Title: MultiVision Training


1
MultiVision Training
  • 3D Modeling

2
3D Modeling Overview
  • MultiVision takes the oblique images together
    with the DXF layers and uses them to create 3D
    models of objects from the actual images (not
    simulations).
  • This important feature can be used for a wide
    variety of applications such as urban planning,
    architectural design, etc.
  • MultiVision can sample polygonal, cylindrical and
    conical objects, crop them from the source image
    (exclusive to MultiVision) and create 3D models.

3
Creating 3D Images
1. In the Toolbar, click
Select for conical objects
Select for polygonal objects
4
Creating 3D Images
2. Mark the start point
1. Mark the ground point
5
Creating 3D Images from Polygonal Objects
The final point closes the outline and the
complete 3D model outline is displayed.
6
Creating 3D Images from Polygonal Objects
The complete 3D model outline as it appears in
all the obliques
7
Viewing the 3D Model
In the Options menu, go to Cropping
Then click View 3D
8
Viewing the 3D Model
The selected object appears in the 3D View window.
9
Viewing the 3D Model (cont.)
Click and drag the mouse to view the object from
all directions
10
Viewing the 3D Model (cont.)
3D modeling component files.
  • At the same time, all the images that construct
    the 3D image (all the facades, roofs, etc.) are
    saved separately together with a text file
    containing the XYZ coordinates defining the
    polygons and their locations within the
    rectangular frame.
  • 3D modelers can use these to reconstruct 3D
    simulations of the objects.

11
Saving the Cropped 3D Image
In the Options menu, go to Cropping
Then click Crop
12
Saving the Cropped 3D Image
The Save Croppings As window opens
Give the image a name and save it to the location
of your choice.
13
Erasing 3D Modeling Outline Elements
  • To erase a line in a single window
  • In the toolbar, click the Erase button In the
    desired window, click the line in the 3D outline
    you want to erase. That line and all its
    associated elements are erased only in that
    window.
  • To erase a selected line from all oblique images
  • In one of the windows, click the line you want to
    erase.
  • On the mouse, press both buttons. The line is
    erased in all the oblique images (the same line
    in each image)
  • To erase all measurement lines
  • In the File menu, select Reset Project. All
    measurement and other lines in all images are
    erased.

14
Duplicating 3D Outlines
  • If, after you create the 3D outline and you view
    the image from a different direction but the
    outline does not appear on the new images, you
    can duplicate the outline and drag or copy it to
    the new image.
  • Thanks to the known coordinates, no matter where
    you drop the duplicate outline, Multivision
    knows where the outline should go and places it
    on the correct structure.

15
Duplicating a 3D Outline
  • With the Polygon or Cone tool, create a 3D
    outline.
  • In the Object Transformation menu, select
    Dragorin the Toolbar, click the arrow next to
    the Object Transformation icon then click the
    Drag button .
  • Drag the duplicate outline to the same object in
    another window. From the coordinates of the
    original outline, Multivision calculates the
    correct position and drops the outline correctly
    on the object.

Object Transformation Menu
Drag button
16
Duplicating a 3D Outline (cont.)
  • You can also place the duplicate outline anywhere
    in the MultiVision viewer and use it to create
    new outlines for similar objects.
  • Once the outline is more or less in the position
    you want, you can use the Shift Duplicate tool to
    position one point of the outline to the
    corresponding point on the new structure and then
    use the Rotate tool to rotate the outline to the
    correct perspective.

Shift Duplicate
Rotate
