CS380 LAB III OpenGL

1
CS380 LAB III OpenGL

• Jonghyeob Lee
• Reference1. OpenGL course slides by Rasmus
  Stenholt
• Reference2. http//nehe.gamedev.net/

2
Goal

• Introduce OpenGL programming
• Help you do CS380 homework by yourself

3
Notice

• Use Noah board for your questions
  (http//noah.kaist.ac.kr/course/CS380)

4
Outline

• Viewing Transformation
• Projection and Orthographic Projection

5
Transformation pipeline

• Stages of vertex transformation

Modelview Matrix
Projection Matrix
Viewport Mapping
Object coords
Camera coords
Normalized coords
Window coords
6
Transformation pipeline

• Matrices are set up on stacks
• Matrix commands are post-multiplied onto the
  current matrix
• The last command issued is the first
  transformation applied to the object
• Can save/restore the current matrix

7
Transformation pipeline

• Save / Restore the current matirx
• glPushMatrix()
• glPopMatrix()
• Change the current matrix stack
• glMatrixMode(Glenum mode)
• GL_MODELVIEW, GL_PROJECTION, GL_TEXTURE

8
Modelview transformation

• Modeling transformation
• Model local coordinates ? world coordinates
• Viewing transformation
• world coordinates ? eye coordinates

9
Viewing Transformation

• Another change of coordinate systems
• Maps points from world space into eye space
• Viewing position is transformed to the origin
• Viewing direction is oriented along some axis
• A viewing volume is defined
• Combined with modeling transformation to form
  the modelview matrix in OpenGL

10
Camera View

• Camera coordinate system
• The camera is located at the origin
• The cameras optical axis is along one of the
  coordinate axes (-z in OpenGL convention)
• The up axis (y axis) is aligned with the
  cameras up direction
• We can greatly simplify the clipping and
  projection steps in this frame
• The viewing transformation can be expressed
  using the rigid body transformations discussed
  before

11
Viewing Transformation Steps

• Viewing transformation should align the world and
  camera coordinate frames
• We can transform the world frame to the camera
  frame with a rotation followed a translation

Rotate
Translate
12
Intuitive Camera Specification

• How to specify a cameragluLookAt (eyex, eyey,
  eyez, centerx, centery, centerz, upx, upy, upz)
• (eyex, eyey, eyez) Coordinates of the camera
  (eye) location in the world coordinate system
• (centerx, centery, centerz) the look-at point,
  which should appear in the center of the camera
  image, specifies the viewing direction
• (upx, upy, upz) an up-vector specifies the
  camera orientation by defining a world space
  vector that should be oriented upwards in the
  final image
• This intuitive specification allows us to specify
  an arbitrary camera path by changing only the eye
  point and leaving the look-at and up vectors
  untouched
• Or we could pan the camera from object to object
  by leaving the eye-point and up-vector fixed and
  changing only look-at point

13
Example

• void display()
• glClear(GL_COLOR_BUFFER GL_DEPTH_BUFFER_BIT)
• glColor3f(0.0, 1.0, 0.0)
• glLoadIdentity()
• gluLookAt(0.0, 0.0, 0.0, 0.0, 0.0, -1.0, 1.0,
  1.0, 0.0)
• glutWireTeapot(0.5)
• glFlush()

14
Tutorials

• Change your camera view based on key inputs
• q eyex 0.1, i eyex -0.1
• w eyey 0.1, o eyey -0.1
• e eyez 0.1, p eyez -0.1
• a centerx 0.1, j centerx -0.1
• s centery 0.1, k centery -0.1
• d centerz 0.1, l centerz -0.1
• z upx 0.1, b upx -0.1
• x upy 0.1, n upy -0.1
• c upz 0.1, m upz -0.1

15
Tutorials

• Set camera view to following figures

16
The Matrix for glLookAt

• (u, v, w, eye) forms the viewing coordinate
  system
• w eye look
• u up w
• v w u
• The matrix that transforms coordinates from
  world frame to viewing frame.
• dx - eye u
• dy - eye v
• dz - eye w

17
Setup Camera

• Since viewing transformation is a rotation and
  translation transformation. We can use
  glRotatef() and glTranslatef() instead of
  gluLookAt()
• In the previous example (view a scene at origin
  from (10, 0, 0) ), we can equivalently use
• glMatrixMode(GL_MODELVIEW)
• glLoadIdentity()
• glRotatef(45, 0, 0, 1)
• Since the viewing transformation is applied after
  modeling transformations, it should be set before
  modeling transformations.

18
Set Viewing Transformation

• Furthermore, glTranslatef() and glRotatef() can
  be used to define custom viewing control.
• Example
• void display()
• glRotatef(angle, axisx, axisy, axisz)
• glTranslatef(xpos, ypos, zpos)

19
Projection Transformations

• The projection transformation maps all of our
  3-D coordinates onto our desired viewing plane.

• Greatly simplified by using the camera (viewing)
  frame.
• projection matrices do not transform points from
  our affine space back into the same space.
• Projection transformations are not affine and we
  should expect projection matrices to be less
  than full rank

20
Orthographic Projection

• The simplest form of projection
• simply project all points along lines parallel
  to the z-axis (x, y, z)-gt(x, y, 0)
• Here is an example of an parallel projection of
  our scene. Notice that the parallel lines of
  the tiled floor remain parallel after
  orthographic projection

21
Orthographic Projection

• The projection matrix for orthographic projection
  is simple
• Notice the units of the transformed points are
  still the same as the model units. We need to
  further transform them to the screen space.
• OpenGL functions for orthographic projection
  gluOrtho2D(left, right, bottom, top),
  glOrtho(left, right, bottom, top, near, far)

22
Perspective Projection

• Perspective projection is important for making
  images appear realistic.
• causes objects nearer to the viewer to appear
  larger than the same object would appear farther
  away
• Note how parallel lines in 3D space may appear to
  converge to a single point when viewed in
  perspective.

23
Viewing Frustum and Clipping

• The right picture shows the view volume that is
  visible for a perspective projection window,
  called viewing frustum
• It is determined by a near and far cutting
  planes and four other planes
• Anything outside of the frustum is not shown on
  the projected image, and doesnt need to be
  rendered
• The process of remove invisible objects from
  rendering is called clipping

24
OpenGL Perspective Projection

• Set viewing frustum and perspective projection
  matrix
• glFrustum(left,right,bottom,top,near,far)
• left and right are coordinates of left and right
  window boundaries in the near plane
• bottom and top are coordinates of bottom and top
  window boundaries in the near plane
• near and far are positive distances from the eye
  along the viewing ray to the near and far planes
• Projection actually maps the viewing frustum to a
  canonical cube the preserves depth information
  for visibility purpose.

25
The OpenGL Perspective Matrix

• Matrix M maps the viewing frustum to a NDC
  (canonical cube)
• We are looking down the -z direction

26
Near/Far and Depth Resolution

• It may seem sensible to specify a very near
  clipping plane and a very far clipping plane
• Sure to contain entire scene
• But, a bad idea
• OpenGL only has a finite number of bits to store
  screen depth
• Too large a range reduces resolution in depth -
  wrong thing may be considered in front
• Always place the near plane as far from the
  viewer as possible, and the far plane as close as
  possible

27
Perspective Projection

• If the viewing frustum is symmetrical along the
  x and y axes. It can be set using
  gluPerspective()
• gluPerspective(?,aspect,n,f)
• ? the field of view angle
• aspect the aspect ratio of the display window
  (width/height)

28
Set a view
int main( int argc, char argv )
glutReshapeFunc( reshape )
void reshape(int width, int height)
glViewport(0, 0, width, height)
glMatrixMode(GL_PROJECTION)
glLoadIdentity()
double aspect width/double(height)
gluPerspective(45, aspect, 1, 1024)
29
Next time

• Lighting and Texture mapping
