effects materials temperature rises, change of
  state of material, material has a chemical change

13
Conduction

• Movement of energy through direct contact
• Only way heat can travel through solids
• Heat transfer-molecules move
• Burner pan sauce

14
Convection

• Heat transfer
• Occurs in liquids and gases
• Transfer of energy by the flow of a liquid or gas
• Warm air carries heat up

15
Aim What is insulation?
16
Insulation

• Prevents heat from flowing in or out of a
  material
• Use a material that is not a good conductor of
  heat
• Examples
• Insulation in a house-contains fiberglass and a
  lot of air
• Foam used to keep foods cold

17
Aim What causes thermal expansion?
18
Thermal Expansion

• Any kind of matter expanding when its
  temperature is raised
• Examples
• Bimetallic strip-one metal expands more than the
  other causing the thermostat to turnoff
• Steel is placed in roadways to prevent them from
  bending on the hottest days

19

• As the temperature of a solid, liquid or gas is
  raised, the particles move around faster and take
  up more space
• This causes the material to increase in volume
• Different materials expand or contract at their
  own rate
• Hot glass can shatter easily when placed in cold
  water because of unequal contraction

20
Aim What is pressure?
21
Pressure

• Is the force on each unit of area of a surface
• is the result of colliding gas molecules that
  push on each unit of a surface
• 2 laws explain pressure

22
Boyles Law

• Air enters the pump when you pull up the
  handle-particles are spread out
• When you press down on the handle the particles
  are forced into a smaller volume
• Smaller volume, higher pressure
• Larger volume, lower pressure
• Higher pressure forces air into the tire

23
Charles Law

• Change in temperature affects pressure
• Volume of a gas increases when we raise its
  temperature while keeping its pressure constant
• Volume of gas decreases when the temperature
  decreases, pressure is constant

24
Aim What causes changes of state?
25
Changes of State

• States solid, liquid or gas
• Removing or adding energy causes matter to change
  from one state to another
• Melting solid to liquid
• Particles move faster as the temperature is
  raised
• Vaporization liquid to gas
• If heat is applied particles will continue to
  move faster and faster

26

• Condensation gas to liquid
• Heat is removed from a gas
• Particles slow down as the temperature falls
• Freezing liquid to solid
• Energy is removed steadily
• Particles become locked into fixed positions
• Temperature of a substance does not change while
  a change of state occurs
• Temperature changes only when all of the
  substance has changed state

27

• boiling-temperature stays unchanged while a
  liquid is boiling
• Occurs when bubbles of vapor escape from a liquid
• Evaporation-particles vaporize at the surface
  when turning a liquid into a gas

28
Aim How is a forced-air heating system different
from a steam-heating system?
29
Steam Heat

• Changes of state in water are used to transfer
  energy from the furnace to air in the room
• Furnace heats the water causing vaporization
• Steam is produced and sent through the radiator
• Air in the room is heated by conduction-air comes
  into contact with hot radiator

30

• Radiation-waves of energy (infrared) are spread
  through the room
• Air circulates through the room by convection
• hot air rises and cooler air sinks down

31
Forced-Air Heat

• Does not involve changes of state
• Buildings are heated with air alone
• Hot air is forced up from the furnace and blown
  out through vents
• Convection helps circulate air
• Cooler air exits through air duct and enters air
  blower to be heated by the furnace

32
Aim How do gases drive a car?
33
Aim How can the suns energy be used?
34
Solar Heating

• 2 types of solar heating
• Active solar heating
• Sun heats water
• Pump circulates the heat throughout the building
• Passive solar heating
• Thick wall stores heat from the sun
• Heat is distributed by convection

35
Solar Cells

• Scientists developed materials made of silicon
  that produce electrons called solar cells
• Solar cells generate an electric current from
  sunlight
• Can power vehicles
• Can provide electricity to buildings

36
Aim How are fossil fuels formed?
37
Fossil Fuels

• The remains of plants and animals are buried
  under sand or mud
• Over time, pressure turns them into a thick oil
  or gas
• Ex coal, oil, natural gas
• Give off large amounts of heat when burned
• Are nonrenewable resources

38
Aim How can modern plant and animal matter give
us energy?
39
Biomass conversion

• Animal and plant matter is changed into high
  quality fuels
• Enables us to conserve fossil fuels
• Fuels produced are examples of renewable
  resources
• 2 methods
• Yeast cells used
• Grain is mixed with yeast cells
• Change sugar in grains to ethyl alcohol and CO2
• Ethyl alcohol is a good fuel and can be mixed
  with gasoline

40

• 2. Bacteria used
• Bacteria is used to digest wastes where air is
  lacking
• Garbage from landfills is placed in airtight
  tanks
• Bacteria produce methane gas-main ingredient of
  natural gas

41
Aim What are the advantages and disadvantages of
nuclear fusion and fission?
42
Aim Which is better fission or fusion?
43
Aim What are other sources of energy?
44
Wind Energy

• For centuries farmers have been using windmills
  to pump water on farms
• Many small wind driven electric generators were
  built between 1930 and 1960
• The production of windmills stopped when electric
  companies strung wires in most parts of the
  country
• Now there is a growing demand for energy

45

• Manufacturers have started to build wind turbines
  to convert wind into electricity
• Most of them are located in California
• 1 of Californias energy comes from these
  turbines
• This source of energy is clean and renewable

46
Hydroelectricity

• Flow of water causes turbines to spin to drive a
  generator producing electricity
• US gets 15 of its electricity from this source
• Hoover Dam
• Causes little pollution
• Few of sites where dams can be built
• Need to carefully plan the building of a dam-do
  not want to harm plant and animal species
