Why MSi products stand out vs. competition

1
Why MSi products stand out vs. competition
2
The Crimpfin heat sink

• Patented air flow design
• High grade conductive blended aluminum alloy
• Curved fins provide 20 more surface area
• 60 less weight than die cast competitors
• Runs 9? cooler than any other LED lamp

3
Dimmable Power Supply

• Custom designed driver
• Runs at 60 of capacity
• Optimized efficiency less energy used
• Long Life industrial spec components
• CAPs rated in excess 50,000 hours
• Wide dimmer compatibility

4
The Custom Optic

• Proprietary Optical Design
• 93 efficiency in light output
• Anti-glare facets on lense
• Eliminates shadows, watermarks and lines
• Air flow vents throughout the top retainer
• Optical grade acrylic for clear imaging
• Manufactured in 10K clean room

5
The Custom PCB

• Proprietary conductive material
• Completely designed in-house
• Optical Electrical test inspection
• 100 production traceability
• High Temperature, Long Life Capacitors

6
Performance LED Chip

• High performance LED chip
• Single Diode
• Blended binning for consistency and CCT
• Proprietary Binning Formula
• Full control over the color and quality of chip

7
The A19 Technology
3M IP
3M Product
3M ESR Film (lining walls)
Integrated Heatsink
Tapered Microprism Light Guide
Light Guide
Light Extraction Pattern using glass bead
technology
3M Adhesive
3M Optically Clear Adhesive
3M custom pin strip socket connectors
LED Light Engine (Ring)
