Introduction to Minerals

1
Introduction to Minerals

• And you thought you were finished with chemistry ?

2
Photos of really cool places!

• As we study rocks and minerals, remember these
  spectacular sites
• Think about how they formed
• Travel and ask questions!

3
Why should we care?

• Salar de Uyini, Bolivia
• Worlds largest salt flat

4
Antelope Canyon, AZ
5
Zhangye Danxia Landform, Gansu, China
6
Fly Geyser, NV
7
Naica Mine, Mexico
8
What is a mineral?

• Naturally occurring
• Homogeneous solid
• Definite, but generally not fixed, composition
• Ordered atomic arrangement
• Inorganic processes

9
Mineral Examples How are compounds related to
minerals?

• 3. Definite composition
• SiO2 OR FeS2

10
Mineral Crystal Shapes

• Crystalline 3D periodic arrays of precise
  geometric arrangement of atoms
• Cut on the solid lines and fold on the dotted
  lines

11
Mineral or Not?

• At your table discuss whether or not the
  following materials are minerals.
• Be ready to justify your answers!
• Snowflake
• Coal
• Rock salt
• Window glass
• Graphite
• Oxygen

12
Mineral or Notanswers

• Snowflake - Mineral
• Coal - Not
• Table salt - Mineral
• Window glass - Not
• Graphite Mineral
• Oxygen- Not

13
How do minerals form?

• There are four ways that minerals form
• Crystallization within magma (i.e. tourmaline,
  olivine, quartz, feldspar)
• Precipitation from solution (salt flats)
• Changes in pressure or temperature
• Formation from hydrothermal solutions

14
How are minerals classified?

• 4,000 known minerals
• International Mineralogical Association uses
  chemical composition to classify minerals
• 8 mineral classes that are categorized by their
  anion group

15
8 mineral classes

1. Silicate (SiO2)
2. Carbonate (CO3)
3. Sulfate (SO4)
4. Halide (F, Cl, I, Br are most common)
5. Oxide (usually a single O or OH)
6. Sulfide (S is usually bonded to a metal ores)
7. Phosphate (AO4 where A can be P, Sb, As, V
8. Element

16
How do you identify minerals?

• Geologists rely on several simple tests to
  identify minerals.
• These are based on physical and chemical
  properties.
• How would you use the 8 identifying properties to
  identify the minerals at your table?

17
8 Identifying Properties

• Color This is the most noticeable
  characteristics of a mineral and the least
  helpful
• - This is determined by the presence of trace
  elements in certain compounds.
• Ex Quartz these are all the same

18

• Luster The way that a mineral reflects light
  from its surface.
• - Described as Metallic or Non-Metallic
• - Metallic Reflect light like Gold,
  Copper, Silver
• - Non-Metallic Calcite, Gypsum, Sulfur

19
Non-Metallic Luster continued

• Most common Non-metallic Luster Descriptions
• Adamantine brilliant like a polished diamond
• Vitreous glassy, like glazed porcelain or
  quartz
• Resinous yellow, dark orange, or brown like
  tree sap
• Pearly Exhibiting a luster similar to the
  inside of a mollusk shell or shirt button
• Silky minerals that have a very fine fibrous
  structure
• Earthy dull, little reflection

20

• Texture Describes how a mineral feels to the
  touch.
• - Words to describe Smooth, Rough,
  Ragged, Greasy, Glassy.

Smooth
Rough
21

• Streak The color of a mineral when it is broken
  up or in powdered form.
• - Usually rubbed against a porcelain plate,
  which leaves a powder behind.
• - Sometimes the external color doesnt match
  streak color.
• - Streak hardly ever changes, even though the
  colors of a mineral do

Pyrite Streaks greenish
Gold Streaks yellow
22

• Hardness a measure of how easily a mineral can
  be scratched.
• - Measured on the Mohs Hardness Scale
  Ranges from 1 10
• 1 Softest
• 10 Hardest

Diamond 10
Talc 1
23
Mohs Hardness Scale
Name Hardness Hardness of Common Objects
Talc 1 Softest
Gypsum 2 Scratched by Fingernail
Calcite 3 Scratch by Penny
Fluorite 4 Scratched by Nail
Apatite 5 Scratched by Glass
Feldspar 6 Scratched by Steel File
Quartz 7
Topaz 8 Scratches quartz
Corundum 9 Scratches Topaz
Diamond 10 Hardest Scratches Everything
24
(No Transcript)
25

• Cleavage and 7. Fracture How a mineral will
  break.
• - Cleavage a mineral that splits relatively
  easily and evenly along one or more flat planes.
• - Fracture Minerals that break with rough or
  jagged edges.

Fracture
Cleavage
26
8. Special Properties Magnetic, odor, reacts
to an acid, Tastes like salt, fluoresces, double
refraction,
Sphalerite Smells like rotten eggs
Calcite Reacts to HCL
Magnetite Magnetic
27
Double Refraction- Calcite
