QBM117 Business Statistics

1
QBM117Business Statistics

• Descriptive Statistics
• Numerical Descriptive Measures

2
Objectives

• To introduce numerical measures for describing
  the central location of data
• To introduce numerical measures for describing
  the variability of data

3
Numerical Descriptive Methods

• We have looked at tabular and graphical methods
  for presenting data.
• Although these methods help us to highlight
  important features of the data, they do not tell
  the whole story.
• Numerical descriptive measures allow us to be
  more precise in describing the characteristics of
  the data.

4
Numerical Descriptive Methods for Quantitative
Data

• Most numerical descriptive measures are obtained
  through arithmetic operations on the data.
• Arithmetic calculations can only be applied to
  quantitative data.
• Consequently most of the numerical descriptive
  measures we will discuss are for quantitative
  data.

5
Parameters and Statistics

• Recall the terms introduced in lecture 2 week 1
  population, sample, parameter, statistic
• Numerical measures calculated from sample data
  are called sample statistics.
• Numerical measures calculated from population
  data are called population parameters.

6

• We will look at a number of descriptive
  statistics and for each we will learn how to
  calculate both the population parameter and the
  sample statistic.
• In practice we usually collect data from a sample
  and calculate sample statistics to use as
  estimates of population parameters.

7
Notation

• Statistics are usually represented by Roman
  letters
• sample mean
• sample standard deviation s
• Parameters are usually represented by Greek
  letters
• population mean ?
• population standard deviation ?

8
Properties of numerical data

• Three major properties that describe quantitative
  data are
• - measures of central tendency
• - measures of dispersion
• - measures of shape

9
Measures of Central Tendency

• In most sets of data there is a tendency for the
  data to group about a central point.
• This phenomenon is referred to as central
  tendency.
• We will look at three measures of central
  tendency mean, median and mode

10
The Mean

• The most popular and useful measure of central
  tendency is the arithmetic mean, widely known as
  the average.
• The mean is calculated by summing all the
  observations and dividing by the number of
  observations.
• It can easily be calculated using the statistics
  function on your calculator.

11

• The mean of a sample of n measurements
• is defined as
• The mean of a population of N measurements
• is defined as

12

• I have shown you the formulas so that you
  understand how the mean is calculated.
• However it is expected that you will calculate
  the mean using the statistics function on your
  calculator.
• If you are unsure of how to use the statistics
  functions on your calculator refer to your
  calculator manual.
• The population mean or the sample mean are
  calculated using the same button on your
  calculator.

13
Example 1

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the mean of the data.

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
14
The Median

• The median is the middle value when the data are
  arranged in order.
• To calculate the median
• - Order the data from smallest to largest
• - If the number of observations is odd, the
  median is the middle value.
• - If the number of observations in even, the
  median is the mean of the two middle
  observations.

15
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the median.

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
16

• Order the data.
• 4 10 15 16 18 20 21 23 28 29 29 31 33
  35 37
• median
• There are 15 observations and so the median will
  be the middle value.
• It will be the 8th value.

17
Stem and Leaf Display

• A useful tool for ordering data is the stem and
  leaf display.
• To construct and stem and leaf display separate
  each observation into
• a stem, consisting of all but the last digit
• and a leaf, the final digit.
• Write the stems in a vertical column (smallest at
  top) .
• Write each leaf in the row to the right of the
  stem.
• Redraw, ordering the leaves.

18
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Construct and stem and leaf display and
  calculate the median.

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
19
0 4
1 6 0 5 8
2 0 8 3 9 1 9
3 1 7 3 5

• Ordered

0 4
1 0 5 6 8
2 0 1 3 8 9 9
3 1 3 5 7
20
The Mode

• The mode is the value that occurs most
  frequently.
• The mode doesnt necessarily lie in the middle.
• Its claim to be a measure of central tendency is
  based on the fact that it indicates the location
  of greatest concentration of values.
• The mode is a measure of central tendency that
  can be used for qualitative data.

21
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the mode.
• mode 29

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
22

• If no data value occurs more than once then there
  is no mode.
• A data set may have more than one mode.
• If there are two modes then the data are bimodal.
• If there are more than two modes the data are
  multimodal.

23
Example 2

• A survey of television-viewing habits among
  university students provided the following data
  on viewing time in hours per week
• Calculate the mean, median and mode.

14 9 12 4 20 26 17 15
18 15 10 6 16 15 8 5
24

• mean 13.125
• 4 5 6 8 9 10 12 14 15 15 15 16 17
  18 20 26
• median
• median 14.5
• mode 15

25
Mean, Median or Mode

• There are several factors to consider when making
  our choice of measure of central tendency.
• The mean is generally our first selection.
• However, there are circumstances when the median
  is better.
• The mode is seldom the best measure of central
  tendency.

26

• The mean is a popular measure because it is
  simple to calculate and interpret, and lends
  itself to mathematical manipulation.
• However the mean is sensitive to skewness and
  outliers.
• The mean can be thought of as the balance point
  of the data.
• If there are a few data points that are far from
  the bulk of the data, the mean moves towards them
  in order to maintain balance.

27

• The mean is the preferred measure of central
  tendency.
• However, if the data are skewed or contain
  outliers then the median is the preferred measure
  of central tendency.
• If the data are qualitative, the mode must be
  used.

28
Relationship between Mean, Median and Mode

• If the data is unimodal and symmetric, the mean,
  median and mode coincide.
• If the data are unimodal and positively skewed,
  the mean is greater than the median, which is
  greater than the mode.
• If the data are unimodal and negatively skewed,
  the mean is less than the median, which is less
  than the mode.

29
Measures of Dispersion

• In addition to knowing the central location of
  the data values, it is important to know how the
  values vary about this point.
• We are now going to look at measures of
  dispersion, also referred to as
• - measures of spread
• - measures of variability
• We will look at three measures of dispersion
• range, standard deviation and coefficient of
  variation

30
The Range

• The range is the difference between the largest
  and smallest observations in a data set.
• The range measures the total spread of the data
  set.
• Although the range is a simple measure of
  variability, it does not take into account how
  the data are distributed between the smallest and
  largest values.
• Hence the range is seldom used as the only
  measure.

31
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the range.
• range 37 4 33

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
32
Variance and Standard Deviation

• The variance and the standard deviation are the
  two most widely accepted measures of dispersion.
• The variance is the square root of the standard
  deviation.
• Both measures take into account how far each data
  value is away from the mean.

33
Population Variance

• The variance of a population of N measurements
• having mean ? is defined as

34
Sample Variance

• The variance of a sample of n measurements
• having mean is defined as

35
Standard Deviation

• Calculating the variance involves squaring the
  original measurements and hence the unit attached
  to the variance is the square of the unit
  attached to the original measurements.
• Taking the square root of the variance gives as a
  measure of variability that is in the same units
  as the data.
• This measure is the standard deviation.

36
Population Standard Deviation

• The standard deviation of a population of N
  measurements having mean µ is defined as

37
Sample Standard Deviation

• The standard deviation of a sample of n
  measurements having mean is defined as

38
Calculating the Standard Deviation and Variance

• As with the mean, you are expected to calculate
  the standard deviation and variance using the
  statistics functions on your calculator.
• You are not to use the formulae, these have been
  provided to help you understand what the standard
  deviation and variance are.
• Note that the population standard deviation and
  sample standard deviation are calculated using
  different buttons on your calculator.

39
Important Points about the Standard Deviation

• The standard deviation cannot be negative.
• The standard deviation is zero if, and only if,
  all of the observations have the same value.
• Like the mean, the standard deviation is not
  resistant. Strong skewness or a few outliers can
  greatly increase the standard deviation.

40
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the standard deviation and the
  variance.

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
41
Coefficient of Variation

• In some situations we may be interested in a
  measure of variability that indicates how large
  the standard deviation is in relation to the
  mean.
• This measure is called the coefficient of
  variation (CV) and is calculated by dividing the
  standard deviation of a data set by the mean.
• The CV allows us to compare the variability of
  two data sets having different units of
  measurement.

42

• A standard deviation of 1mm would be considered
  very large for the measured thickness of CDs on a
  production line.
• However a standard deviation of 1mm would be
  considered small for the height of a telephone
  pole.
• When the means for data sets differ greatly we do
  not get an accurate picture of the relative
  variability in the two data sets by comparing the
  standard deviations.

43
Calculating the Coefficient of Variation

• The sample coefficient of variation is calculated
  by
• The population coefficient of variation is
  calculated by

44
Example 1 revisited

• The following data are the price-earnings ratios
  for a set of stocks whose prices are quoted by
  NASDAQ
• Calculate the coefficient of variation.

4 20 16 28 31
10 23 37 29 15
33 21 18 35 29
45
Example 2 revisited

• A survey of television-viewing habits among
  university students provided the following data
  on viewing time in hours per week
• Calculate the range, standard deviation,
  variance and coefficient of variation.

14 9 12 4 20 26 17 15
18 15 10 6 16 15 8 5
46

• range 26 6 20
• standard deviation s 5.92 (2d.p.)
• variance s2 35.05
• coefficient of variation cv 0.45 (2d.p.)

47
Interpreting the Standard Deviation

• The standard deviation, as a measure of average
  deviation around the mean, helps you understand
  how the observations are distributed above and
  below the mean.
• A data set with a large standard deviation has
  much dispersion with values widely scattered
  around its mean.
• A data set with a small standard deviation has
  little dispersion with the values tightly
  clustered about the mean.

48
Chebyshes Theorem

• More than a century ago, Russian mathematician
  Pavroty Chebyshev, found that regardless of how a
  data set is distributed, the proportion of
  observations that are contained within distances
  of k standard deviations of the mean is at least
  1-(1/k2).
• This is known as Chebyshevs theorem.

49

• Regardless of the shape of the distribution,
  Chebyshevs theorem states
• At least 75 of the observations must lie within
  2 standard deviations of the mean
• At least 89 of the observations must lie within
  3 standard deviations of the mean
• At least 94 of the observations must lie within
  4 standard deviations of the mean

50
Example 3.11 from text (pg 86)

• The duration (in minutes) of a sample of 30
  long-distance telephone calls placed by a firm in
  Melbourne in a given week are given in Table 3.2
  on page 86 of the text.
• The 30 telephone-call durations have a mean of
  10.26 and a standard deviation of 4.29.
• Chebyshevs theorem states that at least 75 of
  the call durations lie within 2 standard
  deviations of the mean.

51

• When we look at the data we find that all but
  the largest of the 30 durations fall within this
  interval.
• That is, the interval actually contains 96.7 of
  the call durations.

52
Empirical Rule

• A more exact rule applies if the distribution of
  the data is bell-shaped.
• The empirical rule has evolved from empirical
  studies that have produced samples possessing
  bell-shaped distributions.

53

• The empirical rule states that for data with a
  bell-shaped distribution
• About 68 of all observations lie within 1
  standard deviation of the mean
• About 95 of all observations lie within 2
  standard deviations of the mean
• Almost all 94 of the observations lie within 3
  standard deviations of the mean

54
Example 3.12 from text (pg 87)

• The data in the sample of telephone-call
  durations in Table 3.2 have a mean of 10.26, a
  standard deviation of 4.29, and the durations
  have an approximately bell-shaped distribution
  (see Figure 3.5).
• According to the empirical rule, approximately
  68 of the observations should lie in the
  interval

55

• According to the empirical rule, approximately
  68 of the observations should lie in the
  interval
• If we look at the data we see that 21 out of the
  30 durations are contained in this interval, i.e.
  70.
• This is very close the the empirical rules
  approximation.

56

• According to the empirical rule, approximately
  95 of the observations should lie in the
  interval
• If we look at the data we see that 29 out of the
  30 durations are contained in this interval, i.e.
  96.7.
• This is very close the the empirical rules
  approximation.

57

• Reading for next lecture
• Chapter 3 Sections 3.5 - 3.6
• Exercises
• 3.7
• 3.20
• 3.25a
• 3.31
