Spreadsheet-Based Decision Support Systems
Chapter 11 Introduction to the Visual Basic
Environment
Prof. Name
name_at_email.com Position
[phone] University Name
2
Overview

• 11.1 Introduction
• 11.2 The Visual Basic Editor
• 11.3 The Object Browser
• 11.4 Summary

3
Introduction

• The basics of the Visual Basic Editor
  environment.
• The components of the Project Explorer,
  Properties, and Code Windows.
• The difference between a property, method, and
  event.
• The Object Browser.

4
Visual Basic Editor

• Project Explorer
• Properties Window
• Code Window
• Immediate and Watch Windows
• VBE Toolbars

5
Visual Basic Editor

• The Visual Basic Editor (VBE) is the environment
  in which you work with VBA programming code.
• Developer tab on the Ribbon
• ALT F11
• Three main windows in the VBE
• Project Explorer
• Properties
• Code
• Two other windows in VBE, used for debugging
• Immediate
• Watch

6
Visual Basic Editor (contd)

• The Visual Basic Editor windows

7
Project Explorer

• Lists all projects in any open workbook.
• Each workbook has a project, and each project can
  have several parts.
• Objects Workbook and worksheets
• Modules contain the VBA code for any macro.
• Standard modules are used for writing general
  procedures, or sections of code, to perform
  different tasks with Excel objects
• Class modules are used to create new properties
  and methods for more advanced coding.
• Forms the user interface tools in Excel.
• Use Insert gt Module or Insert gt User Form to add
  a new module or form to the current project can
  also use icon from standard toolbar.

8
Properties Window

• Contains detailed information about any selected
  part of a project in the Project Explorer.
• Some basic naming and formatting properties can
  be modified for worksheets and workbooks.
• Properties are very important for user forms
• Formatting
• Position
• Picture
• Scrolling
• Behavior

9
Code Window

• Displays the VBA code for the highlighted part of
  a project in the Project Explorer.
• When macros are recorded they are simultaneously
  created as VBA code in the Visual Basic Editor.
• There are two types of procedures
• Sub procedures
• Function procedures

10
Immediate and Watch Windows

• Both of these windows are used for debugging.
• Immediate Window executes whatever is entered
  immediately.
• Watch Window displays values of inserted
  variables.
• Use the View menu option to view or hide any
  window.

11
VBE Toolbars

• There are four toolbars in VBE
• Standard
• Edit
• Debug
• UserForm
• The Standard toolbar allows you to
• Switch to the Excel window, insert a user form,
  module, or procedure, and save our current code
  modifications.
• Run, pause, or stop your code.
• View the design mode of our form design.
• Perform several standard editing options, such as
  cut, copy, paste, search, undo, and redo.

12
The Object Browser

• Properties, Methods and Events
• Libraries, Classes, and Members

13
Object Browser

• Provides a list of properties, methods and events
  of all Excel objects which may be manipulated in
  VBA.
• Properties are the physical descriptions of all
  Excel objects.
• The description of the particular property is
  called the value of the property.
• Methods are the actions that can be performed on
  an object.
• The elements of a method statement are called the
  arguments of the method.
• Events are actions that are performed on
  controls.
• A control is a user interface object, such as a
  button or check box.

14
Object Browser

• There are larger categories into which various
  objects are grouped
• Libraries collections of VBA and Excel object
  classes
• Classes groups of related objects
• Members properties, methods, and constants of a
  selected class of objects
• View gt Object Browser or icon from standard
  toolbar.

15
Object Browser (contd)

• All classes containing the searched object are
  shown in the Search Results window.
• All classes and members of a selected class are
  shown in the second window.

16
Summary

• The Visual Basic Editor (VBE) is the environment
  in which you work with VBA programming code.
• There are three main windows in VBE the Code
  Window, the Project Explorer, and the Properties
  Window.
• The Object Browser provides a list of properties
  and methods of all Excel objects that may be
  manipulated in VBA.
• Properties are the physical descriptions of all
  Excel objects, and the description of the
  particular property is called the value of the
  property.
• Methods are the actions that can be performed on
  the object. The elements of a method statement
  are called the arguments of the method.
• Groups of related objects are called classes
  collections of VBA and Excel object classes are
  called libraries and the properties, methods,
  and constants of a selected class of objects are
  known as the members of the class of objects.
