Stoker Best Components

1
Stoker Best Components Alloys

• Manufacturer, Supplier Exporter of
• Industrial Gears and many more Gears.
• Mobile [phone]
• www.stokerbestcomponents.com/

2
OUR PRODUCTS
Mobile [phone]
Industrial Gears Girth Gear Differential Gears Ground Gear Ring Gear
Rack Gear Spur Gear Bevel Gear Cycloidal Gears External Gear
Helical Gears Marine Gears Mining Gears Pinion Gears Planetary Gears
Involute - Non Involute Gears Worm Gear Idler Gears Face Gear Angular Bevel Gears
Winch Gears Herringbone Gears Crown Gears Hypoid Gears Miter Gears
www.stokerbestcomponents.com
3
Industrial Gears
Mobile [phone]
Gears are comprehensively utilized in almost each
industry be it agriculture or aerospace, mining
or pulp and paper industry. For fulfilling the
varied requisites of our customers, we provide
gears in different capacities, speed ratio and
sizes. Different types of gears find application
in distinctive industries.
www.stokerbestcomponents.com
4
Girth Gear
Mobile [phone]
SPECIFICATIONS Material MS or Alloy Steel,
Carbon Steel as per ASTM, AISI, BS, IS, SAE or
any according to customer requirement. Module
Upto 60 Module. Manufacturing Capacity 10mm to
12,000mm Outside Diameter. Type Spur
www.stokerbestcomponents.com
5
Differential gears
Mobile [phone]
These differential gears can be availed in two
distinctive designs hypoid and spiral. We make
these available in different technical aspects,
at effective and competitive rates.
www.stokerbestcomponents.com
6
Ground Gear
Mobile [phone]
Our range of industrial ground gears are known
for high transmission accuracy, and enduring
service-life. Specifications Material MS or
Alloy Steel, Carbon Steel as per BS, ASTM, IS,
SAE, AISI, or any according to customer
requirement. Module Upto 16 Module.
Manufacturing Capacity 50mm to 1,200mm Outside
Diameter. Type Spur and Helical
www.stokerbestcomponents.com
7
Ring Gear
Mobile [phone]

• Ring gears, also known as starter rings, are
  steel rings with teeth that are fitted upon
  periphery flywheel or flexplate of combustion
  engine.
• These ring gears find comprehensive usage for
  automotive applications.
• The main function of starter ring or ring gear
  is transferring torque from starter motor pinion
  to flexplate or flywheel to rotate the engine for
  beginning the cycle. We fabricate these ring
  gears with high precision ensure providing them
  in clients desired specifications, at leading
  rates.

www.stokerbestcomponents.com
8
Rack Gear
Mobile [phone]

• Rack and pinion gears comprise of rack and
  pinions that are utilized for converting
  rotational motion into linear and vice versa.
• Rack and pinion gears are largely utilized in
  automobiles.
• SPECIFICATIONS
• Material MS or Alloy Steel, Carbon Steel as per
  ASTM, BS, IS, AISI, SAE or any as per customer
  requirement.
• Module Upto 20 Module.
• Manufacturing Capacity In Single or Multiple
  Pieces Upto Any Length.

www.stokerbestcomponents.com
9
Spur Gear
Mobile [phone]
Spur gear is the basic type of parallel axis
gears that is used for changing the rotation
speed from one shaft to another. SPECIFICATIONS
Material MS or Alloy Steel, Carbon Steel as
per BS, ASTM, IS, SAE, AISI, or any according to
customer requirement Module Upto 60 Module.
Manufacturing Capacity 10mm to 12,000mm Outside
Diameter. Type Spur
www.stokerbestcomponents.com
10
Bevel Gear
Mobile [phone]
Utilized for connecting intersecting axes. The
bevel gears have tooth bearing faces and are
conically shaped. These gears support changing
the rotation axes of respective shafts, generally
by 90 degree.
SPECIFICATIONS Material MS or Alloy Steel,
Carbon Steel as per BS, ASTM, IS, SAE, AISI, or
any as per customer requirement. Module Upto 30
Module. Manufacturing Capacity 100mm to 3,000mm
Outside Diameter. Type Straight Type
www.stokerbestcomponents.com
11
Cycloidal Gears
Mobile [phone]
These cycloidal gears are utilized for providing
extremely quiet, efficient, and durable
gearbox. We offer these cycloidal gears for
industries at competitive prices.
www.stokerbestcomponents.com
12
External Gear
Mobile [phone]
This type of gears is mostly utilized for
automotive applications.
www.stokerbestcomponents.com
13
Helical Gears
Mobile [phone]
SPECIFICATIONS Material MS or Alloy Steel,
Carbon Steel as per ASTM, BS, IS, AISI, SAE or
any according to customer requirement. Module
Upto 40 Module. Manufacturing Capacity 10mm to
8,500mm Outside Diameter. Type Helical
www.stokerbestcomponents.com
14
Marine Gears
Mobile [phone]

• Marine utilize gears in different vessels such as
  luxury yachts, fast ferry boats, work boats and
  frigates, etc.
• We provide following types of marine gears
• Planetary Gears
• Worm Reduction Gears
• Helical Gears

www.stokerbestcomponents.com
15
Mining Gears
Mobile [phone]

• Types of mining gears are
• Bevel Gear
• Helical Gear
• Right Angle Gear
• Parallel Shaft Gear
• Planetary Gear
• Worm Gear

www.stokerbestcomponents.com
16
Pinion Gears
Mobile [phone]
Pinions gears are utilized for converting
rotation into linear motion. These pinions gears
system includes usage of small round gear called
pinion and large flat gear called rack.
SPECIFICATIONS Material MS or Alloy Steel,
Carbon Steel as per BS, SAE, IS, ASTM, AISI, or
any according customer requirement. Module Upto
15 Module. Manufacturing Capacity 50mm to
1,200mm Outside Diameter. Type Timing Gears,
Motor Gears, Traction Gears, Slewing Ring Gears,
Pump Gears- Spur or Helical.
www.stokerbestcomponents.com
17
Planetary Gears
Mobile [phone]
Planetary gear is a system comprising of one or
more planet gears or outer gears, revolving
around the sun gear or central gear. The planet
gear is mounted upon movable arm or carrier which
itself might rotate relative to sun gear.
Planetary gears form the automatic transmission
systems core.
www.stokerbestcomponents.com
18
Involute Gears Non Involute Gears
Mobile [phone]
Involute gear is among the generally utilized
gearing system today. In Involute gear, the
teeth profiles are involute of a
circle. Involute profile only reduces the teeth
from rubbing each other every time they mesh, and
the high localised stresses could be the cause
for wear.
www.stokerbestcomponents.com
19
Worm Gear
Mobile [phone]

• Worm gears commonly are utilized when large gear
  reduction is required. Wrapped around central
  axle, the worm gears consist of one or more teeth
  in screwed threads form that rotates the gears.
• SPECIFICATIONS
• Material Ferrous and Non Ferrous.
• Type Single, Double or Multiple Starts.
• Manufacturing Capacity 10mm to 5,000mm Outside
  Diameter

www.stokerbestcomponents.com
20
Idler Gears
Mobile [phone]
Idler gear is a wheel placed within two other
gears for transmitting motion from one to another.
www.stokerbestcomponents.com
21
Face Gear
Mobile [phone]

• Face gears are utilized for turning the corner
  between the vertical output rotor shaft and the
  turbine engine an operation currently performed
  by spiral bevel gears.
• Types of Face Gears
• Standard face gear
• Helical face gear
• Offset face gear

www.stokerbestcomponents.com
22
Angular Bevel Gears
Mobile [phone]

• Bevel gears having pitch angles of higher than
  ninety degrees consisting of teeth that points
  inward and are called internal bevel gears.
• Application
• Steel plants
• Automobiles
• Locomotives
• Printing Presses
• Power plants
• Cooling Towers
• Railway Track Inspection machines

www.stokerbestcomponents.com
23
Winch Gears
Mobile [phone]

• Winch gears are utilized for converting the high
  speed, low force input of the handle into low
  speed, high torque output at the drum.
• Types of Winch Gears
• Planetary Winch Gears
• Worm Winch Gears
• Spur Winch Gears

www.stokerbestcomponents.com
24
Herringbone Gears
Mobile [phone]
Herringbone gears (even known as double helical
gears) consist of two helical gears with opposite
angles positioned in the same body. These
herringbone gears generally are utilized in
rolling mills.
www.stokerbestcomponents.com
25
Crown Gears
Mobile [phone]
Crown Gears are easily available in different
configurations - Two way Crown Gear Drives -
Three way Crown Gear Drives that compile with
varied shaft speed and torque requisites. Our
two way crown gear drives and three way crown
gear drives are available at industry competitive
prices.
www.stokerbestcomponents.com
26
Hypoid Gears
Mobile [phone]

• These hypoid gears comprise of features
• Low power consumption
• Long service live
• Simple construction and
• Power transmission is reliable and with uniform
  motionThese hypoid gears find application in
  Agro-industry, Automotive industry, Mining, Power
  station, and Wind turbine industries.

www.stokerbestcomponents.com
27
Miter Gears
Mobile [phone]
Miter Gear imparts a quite and smooth operation
and enduring life when appropriately mounted and
lubricated. These miter gears have suitable
backlash and end of the gear teeth will flush
with each other while functioning. These types
of industrial gears are manufactured using
qualitative and industrial grade materials
imparting them excellent durability.
www.stokerbestcomponents.com
28
Contact Us
www.stokerbestcomponents.com
Mobile [phone]
Contact Person Mr. S K Das Address 1st
floor, Plot No 7 H, industrial Area, NIT, City
Faridabad Pin Code 121001 Mobile
09810534249 Country India Website
http//www.stokerbestcomponents.com/
