Functional evolution of bacterial genome

1
Functional evolution of bacterial genome

• The Escherichia coli case

2
Plan

• Presentation of E. coli
• Genomes sequenced
• Genomic island
• Definition
• Roles
• Examples
• Tools for functional analysis
• Conclusion

3
Escherichia coli

• Theodor Escherich (1857-1911), a German
  pediatrician and bacteriologist discovered
  Escherichia coli, which was named after him in
  1919
• Gram-negative bacilli, facultatively anaerobic,
  non motile or motile by peritrichous flagella

4
E. coli the gram-negative model organism

• Catapulted to prominence by the discovery of
  strain K-12s ability to carry out genetic
  recombination by conjugation (Tatum, 1946) and by
  generalized transduction (Lennox, 1955)
• Easy to rear, small, cheap, rapid growth cycle,
  short lived, genetically manipulable

5
E. coli habitat

• Resident of animal intestinal tracts
• Well adapt to life in rivers, oceans and soils
• Can be found living at -2C in McMurdo Bay
  (Antarctica)
• Indicator of fecal pollution and water
  contamination

Number of E. coli/ml water
6
E. coli a versatile bacteria

• Commensal
• Use a probiotic
• Could be virulent

7
E. coli as a commensal

• Intestinal tract of humans and many animal
  species
• Source of vitamin K and B-complex vitamins
• One of the first bacterial species to colonize
  the infants intestine

8
E. coli as a pathogen

• Intra intestinal infections iPEC
• Extra intestinal infections ExPEC

9
E. coli as a probiotic

• E. coli strain Nissle 1917 (O6K5H1) forms the
  basis of the probiotic preparation Mutaflor
• used for treatment of various intestinal
  disorders (Crohns disease)
• successful colonizer of the human gut

10
iPEC

• ETEC - enterotoxigenic E. coli (Cholera-like)
• EIEC - enteroinvasive E. coli (Shigella-like)
• EHEC - enterohemorrhagic E. coli (Hamburger
  disease)
• EPEC - enteropathogenic E. coli (Neonatal
  diarrhea)
• EAEC - Enteroaggregative E. coli
• DAEC - Diffuse adhering E. coli

11
ExPEC

• UPEC uropathogenic E. coli
• MENEC new born meningitis causing E. coli
• SEPEC septicemia-causing E. coli
• APEC avian pathogenic E. coli

12
Serotyping

• Serotyping scheme based on three types of antigen

• the somatic (O) antigen
• the capsular (K) antigen
• the flagellar (H) antigen
• Over 700 antigenic types

13
E. coli genomes sequences
14
K-12 genome sequences

• Independent efforts by American and Japanese
  groups using two different strains of K-12
  MG1655 and W3110
• These strains were diverged from the same
  ancestral strain about 50 years ago
• Slight but significant differences including the
  large inversion involving the ribosomal RNA genes

15
Genome sequencing

• First genome of E. coli that has been sequenced
  MG1655, a commensal strain in 1997(The complete
  genome sequence of Escherichia coli K-12, Science
  277 (5331), 1453-1474 (1997) )
• Determination of the complete E. coli sequence
  has required almost 6 years

16
General features of MG1655 genome

• 4,639,221-base pair
• 4288 protein-coding genes annotated
• Protein-coding genes account for 87.8 of the
  genome

17
Status of annotation of E. coli gene products
(2006)
18
Genome of E. coli sequenced

• UPEC strain
• Welch et al., 2002, PNAS

19
Genome of E. coli sequenced

• EHEC strains
• EDL933 (Perna et al., 2001, Nature)
• SaKai (Hayashi et al., 2001, DNA Research)

20
Current E. coli genomes sequenced or in progress
Strains type Number of genes Length (bp) Numbers of contigs
B03 commensal 4387 4,629,810 1
MG1655 commensal 4,254 4,639,675 1
W3110 commensal 4,390 4,641,433 1
HS commensal 3,689 4,643,538 1
101NA1 EAEC 4,238 4,880,380 70
536 UPEC 4800 4,900,000 1
21
Current E. coli genomes sequenced or in progress
Strains type Number of genes Length (bp) Numbers of contigs
E24377A ETEC 4,254 4,980,187 1
E2348 EPEC 4,594 5,072,200 4
RS218 NMEC 4,900 5,089,235 1
B7A ETEC 4,637 5,202,558 198
F11 UPEC 4,467 5,206,906 88
H10407 ETEC 5,000 5,208,000 225
22
Current E. coli genomes sequenced or in progress
Strains type Number of genes Length (bp) Numbers of contigs
CFT073 UPEC 5,379 5,231,428 1
042 EAEC 4,899 5,241,977 2
53638 EIEC 4,783 5,289,471 119
B171 EPEC 4,467 5,299,753 159
E110019 Atypical EPEC 4,746 5,384,084 119
23
Current E. coli genomes sequenced or in progress
Strains type Number of genes Length (bp) Numbers of contigs
SAKAI EHEC 5,361 5,498,450 1
E22 EPEC 4,788 5,516,160 109
EDL933 EHEC 5,349 5,289,471 1
24
Undergoing project Coliscope

• Commensal IAI1 (serogroup O8)
• EAEC 55989
• UPEC IAI39 (serogroup 07)
• UPEC UMN026 (serogroup 017)
• Commensal ED1a (serogroup O81)
• MNEC S88 (serogroup O45)

25
Average genome size

• From 4.62 Mb (Commensal isolates)
• To 5.28 Mb (Virulent isolates)
• Much of this diversity comes from bacteriophages
  BUT
• Presence of foreign DNA concept of genomic
  island (GEIs)

26
Genomic islands
27
Definition of genomic island

• Concept of PAI (pathogenicity island) was founded
  in the late 1980s by Jörg Hacker and colleagues
  in Werner Goebel's group at the University of
  Würzburg, Würzburg, Germany

28
Common features of genomic island

• presence of virulence genes
• Specific presence in pathogens, absence in benign
  relatives
• Large distinct chromosomal regions (10 to 200 kb)
• Characteristic base composition different from
  core genome
• Insertion of PAI adjacent to tRNA genes

29
Common features of genomic island

• Frequent association with mobile genetic
  elements, i.e., presence of
• DR
• Cryptic or functional integrase or
  transposase
• IS elements
• Chromosomally integrated conjugative transposons,
  plasmids, and phages
• Genetic instability (if functional mobility
  elements are present)
• Mosaic structures of several acquisitions

30
GEIs can be involved in

• Pathogenicity
• Symbiosis
• Fitness
• Metabolism
• Resistance to xenobiotics

31
Comparison between EHEC and K-12

• Common linear backbone of 4.1 Mb
• 1.34 Mb specific to EHEC (O-islands)
• 0.53 Mb specific to K-12 (K-islands)

32
O-islands larger than 15 kb encoding factors

• LEE (locus of enterocyte effacement)
• Macrophage toxin and ClpB-like chaperone (IAHP
  island)
• RTX-like exoprotein and a transport system

33
Contribution of mobile genetic elements to the
evolution of pathogenic E. coli
34
One of the best studied PAI The LEE

• LEE locus of enterocyte effacement
• Present in enteropathogenic and
  enterohaemmoragic strains
• Encode a type III secretory system that injects
  proteins into host cells to modulate function.

35
A/E lesions caused by EPEC
36
A/E lesions caused by EPEC
37
A/E lesions caused by EPEC
38
The TTSS

• Secretion and translocation of bacterial effector
  proteins into and through the host cell membrane

39
Identification and characterization of a genomic
island from an avian ExPEC strain

• tRNA target screening

40
Avian ExPEC

• Localized infection
• Respiratory diseases
• Some virulence factors identified
• Pathogenicity not fully understood

41
tRNA target screening

• Design of primers after comparison of 4
  completely sequenced strains (MG1655, CFT073,
  EDL933 and Sakai)
• PCR analysis
• Focus on some loci to identify the EcDNA inserted
  (arbitrary PCR followed by a screening of a
  genomic library)

42
selC an integration hot spot
Strain PAI Length (kb) function
E.coli 536 (UPEC) PAI-I536 70 hemolysin
E.coli CFT073 (UPEC) GEI 68
E.coli E2348/69 (EPEC) LEE 35 Type III secretion, invasion
E.coli O157H7 (EHEC) LEE 43 Type III secretion, invasion
E.coli (ETEC) Tia PAI 46 invasion
S.flexneri SHI-2 ND Aerobactin synthesis, transport
S.enterica SPI-3 17 Invasion, survival in monocytes
43
AGI-3

• 49600pb inserted at selC. Mosaic structure 5
  modules of genes
• Presence of mobile genetic elements such as IS
  elements, integrase gene and direct repeats

44
Features of aec35 to 37
DR2
DR1
DR2
DR1
36
yicM
selC
33
37
81
nlpA
34
35
yicL

• aec35 360 aa putative transcriptional regulator
  of the LacI regulator family (99 CFT073 C4494,
  74 Yersinia pestis C092, Yersinia pestis Kim,
  Yersinia pseudotuberculosis)
• aec36 452 aa putative MFS superfamily
  hexuronate transporter (100 CFT073 C4495, 85
  Yersinia pseudotuberculosis)
• aec37 795 aa putative a-glucosidase family 31
  (100 CFT073 C4496 and C4497, 83 Yersinia
  pseudotuberculosis)

45
Prevalence in other bacteria
46
Role in virulence for chicken

• Deletion of 3 orfs aec35, aec36 and aec37 (5kb)
  (Datsenko and Wanner, 2000)
• Experimental reproduction of colibacillosis
• 2 inocula preparations
• cullture at 37C with shaking since OD600nm 0.6,
  frozen at -70C
• culture at 37C without neither shaking nor
  freezing

47
Experimental procedure

• Inoculation of 5.106 CFU (shaken inoculum) or 107
  CFU (non shaken inoculum) to 3 weeks old SPF
  chickens (12/set randomly constituted) into the
  right thoracic air sac
• Blood sampling at 24h and 48h p.i. and bacterial
  numeration
• 48h p.i., euthanasia, necropsy
• Lesion score determination
• Liver sampling and bacterial numeration
• Statistical analysis Wilcoxon-Mann-Withney (non
  parametric test)

48
Bacteraemia
The mutant derivative is less bacteraemic than
the wt strain
49
Liver colonization
The mutant derivative less colonized the liver in
comparison to the wt strain
50
Lesions scores
No lesion score difference
51
Conclusion (1)

• The ?aec35 to aec37 mutant induces same lesions
  as the wt but is less bacteriaemic and is less
  able to colonize liver
• Involvement of these three orfs in the
  pathogenicity of BEN2908 for chickens
• Functional analysis of these three orfs
  (determination of the sugar involved....)

52
Phenotypic analysis of aec35, aec36 and aec37

• Reminder
• Protein identity
• aec35 putative transcriptional regulator LacI
  family
• aec36 putative MFS superfamily hexuronate
  transporter
• aec37 putative glucosidase family 31 of
  glycosyl hydrolases
• Phenotype Microarrays (Biolog Inc.)
• minimal media
• 190 carbon sources
• aerobic conditions 37C
• OD590 mesures (ELISA reader)

53
Phenotypic micro arrays results
54
Growth in minimal media

• M9 Supplemented by trehalose or galacturonate
• Growth followed during 24h in a Bioscreen
  apparatus
• The mutant has a two-fold lower growth rate
  compared to the wt strain

55
Conclusion (2)

• AGI-3 has all the features of a pathogenicity
  island
• Is involved in virulence
• Played a role in carbohydrate metabolism

56
Tools for E. coli functional analysis
57

• E. coli K-12 one of the best-characterized
  organisms in molecular biology
• Many key ressources for functional genomics and
  systems biology of E. coli are still lacking

58
Tools available for K-12 strains

• DNA microarrays transcriptome (available for
  K-12, UPEC and development of patho-arrays)
• The Keio collection mutants 3985 deletions (in
  duplicate) of the K-12 strain strain BW25113
• The ASKA library (A complete Set of E. coli K-12
  ORF Archive)
• Metabolome

59
Transcriptome

• Transcriptome of K-12 in various growth
  conditions
• Transcriptome of uropathogenic Escherichia coli
  during urinary tract infection
• Transcriptome of carbon utilisation in the mouse
  intestine

60
Proteome

• Many in vitro studies for K-12 strains
• Proteomic analysis of extracellular proteins from
  E. coli W3110
• carbon source variation
• Response to stress

61
Metabolome

• Definition the full complement of metabolites
  of an organism
• The E. coli metabolome has been characterized
  using the two-dimensional structures of 745
  metabolites, obtained from the EcoCyc and KEGG
  databases.

62
Conclusion

• E. coli is a versatile bacteria
• Many genomes of several E. coli strains are
  available
• Tools for functional analysis are developed
• A lot of data are available
• Three worlds exist in the field of E. coli
  research (non pathogenic, intestinal pathogenic
  and extra intestinal pathogenic strains)
